2018 CHRYSLER PACIFICA HYBRID Owners Manual

Vehicle Loading....................... .370, 468
Vehicle Modifications/Alterations .................6
Vehicle Storage ............................118
Viscosity, Engine Oil ....................... .439
Voice Recognition System (VR) .................570
Warning Flasher, Hazard .....................378
Warning Lights (Instrument Cluster Description) . . . .178
Warnings And Cautions .......................6
Warranty Information ...................... .591
Washers, Windshield ....................... .436
Washing Vehicle .......................... .487
Water Driving Through ........................ .375
Wheel And Wheel Trim ..................... .480
Wheel And Wheel Trim Care ..................480
Wind Buffeting ........................... .125
Window Fogging ...........................118
Windshield Defroster ....................... .273
Windshield Washers .....................100, 436
Fluid ................................ .436
Windshield Wiper Blades .....................446
Wiper Blade Replacement .....................446
Wipers, Intermittent .....................100, 101
Wrecker Towing .......................... .425
12
INDEX 607

INSTALLATION OF RADIO TRANSMITTING
EQUIPMENT
Special design considerations are incorporated into this
vehicle’s electronic system to provide immunity to radio
frequency signals. Mobile two-way radios and telephone
equipment must be installed properly by trained person-
nel. The following must be observed during installation.
The positive power connection should be made directly
to the battery and fused as close to the battery as possible.
The negative power connection should be made to body
sheet metal adjacent to the negative battery connection.
This connection should not be fused.
Antennas for two-way radios should be mounted on the
roof or the rear area of the vehicle. Care should be used
in mounting antennas with magnet bases. Magnets may
affect the accuracy or operation of the compass on
vehicles so equipped.
The antenna cable should be as short as practical and
routed away from the vehicle wiring when possible. Use
only fully shielded coaxial cable.
Carefully match the antenna and cable to the radio to
ensure a low Standing Wave Ratio (SWR).Mobile radio equipment with output power greater than
normal may require special precautions.
All installations should be checked for possible interfer-
ence between the communications equipment and the
vehicle’s electronic systems.
WARNING:
Operating, servicing and maintaining a
passenger vehicle or off-road highway
motor vehicle can expose you to chemicals
including engine exhaust, carbon monoxide,
phthalates, and lead, which are known to
the State of California to cause cancer and
birth defects or other reproductive harm.
To minimize exposure, avoid breathing
exhaust, do not idle the engine except as
necessary, service your vehicle in a
well-ventilated area and wear gloves or
wash your hands frequently when servicing
your vehicle. For more information go to
www.P65Warnings.ca.gov/passenger-vehicle.

Pacifica Hybrid
OWNER’S MANUAL
Third Edition Rev 1
Printed in the U.S.A.
18RUPHEV-126-AC
©2018 FCA US LLC. All Rights Reserved.
Chrysler is a registered trademark of FCA US LLC.
2018
2018 PACIFICA HYBRID
