2018 Lexus ES300h display

531
ES300h_OM_OM33D45U_(U)8-2. Steps to take in an emergency
8
When trouble arises
If your vehicle overheats
■If the needle of the engine coolant temperature gauge enters the red zone
Stop the vehicle in a safe place and turn off the air conditioning system, and
then stop the hybrid system.
If you see steam:
Carefully lift the hood after the steam subsides.
If you do not see steam:
Carefully lift the hood.
After the hybrid system has
cooled down sufficiently, inspect
the hoses and cooling system for
leaks.Radiator
Cooling fans
If a large amount of coolant leaks,
immediately contact your Lexus
dealer.
The coolant level is satisfactory if
it is between the “FULL” and
“LOW” lines on the reservoir.Reservoir
“FULL”
“LOW”
Radiator cap
The following may indicate that your vehicle is overheating.
●The needle of the engine coolant temperature gauge ( →P. 86) enters the
red zone or a loss of hybrid system po wer is experienced. (For example, the
vehicle speed does not increase.)
●“Hybrid System Overheated” is shown on the multi-information display.
●Steam comes out from under the hood.
Correction procedures
1
2
3
1
2
4
1
2
3
4

5338-2. Steps to take in an emergency
ES300h_OM_OM33D45U_(U)
8
When trouble arises
■If “Hybrid System Overheated” is shown on the multi-information display Stop the vehicle in a safe place.
Stop the hybrid system an d carefully lift the hood.
After the hybrid system has cooled down, inspect the hoses and radiator
core (radiator) for any leaks.
Radiator
Cooling fans
If a large amount of coolant leaks,
immediately contact your Lexus
dealer.
The coolant level is satisfactory if it is between the “FULL” and “LOW” lines
on the reservoir.
Reservoir
“FULL”
“LOW”
Add coolant if necessary.
Water can be used in an emergency
if coolant is unavailable.
Start the hybrid system and check for the multi-information display.
If the message does not disappear:
Stop the hybrid system and contact your Lexus dealer.
If the message is not displayed:
Have the vehicle inspected at the nearest Lexus dealer.
1
2
3
1
2
4
1
2
3
5
6

560
ES300h_OM_OM33D45U_(U)9-2. Customization
Customizable features
■Changing by using the Remote Touch or Lexus Display Audio controller
Vehicles with Remote Touch
Press the “MENU” button on the Remote Touch.
Select on the “Menu”
screen and select .
Various setting can be changed. Refer to the list of settings that can be
changed for details.
Vehicles with Lexus Display Audio controller
Press the “MENU” button on the Lexus Display Audio controller.
Select “Setup” on the “Menu” screen and select “Vehicle”.
Various setting can be changed. Refer to the list of settings that can be
changed for details.
■Changing by using the meter control switches
Press or of the meter control switches, select .
Press or of the meter control switches, select the item or the
desired setting, and then press .
To go back to the previous screen, press .
Your vehicle includes a variety of elec tronic features that can be personalized
to your preferences. These preferenc es can be changed by using the meter
control switches, by using Remote Touch, Lexus Display Audio controller, or
at your Lexus dealer.
Customizing vehicle features
1
2
1
2
1
2

ES300h_OM_OM33D45U_(U)
5619-2. Customization
9
Vehicle specifications
Some function settings are changed simultaneously with other functions being
customized. Contact your Lexus dealer for further details.
Settings that can be changed using th e Remote Touch or Lexus Display Audio
controller
Settings that can be changed using the meter control switches
Settings that can be changed by your Lexus dealer
Definition of symbols: O = Available, — = Not available
Customizable features
1
2
3

562
ES300h_OM_OM33D45U_(U)9-2. Customization
■Multi-information display (
→P. 91)
FunctionDefault
settingCustomized setting
Language EnglishFrench
–O–
Spanish
Units*1miles (MPG US)
miles
(MPG Imperial)
OO–km (L/100 km)
km (km/L)
EV indicator On Off
–O–
switch settingsDrive
information 1Desired status screen
*2–O–
Drive information screen dis-
played on the first screen of

(Drive information 1)Current fuel
consumption
*3–O–Average fuel economy
(after reset)
Drive information screen dis-
played on the second screen
of
(Drive information 2)Distance (range)
*3–O–Average speed
(after reset)
Drive information screen dis-
played on the third screen of

