2018 NISSAN GT-R engine

0 Illustrated table of contentsSeats, seat belts and Supplemental Restraint
System (SRS).................................................................................... 0-2
Front ................................................................................................ 0-2
Rear .................................................................................................. 0-3
Exterior front ................................................................................... 0-4
Exterior rear ..................................................................................... 0-5 Passenger compartment ...................................................... 0-6
Cockpit ................................................................................................ 0-7
Instrument panel ........................................................................ 0-8
Meters and gauges ................................................................... 0-9
Engine compartment ........................................................... 0-10
Warning and indicator lights .......................................... 0-11

NOTICE
If the gauge indicates engine coolant
temperature near the hot (H) end of
the normal range, reduce vehicle
speed to decrease temperature. If
gauge is over the normal range, stop
the vehicle as soon as safely possi-
ble. If the engine is overheated,
continued operation of the vehicle
may seriously damage the engine.
(

— blinks rapidly (about twice asecond):
Pull off the road in a safe area,
and idle the engine. The driv-
ing mode will change to RWD
to prevent the AWD system
from malfunctioning. If the
warning light turns off, you
can drive again. This does
not indicate that there is a
malfunction.
— blinks slowly (about once every 2 seconds):
Pull off the road in a safe area,
and idle the engine. Check
that all tire sizes are the same
as that specified on the Tire
and Loading Information label
located in the driver’s door
opening, tire pressure is cor-
rect and tires are not worn.
(

Transmission clutch temperature high:
The light illuminates if clutch temperature
becomes unusually high. If the light
illuminates, pull off the road in a safe area
and idle the engine. When the light turns
off, driving can be resumed. If the light
illuminates frequently, it is recommended
you contact a GT-R certified NISSAN deal-
er.
NOTICE
.Continuing to drive with the light
on could cause serious damage
to the transmission.
. If the light continues to illumi-
nate, the vehicle cannot be driven
because the engine output may
be reduced and the clutch may be
reduced to keep the clutch disen-
gaged.
R mode start function:
If the R mode start function is used 4
times continuously, the function may be
disabled and cannot be turned on for
protection. While the function is disabled,
the warning light illuminates. When the
warning light goes off, the function can
be used again. (

and remove rings, metal bands,
or any other jewelry. Do not lean
over the battery when jump start-
ing.
. Do not attempt to jump start a
frozen battery. It could explode
and cause serious injury.
. Your vehicle has an automatic
engine cooling fan. It could come
on at any time. Keep hands and
other objects away from it.

headlight switch is turned to OFF.
2. Open the engine hood and remove the cover on the battery and the fuse/
fusible link holder.
3. Remove the fuse/fusible link holder cover.
4. Remove the fuse with the fuse puller that is located in the engine compart-
ment fuse box.

and remove rings, metal bands,
or any other jewelry. Do not lean
over the battery when jump start-
ing.
. Do not attempt to jump start a
frozen battery. It could explode
and cause serious injury.
. Your vehicle has an automatic
engine cooling fan. It could come
on at any time. Keep hands and
other objects away from it.

whenever you work on your ve-
hicle.
. If you must run the engine in an
enclosed space such as a garage,
be sure there is proper ventilation
for exhaust gases to escape.
. Never get under the vehicle while
it is supported only by a jack. If it
is necessary to work under the
vehicle, support it with safety
stands.
. Keep smoking materials, flame
and sparks away from fuel tank
and the battery.
. Your vehicle is equipped with an
automatic engine cooling fan. It
may come on at any time without
warning, even if the ignition key is
in the OFF position and the en-
gine is not running. To avoid
injury, always disconnect the ne-
gative battery cable before work-
ing near the fan.
. The fuel filter or fuel lines should
be serviced by a GT-R certified
NISSAN dealer because the fuel
lines are under high pressure
even when the engine is off.
