2018 CHRYSLER 300 service indicator

In unusual situations involving grossly malfunctioning
engine operation, a scorching odor may suggest severe and
abnormal catalyst overheating. If this occurs, stop the
vehicle, turn off the engine and allow it to cool. Service,
including a tune-up to manufacturer’s specifications,
should be obtained immediately.
To minimize the possibility of catalytic converter damage:
•Do not shut off the engine or interrupt the ignition when
the transmission is in gear and the vehicle is in motion.
• Do not try to start the engine by pushing or towing the
vehicle.
• Do not idle the engine with any spark plug wires
disconnected or removed, such as when diagnostic
testing, or for prolonged periods during very rough idle
or malfunctioning operating conditions.
NOTE: Your vehicle’s exhaust system may be equipped
with an Electronic Exhaust Valve (EEV) system, if the
exhaust system is replaced with aftermarket products a
Malfunction Indicator Lamp (MIL) will illuminate.Cooling System
WARNING!
• You or others can be badly burned by hot engine
coolant (antifreeze) or steam from your radiator. If
you see or hear steam coming from under the hood,
do not open the hood until the radiator has had time
to cool. Never open a cooling system pressure cap
when the radiator or coolant bottle is hot.
• Keep hands, tools, clothing, and jewelry away from
the radiator cooling fan when the hood is raised. The
fan starts automatically and may start at any time,
whether the engine is running or not.
• When working near the radiator cooling fan, discon-
nect the fan motor lead or turn the ignition to the
OFF mode. The fan is temperature controlled and can
start at any time the ignition is in the ON mode.
362 SERVICING AND MAINTENANCE

Tread Wear Indicators
Tread wear indicators are in the original equipment tires to
help you in determining when your tires should be re-
placed.These indicators are molded into the bottom of the tread
grooves. They will appear as bands when the tread depth
becomes a 1/16 of an inch (1.6 mm). When the tread is
worn to the tread wear indicators, the tire should be
replaced. Refer to “Replacement Tires” in this section for
further information.
Life Of Tire
The service life of a tire is dependent upon varying factors
including, but not limited to:
•
Driving style.
• Tire pressure - Improper cold tire inflation pressures can
cause uneven wear patterns to develop across the tire
tread. These abnormal wear patterns will reduce tread
life, resulting in the need for earlier tire replacement.
• Distance driven.
• Performance tires, tires with a speed rating of V or
higher, and Summer tires typically have a reduced tread
life. Rotation of these tires per the vehicle scheduled
maintenance is highly recommended.
Tire Tread
1—WornTire
2—NewTire
8
SERVICING AND MAINTENANCE 385

Brightness, Interior Lights.....................70
Bulb Replacement ......................... .304
Bulbs, Light .......................... .212, 304
Camera, Rear ............................ .277
Capacities, Fluid .......................... .412
Caps, Filler Oil (Engine) ........................ .346, 352
Radiator (Coolant Pressure) .................365
Carbon Monoxide Warning ................209, 409
Cargo Vehicle Loading ......................... .281
Cargo Area Cover ...........................93
Cargo Compartment .........................93
Car Washes .............................. .397
Cellular Phone ........................... .447
Certification Label ......................... .281
Chains, Tire ............................. .392
Changing A Flat Tire ....................... .371
Chart, Tire Sizing .......................... .373
Check Engine Light (Malfunction Indicator Light). . . .137
Checking Your Vehicle For Safety ...............208
Checks, Safety ............................ .208
Child Restraint ........................... .191Child Restraints
Booster Seats ........................... .195
Child Seat Installation .....................205
How To Stow An unused ALR Seat Belt ........202
Infant And Child Restraints .................193
Lower Anchors And Tethers For Children .......197
Older Children And Child Restraints ...........194
Seating Positions ........................ .196
Child Safety Locks ..........................39
Clean Air Gasoline ........................ .406
Cleaning Wheels ............................... .391
Climate Control ............................75
Automatic ..............................75
Coin Holder ............................. .103
Cold Weather Operation ..................... .220
Compact

