5-64
Driving your vehicle
Cruise Control Operation
1. Cruise indicator
2. SET indicator
The Cruise Control system allows
you to drive at speeds above 20 mph
(30 km/h) without depressing the
accelerator pedal.
C CR
R U
U I
IS
S E
E
C
C O
O N
NT
TR
R O
O L
L
(Continued)
- When driving in heavy trafficor when traffic conditions
make it difficult to drive at a
constant speed
- When driving on rainy, icy, or snow-covered roads
- When driving on hilly or windy roads
- When driving in windy areas
- When driving with limited view (possibly due to bad
weather such as fog, snow,
rain and sandstorm)
OAE056067N
Take the following precautions:
Always set the vehicle speed
under the speed limit.
If the Cruise Control is left on,
(cruise ( ) indicator
light in the instrument cluster
is illuminated) the Cruise
Control can be activated unin-
tentionally. Keep the Cruise
Control system off (cruise
( ) indicator light
OFF) when the Cruise Control
is not in use, to avoid inadver-
tently setting a speed.
Use the Cruise Control sys-
tem only when traveling on
open highways in good
weather.
Do not use the Cruise Control
when it may be unsafe to keep
the vehicle at a constant
speed:
(Continued)
WARNING

5-70
Driving your vehicle
Smart Cruise Control Speed
To set Smart Cruise Controlspeed
1. Push the CRUISE button on the
steering wheel to turn the system
on. The cruise ( ) indi-
cator will illuminate.
2. Accelerate to the desired speed. The Smart Cruise Control speedcan be set as follows:
when there is no vehicle in front
when there is a vehicle in front 3. Push the toggle switch down
(SET-). The Set Speed and
Vehicle-to-Vehicle Distance on the
LCD display will illuminate.
4. Release the accelerator pedal. The desired speed will automati-
cally be maintained.
If there is a vehicle in front of you, the
speed may decrease to maintain the
distance to the vehicle ahead.
On a steep grade, the vehicle may
slow down or speed up slightly while
going uphill or downhill.
(Continued)
Do not use the Smart Cruise
Control when it may not be
safe to keep the vehicle at a
constant speed:
- When driving in heavy traffic or when traffic conditions
make it difficult to drive at a
constant speed
- When driving on rainy, icy, or snow-covered roads
- When driving on a steep downhill or uphill
- When driving in windy areas
- When driving in parking lots
- When driving near crash barriers
- When driving on a sharp curve
- When driving with limited view (possibly due to bad
weather, such as fog, snow,
rain or sandstorm)
- When the vehicle sensing ability decreases due to
vehicle modification result-
ing level difference of the
vehicle's front and rear
OAE056068
OAE056069

7-73
7
Maintenance
Caring for the leather seats- Vacuum the seat periodically toremove dust and sand on the seat.
It will prevent abrasion or damage
of the leather and maintain its qual-
ity.
- Wipe the natural leather seat cover often with dry or soft cloth.
- Use of proper leather protector may prevent abrasion of the cover
and helps maintain the color. Be
sure to read the instructions and
consult a specialist when using
leather coating or protective agent.
- Light colored (beige, cream beige) leather is easily contaminated and
the stain is noticeable. Clean the
seats frequently.
- Avoid wiping with wet cloth. It may cause the surface to crack. Cleaning the leather seats
- Remove all contaminations instant-ly. Refer to instructions below for
removal of each contaminant.
- Cosmetic products (sunscreen, foundation, etc.)
Apply cleansing cream on a cloth
and wipe the contaminated spot.
Wipe off the cream with a wet cloth
and remove water with a dry cloth.
- Beverages (coffee, soft drink, etc.) Apply a small amount of neutral
detergent and wipe until contami-
nations do not smear.
- Oil Remove oil instantly with
absorbable cloth and wipe with
stain remover used only for natu-
ral leather.
- Chewing gum Harden the gum with ice and
remove gradually.Cleaning the seat belt webbing
Clean the belt webbing with any mild
soap solution recommended for
cleaning upholstery or carpet. Follow
the instructions provided with the
soap. Do not bleach or re-dye the
webbing because this may weaken
the seat belt.
Cleaning the interior windowglass
If the interior glass surfaces of the
vehicle become fogged (that is, cov-
ered with an oily, greasy or waxy
film), they should be cleaned with
glass cleaner. Follow the directions
on the glass cleaner container.
Do not scrape or scratch the
inside of the rear window. This
may result in damage to the rear
window defroster grid.
NOTICE

