When the Intelligent Key battery is dis-
charged or strong radio waves are present
near the operating location, the Intelligent
Key operating range becomes narrower, and
the Intelligent Key may not function properly.
The operating range is within 31.5 in (80 cm)
from each request switch
1.
If the Intelligent Key is too close to the door
glass, handle or rear bumper, the request
switches may not function.
When the Intelligent Key is within the operat-
ing range, it is possible for anyone, even
someone who does not carry the Intelligent
Key, to push the request switch to lock/
unlock the doors.
DOOR LOCKS/UNLOCKS
PRECAUTION
•Do not touch the door handle request
switch with the Intelligent Key held in your
hand as illustrated. The close distance to
the door handle will cause the Intelligent
Key system to have difficulty recognizing
that the Intelligent Key is outside the ve-
hicle.
•To prevent the Intelligent Key from being
left inside the vehicle, make sure you carry
the Intelligent Key
INFINITI INTELLIGENT KEY
OPERATION
You can lock or unlock the doors without
taking the Intelligent Key out of your pocket
or bag.
When you carry the Intelligent Key with you,
you can lock or unlock all doors by pushing
the door handle request switch within the
range of operation.
Locking doors
1. Push the P (Park) button to engage the P
(Park) position, place the ignition switch in
the LOCK position and make sure you
carry the Intelligent Key with you.
2. Close all doors.
3. Touch any sensor surface
1or2.
WPD0375ZNPA1489
3-10Pre-driving checks and adjustments

4. All doors and the lift gate will lock.
5. The turn signals flash three times.
NOTE
•Doors do not lock by pushing the door
handle request switch while any door is
open. However, doors lock with the me-
chanical key even if any door is open.
•The driver's door and the door at which the
handle is used, must both be closed.
•The doors may not lock when the Intelli-
gent Key is in the same hand that is oper-
ating the request switch to lock the door.
Put the Intelligent Key in a purse, pocket or
your other hand.
CAUTION
•When locking the doors using the re-
quest switch, make sure to have the In-
telligent Key in your possession before
operating the request switch to prevent
the Intelligent Key from being left in the
vehicle.
•The request switch is operational only
when the Intelligent Key has been de-
tected by the Intelligent Key system.
Unlocking doors
1. Carry the Intelligent Key.
2. Touch the inner surface of the door
handle.
3. All doors and the lift gate will unlock.
4. The turn signals flash once.
CHANGING THE SETTINGS OF
THE LOCKING SYSTEM
You can change the settings of the locking
system. This means that only the driver's door
and the fuel-filler lid are unlocked when the
vehicle is unlocked. This is useful if you fre-
quently travel alone.
To change the setting:simultaneously
press theandbuttons for approxi-
mately 6 seconds.
NOTE
If the setting of the locking system is
changed within the signal range of the ve-
hicle, pressing the
andbutton will
lock or unlock the vehicle.The key now functions as follows:
To unlock the driver's door:press the
button once.
To unlock centrally:press the
button
twice.
To lock centrally:press the
button.
The Intelligent Key function is changed as
follows:
To unlock the driver's door:touch the inner
surface of the door handle on the driver's
door.
To unlock centrally:touch the inner surface
of the door handle on the front passenger
door or the rear door.
To lock centrally:touch the outer sensor sur-
face on one of the door handles
To restore the factory settings:
simultane-
ouslypress theandbutton for ap-
proximately 6 seconds.
Pre-driving checks and adjustments3-11

The bird's-eye view shows the overhead view
of the vehicle, which helps confirm the vehicle
position.
The vehicle icon
1shows the position of the
vehicle.
NOTE
The size of the vehicle icon on the bird's-eye
view may differ somewhat from the actual
vehicle.
The areas that the cameras cannot cover
2are indicated in black.
The non-viewable area
2is highlighted in
yellow for several seconds after the bird's-
eye view is displayed. It will be shown only the
first time after the ignition switch is placed in
the ON position.
When the corner of the vehicle moves closer
to an object, the corner sensor indicator
3appears.Front-side view:
Guiding lines that indicate the approximate
width and the front end of the vehicle are
displayed on the monitor.
The front-of-vehicle line
1shows the front
part of the vehicle.
The side-of-vehicle line
2shows the ap-
proximate vehicle width including the outside
mirrors.
The extensions
3of both the front1and
side
2lines are shown with a green dotted
line.
The corner sensor indicator
4will appear
when a corner of the vehicle moves closer to
an object.
DIFFERENCE BETWEEN
PREDICTED AND ACTUAL
DISTANCES
The displayed guidelines and their locations
on the ground are for approximate reference
only. Objects on uphill or downhill surfaces or
projecting objects will be actually located at
distances different from those displayed in
the monitor relative to the guidelines (refer to
illustrations). When in doubt, turn around and
view the objects as you are backing up, or
park and exit the vehicle to view the position-
ing of objects behind the vehicle.
NAA1681SAA1842Z
Left-Hand Drive (LHD) models*
Display screen, heater and air conditioner, and audio system4-15