Disc (CD) Maintenance ................464
Compact Spare Tire ........................ .389
Console, Floor ............................ .103
Contract, Service .......................... .468
Cooling Pressure Cap (Radiator Cap) ............365
Cooling System ........................... .362
Adding Coolant (Antifreeze) .................364
Coolant Capacity ........................ .412
Coolant Level ....................... .363, 366
474 INDEX

Key FobArm The System ..........................32
Panic Alarm .............................20
Programming Additional Key Fobs ..........23, 31
Unlatch The Trunk ........................20
Key Fob Battery Service (Remote Keyless Entry) .....21
Key Fob Programming (Remote Keyless Entry) ......23
Key-In Reminder ............................26
Keyless Enter-N-Go ..................... .35, 217
Enter The Trunk ..........................20
Passive Entry ............................35
Passive Entry Programming ..................35
Keys ....................................17
Replacement ......................... .23, 31
Key, Sentry (Immobilizer) ......................30
Lane Change And Turn Signals .................67
Lane Change Assist ..........................67
LaneSense ............................... .272
Lap/Shoulder Belts ........................ .169
Latches ................................. .212
Hood ..................................90
Lead Free Gasoline ........................ .405
Leaks, Fluid ............................. .212
Life Of Tires ............................. .385Light Bulbs
.......................... .212, 304
Lights .................................. .212
AirBag .........................125, 178, 210
Automatic Headlights ......................64
Brake Assist Warning ..................... .146
Brake Warning ...................... .126, 403
Bulb Replacement ....................... .304
Cruise ............................ .134, 135
Daytime Running .........................63
Dimmer Switch, Headlight ...................63
Engine Temperature Warning ................128
Exterior .............................. .212
Fog ...................................66
Hazard Warning Flasher ...................298
Headlights ....................... .62, 66, 306
Headlights On With Wipers ..................65
Headlight Switch .........................62
High Beam ..............................63
High Beam/Low Beam Select .................63
Instr

ument Cluster ........................62
Intensity Control ..........................70
Interior ................................67
License ............................... .309
Lights On Reminder .......................66
Malfunction Indicator (Check Engine) ..........129
12
INDEX 479

Map Reading............................68
Park .............................. .65, 135
Passing ................................64
Reading ................................68
Seat Belt Reminder ...................... .128
Security Alarm ......................... .129
Service ............................... .304
Tire Pressure Monitoring (TPMS) ..........131, 160
Traction Control ........................ .146
Turn Signals ....................63, 67, 135, 212
Vanity Mirror ............................61
Warning Instrument Cluster Descriptions . . . .128, 135
Loading Vehicle ....................... .281, 282
Capacities ............................. .282
Tires................................. .377
Load Leveling System ........................96
Load Shed Battery Saver On ...................123
Load Shed Electrical Load Reduction .............123
Load Shed Intelligent Battery Sensor .............123
Locks Automatic Door ..........................39
Auto Unlock .............................39
Child Protection ..........................39
Power Door .............................34
Low Tire Pressure System .....................160 Lubrication, Body
......................... .357
Lug Nuts ............................... .404
Maintenance Free Battery .....................349
Maintenance Schedule ....................341, 342
Malfunction Indicator Light (Check Engine) . . . .129, 137
Manual Park Release ....................... .332
Manual, Service ........................... .470
Media Hub .............................. .447
Memory Feature (Memory Seats) ................41
Memory Seat ..............................41
Memory Seats And Radio .....................41
Methanol ............................... .407
Mirrors ..................................57
Electric Powered ..........................59
Electric Remote ...........................59
Heated .................................61
Outside ................................

58
Rearview ........................... .57, 298
Vanity .................................61
Modifications/Alterations, Vehicle ................6
Monitor, Tire Pressure System ..................160
Mopar Parts ............................. .469
480 INDEX
