2018 INFINITI QX60 key

1. Drive belt automatic tensioner pulley
2. Generator pulley
3. Air conditioner compressor pulley
4 Crankshaft pulley
WARNING
Be sure the ignition key is in the OFF or
LOCK position before servicing drive belt.
The engine could rotate unexpectedly.1. Visually inspect the belt for signs of un- usual wear, cuts, fraying or looseness. If
the belt is in poor condition or is loose,
have it replaced or adjusted. It is recom-
mended that you visit an INFINITI re-
tailer for this service. 2. Have the belt checked regularly for con-
dition and tension in accordance with
the maintenance schedule found in your
"Maintenance and schedules" section of
this manual.
REPLACING SPARK PLUGS
Iridium-tipped spark plugs
It is not necessary to replace iridium-tipped
Aspark plugs as frequently as conventional
type spark plugs because they last much lon-
ger. Follow the maintenance log shown in the
"Maintenance and schedules" section of this
manual. Do not service iridium-tipped spark
plugs by cleaning or regapping.
∙ Always replace spark plugs with recom-
mended or equivalent ones.
LDI2099SDI1895
DRIVE BELT SPARK PLUGS
Do-it-yourself8-15

CAUTION
Be careful not to allow children to swallow
the battery or removed parts.
INFINITI INTELLIGENT KEY
Replace the battery in the Intelligent Key as
follows:1. Remove the mechanical key from the In- telligent Key.
2. Insert a small flathead screwdriver
A
into the slitBof the corner and twist it
to separate the upper part from the
lower part. Place a cloth over the screw-
driver to protect the casing.
LDI2001
BATTERY REPLACEMENT
8-22Do-it-yourself

CHASSIS & BODY
MAINTENANCE
Abbreviations: I = Inspect and correct or replace as necessary, R = Replace,
MAINTENANCE OPERATION
Perform at number of miles, kilometers or months, whichever comes first. miles x 1,000
(km x 1,000) Months MAINTENANCE INTERVAL
5
(8) 6 10
(16) 12 15
(24) 18 20
(32) 24 25
(40) 30 30
(48) 36 35
(56) 42 40
(64) 48 45
(72) 54 50
(80) 60 55
(88) 66 60
(96) 72
Brake lines & cables II I II I
Brake pads & rotors II I II I
Brake fluid RRR
CVT fluid See NOTE (1)II I II I
Transfer fluid & differential gear oil See NOTE (2)II I II I
Steering gear and linkage, axle and suspension parts III
Tire rotation See NOTE (3)
Propeller shaft (AWD models) & drive shaft boots II I II I
Exhaust system III
In-cabin microfilter RRRR
Intelligent Key battery RRRR
9-10Maintenance and schedules

MAINTENANCE OPERATION
Perform at number of miles, kilometers or months, whichever comes first. miles x 1,000
(km x 1,000) Months MAINTENANCE INTERVAL
65
(104) 78 70
(112) 84 75
(120) 90 80
(128) 96 85
(136) 102 90
(144) 108 95
(152) 114 100
(160) 120 105
(168) 126 110
(176) 132 115
(184) 138 120
(192) 144
Brake lines and cables IIIIII
Brake pads and rotors IIIIII
Brake fluid RRR
CVT fluid See NOTE (1)IIIIII
Transfer fluid & differential gear oil See NOTE (2)IIIIII
Steering gear and linkage, axle and suspension
parts III
Tire rotation See NOTE (3)
Propeller shaft (AWD models) & drive shaft
boots IIIIII
Exhaust system III
In-cabin microfilter RRRR
Intelligent Key battery RRRR
NOTE:
Maintenance items with “” should be performed more frequently according to “Maintenance under severe driving conditions”.
(1) If towing a trailer, using a camper or a car-top carrier or driving on rough or muddy roads, inspect CVT fluid deterioration every
60,000 miles (96,000 km), then change CVT fluid if necessary. And if the inspection is not performed, change (not just inspect) CVT fluid
every 60,000 miles (96,000 km). It is recommended that you visit an INFINITI retailer for this service.
(2) If towing a trailer, using a camper or a car-top, or driving on rough or muddy roads, change (not just inspect) oil at every 20,000 miles
(32,000 km) or 24 months.
(3) For additional information on tire rotation, refer to “General maintenance” in this section.
Maintenance and schedules9-11

