2018 LEXUS RCF key

375
Maintenance and care
6
RC350_RC300 AWD_RC3 00_RC F_U(OM24748U) 6-1. Maintenance and care
Cleaning and protecting
the vehicle exterior ................ 376
Cleaning and protecting
the vehicle interior................... 381
6-2. Maintenance
Maintenance
requirements ............................384
General maintenance.............. 387
Emission inspection and
maintenance (I/M)
programs ....................................390
6-3. Do-it-yourself
maintenance
Do-it-yourself service
precautions................................. 391
Hood ............................................... 393
Positioning a floor jack ............ 394
Engine compartment ............... 397
Tires ...................................................412
Tire inflation pressure............... 420
Wheels ........................................... 423
Air conditioning filter ............... 425
Electronic key battery .............. 427
Checking and replacing
fuses .............................................. 429
Light bulbs..................................... 432

376
RC350_RC300 AWD_RC3 00_RC F_U(OM24748U)6-1. Maintenance and care
●
Working from top to bott om, liberally apply water to the vehicle body, wheel
wells and underside of the vehicl e to remove any dirt and dust.●
Wash the vehicle body using a sponge or soft cloth, such as a chamois. ●
For hard-to-remove marks, use car wa sh soap and rins e thoroughly with
water. ●
Wipe away any water. ●
Wax the vehicle when the waterproof coating deteriorates. If water does not bead on a clean surface, apply wax when the vehicle body is cool.■
CFRP (Carbon Fiber Reinforced Plastic) part (if equipped)●
As the CFRP parts may change color if th ey are exposed to ultraviolet rays for
extended periods of time, Lexus recommends that your vehicle be stored in a place
where it will not be exposed to direct sunlight. ●
Do not use wax that contains abrasives. ■
Black stainless steel window moldings (vehicles with matte black painted wheels)
■
Self-restoring coat
*The vehicle body has a self-restoring coating that is resistant to small surface scratches
caused in a car wash etc. ●
The coating lasts for 5 to 8 years from when the vehicle is delivered from the plant. ●
The restoration time differs depending on the depth of the scratch and outside tem-
perature.
The restoration time may become shorter when the coating is warmed by applying
warm water. ●
Deep scratches caused by keys, coins, etc. cannot be restored. ●
Do not use wax that contains abrasives.
* : CFRP parts (if equipped) do not have a self-restoring coat.Cleaning and protect ing the vehicle exteriorPerform the following to protect the ve hicle and maintain it in prime condi-
tion:
The stainless steel window moldings are made
of black oxide coated stainless steel.
When cleaning the vehicle, do not scrub the
moldings with an abrasive cleaner as their finish
may be damaged or the color may change.

3776-1. Maintenance and care
6
Maintenance and care
RC350_RC300 AWD_RC3 00_RC F_U(OM24748U)■
Automatic car washes (vehicles without CFRP parts) ●
Fold the mirrors before washing the vehicle. Start washing from the front of the vehicle.
Make sure to extend the mirrors before driving. ●
RC F: Wash the vehicle with the active rear wing retracted. If the vehicle is washed with
the active rear wing raised, depending on the type of automatic car wash, the brushes
of the automatic car wash may become stuck on the active rear wing. In this case, the
active rear wing may not be washed very well or may even be scratched or damaged.●
Brushes used in automatic car washes may scratch the vehicle body and damage the
paint. ■
Automatic car washes (vehicles with CFRP parts)
Do not use automatic car washes as they may scratch the CFRP parts and damage the
paint. ■
High pressure car washes ●
Do not allow the nozzles of the car wash to come within close proximity of the windows. ●
Before using the car wash, check that the fuel filler door on your vehicle is closed prop-
erly. ■
When using a car wash
If the door handle becomes wet while the electronic key is within the effective range, the
door may lock and unlock repeatedly. In that case, follow the following correction proce-
dures to wash the vehicle: ●
Place the key in a position 6 ft. (2 m) or more separate from the vehicle while the vehi-
cle is being washed. (Take care to ensure that the key is not stolen.) ●
Set the electronic key to battery-saving mo de to disable the sm art access system with
push-button start. (  P. 158)■
Aluminum wheels (vehicles without matte black painted wheels) ●
Remove any dirt immediately by using a neutral detergent. ●
Wash detergent off with water immediately after use. ●
To protect the paint from damage, make sure to observe the following precautions.
• Do not use acidic, alkaline or abrasive detergent
• Do not use hard brushes
• Do not use detergent on the wheels when they are hot, such as after driving or park-
ing in hot weather■
Aluminum wheels (vehicles with matte black painted wheels)
As matte black painted wheels require differ ent cleaning methods than conventional alu-
minum wheels. For details, consult your Lexus dealer. ●
Remove dirt using water. If the wheels are excessively dirty, use a sponge or soft cloth
dampened with a diluted neutral detergent to remove the dirt. ●
When using detergent, make sure to rinse it off with water immediately. Then use a soft
cloth to wipe off the water. ●
To prevent the matte black paint from being damaged, make sure to observe the follow-
ing precautions:
• Do not scrub or polish the whee ls using a brush or dry cloth.
• Do not use any wheel coatings or abrasive detergents.
• When using an automatic car wash, disable/do not select the wheel brush function
(if such an option is available).
• Do not use a high pressure pre ssure washer or steam cleaner.
• Do not use detergent on the wheels when they are hot, such as after driving or park-
ing in hot weather.