(Drive information 3)Average fuel economy
(after refuel)
*3–O–
Elapsed time (after start)
Pop-up displayOnOff–O–
Accent colorColor 1Color 2OO–
Changeover to tachometer
when sport mode is selected AutoHybrid system
indicator
(always) –O–
Tachometer (always)
123

ES300h_OM_OM33D45U_(U)
5639-2. Customization
9
Vehicle specifications
*1: The default setting varies according to countries.
*2: Some status screens cannot be registered (indicated on the multi-information display)
*3: 2 of the following items: current fuel consumption, average fuel economy (after reset),
average fuel economy (after refuel), average fuel economy (after start), average vehi-
cle speed (after reset), average vehicle spee d (after start), distance (driving range),
distance (after start), elapsed time (after reset), elapsed time (after start), blank
■LDA (Lane Departure Alert with steering control) ( →P. 216)
■PCS (Pre-Collision System) ( →P. 205)
■AFS (Adaptive Front-lighting System) (if equipped) ( →P. 183)
FunctionDefault
settingCustomized setting
Steering AssistOnOff—O—
Alert means
(Steering
vibration)
(Buzzer)—O—
Alert sensitivityStandardHigh—O—
Vehicle sway warningOnOff—O—
Vehicle sway warning sensi-
tivityStandardLow—O—High
123
FunctionDefault settingCustomized setting
PCS (Pre-Collision System)OnOff—O—
Alert timing
(Middle)

(Far)
—O—

(Near)
123
FunctionDefault settingCustomized setting
AFS (Adaptive Front-lighting
System)OnOff—O—
123

568
ES300h_OM_OM33D45U_(U)9-2. Customization
■Automatic light control system (
→P. 182)
■Lights ( →P. 182)
*:Except for Canada
■Intuitive parking assi st (if equipped) (→P. 237)
■Automatic air conditioning system ( →P. 384)
FunctionDefault settingCustomized
setting
Adjust the sensitivity of the
ambient light sensor0-2 to 2O—O
Adjust the time
elapsed before the headlights
automatically turn off
30 seconds
Off
O—O60 seconds
90 seconds
Welcome light illumination
controlOnOff——O
123
FunctionDefault settingCustomized setting
Daytime running lights can be
disabled*OnOffO—O
123
FunctionDefault settingCustomized setting
Detection distance of the
front/rear center sensorFarNearO—O
Alert volume can be adjusted31 to 5O—O
Display setting
(when intuitive parking assist
is operating)All sensors displayedDisplay offO—O
123
FunctionDefault settingCustomized
setting
A/C Auto switch operationOnOffO—O
Exhaust gas sensor sensitivity0-3 to 3O—O
123

570
ES300h_OM_OM33D45U_(U)9-2. Customization
■Rear sunshade (if equipped) (
→P. 408)
■Seat belt reminder ( →P. 504)
■Vehicle customization
●When the smart access system with push-button start is off, the selecting door to
unlock cannot be customized.
●When the doors remain closed after unloc king the doors and the automatic door lock
function is activated, the signals will be ge nerated in accordance with the operation
buzzers and the operation signal (emergency flashers) settings.
■When customizing using Remote Touc h or Lexus Display Audio controller
Stop the vehicle in a safe place, apply the parking brake, and shift the shift lever to P. Also,
to prevent 12-volt battery discharge, leave the hybrid system operating while customiz-
ing the features.
FunctionDefault settingCustomized setting
Reverse operationOnOff——O
Time elapsed before the
reverse operation feature
activates
0.7 seconds
0 second
——O0.9 seconds
1.2 seconds
123
FunctionDefaultsettingCustomized setting
Vehicle speed linked seat belt
reminder buzzerOnOff——O
123
WARNING
■During customization
As the hybrid system needs to be operating during customization, ensure that the vehi-
cle is parked in a place with adequate ventil ation. In a closed area such as a garage,
exhaust gases including harmful carbon mo noxide (CO) may collect and enter the
vehicle. This may lead to death or a serious health hazard.
NOTICE
■During customization
To prevent 12-volt battery discharge, ensure that the hybrid system is operating while
customizing features.
