2018 MAZDA MODEL CX-9 fog light

4When Driving
Information concerning safe driving and stopping.
Start/Stop Engine.............................. 4-4 Ignition Switch........ ..................... 4-4
Starting the Engine....................... 4-5
Turning the Engine Off...............4-10
Instrument Cluster and Display............
........................................................... 4-12 Meters and Gauges..................... 4-12
Multi-information Display and INFO
Switch
*....................................... 4-20
Active Driving Display
*............. 4-28
Warning/Indicator Lights............4-31
Automatic Transaxle....................... 4-40 Automatic Transaxle
Controls...................................... 4-40
Shift-Lock System...................... 4-41
Transaxle Ranges........................4-41
Manual Shift Mode..................... 4-43
Driving Tips................................4-48
Switches and Controls..................... 4-49
Lighting Control......................... 4-49
Fog Lights
*................................. 4-54
Turn and Lane-Change
Signals........................................ 4-54
Windshield Wipers and
Washer........................................ 4-55
Rear Window Wiper and
Washer........................................ 4-59
Rear Window Defogg er.............. 4-59
Horn............................................ 4-61
Hazard Warning Flasher............. 4-61
HomeLink Wireless Control
System
*.......................................4-62
Brake................................................ 4-66 Brake System.............................. 4-66
Hill Launch Assist (HLA).......... 4-70
ABS/TCS/DSC/Trailer Stability Assist
(TSA)................................................ 4-72 Antilock Brake System
(ABS)..........................................4-72
Traction Control System
(TCS).......................................... 4-73
Dynamic Stability Control
(DSC)..........................................4-75
Trailer Stability Assist (TSA)..... 4-76
Fuel Economy Monitor................... 4-77 Fuel Economy Monito r...............4-77
Drive Selection................................. 4-79 Drive Selection........................... 4-79
*Some models.4-1
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

Fog Lights*
The fog lights can be turned on with the
ignition switched ON and the headlights
turned on.
Use this switch to turn on the fog lights.
The fog lights will i mprove visibility at
night and during foggy conditions.
The fog lights turn on when the fog light
switch is tu rned to the
position and turn
off when the switch is turned to the
position.
Fo g light switch
NOTE
•The fog lights will turn off when the
headlights are set at high beams.
Turn and Lane-Change
Signals
The ignition must be switched ON to use
the turn and lane-change signals.
▼Tu r n S i g n a l s
Move the signal lever down (for a left
turn) or up (for a right turn) to the stop
position. The signal will self-cancel after
the turn is completed.

If the indicator light continues to flash
after a turn, ma
nually return th e lever to its
original position.
Right turn
Left turn
Right lane change
Left lane change OFF
The turn signal indicators in the
instrument cluster
flash according to the
operation of the turn signal lever to show
which signal is working.

NOTE
•If an indicator light stays on without
flashing or if it flashes abnormally, one
of the turn signal bulbs may be burned
out.
•A personalized function is available to
change the turn indicator sound volume.
(page 9-11)
When Driving
Switches and Controls
4-54*Some models.
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

Rear Window Wiper andWa s h e r
The ignition must be switched ON to use
the wiper.
▼Rear Window Wiper
Turn the wiper on by turning the rear
wiper/washer switch.
Switch Posi-
tion Wiper operation
Stop
Intermittent
Normal
▼
Rear Window Washer
To spray washer fluid, turn the rear wiper/
washer switch to either of the
position.
After the switch is released, the washer
will stop.
If the washer does not work, inspect the
fluid level (pa ge 6-29). If the fluid level
is normal and the washer still does not
work, consult an Authorized Mazda
Dealer.
Rear Window Defogger
The rear window defogger clears fog from
the rear window.

The ignition must be switched ON to use
the defogger.

Press the switch to turn on the rear
window defogger. The rear window
defogger operates for about 15 minutes
and then turns off automatically.
The indicator light illuminates when the
defogger is operating.

To turn off the rear window defogger
before the 15 minutes has elapsed, press
the switch again.
Indicator light
CAUTION
 Do not use sharp instruments or window
cleaners with abrasives to clean the
inside of the rear window surface. They
may damage the defogger grid inside the
window.
When Driving
Switches and Controls
4-59
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

NOTE
•This defogger is not designed for
melting snow. If there is an
accumulation of snow on the rear
window, remove it before using the
defogger.
▼Mirror Defogger*
The mirror defoggers defrost the outside
mirrors.

The mirror defoggers operate in
conjunction with the rear window
defogger.
To turn on the mirror defoggers, switch the
ignition ON and press the rear window
defogger switch (page 4-59).
Indicator light
▼
Windshield Wiper De-icer*
The thermal filaments at the following
positions heat up and facilitate the removal
of snow accumulated on the windshield.
The windshield
wiper de-icer operates in
conjunction with the rear window
defogger.
To turn on the windshield wiper de-icer,
switch the ignition ON and press the rear
window defogger switch (page 4-59).
Indicator light
When Driving
Switches and Controls
4-60*Some models.
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

