2018 NISSAN GT-R TPMS

The low tire pressure warning light warns
of low tire pressure and flat tire, or
indicates that the TPMS is not functioning
properly.
After the ignition switch is pushed to the
ON position, the warning light illuminates
for about 1 second and turns off.
Low tire pressure warning:
If the vehicle is being driven with low tire
pressure, the warning light will illuminate.
When the low tire pressure warning
light illuminates, you should stop and
adjust the tire pressure of all 4 wheels
to the recommended COLD tire pressure
shown on the Tire and Loading Infor-
mation label located in the driver’s door
opening.
The low tire pressure warning light does
not automatically turn off when the tire
pressure is adjusted. After the tire is
inflated to the recommended pressure,
the vehicle must be driven at speeds
above 16 MPH (25 km/h) to activate the
TPMS and turn off the low tire pressure
warning light. Use a tire pressure gauge
to check the tire pressure. (

The low tire pressure warning light warns
of low tire pressure and flat tire, or
indicates that the TPMS is not functioning
properly.
After the ignition switch is pushed to the
ON position, the warning light illuminates
for about 1 second and turns off.
Low tire pressure warning:
If the vehicle is being driven with low tire
pressure, the warning light will illuminate.
When the low tire pressure warning
light illuminates, you should stop and
adjust the tire pressure of all 4 wheels
to the recommended COLD tire pressure
shown on the Tire and Loading Infor-
mation label located in the driver’s door
opening.
The low tire pressure warning light does
not automatically turn off when the tire
pressure is adjusted. After the tire is
inflated to the recommended pressure,
the vehicle must be driven at speeds
above 16 MPH (25 km/h) to activate the
TPMS and turn off the low tire pressure
warning light. Use a tire pressure gauge
to check the tire pressure. (

placard or tire inflation pressure label)
is located in the driver’s door opening.
. You can also check the pressure of all
tires on the touch screen display.
Refer to the separate Multi Function
Display Owner’s Manual.
. The tire pressure sensor should be
reset anytime the wheels or tires are
removed or replaced.
. If the tire is removed in order to
replace the tire pressure sensor bat-
tery, it may not be possible to reuse
the removed tire from the wheel. To
replace the tire pressure sensor bat-
tery, it is recommended you contact a
GT-R certified NISSAN dealer.
NOTICE
.The TPMS may not function prop-
erly when the wheels are
equipped with tire chains or the
wheels are buried in snow.
. The TPMS may not function prop-
erly if the TPMS sensor is not

reset and when wheels/tires from
another GT-R are installed on
your vehicle.
. The TPMS will not function prop-
erly if non-GT-R wheels are in-
stalled on the vehicle.
. Do not place metalized film or
any metal parts (antenna, etc.) on
the windows. This may cause
poor reception of the signals
from the tire pressure sensors,
and the TPMS will not function
properly.
Some devices and transmitters may tem-
porarily interfere with the operation of
the TPMS and cause the low tire pressure
warning light to illuminate. Some exam-
ples are:
. Facilities or electric devices using
similar radio frequencies are near the
vehicle.
. If a transmitter set to similar frequen-
cies is being used in or near the
vehicle.
. If a computer (or similar equipment) or
a DC/AC converter is being used in or
near the vehicle.
Low tire pressure warning light may
illuminate in the following cases. .
If the vehicle is equipped with a wheel
and tire without TPMS.
. If the TPMS has been replaced and the
ID has not been registered.
. If the wheel is not originally specified
by NISSAN.
FCC Notice:
For USA:
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference,
and (2) this device must accept any
interference received, including inter-
ference that may cause undesired op-
eration.
Note: Changes or modifications not
expressly approved by the party re-
sponsible for compliance could void
the user’s authority to operate the
equipment.
For Canada:
This device complies with Industry Ca-
nada licence-exempt RSS standard(s).
Operation is subject to the following
two conditions: (1) this device may not
cause interference, and (2) this device
must accept any interference, including
interference that may cause undesired
operation of the device.

could affect the proper operation
of the TPMS.
. Do not inject any tire liquid or
aerosol tire sealant into the tires,
as this may cause a malfunction
of the tire pressure sensors.
NOTE:
. You can check the pressure of all
four tires on the touch screen dis-
play. See the separate Multi Func-
tion Display Owner’s Manual.
. The tires of this vehicle are filled
with nitrogen gas. When the tire
pressure is low, fill the tires with
nitrogen. It is recommended you
contact a GT-R certified NISSAN
dealer for information on filling the
tires with nitrogen.
. If nitrogen is not available, com-
pressed air may be safely used
under normal driving conditions.
However, NISSAN recommends re-
filling with nitrogen for maximum
tire performance.

could affect the proper operation
of the TPMS.
. Do not inject any tire liquid or
aerosol tire sealant into the tires,
as this may cause a malfunction
of the tire pressure sensors.
NOTE:
. You can check the pressure of all
four tires on the touch screen dis-
play. See the separate Multi Func-
tion Display Owner’s Manual.
. The tires of this vehicle are filled
with nitrogen gas. When the tire
pressure is low, fill the tires with
nitrogen. It is recommended you
contact a GT-R certified NISSAN
dealer for information on filling the
tires with nitrogen.
. If nitrogen is not available, com-
pressed air may be safely used
under normal driving conditions.
However, NISSAN recommends re-
filling with nitrogen for maximum
tire performance.

NOTICE
Make sure the tire valve stem cap is
installed and that the valve stem is
tight. When installing the cap, make
sure to tighten the cap by hand. If a
tool is used to tighten the cap, the
cap may be damaged.TIRE PRESSURE
Tire Pressure Monitoring System
(TPMS)This vehicle is equipped with the Tire
Pressure Monitoring System (TPMS). It
monitors tire pressure of all tires. When
the low tire pressure warning light is lit,
one or more of your tires is significantly
under-inflated. The system also displays
pressure of all tires on the touch screen
display by sending a signal from a sensor
that is installed in each wheel.
The TPMS will activate only when the
vehicle is driven at speeds above 16 MPH
(25 km/h). Also, this system may not
detect a sudden drop in tire pressure.
(

placard or tire inflation pressure label)
is located in the driver’s door opening.
. You can also check the pressure of all
tires on the touch screen display.
Refer to the separate Multi Function
Display Owner’s Manual.
. The tire pressure sensor should be
reset anytime the wheels or tires are
removed or replaced.
. If the tire is removed in order to
replace the tire pressure sensor bat-
tery, it may not be possible to reuse
the removed tire from the wheel. To
replace the tire pressure sensor bat-
tery, it is recommended you contact a
GT-R certified NISSAN dealer.
NOTICE
.The TPMS may not function prop-
erly when the wheels are
equipped with tire chains or the
wheels are buried in snow.
. The TPMS may not function prop-
erly if the TPMS sensor is not