A[Settings] key
B

MOD SYSTEM OPERATION
The MOD system will activate automatically
under the following conditions:
•When the shift lever is in the R (Reverse)
position. When the shift lever is moved to
the R (Reverse) position to activate the
Around View Monitor and MOD, the icons
and the messages may not be displayed
immediately.
•When thebutton is pressed
to switch from a different screen to the
camera view on the display.
•When vehicle speed decreases below ap-
proximately 5 MPH (8 km/h).
•When the ignition switch is placed in the
OFF position and then back to the ON
position.
NOTE
•The MOD system does not detect moving
objects in the front-side view. The MOD
icon is not displayed on the screen when in
this view.
•While the parking sensor warning tone is
sounding, the MOD system does not chime.
The MOD system operates in the following
conditions when the camera view is dis-
played:
When the shift lever is in the R (Reverse)
position and the vehicle speed is approxi-
mately 5 MPH (8 km/h ) or less, the MOD
system detects moving objects in the camera
view. The MOD system will not operate if the
lift gate is open.
When the MOD system detects moving ob-
jects near the vehicle, a chime will be heard
and a yellow frame
1will be displayed on
the monitor.
While the MOD system continues to detect
moving objects, the yellow frame continues
to be displayed.
The yellow frame
1is displayed on each
view in the rear view modes.
A blueicon is displayed in the view
where the MOD system is operative. A gray
MOD icon is displayed in the view where the
MOD system is not operative.
NAA1781
Bird's-eye view
NAA1782
Front view / rear view
Display screen, heater and air conditioner, and audio system4-25

Cruise control.......................5-46
Cruise control operations..............5-47
Intelligent Cruise Control (ICC) system
(Full speed range) (if equipped)............5-49
ICC system operation................5-50
ICC switch (cruise control lever)..........5-51
ICC system display and indicators.........5-52
Operating ICC.....................5-53
ICC Limitations....................5-56
Tips for driving with the ICC system.......5-58
System temporarily unavailable..........5-60
System maintenance.................5-62
Forward emergency braking (FEB) system
(if equipped)........................5-62
FEB system operation................5-63
Turning the FEB system on/off..........5-66
FEB system limitations................5-67
System temporarily unavailable..........5-67
System maintenance.................5-68
FCC Notice.......................5-69
Active sound enhancement...............5-69
Active sound enhancement.............5-70
Intelligent Parking Assist (IPA) (if equipped). . . .5-70
Important safety notes...............5-70
Detecting parking spaces..............5-71
Parking.........................5-73
Exiting a parking space...............5-74Canceling IPA.....................5-75
Camera Aiding Sonar (parking sensor) function
(if equipped)........................5-76
Sonar function overview...............5-77
Range of the sensors.................5-81
Sonar function OFF switch.............5-81
Sonar function settings...............5-82
Sonar function limitations..............5-82
Problems with sonar function...........5-83
System maintenance.................5-84
Break-in schedule.....................5-84
Fuel efficient driving tips................5-85
Increasing fuel economy.................5-86
Four-Wheel Drive (4WD) (if equipped)........5-86
Parking...........................5-87
Switching off the engine..............5-88
Extended parking...................5-89
Electric power steering system............5-89
Brake system........................5-90
Brake precautions..................5-90
Anti-lock Braking System (ABS)..........5-91
Vehicle Dynamic Control (VDC) system.......5-92
Traction Control System (TCS)..........5-94
Characteristics of VDC...............5-94
EBD (electronic brake force distribution). . . .5-95
Steer Control......................5-95
Hill Start Assist (HSA)..................5-95

