SMALL CHILDREN
Children that are over 1 year old and weigh at
least 20 lbs (9 kg) should remain in a rear-
facing child restraint as long as possible up to
the height or weight limit of the child re-
straint. Children who outgrow the height or
weight limit of the rear-facing child restraint
and are at least 1 year old should be secured
in a forward-facing child restraint with a har-
ness. Refer to the manufacturer’s instructions
for minimum and maximum weight and
height recommendations. INFINITI recom-
mends that small children be placed in child
restraints that comply with Federal Motor
Vehicle Safety Standards or Canadian Motor
Vehicle Safety Standards. You should choose
a child restraint that fits your vehicle and
always follow the manufacturer’s instruc-
tions for installation and use.
LARGER CHILDREN
Children should remain in a forward-facing
child restraint with a harness until they reach
the maximum height or weight limit allowed
by the child restraint manufacturer.
Children who are too large for child restraints
should be seated and restrained by the seat
belts which are provided. The seat belt may
not fit properly if the child is less than 4 ft 9 in
(142.5 cm) tall and weighs between 40 lbs(18 kg) and 80 lbs (36 kg). A booster seat
should be used to obtain proper seat belt fit.
Once a child outgrows the height or weight
limit of the harness-equipped forward-facing
child restraint, INFINITI recommends that
the child be placed in a commercially available
booster seat to obtain proper seat belt fit. For
a seat belt to fit properly, the booster seat
should raise the child so that the shoulder belt
is properly positioned across the chest and
the top, middle portion of the shoulder. The
shoulder belt should not cross the neck or
face and should not fall off the shoulder. The
lap belt should lie snugly across the lower hips
or upper thighs, not the abdomen. A booster
seat can only be used in seating positions that
have a three-point type seat belt. The
booster seat should fit the vehicle seat and
have a label certifying that it complies with
Federal Motor Vehicle Safety Standards or
Canadian Motor Vehicle Safety Standards.
A booster seat should be used until the child
can pass the seat belt fit test below:
•Are the child’s back and hips against the
vehicle seatback?
•Is the child able to sit without slouching?
•Do the child’s knees bend easily over the
front edge of the seat with feet flat on the
floor?
•Can the child safely wear the seat belt
(lap belt low and snug across the hips
and shoulder belt across mid-chest and
shoulder)?
•Is the child able to use the properly ad-
justed head restraint/headrest?
•Will the child be able to stay in position for
the entire ride?
If you answered no to any of these questions,
the child should remain in a booster seat us-
ing a three-point type seat belt.
NOTE
Laws in some communities may follow dif-
ferent guidelines. Check local and state
regulations to confirm your child is using the
correct restraint system before traveling.
WARNING
Never let a child stand or kneel on any seat
and do not allow a child in the cargo area.
The child could be seriously injured or killed
in a sudden stop or collision.
1-18Safety — seats, seat belts and supplemental restraint system

If the child restraint is equipped with a top
tether strap, route the top tether strap
and secure the tether strap to the tether
anchor point. For additional information,
refer to "Installing top tether strap".
Do not install child restraints that require
the use of a top tether strap in seating
positions that do not have a top tether
anchor.
3. The back of the child restraint should be
secured against the vehicle seatback.
If necessary, adjust or remove the head
restraint/headrest to obtain the correct
child restraint fit. If the head restraint/
headrest is removed, store it in a secure
place.Be sure to reinstall the head
restraint/headrest when the child re-
straint is removed.For additional infor-
mation about head restraint/headrest
adjustment, refer to "Head restraints/
Headrests". If the seating position does
not have an adjustable head restraint/
headrest and it is interfering with the
proper child restraint fit, try another seat-
ing position or a different child restraint.4. For child restraints that are equipped with
webbing-mounted attachments, remove
any additional slack from the webbing of
the anchor attachments. Press down-
ward and rearward firmly in the center of
the child restraint with your knee to com-
press the vehicle seat cushion and seat-
back while tightening the webbing of the
anchor attachments.
5. Tighten the tether strap according to the
manufacturer's instructions to remove
any slack.6. After attaching the child restraint, test it
before you place the child in it. Push it
from side to side while holding the child
restraint near the LATCH attachment
path. The child restraint should not move
more than 1 inch (25 mm), from side to
side. Try to tug it forward and check to see
if the LATCH attachment holds the re-
straint in place. If the restraint is not se-
cure, tighten the LATCH attachment as
necessary, or put the restraint in another
seat and test it again. You may need to try
a different child restraint. Not all child re-
straints fit in all types of vehicles.
7. Check to make sure the child restraint is
properly secured prior to each use. If the
child restraint is loose, repeat steps 3
through 6.
SSS0647Z
Forward-facing — step 4
SSS0638Z
Forward-facing — step 6
1-28Safety — seats, seat belts and supplemental restraint system

