2018 LEXUS RCF remote start

428 6-3. Do-it-yourself maintenance
RC350_RC300 AWD_RC3 00_RC F_U(OM24748U)■
Use a CR2032 lithium battery ●
Batteries can be purc hased at your Lexus dealer, loca l electrical appliance shops or
camera stores. ●
Replace only with the same or equivalent type recommended by the manufacturer. ●
Dispose of used batteries according to local laws. ■
When the card key battery needs to be replaced (if equipped)
The battery for the card key is available only at Lexus dealers. Your Lexus dealer can
replace the battery for you. ■
If the electronic key battery is depleted
The following symptoms may occur: ●
The smart access system with push-button start and wireless remote control will not
function properly. ●
The operational rang e will be reduced.
WARNING ■
Removed battery and other parts
These parts are small and if swallowed by a child, they can cause choking. Keep away
from children. Failure to do so coul d result in death or serious injury.
NOTICE ■
For normal operation after replacing the battery
Observe the following precautions to prevent accidents: ●
Always work with dry hands.
Moisture may cause the battery to rust. ●
Do not touch or move any other co mponent inside the remote control.●
Do not bend either of the battery terminals.

518 7-2. Steps to take in an emergency
RC350_RC300 AWD_RC3 00_RC F_U(OM24748U)Use the mechanical key (  P. 141) in order to perfor m the following operations:■
Unlocking the door
Insert the mechanical key while
pulling on the driver’s door han-
dle.
Unlocking the door.
Remove the key, return the handle, and then pull the handle again.If the electronic key do es not operate properlyIf communication between the electron ic key and vehicle is interrupted (  P.
158) or the electronic key cannot be used because the battery is depleted,
the smart access system with push-butto n start and wireless remote control
cannot be used. In such cases, the doors and trunk can be opened and the
engine can be started by following the procedure below.
Locking and unlocking the doors and opening the trunk 1
2
3

524 7-2. Steps to take in an emergency
RC350_RC300 AWD_RC3 00_RC F_U(OM24748U)Start the engine of the second vehicle. Increase the engine speed slightly and
maintain at that level for approximatel y 5 minutes to recharge the battery of
your vehicle.
Open and close any of the door of your vehicle with the engine switch off.
Maintain the engine speed of the second vehicle and start the engine of your
vehicle by turning the engine switch to IGNITION ON mode.
Once the vehicle’s engine has started, remove the jumper cables in the exact
reverse order from which they were connected.
Once the engine starts, have the vehicle inspected at your Lexus dealer as soon
as possible. ■
Starting the engine when the battery is discharged
The engine cannot be started by push-starting. ■
To prevent battery discharge ●
Turn off the headlights and the audio system while the engine is off. ●
Turn off any unnecessary electrical componen ts when the vehicle is running at a low
speed for an extended period , such as in heavy traffic.■
Charging the battery
The electricity stored in the battery will disc harge gradually even when the vehicle is not
in use, due to natural discharge and the draini ng effects of certain electrical appliances. If
the vehicle is left for a long time, the battery may discharge, and the engine may be
unable to start. (The battery recharges automatically during driving.) ■
When recharging or replacing the battery ●
In some cases, it may not be possible to un lock the doors using the smart access system
with push-button start when the battery is discharged. Use the wireless remote control
or the mechanical key to lock or unlock the doors. ●
The engine may not start on the first attempt after the battery has recharged but will
start normally after the second attempt. This is not a malfunction. ●
The engine switch mode is memorized by the vehicle. When the battery is recon-
nected, the system will return to the mode it was in before the battery was discharged.
Before disconnecting the battery, turn the engine switch off.
If you are unsure what mode the engine switch was in before the battery discharged, be
especially careful when reconnecting the battery. 5
6
7
8

5718-2. Customization
RC350_RC300 AWD_RC3 00_RC F_U(OM24748U) 8
Vehicle specifications ■
Door lock (  P. 145, 151, 518)
■
Smart access system with push-button start and wireless remote control
(  P. 145, 151) Function Default setting Customized setting
Unlocking using a mechanical
key Driver’s door
unlocked in one
step, both side
doors unlocked in
two steps Both side doors
unlocked in one
step — O
Automatic door lock Shifting the shift
lever to position
other than P Off
O OVehicle speed is
approximately 12
mph (20 km/h) or
higher
Automatic door unlock Shifting the shift
lever to P Off
O O
Driver’s door is
opened
Locking/unlocking of the trunk
when both side doors are
locked/unlocked On Off — O 1 2
Function Default setting Customized setting
Operation buzzer volume 5 Off
O O
1 to 7
Operation signal (Emergency
flashers) On Off O O
Time elapsed before automatic
door lock function is activated if
door is not opened after being
unlocked 60 seconds Off
O O30 seconds
120 seconds
Open door warning buzzer On Off — O
Welcome light illumination con-
trol On Off O O 1 2

