2018 KIA K900 engine coolant

Maintenance
7
7-37
Changing the coolant
Have coolant changed by an author-
ized K900 Kia dealer according to
the Maintenance Schedule at the
beginning of this section.
Put a thick cloth around the radiator
cap before refilling the coolant in
order to prevent the coolant from
overflowing into engine parts such as
the generator.
Radiator cap
Do not remove the radiator cap
when the engine and radiator
are hot. Scalding hot coolant
and steam may blow out under
pressure causing serious injury.
WARNING
KH USA 7:2018 4/14/2017 6:37 PM Page 37

Maintenance
7
7-105
Canister
Fuel vapors generated inside the fuel
tank are absorbed and stored in the
onboard canister. When the engine is
running, the fuel vapors absorbed in
the canister are drawn into the
engine intake manifold through the
purge control solenoid valve.
Purge Control Solenoid Valve(PCSV)
The purge control solenoid valve is
controlled by the Engine Control
Module (ECM); when the engine
coolant temperature is low during
idling, the PCSV closes so that evap-
orated fuel is not taken into the
engine. After the engine warms-up
during ordinary driving, the PCSV
opens to introduce evaporated fuel to
the engine.
3. Exhaust emission control system
The Exhaust Emission Control
System is a highly effective system
which controls exhaust emissions
while maintaining good vehicle per-
formance.
Vehicle modifications
This vehicle should not be modi-
fied. Modification of your vehicle
could affect its performance, safety
or durability and may even violate
governmental safety and emis-
sions regulations.
In addition, damage or perform-
ance problems resulting from any
modification may not be covered
under warranty.
Use of unauthorized electric devices may cause: Abnormal
vehicle operation, Wire damage,
Battery discharge, Fire.
Be careful not to damage your
vehicle by use of unauthorized
electric devices.
Engine exhaust gas precautions
(carbon monoxide)
Carbon monoxide can be present with other exhaust fumes.
Therefore, if you smell exhaust
fumes of any kind inside your vehi-
cle, have it inspected and repaired
immediately. If you ever suspect
exhaust fumes are coming into
your vehicle, drive it only with all
the windows fully open. Have your
vehicle checked and repaired
immediately.
KH USA 7:2018 4/14/2017 6:41 PM Page 105

Specifications, Consumer information and Reporting safety defects
8
8-7
*1Refer to the recommended SAE viscosity numbers on the next page.
*
2Engine oils labeled Energy Conserving Oil are now available. Along with other additional benefits, they contribute
to fuel economy by reducing the amount of fuel necessary to overcome engine friction. Often, these improvements
are difficult to measure in everyday driving, but in a year’s time, they can offer significant cost and energy savings.
*
3If the ACEA A5 engine oil is not available in your country, you are able to use API service SL, ILSAC GF-3, ACEA
A3.
LubricantVolumeClassification
Coolant 3.8L9.1 US qt. (8.6 l)Mixture of antifreeze and water
(Ethylene glycol base coolant for aluminum radiator)
5.0L11.4 US qt. (10.8 l)
Brake fluid0.7~0.8 US qt. (0.7~0.8 l)DOT-3 or DOT-4
Rear differential oil1.48 US qt. (1.4 l)Hypoid gear oil MS 517-15, SAE 75W/85
Fuel19.81 US gal. (75 l)Refer to “Fuel requirements” in section 1
KH USA 8:2018 4/14/2017 6:44 PM Page 7