Installing top tether strap
The child restraint top tether strap must be
used when installing the child restraint with
the LATCH lower anchor attachments. First,
secure the child restraint with the LATCH
lower anchors (rear outboard seating posi-
tions only).
The LATCH anchor points are provided to
install child restraints in the rear outboard
seating positions only, as shown. Do not at-
tempt to install a child restraint in the center
position using the LATCH anchors.
WARNING
Child restraint anchorages are designed to
withstand only those loads imposed by
correctly fitted child restraints. Under no
circumstances are they to be used to attachadult seat belts, or other items or equip-
ment to the vehicle. Doing so could damage
the child restraint anchorages. The child
restraint will not be properly installed us-
ing the damaged anchorage, and a child
could be seriously injured or killed in a
collision.
Outboard seating positions with removable
head restraints/headrests:
1. If necessary, raise or remove the head
restraint/headrest and store it in a secure
place. Be sure to reinstall the head
restraint/headrest when the child re-
straint is removed. For additional informa-
tion about head restraint/headrest ad-
justment, removal and installation, refer to
"Head restraints/Headrests".
2. Position the top tether strap
1over the
seatback as shown.
3. Secure the tether strap to the tether an-
chor point
2on the seatback behind the
child restraint as shown.
4.
Tighten the tether strap according to the
manufacturer's instructions to remove any
slack.
Outboard seating positions with fixed head
restraints/headrests:
1. If the child restraint has a single tether
strap, route the strap
1over the top of
the outer head restraint/headrest. If the
child restraint has two tether straps, route
them round each side of the outer head
restraint/headrest.
2. Secure the tether strap to the tether an-
chor point
2on the seatback behind the
child restraint as shown.
3. Tighten the tether strap according to the
manufacturer's instructions to remove
any slack.
If you have any questions when installing
a top tether strap, it is recommended
that you visit an INFINITI retailer for this
service.
FORWARD-FACING CHILD
RESTRAINT INSTALLATION
USING THE SEAT BELTS
WARNING
The three-point seat belt with Automatic
Locking Retractor (ALR) must be used
when installing a child restraint. Failure to
use the ALR mode will result in the child
restraint not being properly secured. The
NIC2849
Safety — seats, seat belts and supplemental restraint system1-29

restraint could tip over or be loose and
cause injury to a child in a sudden stop or
collision. Also, it can change the operation
of the front passenger air bag. For addi-
tional information, refer to "Front passen-
ger air bag and status light".
For additional information, refer to all Warn-
ings and Cautions in the "Child safety" and
"Child restraints" before installing a child re-
straint.
Do not use the lower anchors if the combined
weight of the child and the child restraint
exceeds 65 lb (29.5 kg). If the combined
weight of the child and the child restraint is
greater than 65 lb (29.5 kg), use the vehicle
seat belt (not the lower anchors) to install the
child restraint. Be sure to follow the child
restraint manufacturer's instructions for in-
stallation.
Follow these steps to install a forward-
facing child restraint using the vehicle seat
belt in the rear seats or in the front passenger
seat:1.If you must install a child restraint in the
front seat, it should be placed in a
forward-facing direction only. Move the
seat to the rearmost position. Child re-
straints for infants must be used in the
rear-facing direction and, therefore,
must not be used in the front seat.2. Position the child restraint on the seat.
Always follow the child restraint manu-
facturer's instructions. The back of the
child restraint should be secured against
the vehicle seatback. If necessary, adjust
or remove the head restraint/headrest to
obtain the correct child restraint fit. If the
head restraint/headrest is removed, store
it in a secure place.Be sure to reinstall the
head restraint/headrest when the child
restraint is removed.For additional infor-
mation about head restraint/headrest
adjustment, removal and installation, re-
fer to "Head restraints/Headrests".
If the seating position does not have an
adjustable head restraint/headrest and it
is interfering with the proper child re-
straint fit, try another seating position or a
different child restraint.
WRS0699Z
Forward-facing (front passenger seat) —
step 1
1-30Safety — seats, seat belts and supplemental restraint system

Installing top tether strap
WARNING
Child restraint anchorages are designed to
withstand only those loads imposed by
correctly fitted child restraints. Under no
circumstances are they to be used to attach
adult seat belts, or other items or equip-
ment to the vehicle. Doing so could damage
the child restraint anchorages. The child re-
straint will not be properly installed using
the damaged anchorage, and a child could
be seriously injured or killed in a collision.
The child restraint top tether strap must be
used when installing the child restraint with
seat belts.
First, secure the child restraint with the seat
belt.Outboard seating positions with removable
head restraints/headrests:
1. If necessary raise or remove the head
restraint/headrest and store it in a secure
place. Be sure to reinstall the head
restraint/headrest when the child re-
straint is removed. For additional informa-
tion about head restraint/headrest ad-
justment, removal and installation, refer to
"Head restraints/Headrests".
2. Position the top tether strap
1over the
seatback as shown.
3. Secure the tether strap to the tether an-
chor point
2on the seatback behind the
child restraint as shown.
4. Tighten the tether strap according to the
manufacturer's instructions to remove
any slack.
Outboard seating positions with fixed head
restraints/headrests:
1. If the child restraint has a single tether
strap, route the strap
1over the top of
the outer head restraint/headrest. If the
child restraint has two tether straps, route
them round each side of the outer head
restraint/headrest.
2. Secure the tether strap to the tether an-
chor point
2on the seatback behind the
child restraint as shown.
NIC2848
Rear seat - Type A
NIC2903
Rear seat - Type B
Safety — seats, seat belts and supplemental restraint system1-33

