5037-2. Steps to take in an emergency
CAMRY_U (01999-06122)
7
When trouble arises
■When the tire pressure warning light comes on
Inspect the tires to check if a tire is punctured.
If a tire is punctured: →P. 512
If none of the tires are punctured:
Turn the engine switch off then turn it to the “ON” position (vehicle without
a smart key system) or IGNITION ON mode (vehicle with a smart key
system). Check if the tire pressure warning light comes on or blinks.
If the tire pressure warning light comes on
After the temperature of the tires has lowered sufficiently, check the
inflation pressure of each tire and adjust them to the specified level.
If the warning light does not turn off even after several minutes have
elapsed, check that the inflation pressure of each tire is at the specified
level and perform initialization. (→P. 446)
If the warning light does not turn off several minutes after the initialization
has been performed, have the vehicle inspected by your Toyota dealer
immediately.
If the tire pressure warning light blinks for 1 minute then stays on
There may be a malfunction in the tire pressure warning system. Have
the vehicle inspected by your Toyota dealer immediately.
■The tire pressure warning light may come on due to natural causes
The tire pressure warning light may come on due to natural causes such
as natural air leaks and tire inflation pressure changes caused by tem-
perature. In this case, adjusting the tire inflation pressure will turn off the
warning light (after a few minutes).
■When a tire is replaced with a spare tire
The compact spare tire is not equipped with a tire pressure warning valve
and transmitter. If a tire goes flat, the tire pressure warning light will not
turn off even though the flat tire has been replaced with the spare tire.
Replace the spare tire with the repaired tire and adjust the tire inflation
pressure. The tire pressure warning light will go off after a few minutes.
■Conditions that the tire pressure warning system may not function
properly
→P. 4 5 1
■Warning buzzer
In some cases, the buzzer may not be heard because of noisy place or an
audio sound.
1
2

5468-1. Specifications
CAMRY_U (01999-06122)
*: The fluid capacity is a reference quantity.
If replacement is necessary, contact your Toyota dealer.
Electrical system
Battery
Specific voltage reading at
68°F (20°C):12.3 V or higher
If the voltage is lower than the standard
value, charge the battery.
(When checking the voltage, after turning
the engine switch off, wait for 30 seconds
with the high beam headlights illuminated,
then turn the high beam headlights off and
check the voltage.)
Batteries with vent plugs
Specific gravity reading at
68°F (20°C):1.25 or higher
If the specific gravity is lower than the stan-
dard value, charge the battery.
Charging rates
Batteries without vent plugs
5 A max.
Batteries with vent plugs
Quick charge
Slow charge15 A max.
5 A max.
Automatic transaxle
Fluid capacity*
2.5 L 4-cylinder (A25A-FKS) engine
7.7 qt. (7.3 L, 6.4 Imp. qt.)
3.5 L V6 (2GR-FKS) engine
7.9 qt. (7.5 L, 6.6 Imp. qt.)
Fluid type Toyota Genuine ATF WS
NOTICE
■Transmission fluid type
Using transmission fluid other than “Toyota Genuine ATF WS” may cause
deterioration in shift quality, locking up of the transmission accompanied by
vibration and, ultimately, damage to the vehicle’s transmission.

595What to do if... (Troubleshooting)
CAMRY_U (01999-06122)
●Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. (→P. 74)
●Vehicles without a smart key system:
To stop the alarm, turn the engine switch to the “ON” position or start the
engine.
Vehicles with a smart key system:
To stop the alarm, turn the engine switch to IGNITION ON mode or start
the engine.
●Is the message displayed on the multi-information display?
Check the message on the multi-information display. (→P. 507)
●When a warning light turns on or a warning message is displayed, refer to
P. 497, 507.
●Stop the vehicle in a safe place and replace the flat tire with the spare
tire. (→P. 512)
●Try the procedure for when the vehicle becomes stuck in mud, dirt, or
snow. (→P. 537)
An alarm is activated and the horn sounds
(vehicles with an alarm)
A warning buzzer sounds when leaving the vehicle
(vehicles with a smart key system)
A warning light turns on or a warning message is displayed
When a problem has occurred
If you have a flat tire
The vehicle becomes stuck

