2018 FIAT TIPO 5DOORS STATION WAGON Owner handbook (in English)

Versions 1.4 T-jet 120 HP 1.4 T-jet 120 HP LPG
Type code 940B7000 940B7000
Cycle Otto Otto
Number and position of cylinders 4 in line 4 in line
Piston bore and stroke (mm) 72 × 84 72 × 84
Total displacement (cm³) 1368 1368
Compression ratio 9.8:1 9.8:1
Maximum power (EC) (kW) 88 88
corresponding engine speed (rpm) 5000 5000
Maximum torque (EC) (Nm) 215 215
corresponding engine speed (rpm) 2500 2500
Spark plugs NGK IKR9J8 NGK IKR9J8
FuelUnleaded petrol with R.O.N. no lower than 95
(EN228 specifications)LPG for motor vehicles (EN589 Specification)
207

Versions 1.3 MultiJet 95 HP1.6 Multijet 120 HP /
1.6 Multijet 120 HP ECO1.6 Multijet 115 HP /
1.6 Multijet 115 HP ECO(*)
Type code 55266963 55260384 55260384
Cycle Diesel Diesel Diesel
Number and position of cylinders 4 in line 4 in line 4 in line
Piston bore and stroke (mm) 69.6 × 82 79.5 × 80.5 79.5 × 80.5
Total displacement (cm³) 1248 1598 1598
Compression ratio 16.8:1 16.5:1 16.5 : 1
Maximum power (EC) (kW) 70 88 84.4
corresponding engine speed (rpm) 3750 3750 3750
Maximum torque (EC) (Nm) 200 320 320
corresponding engine speed (rpm) 1500 1750 1750
FuelDiesel for motor vehicles (EN
590 Specification)Diesel for motor vehicles (EN
590 Specification)Diesel for motor vehicles (EN
590 Specification)
(*) Version for specific markets
WARNING
186)Modifications or repairs to the supply system that are not carried out correctly or do not take the system technical specifications into
account can cause malfunctions leading to the risk of fire.
208
TECHNICAL DATA

WHEELS
SNOW TYRES
187)
Use snow tyres of the same size as the
standard tyres provided with the car.
The Fiat Dealership will be happy to
provide advice concerning the most
suitable type of tyre for the customer's
requirements.
For the type of snow tyre to be used,
inflation pressures and the
specifications of the tyres, carefully
follow the instructions given in this
chapter.
The winter features of these tyres are
reduced considerably when the tread
depth is below 4 mm. Replace them in
this case.
Due to the specific characteristics of
snow tyres, in normal weather
conditions or on long motorway
journeys, the performance of these
tyres is lower than that of standard
tyres.
Their usage should therefore be
restricted in accordance with their
type-approval; always comply with
specific local regulations relating to the
use of snow tyres.All four tyres should be the same (brand
and track) to ensure greater safety
when driving and braking as well as a
good manoeuvrability. Remember that
you should not change the rotation
direction of the tyres.
209

RIMS AND TYRES PROVIDED
188)
Alloy or pressed steel rims. Tubeless radial carcass tyres.
All approved tyres are listed in the Registration Document.
IMPORTANT If there are any discrepancies between the Owner Handbook and the Registration Document, take the information
from the latter. For safe driving, the car must be fitted with tyres of the same make and type on all wheels.
IMPORTANT Do not use air chambers with tubeless tyres.
Versions Wheels Tyres provided Spare wheel(*)
210
TECHNICAL DATA
1.4 16V 95 HP /
1.3 Multijet
95 HP6J X 15 H2 ET38 195/65 R15 91H 195/65 R15 91H
6.5J X 16 H2 ET39
205/55 R16 91H(**)205/55 R16 91H
7J X 17 H2 ET41
225/45 R17 91V
(**)205/55 R16 91H
189)
1.4 T-jet 120 HP /
1.6 E.TorQ6J X 15 H2 ET38
(***)195/65 R15 91H(***)195/65 R15 91H(***)
6.5J X 16 H2 ET39
205/55 R16 91H(**)205/55 R16 91H
7J X 17 H2 ET41
225/45 R17 91V
(**)205/55 R16 91H
189)
7.5J X 18 H2 ET44
225/40 R18 92W XL GoodYear(****)205/55 R16 91H
189)
1.4 T-jet 120 HP
LPG6.5J X 16 H2 ET39
205/55 R16 91H
(**)—
7J X 17 H2 ET41
225/45 R17 91V
(**)—
7.5J X 18 H2 ET44
225/40 R18 92W XL GoodYear
(****)—
(*) A size 135/70 R16 space-saver spare wheel may be ordered as an alternative to the spare wheel for TIPO 5DOOR versions.
(**) M+S Goodyear Vector 4Seasons Gen-2 or equivalent tyres of the same size are available as optional for versions/markets, where provided
(***) For TIPO 5DOOR versions
(****) For versions/markets, where provided. Tyres offering equivalent performance can be used as an alternative.

