90Instruments and controlsInstruments and
controlsControls ....................................... 91
Steering wheel adjustment ........91
Steering wheel controls .............91
Heated steering wheel ...............92
Horn ........................................... 92
Windscreen wiper/washer .........92
Rear window wiper/washer .......94
Outside temperature ..................95
Clock ......................................... 95
Power outlets ............................. 97
Power connector .......................98
Ashtrays .................................... 99
Warning lights, gauges and indi‐ cators ......................................... 101
Instrument cluster ....................101
Speedometer ........................... 104
Odometer ................................ 105
Trip odometer .......................... 105
Tachometer ............................. 106
Fuel gauge .............................. 106
Fuel selector ............................ 106
Engine coolant temperature gauge ..................................... 107
Service display ........................ 108Control indicators ....................109
Turn signal ............................... 109
Seat belt reminder ...................109
Airbag and belt tensioners .......110
Airbag deactivation ..................110
Charging system .....................111
Malfunction indicator light ........111
Brake and clutch system .........111
Electric parking brake ..............111
Electric parking brake fault ......111
Antilock brake system (ABS) ...112
Gear shifting ............................ 112
Following distance ...................112
Lane keep assist .....................112
Electronic Stability Control off . 112
Electronic Stability Control and Traction Control system .........112
Traction Control system off .....113
Preheating ............................... 113
Tyre pressure monitoring system .................................... 113
Engine oil pressure ..................113
Low fuel ................................... 113
Immobiliser .............................. 114
Exterior light ............................ 114
High beam ............................... 114
High beam assist .....................114
LED headlights ........................ 114
Fog light ................................... 114
Rear fog light ........................... 114Cruise control.......................... 114
Adaptive cruise control ............114
Vehicle detected ahead ...........115
Speed limiter ........................... 115
Traffic sign assistant ................115
Door open ................................ 115
Information displays ...................115
Driver Information Centre ........115
Info display .............................. 121
Vehicle messages ......................123
Warning chimes .......................124
Battery voltage ........................ 124
Vehicle personalisation ..............125
Telematics service .....................131
OnStar ..................................... 131

Instruments and controls105Odometer
The total recorded distance is
displayed in km.
Trip odometer The recorded distance since the last
reset is displayed on the trip computer
page.
Trip odometer counts up to
9,999 km and then restarts at 0.
Two trip odometer pages are
selectable for different trips.
Midlevel instrument cluster
Select ; by pressing Menu on the
turn signal lever. Turn adjuster wheel
on turn signal lever and select ;1
or ; 2. Each trip odometer page can
be reset separately by pressing
SET/CLR on the turn signal lever for
a few seconds on the respective
menu.
Uplevel instrument cluster
Select Info page J on main menu.
Choose page Trip A or Trip B by
pressing o on the steering wheel.
Each trip odometer can be reset separately when ignition is on: select
respective page, press >. Confirm by
pressing 9.
Driver Information Centre 3 115.

Instruments and controls115Adaptive cruise control 3 186.
Vehicle detected ahead A illuminates green or yellow.
Illuminates green
A vehicle ahead is detected in the
same lane.
Illuminates yellow The distance to a preceding moving
vehicle gets too small or when
approaching another vehicle too
rapidly.
Adaptive cruise control 3 186,
Forward collision alert 3 193.
Speed limiter
L illuminates white or green.
Illuminates white The system is on.
Illuminates green
Speed limiter is active. Set speed is
indicated near L symbol.Speed limiter 3 184.
Traffic sign assistant
L displays detected traffic signs as
control indicator.
Traffic sign assistant 3 211.
Door open h illuminates red.
A door or the tailgate is open.Information displays
Driver Information Centre The Driver Information Centre is
located in the instrument cluster.
Depending on the version and the
instrument cluster, the Driver
Information Centre is available as
Midlevel display or Uplevel display.
Driver Information Centre indicates
depending on the equipment:
● overall and trip odometer
● vehicle information
● trip/fuel information
● driving economy information ● vehicle and warning messages
● audio and infotainment information
● phone information
● navigation information
● vehicle settings

Instruments and controls117● Navigation information,displayed by Navigation, see
description below.
● Vehicle information, displayed by
Options , see description below.
Some of the displayed functions differ
when the vehicle is being driven or at
a standstill and some functions are
only active when the vehicle is being
driven.
Selecting menus and functions
The menus and functions can be selected via the buttons on the right
side in the steering wheel.● Press p to open main menu page.
● Select a main menu page with Q or P.
● Confirm a main menu page with 9.
Once a main menu page is selected,
press Q or P to select subpages.
● Press q to open a next folder of
the selected subpage.
● Press Q or P to select functions
or to set a numeric value, if
required.
● Press 9 to select and confirm a
function.
Vehicle and service messages pop-
up in the Driver Information Centre
when required.
Confirm messages by pressing 9.
Vehicle messages 3 123.Trip/fuel information menu, ;
or Info
The following list contains all possible Info Menu pages. Some may not be
available for your particular vehicle.
Depending on the display, some
functions are symbolised.
Turn the adjuster wheel or press Q
or P to select a page:
● Trip odometer 1/2 or A/B
● Average fuel consumption
● Average speed
● Digital speed
● Fuel range
● Instantaneous fuel consumption
● Remaining oil life
● Tyre pressure
● Traffic sign assistant
● Following distance
● Timer
● Outside temperature

