2018 CHRYSLER 300 snow chains

display dashes (- -) in place of the pressure value to
indicate which sensor is not being received.
If the ignition switch is cycled, this sequence will repeat,
providing the system fault still exists. If the system fault no
longer exists, the TPM Telltale Light will no longer flash,
and theService Tire Pressure System message will no
longer display, and a pressure value will display in place of
the dashes. A system fault can occur due to any of the
following:
• Signal interference due to electronic devices or driving
next to facilities emitting the same radio frequencies as
the TPM sensors.
• Installing aftermarket window tinting that contains ma-
terials that may block radio wave signals.
• Accumulation of snow or ice around the wheels or
wheel housings.
• Using tire chains on the vehicle.
• Using wheels/tires not equipped with TPM sensors. Vehicles With Compact Spare
1. The compact spare tire or non-matching full size does
not have a tire pressure monitoring sensor. Therefore,
the TPMS will not monitor the pressure in the compact
spare tire.
2. If you install the compact or non-matching full size spare tire in place of a road tire that has a pressure below
the low-pressure warning limit, upon the next ignition
key cycle, the “TPMS Telltale Light” will remain on and
a chime will sound. In addition, the graphic in the
instrument cluster will still display a different color
pressure value and an Inflate to XXmessage.
3. After driving the vehicle for up to 20 minutes above 15 mph (24 km/h), the “TPMS Telltale Light” will flash
on and off for 75 seconds and then remain on solid. In
addition, the instrument cluster will display a “Service
Tire Pressure System” message for five seconds and then
display dashes (- -) in place of the pressure value.
4. For each subsequent ignition key cycle, a chime will sound, the “TPMS Telltale Light” will flash on and off
for 75 seconds and then remain on solid, and the
instrument cluster will display a “Service Tire Pressure
164 SAFETY

NOTE:If you intend parking or storing your vehicle for an
extended period after cleaning the wheels with wheel
cleaner, drive your vehicle and apply the brakes to remove
the water droplets from the brake components. This activ-
ity will remove the red rust on the brake rotors and prevent
vehicle vibration when braking.
Dark Vapor Chrome, Black Satin Chrome, or Low Gloss
Clear Coat Wheels
CAUTION!
If your vehicle is equipped with these specialty
wheels, DO NOT USE wheel cleaners, abrasives, or
polishing compounds. They will permanently damage
this finish and such damage is not covered by the New
Vehicle Limited Warranty. HAND WASH ONLY US-
ING MILD SOAP AND WATER WITH A SOFT
CLOTH. Used on a regular basis; this is all that is
required to maintain this finish.
Tire Chains (Traction Devices)
Use of traction devices require sufficient tire-to-body clear-
ance. Follow these recommendations to guard against
damage. •
Traction device must be of proper size for the tire, as
recommended by the traction device manufacturer.
• Install on Rear Tires Only.
• Due to limited clearance for a Rear Wheel Drive (RWD)
vehicle, on P215/65R17, and P225/60R18 tires with a
Peerless Chain Super Z6 low profile traction device or
equivalent is recommended.
• Due to limited clearance for an All Wheel Drive (AWD)
vehicle, P235/55R19, 235/55R19 tires with the use of a
traction device that meets the SAE type “Class S”
specification is recommended.
• No other tire sizes are recommended for use with a tire
chain or traction device.
WARNING!
Using tires of different size and type (M+S, Snow)
between front and rear axles can cause unpredictable
handling. You could lose control and have a collision.
392 SERVICING AND MAINTENANCE

Security Alarm......................... .32, 129
Arm The System ..........................32
Selection Of Coolant (Antifreeze) ...............413
Sentry Key Key Programming .........................31
Sentry Key (Immobilizer) ......................30
Sentry Key Replacement ....................23, 31
Service Assistance ......................... .466
Service Contract .......................... .468
Service Manuals .......................... .470
Shifting ................................ .224
Automatic Transmission ................224, 226
Shoulder Belts ............................ .169
Side View Mirror Adjustment ...................58
Signals, Turn ....................... .67, 135, 212
Siri .................................... .459
SiriusXM Guardian Vehicle Health Alert ...................... .458
Snow Chains (Tire Chains) ....................392
Snow Tires .............................. .388
Spare Tire ............................... .321
Spare Tires ........................ .388, 389, 390
Spark Plugs ............................. .413Specifications
Fuel (Gasoline) ......................... .413
Oil.................................. .413
Speed Control Accel/Decel ........................ .237, 238
Accel/Decel (ACC Only) ...................244
Cancel ............................... .239
Resume .............................. .239
Set .................................. .237
Speed Control (Cruise Control) ..........236, 237, 239
Sport Mode .............................. .234
Starting ............................. .216, 217
Automatic Transmission ....................216
Button .................................24
Cold Weather .......................... .220
Engine Fails To Start ..................... .220
Starting

And Operating ...................216, 217
Starting Procedures ..................... .216, 217
Steering ..................................54
Column Lock ............................54
Power ............................... .235
Tilt Column .......................... .54, 55
Wheel, Heated ...........................56
Wheel, Tilt .......................... .54, 55
484 INDEX

Steering Wheel Audio Controls.................445
Storage ................................. .395
Storage, Vehicle ........................ .81, 395
Storing Your Vehicle ....................... .395
Stuck, Freeing ............................ .334
Sunglasses Storage ..........................112
Sun Roof .................................86
Supplemental Restraint System - Air Bag ..........180
Synthetic Engine Oil ....................... .352
Telescoping Steering Column ................54, 55
Temperature Control, Automatic (ATC) ............80
Tilt Steering Column ..................... .54, 55
Time Delay, Headlight ........................65
Tire And Loading Information Placard ............377
Tire Markings ............................ .371
Tires......................... .212, 381, 388, 394
Aging (Life Of Tires) ..................... .385
Air Pressure ........................... .381
Chains ............................... .392
Changing ....................321, 324, 328, 371
Compact Spare ......................... .389
Flat Changing .......................... .328
General Information ...................381, 388
High Speed ............................ .383Inflation Pressure
....................... .382
Jacking ........................... .324, 371
Life Of Tires ........................... .385
Load Capacity ...................... .377, 378
Pressure Monitoring System (TPMS) ........131, 160
Quality Grading ........................ .394
Radial ............................... .383
Replacement ........................ .328, 386
Rotation .............................. .393
Safety ............................ .371, 381
Sizes ................................ .373
Snow Tires ............................ .388
Spar

e Tire ............................. .321
Spare Tires ......................... .388, 390
Spinning .............................. .384
Trailer Towing .......................... .288
Tread Wear Indicators .....................385
Wheel Mounting ........................ .328
Wheel Nut Torque ....................... .404
Tire Safety Information ...................... .371
Tongue Weight/Trailer Weight .................286
To Open Hood .............................90
Towing ................................. .282
Behind A Motorhome ..................... .292
Disabled Vehicle ........................ .336
12
INDEX 485
