2018 TOYOTA CAMRY stop start

5057-2. Steps to take in an emergency
CAMRY_U (01999-06122)
7
When trouble arises
WARNING
■Maintenance of the tires
Each tire, including the spare (if provided), should be checked monthly
when cold and inflated to the inflation pressure recommended by the
vehicle manufacturer on the vehicle placard or tire inflation pressure
label (tire and load information label). (If your vehicle has tires of a dif-
ferent size than the size indicated on the vehicle placard or tire inflation
pressure label [tire and load information label], you should determine
the proper tire inflation pressure for those tires.)
As an added safety feature, your vehicle has been equipped with a tire
pressure monitoring system (TPMS-tire pressure warning system) that
illuminates a low tire pressure telltale (tire pressure warning light) when
one or more of your tires is significantly under-inflated. Accordingly,
when the low tire pressure telltale (tire pressure warning light) illumi-
nates, you should stop and check your tires as soon as possible, and
inflate them to the proper pressure. Driving on a significantly under-
inflated tire causes the tire to overheat and can lead to tire failure.
Under-inflation also reduces fuel efficiency and tire tread life, and may
affect the vehicle’s handling and stopping ability.
Please note that the TPMS (tire pressure warning system) is not a sub-
stitute for proper tire maintenance, and it is the driver’s responsibility to
maintain correct tire pressure, even if under-inflation has not reached
the level to trigger illumination of the TPMS low tire pressure telltale (tire
pressure warning light).
Your vehicle has also been equipped with a TPMS (tire pressure warn-
ing system) malfunction indicator to indicate when the system is not
operating properly. The TPMS (tire pressure warning system) malfunc-
tion indicator is combined with the low tire pressure telltale (tire pressure
warning light). When the system detects a malfunction, the telltale will
flash for approximately one minute and then remain continuously illumi-
nated. This sequence will continue upon subsequent vehicle start-ups
as long as the malfunction exists. When the malfunction indicator is illu-
minated, the system may not be able to detect or signal low tire pres-
sure as intended.
TPMS (tire pressure warning system) malfunctions may occur for a vari-
ety of reasons, including the installation of replacement or alternate tires
or wheels on the vehicle that prevent the TPMS (tire pressure warning
system) from functioning properly. Always check the TPMS (tire pres-
sure warning system) malfunction telltale after replacing one or more
tires or wheels on your vehicle to ensure that the replacement or alter-
nate tires and wheels allow the TPMS (tire pressure warning system) to
continue to function properly.

5097-2. Steps to take in an emergency
CAMRY_U (01999-06122)
7
When trouble arises
■Warning messages
The warning messages explained below may differ from the actual messages
according to operation conditions and vehicle specifications.
■System warning lights
The master warning light does not come on or flash in the following cases.
Instead, a separate system warning light will come on along with a message
shown on the multi-information display.
●Malfunction in the ABS
The ABS warning light comes on. (→P. 497)
●Malfunction in the tire pressure warning system
The tire pressure warning light comes on. (→P. 500)
●Remaining fuel level is low
The low fuel level warning light comes on. (→P. 500)
■If a message instructing to refer to the Owner’s Manual is displayed
●If the following messages are shown, there may be a malfunction.
Immediately stop the vehicle in a safe place and contact your Toyota dealer.
Continuing to drive the vehicle may be dangerous.
• “Low Braking Power Stop in a Safe Place See Owner’s Manual”
• “Oil Pressure Low Stop in a Safe Place See Owner’s Manual”
• “Charging System Malfunction Stop in a Safe Place See Owner’s Man-
ual”
●If the following message is shown, there may be a malfunction.
Immediately have the vehicle inspected by your Toyota dealer.
• “Smart Key System Malfunction See Owner’s Manual”
●If “Engine Coolant Temp High Stop in a Safe Place See Owner’s Manual” is
displayed, follow the instructions accordingly. (→P. 534)
■If “Shift to P Before Exiting Vehicle” is shown
Message is displayed when the driver’s door is opened without turning the
engine switch off with the shift lever in any position other than P.
Shift the shift lever to P.
■If “Auto Power Off to Conserve Battery” is displayed
This message is displayed when the power was cut off due to the automatic
power off function.
The next time the engine is started, increase the engine speed slightly and
maintain it at that speed for approximately 5 minutes to recharge the battery.

