2018 LEXUS LX570 climate control

398
LX570_OM_OM60Q78U_(U) 5-2. Lexus Climate Concierge
Lexus Climate Concierge “CLIMATE CONCIERGE” switch When the switch is pressed, the indica-
tor above the switch illuminates and all
of the following systems operate in auto-
matic mode.
If any of the system is operated manually,
the indicator turns off. However, all
other functions continue to operate in
automatic mode.
■
Automatic air conditioning system ( → P. 399, 410)The temperature can be adjusted individually for the driver seat, passenger seat, and
rear seats.
When a passenger is detected in the second seat, the rear air conditioning operates
in automatic mode.■
Seat heaters and ventilators (if equipped) ( → P. 413)Heating or ventilation is automatically se lected according to the set temperature of
the air conditioning system, the outside temperature, etc.
The seat heaters and ventilators of the front passenger seat and second outboard
seats operate in automatic mode if passengers are detected.■
Heated steering wheel (if equipped) ( → P. 413)Heated steering wheel operates automatically according to the outside temperature
and cabin temperature. ■
Front air conditioning system operation
To improve air conditioning performance in th e front seat area, the air outlets on the rear
of the console box may close when there is no passenger in the second seat. ■
Rear air conditioning system operation
The rear air conditioning system may stop automatically when there is no passenger in
the second seat. ■
Seat heater/ventilator operation
When automatic mode is selected using th e seat heater/ventilator switch, passenger
detection is not performed.The seat heaters, seat ventilators and heated steering wheel are each auto-
matically controlled accord ing to the set temperature of the air conditioning
system, the outside and cabin temperat ure, etc. Lexus Climate Concierge
allows a comfortable condition to be maintained without adjusting each sys-
tem.

LX570_OM_OM60Q78U_(U) 5738-1. Specifications
8
Vehicle specifications This information has been prepared in acco rdance with regulations issued by the
National Highway Traffic Safety Administra tion of the U.S. Department of Trans-
portation.
It provides the purchasers and/or prospe ctive purchasers of Lexus vehicles with
information on uniform tire quality grading.Your Lexus dealer will help answer any ques tions you may have as you read this infor-
mation.■
DOT quality grades
All passenger vehicle tires must conform to Federal Safety Requirements in
addition to these grades. Quality grad es can be found where applicable on
the tire sidewall between tread shoulder and maximum section width. For example: Treadwear 200 Traction AA Temperature A■
Treadwear
The treadwear grade is a comparative rati ng based on the wear rate of the tire
when tested under controlled conditio ns on a specified government test
course. For example, a tire graded 150 would wear one and a half (1 - 1/2) times as well on
the government course as a tire graded 100.
The relative performance of tires depends upon the actua l conditions of their use.
Performance may differ significantly from the norm due to variations in driving
habits, service practices and difference s in road characteristics and climate.■
Traction AA, A, B, C
The traction grades, from highest to lo west, are AA, A, B and C, and they rep-
resent the tire’s ability to stop on wet pavement as measured under controlled
conditions on specified government test surfaces of asphalt and concrete. A tire marked C may have poor traction performance.
Warning: The traction grade assigned to this tire is based on braking (straight
ahead) traction tests and does not include cornering (turning) traction.Uniform Tire Quality Grading

620 Alphabetical index
LX570_OM_OM60Q78U_(U) Language (multi-information
display)...................................................590
LATCH system ........................................ 63
LDA (Lane Departure Alert) ............261
Lever
Auxiliary catch lever ......................... 472
Hood lock release lever ................. 472
Shift lever ................................................. 210
Turn signal lever ................................... 217
Wiper lever ................................ 231, 235
Lexus climate concierge ................... 398
Climate concierge switch............. 398
Lexus parking assist monitor
*Lexus Safety System+......................... 242
License plate lights................................. 221
Light switch ............................................. 221
Replacing light bulbs ....................... 508
Light
Automatic High Beam system .... 224
Engine switch light...............................417
Fog light switch ................................... 229
Headlight switch................................... 221
Illuminated entry system .................. 419
Interior lights .......................................... 418
Luggage compartment light ..........417
Personal lights ...................................... 419
Replacing light bulbs ....................... 508
Turn signal lever ................................... 217
Vanity lights ........................................... 431
Light bulbs
Replacing .............................................. 508
Lock steering column ......................... 207
Luggage cover ...................................... 428 Maintenance
Do-it-yourself maintenance ......... 470
General maintenance ..................... 466
Maintenance data............................. 558
Maintenance requirements .......... 464
Scheduled maintenance ................ 464
Malfunction indicator lamp .............. 520
Meter............................................................ 88
Indicators .................................................. 82
Instrument panel light control ........ 89
Meters ........................................................88
Multi-information display.................... 91
Warning lights.....................................520
Warning messages ..........................528
Micro dust and pollen filter .............. 405
Mirrors
Inside rear view mirror..................... 160
Outside rear view mirror
defoggers...........................................405
Outside rear view mirrors .............. 162
Vanity mirrors ....................................... 431
Moon roof .................................................168
Jam protection function....................169
Operation............................................... 168
MP3 disc
*L M

624 Alphabetical index
LX570_OM_OM60Q78U_(U) Snow tires ................................................ 382
“SOS” button.......................................... 452
Spare tire
Inflation pressure ............................... 565
Storage location .................................532
Spark plug ............................................... 562
Specifications .........................................558
Speedometer ............................................ 88
SRS airbags................................................ 38
Steering
Column lock release ........................207
Fluid.......................................................... 564
Steering wheel ........................................ 158
Adjustment ............................................. 158
Audio switches
* Meter control switches ...................... 93
Power easy access system .............. 151
Telephone switches
*Stop/tail lights
Replacing light bulbs ....................... 508
Storage feature ..................................... 420
Stuck
If the vehicle becomes stuck ....... 555
Sun visors ...................................................431
Sunshade
Roof............................................................ 169
Rear door...............................................443 Switch
Audio remote control switches
* Automatic High Beam switch ..... 225
Center differential lock/unlock
switch ...................................................304
Climate concierge switch .............398
Cruise control switch ........... 269, 281
Door lock switch.................................... 117
Driving mode select switch .......... 284
Driving position memory
switches ................................................ 152
Emergency flashers switch ............ 510
Engine switch ......................................205
Fog light switch ................................... 229
Four-wheel drive control
switch ...................................................303
Garage door opener
switches .............................................. 445
Headlight cleaner switch ............... 238
Interior light switch..............................418
Intuitive parking assist...................... 287
Ignition switch......................................205
LDA (Lane Departure Alert)....... 263
Light switches ........................................ 221
Meter control switches ...................... 93
Moon roof switches .......................... 168
Outside rear view mirror
switches ................................................ 162
Paddle shift switches.......................... 212
Personal light switch ..........................419
Power back door switch.................. 124
Power door lock switch ..................... 117
Power window switch .......................165