3. Tighten the tether strap according to the
manufacturer's instructions to remove
any slack.
Center seating position with adjustable
head restraint/headrest:
1. Raise the head restraint/headrest. For
additional information about head
restraint/headrest adjustment, removal
and installation, refer to "Head restraints/
Headrests".
2. Position the top tether strap
1under
the head restraint/head rest and over
the seatback, between the two head
restraint/headrest stalks as shown.
3. Secure the tether strap to the tether an-
chor point
2on the seatback behind the
child restraint as shown.
4. Tighten the tether strap according to the
manufacturer's instructions to remove
any slack.
If you have any questions when installing
a top tether strap, it is recommended
that you visit an INFINITI retailer for this
service.
BOOSTER SEATS
For additional information on installing a
booster seat in your vehicle, follow the in-
structions outlined in this section.
Precautions on booster seats
WARNING
If a booster seat and seat belt are not used
properly, the risk of a child being injured or
killed in a sudden stop or collision greatly
increases:
•Make sure the shoulder portion of the
belt is away from the child's face and
neck and the lap portion of the belt does
not cross the stomach.
•Make sure the shoulder belt is not be-
hind the child or under the child’s arm.
•A booster seat must only be installed in a
seating position that has a lap/shoulder
belt.
Booster seats of various sizes are offered
by several manufacturers. When selecting
any booster seat, keep the following points in
mind:
LRS0501Z
LRS0464Z
1-34Safety — seats, seat belts and supplemental restraint system

Follow these steps to install a booster seat in
the rear seat or in the front passenger seat:
1.If you must install a booster seat in the
front seat, move the seat to the rearmost
position.
2. Position the booster seat on the seat.
Only place it in a front-facing direction.
Always follow the booster seat manufac-
turer’s instructions.
3. The booster seat should be positioned on
the vehicle seat so that it is stable.
If necessary, adjust or remove the head
restraint to obtain the correct booster
seat fit. If the head restraint is removed,store it in a secure place.Be sure to rein-
stall the head restraint when the booster
seat is removed.
For additional information about head
restraint/headrest adjustment, removal
and installation, refer to "Head restraints/
Headrests".
If the seating position does not have an
adjustable head restraint/headrest and it
is interfering with the proper booster seat
fit, try another seating position or a differ-
ent booster seat.
4. Position the lap portion of the seat belt
low and snug on the child’s hips. Be sure to
follow the booster seat manufacturer’s
instructions for adjusting the seat belt
routing.
5. Pull the shoulder belt portion of the seat
belt toward the retractor to take up extra
slack. Be sure the shoulder belt is posi-
tioned across the top, middle portion of
the child’s shoulder. Be sure to follow the
booster seat manufacturer’s instructions
for adjusting the seat belt routing.
6. Follow the warnings, cautions and in-
structions for properly fastening a seat
belt shown in "Precautions on seat belt
usage" earlier in this section.
WRS0699ZLRS0451Z
Rear center position
LRS0452Z
Rear outboard position
1-36Safety — seats, seat belts and supplemental restraint system

You do not have to remove the start/stop
button from the ignition lock when you leave
the vehicle. You should, however, always
take the key with you when leaving the ve-
hicle. As long as the key is in the vehicle:
•The vehicle can be started using the push-
button ignition switch.
•The electrically powered equipment can be
operated.
EMERGENCY ENGINE SHUT OFF
To shut off the engine in an emergency situ-
ation while driving, perform the following
procedure:
•Rapidly push the push-button ignition
switch 3 consecutive times in less than
1.5 seconds, or
•Push and hold the push-button ignition
switch for more than 2 seconds.
•Make sure the area around the vehicle is
clear.
•Check fluid levels such as engine oil, cool-
ant, brake fluid, and windshield-washer
fluid as frequently as possible, or at least
whenever you refuel.
•Check that all windows and lights are
clean.
•Visually inspect tires for their appearance
and condition. Measure and check the tire
pressure for proper inflation.
•Check that all doors are closed.
•Position seat and adjust head restraints/
headrests.
•Adjust the inside and outside rear view
mirrors.
•Fasten your seat belt and ask all passen-
gers to do likewise.
•Check the operation of the warning lights
when the ignition switch is pushed to the
ON position.
STARTING PROCEDURE WITH
THE KEY
0OFF position
1ACC position
2ON position
3START position
1. Apply the parking brake.
2. Shift the transmission to position P (Park)
by pressing the

button.
The transmission position indicator in the
vehicle information display shows

When the transmission is in position N
(Neutral), you can also start the engine
with the brake pedal depressed.
The starter is designed not to operate if the
shift lever is in any of the driving positions.
NPA1483
BEFORE STARTING ENGINE STARTING ENGINE
5-16Starting and driving