Battery........................................................................\
....7-49
Battery replacement (for smart key) ................................4-9
Battery saver function ..................................................4-129
Before driving ..................................................................5-4
Blind Spot Detection System(BSD) ..............................5-86BSD (Blind Spot Detection) /LCA (Lane Change Assist) .....................................5-87
RCTA (Rear cross traffic alert) .................................5-90
Bluetooth
®Wireless Technology hands-free ...............4-182
Brake system..................................................................5-27 Autonomous emergency braking (AEB)...................5-49
Anti-lock brake system (ABS) ..................................5-41
Auto Hold ..................................................................5-37
Electric parking brake (EPB) ....................................5-31
Electronic stability control (ESC) .............................5-43
Hill-start assist control (HAC) ..................................5-47
Power brakes .............................................................5-27
Brakes fluid....................................................................7-38\
Bulb replacement ...........................................................7-89
Bulb wattage ....................................................................8-3
Button start/stop, see engine start/stop button .................5-6
Camera see the Rear-Camera Display .........................4-122
Capacities (Lubricants) ....................................................8-6
Care Exterior care ..............................................................7-96 Interior care .............................................................7-102
Tire care.....................................................................7-5\
4
Center console storage .................................................4-164
Central door lock switch................................................4-19
Certification label ........................................................5-108
Chains - Tire ................................................................5-101
Checking tire inflation pressure.....................................7-55
Child restraint system ....................................................3-32 Lower anchor system ................................................3-37
Seat belt .....................................................................3-3\
3
Child-protector rear door lock .......................................4-20
Climate control additional features .............................4-163 Cluster ionizer .........................................................4-163
Smart ventilation .....................................................4-163
Climate control air filter ................................................7-44
Clock ........................................................................\
....4-174
Clothes hanger .............................................................4-175
Combined instrument, see instrument cluster ...............4-67
Compact spare tire .........................................................6-24
Compact spare tire replacement ....................................7-59
Consumer assistance(U.S. only) ....................................8-11
Coolant ........................................................................\
...7-34
Cooling fluid, see engine coolant ..................................7-34
Crankcase emission control system .............................7-102
Cruise control system ....................................................5-62 To set cruise control speed ........................................5-63
Cup holder ...................................................................4-168\
Curtain air bag ...............................................................3-56
Index
I-3
I
C
KH USA Index:2018 4/18/2017 10:39 AM Page 3

Dashboard illumination, see instrument panelillumination ...............................................................4-68
Dashboard, see instrument cluster .................................4-67
Daytime running light .................................................4-130
Defogging (Windshield) ..............................................4-158
Defogging logic ...........................................................4-159
Defroster ......................................................................4-\
143 Outside rearview mirror defroster ..........................4-143
Rear window defroster ............................................4-143
Wiper deicer ............................................................4-143
Defrosting (Windshield) ..............................................4-158
Dimensions ......................................................................8-\
2
Display illumination, see instrument panel illumination ....4-68
Displays, see instrument cluster ....................................4-67
Door courtesy lamp .....................................................4-141
Door locks......................................................................4-\
16 Auto door lock/unlock feature ..................................4-19
Central door lock switch ...........................................4-18
Child-protector rear door lock ..................................4-20
Impact sensing door unlock system ..........................4-19
Power Door Latch .....................................................4-17
Rear door lock button................................................4-18
DRIVE mode .................................................................5-54 Conditions that limit active ECO MODE .................5-55
DRIVE MODE indicator screen ...............................5-58
ECO MODE driving .................................................5-55 Drive mode integrated control system ...........................5-54
DRIVE mode / SNOW mode ....................................5-54
Driver Information System (DIS) ................................4-180
Driver position memory system.......................................3-8
Driver's and passenger's front air bag ............................3-52
Driving at night ..............................................................5-97
Driving in flooded areas ................................................5-98
Driving in the rain..........................................................5-98
Driving off-road .............................................................5-99
Economical operation ....................................................5-94
Electric chromic mirror (ECM) .....................................4-48
Electric parking brake (EPB).........................................5-31
Electrical equipment(U.S. only) ....................................8-14
Electronic stability control (ESC) .................................5-43
Emergency starting ..........................................................6-5 Jump starting ...............................................................6-5
Emergency while driving .................................................6-3
Emission control system ..............................................7-104 Crankcase emission control system ........................7-104
Evaporative emission control System .....................7-104
Exhaust emission control system ............................7-105
Engine ........................................................................\
......8-2
Engine compartment ........................................................2-7
Engine coolant ...............................................................7-34
Engine Coolant Temperature guage ..............................4-70
I-4
Index
E
D
KH USA Index:2018 4/18/2017 10:39 AM Page 4