598Alphabetical index
CAMRY_U (01999-06122)
Child safety ................................ 51
Airbag precautions .................. 35
Battery precautions ....... 441, 533
Child restraint system ............. 52
How your child should wear
the seat belt .......................... 28
Installing child restraints ......... 52
Moon roof precautions .......... 177
Panoramic moon roof
precautions ......................... 181
Power window lock switch .... 170
Power window precautions ... 173
Rear door child-protectors .... 140
Removed electronic key
battery precautions ............. 469
Seat belt extender
precautions ........................... 31
Seat belt precautions .............. 30
Seat heater precautions........ 369
Trunk precautions ................. 147
Child-protectors....................... 140
Cleaning ........................... 414, 417
Aluminum wheels.................. 415
Exterior ................................. 414
Interior................................... 417
Seat belts .............................. 418
Clock
*
Coat hooks ............................... 394
Compass .................................. 408
Condenser ................................ 438
Console box ............................. 374
Consumption
screen............................. 120, 122
Coolant
Capacity ................................ 545
Checking ............................... 437
Preparing and checking
before winter....................... 345Cooling system........................ 437
Engine overheating............... 534
Cruise control
Cruise control ....................... 289
Dynamic radar cruise
control ................................ 276
Dynamic radar cruise control
with full-speed range .......... 263
Cup holders ............................. 376
Curtain shield airbags............... 33
Customizable features ............ 567
Daytime running light
system.................................... 220
Defogger
Outside rear view
mirrors ................ 351, 357, 364
Rear window ......... 351, 357, 364
Windshield ............ 351, 357, 364
Dimensions .............................. 540
Dinghy towing.......................... 197
Display
Dynamic radar cruise
control ................................ 276
Dynamic radar cruise control
with full-speed range .......... 263
LDA (Lane Departure Alert
with steering control) .......... 253
Multi-information
display ............................ 87, 99
Warning messages ............... 507
Do-it-yourself maintenance .... 428
Door courtesy lights
Location ................................ 370
Wattage ................................ 550
D

600Alphabetical index
CAMRY_U (01999-06122)
Engine
ACCESSORY mode ............. 201
Compartment ........................ 432
Engine switch................ 198, 200
Hood ..................................... 430
How to start the
engine......................... 198, 200
Identification number ............ 542
If your vehicle has to be
stopped in an
emergency.......................... 487
Ignition switch
(engine switch) ........... 198, 200
Overheating .......................... 534
Engine coolant
Capacity ................................ 545
Checking ............................... 437
Preparing and checking
before winter....................... 345
Engine coolant temperature
gauge........................................ 84
Engine immobilizer system ...... 71
Engine oil
Capacity ................................ 543
Checking ............................... 434
Preparing and checking
before winter....................... 345
Engine switch .................. 198, 200
Enhanced VSC ......................... 294
Entune Audio
*
Entune Audio Plus*
Entune Premium Audio*
EPS
(Electric Power Steering)...... 295
Warning light ......................... 498
Event data recorder (EDR) .......... 8Flat tire ..................................... 512
Floor mats .................................. 22
Fluid
Automatic transaxle .............. 546
Brake .................................... 547
Washer ................................. 443
Front interior light ................... 371
Front passenger occupant
classification system .............. 45
Front passenger’s seat belt
reminder light ........................ 500
Front personal lights............... 372
Front seats ............................... 158
Adjustment............................ 158
Cleaning ............................... 417
Correct driving posture ........... 24
Head restraints ..................... 162
Seat heaters ......................... 369
Front side marker lights
Light switch ........................... 219
Replacing light bulbs .... 475, 483
Wattage ................................ 550
Front turn signal lights
Replacing light bulbs .... 474, 483
Turn signal lever ................... 211
Wattage ................................ 550
Fuel
Capacity................................ 542
Fuel gauge.............................. 84
Fuel pump shut off system ... 496
Information............................ 551
Refueling .............................. 231
Type.............................. 542, 551
Warning light......................... 500
Fuel consumption ................... 120
Fuel filler door ......................... 231
Refueling .............................. 231
When the fuel filler door
cannot be opened .............. 234
Fuel pump shut off system..... 496
Fuses ........................................ 470
F

608Alphabetical index
CAMRY_U (01999-06122)
Seat heater switches ............ 369
“SOS” button ......................... 402
Talk switch
*
Trunk opener switch ............. 144
Vehicle-to-vehicle
distance button ........... 263, 276
VSC OFF switch ................... 295
Window lock switch............... 170
Windshield wiper and
washer switch ..................... 227
Tachometer ................................ 84
Tail lights
Light switch ........................... 219
Replacing light bulbs............. 483
Talk switch
*
Theft deterrent system
Alarm ...................................... 74
Engine immobilizer system ..... 71
Tire inflation pressure ............. 459
Maintenance data ................. 547
Warning light ......................... 500
Tire information ....................... 554
Glossary................................ 561
Size ....................................... 557
Tire identification number ..... 556
Uniform Tire Quality
Grading............................... 559Tire pressure warning system
Initializing .............................. 446
Installing tire pressure
warning valve and
transmitters ........................ 446
Registering ID codes ............ 448
Warning light......................... 500
Tires .......................................... 444
Chains .................................. 346
Checking............................... 444
Glossary ............................... 561
If you have a flat tire ............. 512
Inflation pressure .................. 547
Replacing.............................. 512
Rotating tires ........................ 444
Size....................................... 547
Snow tires ............................. 347
Spare tire .............................. 512
Tire pressure warning
system ................................ 445
Uniform Tire Quality
Grading .............................. 559
Warning light......................... 500
Tools ......................................... 513
Top tether strap ......................... 68
Total load capacity .................. 195
Towing
Dinghy towing ....................... 197
Emergency towing ................ 489
Towing eyelet ....................... 491
Trailer towing ........................ 196
Toyota Entune
*
T