malfunctions may occur for a variety of rea-
sons, including the installation of replace-
ment or alternate tires or wheels on the ve-
hicle that prevent the TPMS from working
properly. Always check the TPMS telltale af-
ter replacing one or more tires or wheels on
your vehicle to ensure that the replacement
or alternate tires and wheels allow the TPMS
to continue to function properly.
The vehicle's wheels have sensors fitted that
monitor the tire pressures in all four tires The
tire pressure monitor warns you if the pres-
sure drops in one or more of the tires The tire
pressure monitor only functions if the corre-
sponding sensors are fitted to all wheels.
Information on tire pressures is shown in the
vehicle information display. After a few min-
utes of driving, the current tire pressure of
each tire is shown in the [Serv.] menu of the
vehicle information display.
WARNING
•Radio waves could adversely affect
electrical medical equipment. Those who
use a pacemaker should contact their
electrical medical equipment manufac-
turer for the possible influences before
use.
•If the low tire pressure warning light il-
luminates or a tire pressure-related
warning is displayed by the vehicle in-
formation display while driving, avoid
sudden steering maneuvers or abrupt
braking, reduce vehicle speed, pull off
the road to a safe location and stop the
vehicle as soon as possible. Driving with
under-inflated tires may permanently
damage the tires and increase the likeli-
hood of tire failure. Serious vehicle dam-age could occur and may lead to an acci-
dent and could result in serious personal
injury. Check the tire pressure for all
four tires. Adjust the tire pressure to the
recommended COLD tire pressure
shown on the tire and loading informa-
tion label to turn the low tire pressure
warning light OFF. If you have a flat tire,
replace it with a replacement tire as
soon as possible.
•If a replacement wheel is fitted without
an INFINITI TPMS Sensor, the TPMS
will not function and the low tire pres-
sure warning light will flash for approxi-
mately 1 minute. The light will remain on
after 1 minute. It is recommended you
contact an INFINITI retailer as soon as
possible for tire replacement and/or
system resetting.
•For models with run-flat tires, although
you can continue driving with a punc-
tured run-flat tire, remember that ve-
hicle handling stability is reduced, which
could lead to an accident and personal
injury. Also, driving a long distance at
high speeds may damage the tires.
–Do not drive at speeds above 50
MPH (80 km/h) and do not drive
more than approximately 93 miles
(150 km) with a punctured run-flat
tire. The actual distance the vehicle
NSD660
5-4Starting and driving

can be driven on a flat tire depends on
outside temperature, vehicle load,
road conditions and other factors.
–If you detect any unusual sounds or
vibrations while driving with a punc-
tured run-flat tire, pull off the road to
a safe location and stop the vehicle as
soon as possible. The tire may be se-
riously damaged and need to be re-
placed.
•Replacing tires with those not originally
specified by INFINITI could affect the
proper operation of the TPMS.
•If you used Emergency Tire Sealant to
repair a minor tire puncture, the TPMS
sensor should be checked when repair-
ing or replacing the tire (for models
equipped with the emergency tire punc-
ture repair kit). It is recommended you
visit an INFINITI retailer for this service.
•INFINITI recommends using only
INFINITI Genuine Emergency Tire Seal-
ant provided with your vehicle. Other
tire sealants may damage the valve stem
seal which can cause the tire to lose air
pressure (for models equipped with the
emergency tire puncture repair kit).
CAUTION
•The TPMS may not function properly
when the wheels are equipped with
snow chains or the wheels are buried in
snow.
•Do not place metallized film or any metal
parts (antenna, etc.) on the windows.
This may cause poor reception of the
signals from the tire pressure sensors,
and the TPMS will not function
properly.
It is the driver's responsibility to set the tire
pressure to the recommended cold tire pres-
sure suitable for the operating situation (see
"Wheels and tires"). Note that the correct tire
pressure for the current operating situation
must first be taught-in to the tire pressure
monitor (see "Restarting TPMS" later in this
section).
If there is a substantial loss of pressure, the
warning threshold for the warning message
is aligned to the reference values taught-in.
Restart the tire pressure monitor after ad-
justing to the cold tire pressure. The current
pressures are saved as new reference values.
This will ensure that a warning message will
only appear if the tire pressure drops signifi-
cantly.The tire pressure monitor does not warn you
of an incorrectly set tire pressure.
TPMS is not able to warn you of a sudden
loss of pressure, e. g. if the tire is penetrated
by a foreign object. In the event of a sudden
loss of pressure, bring the vehicle to a halt by
braking carefully. Avoid abrupt steering ma-
neuvers.
TPMS has a yellow warning light in the com-
bination meter for indicating a pressure loss
or malfunction. Depending on how the warn-
ing light flashes or lights up, a tire pressure
that is too low or a malfunction in TPMS is
indicated:
•If the warning light is lit continuously, the
tire pressure on one or more tires is signifi-
cantly too low. TPMS is not malfunction-
ing.
•If the warning light flashes for around a
minute and then remains lit constantly, the
TPMS is malfunctioning.
In addition to the warning light, a message
appears in the vehicle information display.
Observe the information on display mes-
sages (see "Safety systems"
It may take up to ten minutes for a malfunc-
tion of the tire pressure monitor to be indi-
cated. A malfunction will be indicated by the
Starting and driving5-5