5287-2. Steps to take in an emergency
CAMRY_U (01999-06122)
■Stopping the engine
Shift the shift lever to P and press the engine switch as you normally do when
stopping the engine.
■Replacing the key battery
As the above procedure is a temporary measure, it is recommended that the
electronic key battery be replaced immediately when the battery is depleted.
(→P. 466)
■Changing engine switch modes
Release the brake pedal and press the engine switch in step above.
The engine does not start and modes will be changed each time the switch is
pressed. (→P. 201)
■When the electronic key does not work properly
●Make sure that the smart key system has not been deactivated in the cus-
tomization setting. If it is off, turn the function on.
(Customizable features: →P. 567)
●Check if battery-saving mode is set. If it is set, cancel the function.
(→P. 151)
WARNING
■When using the mechanical key and operating the power windows or
the moon roof or panoramic moon roof
Operate the power window or the moon roof or panoramic moon roof after
checking to make sure that there is no possibility of any passenger having
any of their body parts caught in the window or the moon roof or panoramic
moon roof. Also, do not allow children to operate the mechanical key. It is
possible for children and other passengers to get caught in the power win-
dow or the moon roof or panoramic moon roof.
3

5367-2. Steps to take in an emergency
CAMRY_U (01999-06122)
Start the engine and turn the air conditioning system on to check
that the radiator cooling fan operates and to check for coolant leaks
from the radiator or hoses.
The fan operates when the air conditioning system is turned on immedi-
ately after a cold start. Confirm that the fan is operating by checking the fan
sound and air flow. If it is difficult to check these, turn the air conditioning
system on and off repeatedly. (The fan may not operate in freezing tem-
peratures.)
If the fan is not operating:
Stop the engine immediately and contact your Toyota dealer.
If the fan is operating:
Have the vehicle inspected at the nearest Toyota dealer.
WARNING
■To prevent an accident or injury when inspecting under the hood of
your vehicle
Observe the following precautions.
Failure to do so may result in serious injury such as burns.
●If steam is seen coming from under the hood, do not open the hood until
the steam has subsided. The engine compartment may be very hot.
●Keep hands and clothing (especially a tie, a scarf or a muffler) away from
the fan and belts. Failure to do so may cause the hands or clothing to be
caught, resulting in serious injury.
●Do not loosen the radiator cap and the coolant reservoir cap while the
engine and radiator are hot.
High temperature steam or coolant could spray out.
NOTICE
■When adding engine coolant
Wait until the engine has cooled down before adding engine coolant.
When adding coolant, do so slowly. Adding cool coolant to a hot engine too
quickly can cause damage to the engine.
■To prevent damage to the cooling system
Observe the following precautions:
●Avoid contaminating the coolant with foreign matter (such as sand or dust
etc.).
●Do not use any coolant additives.
6
7

5377-2. Steps to take in an emergency
CAMRY_U (01999-06122)
7
When trouble arises
Stop the engine. Set the parking brake and shift the shift lever to P.
Remove the mud, snow or sand from around the front wheels.
Place wood, stones or some other material under the front wheels
to help provide traction.
Restart the engine.
Shift the shift lever to D or R and release the parking brake. Then,
while exercising caution, depress the accelerator pedal.
If the vehicle becomes stuck
Carry out the following procedures if the tires spin or the vehicle
becomes stuck in mud, dirt or snow:
1
2
3
4
5

595What to do if... (Troubleshooting)
CAMRY_U (01999-06122)
●Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. (→P. 74)
●Vehicles without a smart key system:
To stop the alarm, turn the engine switch to the “ON” position or start the
engine.
Vehicles with a smart key system:
To stop the alarm, turn the engine switch to IGNITION ON mode or start
the engine.
●Is the message displayed on the multi-information display?
Check the message on the multi-information display. (→P. 507)
●When a warning light turns on or a warning message is displayed, refer to
P. 497, 507.
●Stop the vehicle in a safe place and replace the flat tire with the spare
tire. (→P. 512)
●Try the procedure for when the vehicle becomes stuck in mud, dirt, or
snow. (→P. 537)
An alarm is activated and the horn sounds
(vehicles with an alarm)
A warning buzzer sounds when leaving the vehicle
(vehicles with a smart key system)
A warning light turns on or a warning message is displayed
When a problem has occurred
If you have a flat tire
The vehicle becomes stuck