118Instruments and controlsOn Midlevel display the pages
Remaining Oil Life, Tyre Pressure,
Traffic Sign Assistant and Following
Distance are displayed in the Vehicle
information menu, select ?.
Trip odometer 1/2 or A/B
Trip odometer displays the current
distance since a certain reset.
Trip odometer counts up to a distance of 9,999 km then restarts at 0.
To reset on Midlevel display, press SET/CLR for a few seconds.
To reset on Uplevel display, press >
and confirm with 9.
The information of trip odometer page
1/A and 2/B can be reset separately
while the respective display is active.
Average Fuel Consumption
Display of average consumption. The measurement can be reset at any
time and starts with a default value.
To reset on Midlevel display, press
SET/CLR for a few seconds, on
Uplevel display, press > and confirm
with 9.On vehicles with bi-fuel engines:
Average consumption is indicated for
the currently selected mode, CNG or
petrol.
Average speed
Display of average speed. The
measurement can be reset at any
time.
To reset on Midlevel display, press
SET/CLR for a few seconds, on
Uplevel display, press > and confirm
with 9.
Digital speed
Digital display of the instantaneous
speed.
Fuel range
Range is calculated from current fuel
level and current consumption. The
display shows average values.
After refuelling, the range is updated
automatically after a brief delay.
When the level in the fuel tank is low,
a message appears on the display
and the control indicator Y in the fuel
gauge illuminates.When the fuel tank must be refuelled
immediately, a warning message
appears and remains on the display.
Additionally, control indicator Y in the
fuel gauge flashes 3 113.
Fuel range, bi-fuel engine
Display of the approximate total fuel
range and for each fuel tank (CNG
and petrol). A low fuel level in either
tank is indicated by Low in the
respective section.

308Headlight range adjustment ......137
Headlights................................... 136
Headlights when driving abroad 138
Head restraint adjustment .............8
Head restraints ............................ 46
Heated mirrors ............................. 40
Heated rear window ..................... 43
Heated steering wheel .................92
Heating .................................. 54, 56
Heating and ventilation system . 147
High beam ......................... 114, 137
High beam assist ........................114
Hill start assist ........................... 179
Horn ....................................... 14, 92
I
Identification plate .....................280
Ignition switch positions .............158
Immobiliser .......................... 38, 114
Indicators .................................... 104
Info display ................................. 121
Information displays.................... 115
Instrument cluster ......................101
Instrument panel fuse box .........248
Instrument panel illumination .....245
Instrument panel illumination control .................................... 144
Instrument panel overview ........... 10
Interior care ............................... 274
Interior lighting ............................ 144Interior lights ...................... 144, 245
Interior mirrors .............................. 40
Interruption of power supply ......172
Introduction .................................... 3
J
Jump starting ............................. 269
K Key, memorised settings ..............24
Keys ............................................. 20
Keys, locks ................................... 20
L Lane keep assist ................112, 215
Lashing eyes ............................... 81
LED headlights ...................114, 138
Lighting features .........................145
Light switch ................................ 136
Load compartment ................30, 73
Load compartment cover .............79
Load compartment fuse box ......250
Loading information .....................88
Low fuel ..................................... 113
M
Malfunction indicator light ..........111
Manual anti-dazzle ......................40
Manual mode .....................171, 175
Manual seat adjustment ...............48
Manual transmission .................. 173Manual transmission automated 173
Manual windows ..........................41
Massage ....................................... 55
Maximum speed ......................... 254
Memorised settings ......................24
Midlevel display .......................... 115
Mirror adjustment ........................... 9
Misted light covers .....................143
N Natural gas ......................... 106, 219
New vehicle running-in ..............158
Number plate light .....................244
O Object detection systems ...........200
Odometer ................................... 105
Oil, engine .......................... 277, 282
OnStar ........................................ 131
Outside temperature ....................95
Overrun cut-off ........................... 163
P Parking ................................ 19, 166
Parking assist ............................ 200
Parking brake ............................ 177
Parking lights ............................. 143
Particulate filter ........................... 168
Performance .............................. 287
Performing work ........................229
Pollen filter ................................. 156

310Tread depth ............................... 259
Trip odometer ............................ 105
Turn and lane-change signals ...142
Turn signal ................................. 109
Tyre chains ................................ 260
Tyre designations ......................254
Tyre pressure ............................ 254
Tyre pressure monitoring system ............................. 113, 255
Tyre pressures ........................... 293
Tyre repair kit ............................. 261
U
Ultrasonic parking assist............. 200
Upholstery .................................. 274
Uplevel display ........................... 115
Using this manual ..........................3
V Valet mode ................................. 121
Vehicle battery ........................... 233
Vehicle checks............................ 229
Vehicle data ................................ 282
Vehicle data recording and privacy ..................................... 304
Vehicle detected ahead ..............115
Vehicle dimensions .................... 291
Vehicle Identification Number ....280
Vehicle jack ................................ 252
Vehicle messages .....................123
Vehicle personalisation .............125Vehicle security ............................ 36
Vehicle specific data ......................3
Vehicle storage ........................... 228
Vehicle tools ............................... 252
Vehicle unlocking ........................... 6 Vehicle weight ........................... 289
Ventilating ..................................... 54
Ventilation ................................... 147
W
Warning chimes .........................124
Warning lights ............................. 104
Warning triangle .......................... 86
Washer and wiper systems .........14
Washer fluid ............................... 232
Wheel changing .........................264
Wheel covers ............................. 260
Wheels and tyres .......................254
Windows ....................................... 41
Windscreen................................... 41
Windscreen wiper/washer ...........92
Winter tyres ............................... 254
Wiper blade replacement ..........234
