2018 NISSAN GT-R display

Vanity mirror ........................................................... 3-29
Vanity mirror lights ............................................ 2-67
Most common factors contributing to
vehicle corrosion ............................................................. 7-9
Multi Function Display Owner’s Manual ....... 4-2
N
NISSAN Advanced Air Bag System ................ 1-40
NISSAN Vehicle Immobilizer System ............ 2-49
NissanConnect NISMO Plus™ ............................ 4-16
No key warning ............................................................ 2-44
Noises are heard while driving .................. GTR-24
O

GT-R Overview
GTR
Illustrated table of contents
0
Safety — Seats, seat belts and supplemental restraint
systemInstruments and controlsPre-driving checks and adjustmentsDisplay screen, heater, air conditioner and audio systemsStarting and drivingIn case of emergencyAppearance and careMaintenance and do-it-yourselfTechnical and consumer information
123456789
Index
10

4 Display screen, heater, air conditionerand audio systems

HOW TO TURN ON AND OFF PRE-
DICTIVE COURSE LINESIf the RearView Monitor is in operation
and the rear view is displayed, turn on
and off the predictive course line setting
according to the following procedure.
1. Touch the touch screen display.
2. Touch the “Predictive Course Lines”key to turn the feature on or off.

is used.
. Objects in the RearView Monitor
will appear visually opposite
compared to when viewed in the
rearview and outside mirrors.
. Use the displayed lines as a re-
ference. The lines are highly af-
fected by the number of
occupants, fuel level, vehicle po-
sition, road conditions and road
grade.
. Make sure that the trunk lid is
securely closed when backing up.
. Do not put anything on the rear-
view camera. The rearview cam-
era is installed above the license
plate.
. When washing the vehicle with
high-pressure water, be sure not
to spray it around the camera.
Otherwise, water may enter the
camera unit causing water con-
densation on the lens, a malfunc-
tion, fire or an electric shock.
. Do not strike the camera. It is a
precision instrument. Otherwise,
it may malfunction or cause da-
mage resulting in a fire or an
electric shock. The following are operating limitations
and do not represent a system malfunc-
tion:
.
When the temperature is extremely
high or low, the screen may not clearly
display objects.
. When strong light is directly coming
on the camera, objects may not be
displayed clearly.
. Vertical lines may be seen in objects
on the screen. This is due to strong
reflected light from the bumper.
. The screen may flicker under fluores-
cent light.
. The colors of objects on the RearView
Monitor may differ somewhat from
the actual color of objects.
. Objects on the monitor may not be
clear in a dark environment.
. There may be a delay when switching
to the RearView Monitor screen.
. If dirt, rain or snow accumulates on
the camera, the RearView Monitor
may not display objects clearly. Clean
the camera.
. Do not use wax on the camera win-
dow. Wipe off any wax with a clean
cloth dampened with mild detergent
diluted with water.

4 Display screen, heater, air conditionerand audio systems

HOW TO TURN ON AND OFF PRE-
DICTIVE COURSE LINESIf the RearView Monitor is in operation
and the rear view is displayed, turn on
and off the predictive course line setting
according to the following procedure.
1. Touch the touch screen display.
2. Touch the “Predictive Course Lines”key to turn the feature on or off.

is used.
. Objects in the RearView Monitor
will appear visually opposite
compared to when viewed in the
rearview and outside mirrors.
. Use the displayed lines as a re-
ference. The lines are highly af-
fected by the number of
occupants, fuel level, vehicle po-
sition, road conditions and road
grade.
. Make sure that the trunk lid is
securely closed when backing up.
. Do not put anything on the rear-
view camera. The rearview cam-
era is installed above the license
plate.
. When washing the vehicle with
high-pressure water, be sure not
to spray it around the camera.
Otherwise, water may enter the
camera unit causing water con-
densation on the lens, a malfunc-
tion, fire or an electric shock.
. Do not strike the camera. It is a
precision instrument. Otherwise,
it may malfunction or cause da-
mage resulting in a fire or an
electric shock. The following are operating limitations
and do not represent a system malfunc-
tion:
.
When the temperature is extremely
high or low, the screen may not clearly
display objects.
. When strong light is directly coming
on the camera, objects may not be
displayed clearly.
. Vertical lines may be seen in objects
on the screen. This is due to strong
reflected light from the bumper.
. The screen may flicker under fluores-
cent light.
. The colors of objects on the RearView
Monitor may differ somewhat from
the actual color of objects.
. Objects on the monitor may not be
clear in a dark environment.
. There may be a delay when switching
to the RearView Monitor screen.
. If dirt, rain or snow accumulates on
the camera, the RearView Monitor
may not display objects clearly. Clean
the camera.
. Do not use wax on the camera win-
dow. Wipe off any wax with a clean
cloth dampened with mild detergent
diluted with water.