599Alphabetical index
CAMRY_U (01999-06122)
Door lock
Doors .................................... 135
Key........................................ 137
Smart key system ................. 135
Wireless remote control ........ 136
Doors ........................................ 135
Automatic door locking
and unlocking systems ....... 140
Door lock............................... 139
Outside rear view mirrors...... 168
Rear door child-protector ...... 140
Side doors............................. 135
Side windows ........................ 170
Drive information ....................... 90
Drive-Start Control .................. 185
Driving
Break-in tips .......................... 185
Correct posture ....................... 24
Procedures ........................... 184
Winter drive tips .................... 345
Dynamic radar cruise
control .................................... 276
Dynamic radar cruise control
with full-speed range ............ 263Eco drive mode........................ 343
Eco Driving Indicator ........ 97, 111
Eco-friendly driving
information ............................ 102
EDR (Event data recorder).......... 8
Electric Power Steering
(EPS) ...................................... 295
Warning light......................... 498
Electronic key .......................... 126
Battery-saving function ......... 151
If the electronic key does not
operate properly ................. 526
Replacing the battery............ 466
Emergency flashers ................ 486
Emergency, in case of
If a warning buzzer
sounds................................ 497
If a warning light turns on ..... 497
If a warning message is
displayed ............................ 507
If the battery is discharged ... 529
If the electronic key does not
operate properly ................. 526
If the engine will not start ...... 524
If you have a flat tire ............. 512
If you lose your keys ............. 130
If you think something is
wrong ................................. 495
If your vehicle becomes
stuck ................................... 537
If your vehicle has to be
stopped in an emergency ... 487
If your vehicle needs to be
towed.................................. 489
If your vehicle overheats....... 534E
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S
MANUAL”.

600Alphabetical index
CAMRY_U (01999-06122)
Engine
ACCESSORY mode ............. 201
Compartment ........................ 432
Engine switch................ 198, 200
Hood ..................................... 430
How to start the
engine......................... 198, 200
Identification number ............ 542
If your vehicle has to be
stopped in an
emergency.......................... 487
Ignition switch
(engine switch) ........... 198, 200
Overheating .......................... 534
Engine coolant
Capacity ................................ 545
Checking ............................... 437
Preparing and checking
before winter....................... 345
Engine coolant temperature
gauge........................................ 84
Engine immobilizer system ...... 71
Engine oil
Capacity ................................ 543
Checking ............................... 434
Preparing and checking
before winter....................... 345
Engine switch .................. 198, 200
Enhanced VSC ......................... 294
Entune Audio
*
Entune Audio Plus*
Entune Premium Audio*
EPS
(Electric Power Steering)...... 295
Warning light ......................... 498
Event data recorder (EDR) .......... 8Flat tire ..................................... 512
Floor mats .................................. 22
Fluid
Automatic transaxle .............. 546
Brake .................................... 547
Washer ................................. 443
Front interior light ................... 371
Front passenger occupant
classification system .............. 45
Front passenger’s seat belt
reminder light ........................ 500
Front personal lights............... 372
Front seats ............................... 158
Adjustment............................ 158
Cleaning ............................... 417
Correct driving posture ........... 24
Head restraints ..................... 162
Seat heaters ......................... 369
Front side marker lights
Light switch ........................... 219
Replacing light bulbs .... 475, 483
Wattage ................................ 550
Front turn signal lights
Replacing light bulbs .... 474, 483
Turn signal lever ................... 211
Wattage ................................ 550
Fuel
Capacity................................ 542
Fuel gauge.............................. 84
Fuel pump shut off system ... 496
Information............................ 551
Refueling .............................. 231
Type.............................. 542, 551
Warning light......................... 500
Fuel consumption ................... 120
Fuel filler door ......................... 231
Refueling .............................. 231
When the fuel filler door
cannot be opened .............. 234
Fuel pump shut off system..... 496
Fuses ........................................ 470
F