Versions Wheels Tyres provided Spare wheel(*)
211
1.6 Multijet
120 HP /
1.6 Multijet
115 HP
(*****)
6J X 15 H2 ET38 195/65 R15 91H 195/65 R15 91H
6.5J X 16 H2 ET39
205/55 R16 91H
(**)205/55 R16 91H
7J X 17 H2 ET41
225/45 R17 91V
(**)205/55 R16 91H
189)
7.5J X 18 H2 ET44
225/40 R18 92W XL GoodYear(****)205/55 R16 91H
189)
1.6 Multijet
120 HP ECO /
1.6 Multijet
115 HP ECO
(*****)
6.5J X 16 H2 ET39205/55 R16 91H Goodyear
EfficientGrip Performance(**) (****)205/55 R16 91H Goodyear
EfficientGrip Performance(****)
(*) A size 135/70 R16 space-saver spare wheel may be ordered as an alternative to the spare wheel for TIPO 5DOOR versions.
(**) M+S Goodyear Vector 4Seasons Gen-2 or equivalent tyres of the same size are available as optional for versions/markets, where provided
(****) For versions/markets, where provided. Tyres offering equivalent performance can be used as an alternative.
(*****) Versions for specific markets
NOTE On versions with 195 / 65 R15 and 205 / 55 R16 tyres, use smaller snow chains with a maximum projection of 9 mm
beyond the tyre profile.
NOTE Low-profile snow chains with a maximum protrusion of 7 mm beyond the tyre profile can be mounted on versions
equipped with 225 / 45 R17 tyres.
NOTE Chains cannot be fitted on 225/40 R18 92W XL tyres.

COLD TYRE INFLATION PRESSURE (bar)
When the tires are warm, the inflation pressure should be + 0.3 bar in relation to the recommended figure. However, recheck
that the value is correct with the tyre cold.
If it is necessary to raise the vehicle, refer to the "Raising the vehicle" paragraph in the "In an emergency" chapter.
TIPO 5DOOR version
Versions TyresUnladen/medium load Full load
Spare wheelSpace saver
spare
wheel(**)Front Rear Front Rear
1.4 16V
95 HP195 / 65 R15
2.2 2.1 2.6 2.5
(*)
4.2 205 / 55 R16
225 / 45 R17
1.4 T-jet
120 HP /
1.6 E.TorQ /
1.3 Multijet
95 HP195 / 65 R15
2.3 2.1 2.6 2.5 205 / 55 R16
225 / 45 R17
225/
40 R18 92W
XL
GoodYear
(***)
(****)2.5 2.2 2.5 2.5 3.5
.
212
TECHNICAL DATA
(**) Where fitted (*) If the spare wheel is used in an emergency, check pressure and, if necessary, align it to the values prescribed for the tyre of the axle where it is used
.
(***) For versions/markets, where provided. Tyres offering equivalent performance can be used as an alternative.
(****) 1.4 T-jet 120 HP / 1.6 E.TorQ versions

Versions TyresUnladen/medium load Full load
Spare wheelSpace saver
spare
wheel(**)Front Rear Front Rear
1.4 T-jet
120 HP LPG205 / 55 R16
2.3 2.1 2.6
2.5 — — 225 / 45 R17
225/
40 R18 92W
XL GoodYear
(***)
2.5 2.2 2.5
1.6 Multijet
120 HP /
1.6 Multijet
115 HP
(*****)
195 / 65 R15
2.4 2.1 2.6 2.5
(*)
4.2 205 / 55 R16
225 / 45 R17
225/
40 R18 92W
XL GoodYear(***)
2.5 2.2 2.5 2.5 3.5
1.6 Multijet
120 HP ECO /
1.6 Multijet
115 HP ECO
(*****)
205/
55R16 91H
Goodyear
EfficientGrip
Performance
(***)
2.8 2.5 2.6 2.5(*)
.
213
(**) Where fitted
(***) For versions/markets, where provided. Tyres offering equivalent performance can be used as an alternative.
(*****) Version for specific markets (*) If the spare wheel is used in an emergency, check pressure and, if necessary, align it to the values prescribed for the tyre of the axle where it is used

TIPO STATION WAGON version
Versions TyresUnladen/medium load Full load
Spare wheel
Front Rear Front Rear
1.4 16V 95 HP
/ 1.3 Multijet
95 HP195 / 65 R15
2.3 2.3
2.5 2.7
(*)
205 / 55 R16
225 / 45 R17 2.3 2.2
1.4 T-jet 120 HP
/ 1.6 E.TorQ205 / 55 R16 2.3 2.3
225 / 45 R17 2.3 2.2
225/
40 R18 92W XL
GoodYear
(**)2.5 2.2 2.5 2.5 3.5
1.4 T-jet 120 HP
LPG205 / 55 R16 2.3 2.3
2.52.7
— 225 / 45 R17 2.3
2.2 225/
40 R18 92W XL
GoodYear
(**)2.5 2.5
1.6 Multijet
120 HP /
1.6 Multijet
115 HP
(***)
195 / 65 R15 2.4 2.1 2.6 2.5
(*)205 / 55 R16 2.5 2.3
2.52.7
225 / 45 R17 2.4
2.2 225/
40 R18 92W XL
GoodYear
(**)2.5 2.5 3.5
(*) If the spare wheel is used in an emergency, check pressure and, if necessary, align it to the values prescribed for the tyre of the axle where it is used.
(**) For versions/markets, where provided. Tyres offering equivalent performance can be used as an alternative.
(***) Versions for specific markets
214