4096-3. Do-it-yourself maintenance
RC350_RC300 AWD_RC3 00_RC F_U(OM24748U) 6
Maintenance and care ■
Before recharging
When recharging, the battery produces hydrogen gas which is flammable and explosive.
Therefore, observe the following before recharging: ●
If recharging with the battery installed on the vehicle, be sure to disconnect the ground
cable. ●
Make sure the power switch on the charge r is off when connecting and disconnecting
the charger cables to the battery. ■
After recharging/reconnecting the battery
The engine may not start. Follow the procedure below to initialize the system.
Shift the shift lever to P.
Open and close either door.
Restart the engine. ●
Unlocking the doors using the smart access system with push-button start may not be
possible immediately after reconnecting the battery. If this happens, use the wireless
remote control or the mechanical key to lock/unlock the doors.●
Start the engine with the engine switch in ACCESSORY mode. The engine may not
start with the engine switch turned off. However, the engine will operate normally from
the second attempt. ●
The engine switch mode is recorded by the vehicle. If the battery is disconnected and
reconnected, the vehicle will return the engi ne switch mode to the status it was in
before the battery was disconnected. Make su re to turn off the engine before discon-
necting the battery. Take extra care when connecting the battery if the engine switch
mode prior to the battery being disconnected is unknown.
If the system will not start even after mult iple attempts, contact your Lexus dealer.1
2
3

4276-3. Do-it-yourself maintenance
RC350_RC300 AWD_RC3 00_RC F_U(OM24748U) 6
Maintenance and care ●
Flathead screwdriver ●
Small flathead screwdriver ●
Lithium battery CR2032
Take out the mechanical key.
Remove the cover. To prevent damage to the key, wrap the
tip of the screwd river with tape.
Remove the depleted battery. Insert a new battery with the “+” termi-
nal facing up.Electronic key battery Replace the battery with a new one if it is depleted.
You will need the following items:
Replacing the battery 1
2
3

428 6-3. Do-it-yourself maintenance
RC350_RC300 AWD_RC3 00_RC F_U(OM24748U)■
Use a CR2032 lithium battery ●
Batteries can be purc hased at your Lexus dealer, loca l electrical appliance shops or
camera stores. ●
Replace only with the same or equivalent type recommended by the manufacturer. ●
Dispose of used batteries according to local laws. ■
When the card key battery needs to be replaced (if equipped)
The battery for the card key is available only at Lexus dealers. Your Lexus dealer can
replace the battery for you. ■
If the electronic key battery is depleted
The following symptoms may occur: ●
The smart access system with push-button start and wireless remote control will not
function properly. ●
The operational rang e will be reduced.
WARNING ■
Removed battery and other parts
These parts are small and if swallowed by a child, they can cause choking. Keep away
from children. Failure to do so coul d result in death or serious injury.
NOTICE ■
For normal operation after replacing the battery
Observe the following precautions to prevent accidents: ●
Always work with dry hands.
Moisture may cause the battery to rust. ●
Do not touch or move any other co mponent inside the remote control.●
Do not bend either of the battery terminals.

441
When trouble arises
7
RC350_RC300 AWD_RC3 00_RC F_U(OM24748U) 7-1. Essential information
Emergency flashers .................. 442
If your vehicle has
to be stopped in
an emergency .......................... 443
7-2. Steps to take in
an emergency
If your vehicle needs to be
towed ........................................... 444
If you think something is
wrong ............................................ 451
Fuel pump shut off system ...... 452
If a warning light turns on
or a warning buzzer
sounds.......................................... 453
If a warning message is
displayed.....................................460
If you have a flat tire
(vehicles with a
spare tire) ...................................489
If you have a flat tire
(vehicles with
an emergency
tire puncture repair kit) ........502
If the engine will not start ......... 516
If the electronic key does
not operate properly .............. 518
If the vehicle battery is
discharged ................................. 522
If your vehicle overheats ......... 526
If the vehicle becomes
stuck ............................................. 532

4837-2. Steps to take in an emergency
RC350_RC300 AWD_RC3 00_RC F_U(OM24748U) 7
When trouble arises Interior
buzzer Exterior
buzzer Warning message Details/Actions
Con-
tinuous  The driver’s door was opened when
the shift lever was not in P and the
engine switch was not turned off.
 Shift the shift lever to P.
Con-
tinuous Con-
tinuous The driver’s door was opened and
closed while the electronic key was
not in the vehicle, the shift lever was
not in P and the engine switch was
not turned off.
 Shift the shift lever to P.
 Bring the electronic key back
into the vehicle.
Once  The electronic key is not detected
when an attempt is made to start the
engine.
 Start the engine with the elec-
tronic key present. (Flashes)
(Displayed alternately)
(Flashes)