I-2
Air bag warning labels ....................................................2-70
Air bags ........................................................................\
...2-47Additional safety precautions .....................................2-69
Air bag collision sensors ............................................2-63
Air bag inflation conditions .......................................2-65
Air bag non-inflation conditions ................................2-66
Air bag warning labels ...............................................2-70
Curtain air bags ..........................................................2-51
Do not install a child restraint on the front passenger seat..........................................................2-62
Driver's air bag ...........................................................2-49
Driver's knee airbag....................................................2-49
How does the air bags system operate? .....................2-52
Occupant Classification System (OCS) .....................2-58
Passenger’s front air bag ............................................2-49
Side air bags ...............................................................2-50
SRS Care ....................................................................2-68\
SRS components and functions..................................2-52
SRS warning light ......................................................2-53
What to expect after an air bag inflates .....................2-57
Why didn't my air bag go off in a collision ...............2-63
Air cleaner.......................................................................7\
-24
Air conditioning refrigerant label .................................3-140
Air conditioning system specification ..............................8-6
Air conditioning system................................................3-129
Alarm system ..................................................................3-13 Antenna ........................................................................\
.....4-2
Anti-lock Brake System (ABS) ......................................5-26
Appearance care..............................................................7-67
Exterior care ...............................................................7-67
Interior care ................................................................7-71
Armrest ........................................................................\
...2-15
Audio/Video/Navigation system (AVN system)...............4-5
Auto defogging system .................................................3-143
Auto door lock/unlock features Impact sensing door unlock .......................................3-12
Shift lever auto door lock ...........................................3-12
Speed sensing door lock .............................................3-12
Auto light position ........................................................3-115
Automatic climate control system ................................3-129 Air conditioning .......................................................3-137
Air conditioning refrigerant label.............................3-140
Air intake control .....................................................3-135
Automatic heating and air conditioning ...................3-130
Driver only ...............................................................3-137
Fan speed control .....................................................3-136
Manual heating and air conditioning .......................3-131
Mode selection .........................................................3-132
OFF mode.................................................................3-137
Sync button...............................................................3-134
System maintenance .................................................3-139
Temperature control .................................................3-134
Index
A

I-4
Child restraint system (CRS) ..........................................2-36Booster seats...............................................................2-39
Forward-facing child restraint system........................2-39
Installing a child restraint system (CRS) ...................2-39
Lower anchors and tether for children (LATCH system) .....................................................2-40
Rearward-facing child restraint system......................2-38
Securing a child restraint system seat with "Tether Anchor" system ..........................................3-43
Securing a child restraint system with a lap/shoulder belt ......................................................3-44
Securing a child restraint system withthe LATCH anchors system ........................................................2-42
Selecting a child restraint system (CRS) ...................2-37
Child-protector rear door lock ........................................3-12
Climate control air filter .................................................7-26
Clock ........................................................................\
.....3-152
Clothes hanger ..............................................................3-153
Coasting guide ................................................................5-22
Combined instrument, see instrument cluster ................3-54
Compact spare tire replacement .....................................7-39
Consumer information ....................................................8-11
Convertible locking retractor ..........................................2-27
Coolant ........................................................................\
....7-18
Cooling fluid, see engine coolant/inverter coolant .........7-18
Crankcase emission control system ................................7-74
Cruise control system .....................................................5-64
Cup holder.....................................................................3-1\
48
Curtain air bags ...............................................................2-51 Dashboard illumination, see instrument panel
illumination..................................................................3-56
Dashboard, see instrument cluster ..................................3-54
Day/night rearview mirror ..............................................3-19
Daytime running light (DRL) .......................................3-115
Defogging (Windshield) ...............................................3-141
Defroster Rear window defroster .............................................3-142
Defrosting (Windshield) ...............................................3-141
Dimensions .......................................................................8\
-2
Display illumination, see instrument panel illumination..................................................................3-56
Displays, see instrument cluster .....................................3-54
Door locks ........................................................................\
.3-9 Auto door lock/unlock features ..................................3-12
Central door lock switch ............................................3-11
Child-protector rear door lock....................................3-12
Drinks holders, see cup holders ....................................3-148
Driver position memory system .....................................3-14 Easy access function ..................................................3-15
Recalling positions from memory .............................3-15
Storing positions into memory ...................................3-14
Driver's air bag................................................................2-49
Driver's knee airbag ........................................................2-49
Driving at night ...............................................................5-87
Driving in flooded areas .................................................5-88
Driving in the rain...........................................................5-87
Index
D

I-15
Low tire pressure warning light .................................3-68
Malfunction Indicator Lamp (MIL) ...........................3-66
Master warning light ..................................................3-68
Parking brake & brake fluid warning light ................3-63
Ready indicator ..........................................................3-62
Regenerative brake warning light ..............................3-64
Seat belt warning light ...............................................3-63
Service warning light .................................................3-62
SPORT mode indicator light ......................................3-72
Turn signal indicator light ..........................................3-70
Warning light ..................................................................3-62
Washer fluid ....................................................................7-23\
Welcome system ...........................................................3-122 Door handle lamp .....................................................3-122
Headlamp and parking lamp ....................................3-122
Interior lamp .............................................................3-122
Wheel alignment and tire balance ..................................7-38
Wheel replacement .........................................................7-39
Windows ........................................................................\
.3-37 Auto up/down window ...............................................3-39
Automatic reverse ......................................................3-39
Power window lock switch ........................................3-40
Resetting the windows ...............................................3-39
Windshield defrosting and defogging ...........................3-141
Windshield washers ......................................................3-124
Windshield wipers........................................................\
.3-123 Winter driving .................................................................5-89
Snow tires ...................................................................5-89
Tire chains ..................................................................5-89
Winter Precautions ..........................................................5-91
Wiper blade replacement ................................................7-28
Wipers and washers ......................................................3-123 Windshield washers ..................................................3-124
Windshield wipers ....................................................3-123
Wireless cellular phone charging system......................3-151
I
Index
