2018 Ram ProMaster fuse

CavityMaxi Fuse Mini Fuse Description
F18 –7.5 Amp Brown KL30 Manual Transmission Automated
(MTA), KL30 Engine Control Module
(ECM), KL30 Main Relay Coil (3.0 Diesel
Engine)
F19 –7.5 Amp Brown A/C Compressor — If Equipped
F20 –30 Amp Green Windshield Wiper
F21 –15 Amp Blue Fuel Pump
F22 –20 Amp Yellow Engine Control Module (ECM), Ignition
Coils (3.6 Gasoline Engine)
F22 –20 Amp Yellow Engine Control Module (ECM), Primary
Loads (3.0 Diesel Engine)
F23 –20 Amp Yellow Electronic Stability Control (ESC) Valves
F24 –7.5 Amp Brown KL15 Vacuum Pump Relay Coil (3.6 Gaso-
line Engine) — If Equipped
F30 –15 Amp Blue Heated Mirrors
7
IN CASE OF EMERGENCY 189

Front PDC Additional Fuses
The additional fuse box is located inside the front PDC Box.
CavityMini Fuse Description
F61 20 Amp Yellow Vacuum Pump (3.6 Gasoline Engine) — If Equipped
F62 30 Amp Green Transmission Power RELE (3.6 Gasoline Engine) — If
Equipped
F64 7.5 Amp Brown Urea Pump (3.0 Diesel Engine) — If Equipped
F65 20 Amp Yellow UREA NOX SNS 1-2 + PM SNS (3.0 Diesel Engine) — If
Equipped
F66 5 Amp Beige Shifter Transmission Module (STM) (3.6 Gasoline Engine)
— If Equipped
Front Power Distribution Center Additional Fuses
190 IN CASE OF EMERGENCY

Interior Fuses
The interior fuse panel is part of the Body Control Module
(BCM) and is located on the driver’s side under the
instrument panel.
Fuse Panel
7
IN CASE OF EMERGENCY 191

CavityMini Fuse Description
F31 5 Amp Beige INT/A
F34 7.5 Amp Brown Clearance Lights
Fuse Panel Cavity Locations
192 IN CASE OF EMERGENCY

CavityMini Fuse Description
F36 15 Amp Blue +30 (ACM – TPCU – RRM – DLC)
F37 5 Amp Beige INT (BRAKE NO – IPC)
F38 15 Amp Blue Central Locking
F42 5 Amp Beige INT (BSM – SAS – BRAKE NC)
F43 20 Amp Yellow Bi-Directional Washer Pump
F47 20 Amp Yellow Driver Power Window
F48 20 Amp Yellow Passenger Power Window
F49 5 Amp Beige INT (PAM – CCS – RRM – ECM)
F50 7.5 Amp Brown INT (ORC)
F51 5 Amp Beige INT (REAR CAMERA-AUX)
F53 5 Amp Beige +30 (IPC)
F90 7.5 Amp Brown Left High Beam
F93 7.5 Amp Brown Right Fog Lamp
7
IN CASE OF EMERGENCY 193

Right Central Pillar Fuses
The right central pillar fuse panel is located on the interior
side at the base of the passenger side B pillar.
CavityMini Fuse Description
F81 7.5 Amp Brown Seat Heater
F83 20 Amp Yellow Rear Left Windows Heater
F84 20 Amp Yellow Rear Right Windows Heater
F86 20 Amp Yellow Auxiliary Switch (From Battery) — If Equipped
F87 20 Amp Yellow Auxiliary Switch (From Ignition) — If Equipped
Fuse Panel Location
Fuse Panel
194 IN CASE OF EMERGENCY

ENGINE COMPARTMENT
3.6L Engine
1 — Washer Fluid Reservoir
2 — Engine Oil Fill
3 — Engine Oil Dipstick
4 — Brake Fluid Reservoir5 — Power Distribution Center (Fuses)
6 — Coolant Reservoir
7 — Power Steering Reservoir
232 SERVICING AND MAINTENANCE

Clean Air............................. .282
Ethanol .............................. .283
Filler Cap (Gas Cap) ..................... .159
Gasoline .............................. .282
Materials Added ........................ .282
Methanol ............................. .283
Octane Rating ....................... .282, 286
Requirements ....................... .282, 286
Tank Capacity .......................... .286
Fuses .................................. .186
Gas Cap (Fuel Filler Cap) .................159, 160
Gasoline, Clean Air ........................ .282
Gasoline, Reformulated ..................... .282
Gear Ranges ............................. .143
Gear Select Lever Override ....................219
General Information .........................99
Glass Cleaning ........................... .276
Gross Axle Weight Rating .................161, 164
Gross Vehicle Weight Rating ...............161, 163
Guide, Body Builders .........................6
GVWR ................................. .161Hazard
Driving Through Flowing, Rising, Or Shallow
Standing Water ......................... .174
Hazard Warning Flasher ..................... .179
Headlights Cleaning .............................. .273
High Beam ..............................39
High Beam/Low Beam Select Switch ...........39
Passing ................................40
Switch .................................39
Head Restraints ............................32
Heated Mirrors .............................38
Heated Seats ...............................29
Heater, Engine Block ....................... .138
High Beam/Low Beam Select (Dimmer) Switch ......39
Hill Start Assist .............................94
Hitches Trailer Towing .......................... .166
Hood Prop ................................56
Hood Release ..............................56
Ignition ..................................
18
Key ............................... .16, 18
Ignition Key Removal ........................18
Illuminated Entry ...........................44
326 INDEX