NOTE
The timing in which the system switches the headlights changes under the following
conditions. If the system does not switch the headlights appropriately, manually switch
between high and low beams according to the visibility as well as road and traffic
conditions.
•When there are sources of light in the area such as street lamps, illuminated signboards,
and traffic signals.
•When there are reflective objects in the surrounding area such as reflective plates and
signs.
•When visibility is reduced under rain, snow and foggy conditions.
•When driving on roads with sharp turn or hilly terrain.
•When the headlights/rear lamps of vehicles in front of you or in the opposite lane are dim
or not illuminated.
•When there is sufficient darkness such as at dawn or dusk.
•When the luggage compartment is loaded with heavy objects or the rear passenger seats
are occupied.
•When visibility is reduced due to a vehicle in front of you spraying water from its tires
onto your windshield.
When Driving
i-ACTIVSENSE
4-89
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

•When there is a difference in the height between your driving lane and the adjacent
lane.
•Directly after the BSM system becomes operable by changing the setting.
•If the road width is extremely narrow, vehicles two lanes over may be detected. The
detection area of the radar sensors (rear) is set according to the road width of
expressways.
•The BSM warning indicator light may turn on and the vehicle detection screen may be
displayed in the display in reaction to stationary objects (guardrails, tunnels, sidewalls,
and parked vehicles) on the road or the roadside.
Objects such as guardrails and concrete walls
running alongside the vehicle. Places where the width between guardrails or
walls on each side of the vehicle narrows.
The walls at the entrance and exits of tunnels,
turnouts.
•A BSM warning indicator light may flash or the warning beep may be activated several
times when making a turn at a city intersection.
•Turn off the BSM while pulling a trailer or wh
ile an accessory such as a bicycle carrier is
installed to the rear of the vehicle. Otherwise, the radar’s radio waves will be blocked
causing the system to not operate normally.
•In the following cases, it may be difficult to view the illumination/flashing of the BSM
warning indicator lights equipped on the door mirrors.
•Snow or ice is adhering to the door mirrors.
•The front door glass is fogged or covered in snow, frost or dirt.
•The radar sensors (rear) of the BSM may be regulated under the radio wave related laws
of the country where the vehicle is driven. The sensors in this system are approved for use
in the U.S.A. (including territories), Canada, and Mexico. If a vehicle with a BSM is
driven in a country other than the U.S.A., Canada, or Mexico, the system has to be turned
off by changing the setting on the center display.
•The system switches to the Rear Cross Traffic Alert (RCTA) function when the selector
lever is shifted to the reverse (R) position.
Refer to Rear Cross Traffic Alert (RCTA) on page 4-107.
When Driving
i-ACTIVSENSE
4-93
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

Function for cancelling illumination dimmer
If the BSM warning indicator lights turn on when the parking lights are turned on, the
brightness of the BSM warning indicator lights is dimmed.
If the BSM warning indicator light s are difficult to see due to glare from surrounding
brightness when traveling on snow-covered roads or under foggy conditions, press the
dimmer cancellation button to cancel the dimmer and increase th e brightness of BSM
warning indicator light s when they turn on.
Refer to Dashboard Illumination on page 4-16.
Display indicato r (Vehicles with multi-i nformation display and active driving display)
The detected approaching vehicle and warning are displayed in t he multi-information
display and active driving display when the vehicle is moving f orward (BSM operational).
Multi-information DisplayActive Driving Display
Detection and warning indicator Detection and warning indicator
The detected direction is displayed with a detection indicator (white) when an approaching
vehicle is detected. In addition, if the turn signal lever is operated to signal a lane change
while the vehicle is detected, the display changes the color (a mber) of the warning indicator.
When Driving
i-ACTIVSENSE
4-95
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

NOTE
•The TSR does not operate if there is a malfunction in the Forward Sensing Camera (FSC).
•Under the following conditions, the TSR may not operate normally.
•An object placed on the dashboard is reflected in the windshield and picked up by the
camera.
•Heavy luggage is loaded in the luggage compartment or on the rear seat and the
vehicle is tilted.
•The tire pressures are not adjusted to the specified pressure.
•Tires other than standard tires are equipped.
•The vehicle is driven on the ramp and surrounding area to or from a rest area or a
tollgate on a highway.
•When surrounding brightness suddenly changes such as when entering or exiting a
tunnel.
•The illumination of the headlights is weakened because of dirt or the optical axis is
deviated.
•The windshield is dirty or foggy.
•The windshield and camera are fogged (water droplets).
•Strong light is directed at the front of the vehicle (such as backlight or high-beam
headlights of on-coming vehicles).
•The vehicle is making a sharp turn.
•Strong light reflects off the road.
•A traffic sign is in a position which makes it difficult to reflect the light from the
vehicle's headlights, such as when the vehicle is driven at night or in a tunnel.
•The vehicle is driven under weather conditions such as rain, fog, or snow.
•The stored map data for the navigation system is not current.
•A traffic sign is obscured by mud or snow.
•A traffic sign is concealed by trees or a vehicle.
•A traffic sign is partially shaded.
•A traffic sign is bent or warped.
•A traffic sign is too low or too high.
•A traffic sign is too bright or too dark (including electronic traffic signs).
•A traffic sign is too big or too small.
•There is an object similar to the traffic sign being read (such as another traffic sign or
other signs resembling it).
•The TSR does not operate if the active driving display is set to non-display.
•The TSR can be set to inoperable.
Refer to Personalization Features on page 9-11.
When Driving
i-ACTIVSENSE
4-99
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38
