2018 INFINITI Q70 HYBRID fuses

8 Do-it-yourself
Maintenance precautions ................................................ 8-2
Engine compartment check locations .......................... 8-3VQ35HR engine............................................................ 8-3
Engine cooling system...................................................... 8-5 Checking engine coolant level................................... 8-6
Changing engine coolant............................................ 8-6
Inverter cooling system.................................................... 8-7 Checking inverter coolant level ................................ 8-8
Changing inverter coolant.......................................... 8-8
Engine oil.....................................................................\
......... 8-8
Checking engine oil level ............................................ 8-8
Changing engine oil and filter................................... 8-9
Automatic Transmission Fluid (ATF).......................... 8-11
Power steering fluid........................................................ 8-11
Brake fluid...................................................................\
....... 8-12 Brake fluid .................................................................... 8-12
Window washer fluid...................................................... 8-12
12-volt battery ................................................................. 8-13 Checking battery fluid level..................................... 8-14
Jump starting............................................................... 8-15
Spark plugs ........................................................................\
8-15 Replacing spark plugs................................................ 8-15 Air cleaner........................................................................\
.. 8-16
Windshield wiper blades ............................................... 8-17
Cleaning....................................................................... 8-17
Replacing..................................................................... 8-17
Brakes..................................................................\
............... 8-18 Self-adjusting brakes............................................... 8-18
Brake pad wear warning........................................ 8-18
Fuses...................................................................\
................ 8-19 Engine compartment or trunk room ................... 8-19
Passenger compartment ....................................... 8-20
Intelligent Key battery replacement........................... 8-21
Lights........................................................................\
.......... 8-23 Headlights.................................................................. 8-24
Exterior and interior lights.................................... 8-24
Wheels and tires.............................................................. 8-26 Tire pressure .............................................................. 8-26
Tire labeling............................................................... 8-30
Types of tires............................................................. 8-32
Tire chains................................................................... 8-32
Changing wheels and tires..................................... 8-33

JVM0055X
JVM0056X
ENGINE COMPARTMENT OR
TRUNK ROOM
WARNING
Never use a fuse of a higher or lower
amperage rating than that specified on
the fuse box cover. This could damage
the electrical system or electronic con-
trol units or cause a fire.
If any electrical equipment does not operate,
check for an open fuse.
1. Be sure the ignition switch is pushed to the OFF or LOCK position and the
headlight switch is turned to OFF.
2. Open the engine hood or trunk lid and to access the cover on the fuse/fusible link
holder.
3. Remove the fuse/fusible link holder cover.
4. Remove the fuse with the fuse puller.
SDI1754
5. If the fuse is open, replace it with a
new fuse. Spare fuses are stored in the
passenger compartment fuse box.
6. If a new fuse also opens, have the electrical system checked and repaired.
It is recommended you visit an INFINITI
retailer for this service.
The holder also contains the fuses. It is
recommended you visit an INFINITI retailer
for checking and/or replacing.
Fusible links
If any electrical equipment does not operate
and fuses are in good condition, check the
fusible links. If any of these fusible links are
melted, replace only with genuine INFINITI
Do-it-yourself8-19
FUSES

8-20Do-it-yourself
parts.
SDI2034
PASSENGER COMPARTMENT
CAUTION
Never use a fuse of a higher or lower
amperage rating than that specified on
the fuse box cover. This could damage
the electrical system or cause a fire.
If any electrical equipment does not operate,
check for an open fuse.
1. Be sure the ignition switch is pushed to the OFF or LOCK position and the
headlight switch is turned to OFF. 2. Open the fuse box lid.
3. Remove the fuse with the fuse puller
.
4. If the fuse is open, replace it with a new fuse.
5. If a new fuse also opens, have the electrical system checked and repaired.
It is recommended you visit an INFINITI
retailer for this service. Spare fuses are
stored in the fuse box.

EngineBefore starting the INFINITI Direct
Response Hybrid
®System .......................... 5-13
Break-in schedule ........................................ 5-116
Capacities and
recommended fluids/lubricants ................. 10-2
Changing engine coolant ............................... 8-6
Changing engine oil and filter ...................... 8-9
Checking engine coolant level ...................... 8-6
Checking engine oil level ............................... 8-8
Emergency engine shut off ......................... 5-12
Engine block heater .................................... 5-126
Engine compartment check locations ........ 8-3
Engine cooling system ................................... 8-5
Engine oil ........................................................... 8-8
Engine oil and oil
filter recommendation .................................. 10-5
Engine oil replacement indicator ............... 2-27
Engine oil viscosity ........................................ 10-6
Engine serial number .................................... 10-9
Engine specifications .................................... 10-7
If your vehicle overheats ............................. 6-12
Starting the INFINITI Direct Response
Hybrid
®System .............................................. 5-13
Engine coolant temperature gauge ................ 2-31
Entry/exit function
Automatic drive positioner ......................... 3-28
EV mode odometer and twin
trip odometer ........................................................ 2-30
Event Data Recorders (EDR) ......................... 10-19
Exhaust gas (carbon monoxide) ........................ 5-4 Explanation of scheduled
maintenance items ................................................. 9-5
F
F.M.V.S.S./C.M.V.S.S. certification label ...... 10-9
Fail-safe ................................................................. 5-16
Filter
Air cleaner housing filter ............................. 8-16
Changing engine oil and filter ...................... 8-9
Flashers (See hazard warning
flasher switch) ......................................................... 6-2
Flat tire ...................................................................... 6-3
Flat towing .......................................................... 10-16
Floor mat .................................................................. 7-6
Fluid Automatic Transmission Fluid (ATF) ....... 8-11
Brake fluid ....................................................... 8-12
Capacities and
recommended fluids/lubricants ................. 10-2
Engine coolant .................................................. 8-5
Engine oil ........................................................... 8-8
Power steering fluid ..................................... 8-11
Window washer fluid ................................... 8-12
Fog light switch ................................................... 2-43
Forward Emergency Braking (FEB) ............. 5-101
Forward Emergency Braking (FEB) system
warning light ......................................................... 2-14
Front passenger air bag and status light ..... 1-45
Front power seat adjustment ............................. 1-3
Front seat
Front seat adjustment .................................... 1-3 Front-seat active head restraints ...................... 1-8
Fuel
Capacities and
recommended fluids/lubricants ................. 10-2
Fuel economy ............................................... 5-117
Fuel information ............................................ 10-3
Fuel octane rating ......................................... 10-3
Fuel-filler cap .................................................. 3-21
Fuel-filler door ............................................... 3-21
Gauge .................................................................. 2-8
Fuel economy history .................. Hybrid System-7
Fuel efficient driving tips ................................. 5-116
Fuses ....................................................................... 8-19
Fusible links ........................................................... 8-19
G
Garage door opener HomeLink®Universal Transceiver ............ 2-62
Gas cap ................................................................... 3-21
Gauge ........................................................................\
. 2-6 Assist charge gauge ........................................ 2-8
Fuel gauge ......................................................... 2-8
Odometer ............................................................ 2-7
Speedometer ...................................................... 2-7
Tachometer ....................................................... 2-8
Trip computer ................................................. 2-28
General maintenance ................................... 9-2, 9-2
Glove box ............................................................... 2-51
11-3