11 Index
2nd row bench seat adjustment....1-5,1-8
A
Air bag (See supplemental restraint
system).....................1-50
Air bag system Front (See supplemental front impact air
bag system) ................1-57
Air bag warning labels ............1-68
Airbagwarninglight.........1-68,2-13
Air bag warning light,
supplemental ..............1-68,2-13
Air cleaner ...................8-16
Air cleaner housing filter ...........8-16
Air conditioner Air conditioner operation ........4-35
Air conditioner specification label . .10-12
Air conditioner system refrigerant and
oil recommendations ...........10-7
Heater and air conditioner (automatic)
(if so equipped) ..............4-34
Heater and air conditioner controls . .4-35
Servicing air conditioner .........4-43
Alarm system
(See vehicle security system) ........2-32
All-Wheel Drive ...............5-130
Anchor point locations ............1-33
Antenna ....................4-44
Antifreeze ..................5-144
Anti-lock brake warning light .........2-9
Anti-lock Braking System (ABS) .....5-135Armrests.....................1-8
Around View® Monitor
...........4-11
Audible reminders ...............2-15
Autolight switch ...............2-41
Automatic Automatic drive positioner . . .3-39, 3-41
Automatic power window switch . . .2-66
Automatic anti-glare inside mirror .....3-36
Automatic door locks .............3-6
Automatic drive positioner .....3-39,3-41
AWD.....................5-130
B
Backup Collision Intervention (BCI) ....5-59
Battery................5- 144, 8-12
Charge warning light ...........2-10
Battery replacement .............8-22
INFINITI Intelligent Key .........8-22
Keyfob...................8-22
Before starting the engine ..........5-17
Belt (See drive belt) ..............8-15
Blind Spot Intervention (BSI) system . . .5-47
Blind Spot Warning (BSW) .........5-38
Block heater Engine ..................5-145
Boosterseats.................1-47
Brake Anti-lock Braking System (ABS) . . .5-135
Brakefluid.................8-10
Brakelight(Seestoplight) .......8-25
Brake system ..............5-134 Brakewarninglight ............2-9
Brake wear indicators
......2-15,8-19
Parking brake operation .........5-23
Self-adjusting brakes ..........8-19
Brakeassist .................5-136
Brakefluid...................8-10
Brakes .....................8-19
Brake system ................5-134
Break-in schedule ..............5-128
Brightness control Instrument panel .............2-45
Bulb check/instrument panel .........2-8
Bulb replacement ............... 8-25
C
C

apacities and recommended
fuel/lubricants ................10-2
Cargoareastoragebin ...........2-62
Cargolight................... 2-73
Cargo
(See vehicle loading information) .....10-13
Car phone or CB radio ............4-44
Check tire pressure ..............2-28
Child restraints .....1-26,1-26,1 -28, 1-30
LATCH (Lower Anchors and Tethers for
CHildren) System .............1-30
Precautions on child
restraints .......1-29,1-36,1 -42, 1-47
Top tether strap anchor point
locations..................1-33
Child restraint with top tether strap . . . .1-33

Frontseats....................1-2
FuelCapacities and recommended
fuel/lubricants...............10-2
Fuel economy ...............5-130
Fuel-filler door and cap ..........3-31
Fuel gauge ..................2-7
Fueloctanerating.............10-5
Fuel recommendation ...........10-3
Loose fuel cap warning ..........2-28
Fuel efficient driving tips ..........5-129
Fuel-filler door .................3-30
Fuel gauge ....................2-7
Fuses......................8-20
Fusiblelinks ..................8-20
G
Garage door opener, HomeLink® Universal
Transceiver...........2-74,2-75,2-76, 2-77, 2-77, 2-78
Gascap.....................3-31
Gauge Engine coolant temperature gauge ....2-6
Fuel gauge ..................2-7
Odometer ...................2-5
Speedometer .................2-5
Tachometer .................2-6
Trip odometer ................2-5
General maintenance ..............9-2
Glovebox....................2-59
Gloveboxlock.................2-59 H
Hazard warning flasher switch ........6-2
Headlight and turn signal switch ......2-40
Headlight control switch ...........2-40
Headlights ...................8-24
Head restraints .................1-12
Heated rear seats ...............2-48
Heated seats ..................2-47
Heated steering wheel ............2-49
Heater Heater and air conditioner (automatic)
(if so equipped) ...............4-34
Heater and air conditioner controls . . .4-35
Heater operation .............4-36
Heater and air conditioner (automatic). . .4-34
Hill start assist system ............5-139
HomeLink® Universal
Transceiver...........2-74,2-75,2-76, 2-77, 2-77, 2-78
Hood .......................3-23
Hook Luggage hook ...............2-63
Horn.......................2-46
I
Ignition switch Push-button ignition switch .......5-13
Immobilizer system ..............5-17
Important vehicle information label ....10-11
In-cabin microfilter ..............8-16
Increasing fuel economy ..........5-130 Indicator lights and audible reminders
(See warning/indicator lights and audible
reminders)
..............2-8,2-9,2-13
INFINITI Drive Mode Selector ........5-24
INFINITI Intelligent Key System .....3-2, 3-7
Infiniti InTouch™ Owner's Manual ......4-2
INFINITI Vehicle Immobilizer
System ...............2-34,3-4,5-17
Inside automatic anti-glare mirror .....3-36
Instrument brightness control ........2-45
Instrument panel .............0-6,2-2
Instrument

panel dimmer switch ......2-45
Intelligent Cruise Control (ICC) .......5-78
Intelligent Key system Key operating range ............3-8
Keyoperation ...............3-10
Mechanical key ...............3-3
Remote keyless entry operation .....3-14
Troubleshooting guide ..........3-18
Warningsignals..............3-18
Interiorlight...................2-72
ISOFIX child restraints ............1-30
J
Jump starting ..............6-11, 8-14
K
Key.........................3-2
Key fob battery replacement ........8-22
Keyless entry With Intelligent Key system
(See Intelligent Key system) .......3-14
11-3