572 8-2. Customization
RC350_RC300 AWD_RC3 00_RC F_U(OM24748U)■
Smart access system with push-button start (  P. 145, 151, 156)
■
Wireless remote control (  P. 140, 145, 151)
■
Driving position memory
* (  P. 166)
* : If equipped Function Default setting Customized setting
Smart access system with push-
button start On Off — O
Smart door unlocking Driver’s door Both side doors O O
Number of consecutive door
lock operations 2 times As many as desired — O 1 2
Function Default setting Customized setting
Wireless remote control On Off — O
Unlocking operation Driver’s door
unlocked in one
step, both side
doors unlocked in
two steps Both side doors
unlocked in one
step O O
Trunk unlocking operation Press and hold
(short) One short press
— OPush twice
Press and hold
(long)
Off
Alarm (panic mode) On Off — O 1 2
Function Default setting Customized setting
Selecting the door linking driving
position memory with door
unlock operation Driver’s door Both side doors — O 1 2

5778-2. Customization
RC350_RC300 AWD_RC3 00_RC F_U(OM24748U) 8
Vehicle specifications ■
Seat belt reminder (  P. 455)■
Vehicle customization ●
When the smart access system with push-button start is off, the entry unlock function
cannot be customized. ●
When the doors remain closed after unlocking the doors and the timer activated auto-
matic door lock function activates, signals will be generated in accordance with the
operation buzzer volume and operational si gnal (Emergency flashers) function set-
tings. ●
Some settings can be changed using a switch or the Center Display. If a setting is
changed using a switch, the ch anged setting will not be refl ected on the Center Display
screen until the engine switch is turn ed off and then to IGNITION ON mode.■
When customizing usin g the Remote Touch
Stop the vehicle in a safe place, apply the parking brake, and shift the shift lever to P. Also,
to prevent battery discharge, leave the engine running while customizing the features. Function Default setting Customized setting
Vehicle speed linked seat belt
reminder buzzer On Off — O 1 2
WARNING ■
During customization
As the engine needs to be running during customization, ensure that the vehicle is
parked in a place with adequate ventilation. In a closed area such as a garage, exhaust
gases including harmful carbon monoxide (CO) may collect and enter the vehicle. This
may lead to death or a serious health hazard.
NOTICE ■
During customization
To prevent battery discharge, ensure that the engine is running while customizing fea-
tures.

614 What to do if... (Troubleshooting)
RC350_RC300 AWD_RC3 00_RC F_U(OM24748U)●
The seat belt reminder light is flashing
Are the driver and the front passe nger wearing the seat belts? (  P. 455)●
The parking brake indicator is on
Is the parking brake released? (  P. 222)
Depending on the situation, other type s of warning buzzer may also sound.
(  P. 453, 460)
●
Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. (  P. 80)
Do one of the following to de activate or stop the alarms:• Unlock the doors.
• Open the trunk using the entry function or wireless remote control.
• Turn the engine switch to ACCESSORY or IGNITION ON mode, or start the
engine.
●
Is the electronic key left inside th e vehicle or the moon roof opened?
Check the message on the multi-information display. (  P. 460)
●
When a warning light turns on or a wa rning message is displayed, refer to
P. 453, 460. A warning buzzer sounds during driving
An alarm is activated and the horn sounds
A warning buzzer sounds when leaving the vehicle
A warning light turns on or a warning message is displayed

619Alphabetical index
RC350_RC300 AWD_RC3 00_RC F_U(OM24748U)Cleaning......................................... 376, 381
Aluminum wheels .............................. 377
Exterior....................................................376
Interior ...................................................... 381
Seat belts ............................................... 382
Clock ......................................................... 355
Coat hooks..............................................358
Compass .................................................. 366
Condenser .............................................. 406
Console box ............................................ 351
Cooling system ..................................... 404
Engine overheating...........................526
Cruise control
Dynamic radar cruise control..... 268
Cup holders ............................................ 352
Current fuel consumption ....... 108, 122
Curtain shield airbags ........................... 40
Customizable features ....................... 569 Daytime running light system...........226
Defogger
Outside rear view mirrors ............338
Rear window........................................338
Windshield............................................338
Differential
Front differential .................................545
Rear differential................................... 546
Dimension ............................................... 536
Dinghy towing ....................................... 206
Display
Drive information...................... 108, 122
Dynamic radar cruise control .....268
LDA (Lane Departure Alert
with steering control) ................... 265
Multi-information display....... 103, 118
Warning message.............................460
Distance ...........................................108, 122
Do-it-yourself maintenance............... 391
Door courtesy lights
Location ................................................. 347
Door lock
Doors.........................................................145
Smart access system with
push-button start ..............................156
Wireless remote control..................140 D
