Chevrolet Malibu Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11348460) - 2018 - crc - 5/3/17
Vehicle Care 323
Use this rotation pattern when
rotating the tires.
Do not include the compact
spare tire in the tire rotation.
Adjust the front and rear tires to
the recommended inflation
pressure on the Tire and
Loading Information label after
the tires have been rotated.
SeeTire Pressure 0316 and
Vehicle Load Limits 0212.
Reset the Tire Pressure Monitor
System. See Tire Pressure
Monitor Operation 0319. Check that all wheel nuts are
properly tightened. See
“Wheel
Nut Torque” underCapacities
and Specifications 0373.
{Warning
Rust or dirt on a wheel, or on the
parts to which it is fastened, can
make wheel nuts become loose
after time. The wheel could come
off and cause an accident. When
changing a wheel, remove any
rust or dirt from places where the
wheel attaches to the vehicle. In
an emergency, a cloth or a paper
towel can be used; however, use
a scraper or wire brush later to
remove all rust or dirt.
Lightly coat the center of the
wheel hub with wheel bearing
grease after a wheel change or
tire rotation to prevent corrosion
or rust build-up. Do not get
grease on the flat wheel
mounting surface or on the
wheel nuts or bolts.
When It Is Time for New
Tires
Factors such as maintenance,
temperatures, driving speeds,
vehicle loading, and road conditions
affect the wear rate of the tires.
Treadwear indicators are one way to
tell when it is time for new tires.
Treadwear indicators appear when
the tires have only 1.6 mm (1/16 in)
or less of tread remaining.
See Tire Inspection 0322 andTire
Rotation 0322.

Chevrolet Malibu Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11348460) - 2018 - crc - 5/3/17
326 Vehicle Care
control, electronic stability control,
or All-Wheel Drive, the performance
of these systems can also be
affected.
{Warning
If different sized wheels are used,
there may not be an acceptable
level of performance and safety if
tires not recommended for those
wheels are selected. This
increases the chance of a crash
and serious injury. Only use GM
specific wheel and tire systems
developed for the vehicle, and
have them properly installed by a
GM certified technician.
See Buying New Tires 0324 and
Accessories and Modifications
0 270.
Uniform Tire Quality
Grading
The following information relates
to the system developed by the
United States National Highway
Traffic Safety Administration
(NHTSA), which grades tires by
treadwear, traction, and
temperature performance. This
applies only to vehicles sold in
the United States. The grades
are molded on the sidewalls of
most passenger car tires. The
Uniform Tire Quality Grading
(UTQG) system does not apply
to deep tread, winter tires,
compact spare tires, tires with
nominal rim diameters of
10 to 12 inches (25 to 30 cm),
or to some limited-production
tires.
While the tires available on
General Motors passenger cars
and light trucks may vary with
respect to these grades, they
must also conform to federal
safety requirements and additional General Motors Tire
Performance Criteria (TPC)
standards.
Quality grades can be found
where applicable on the tire
sidewall between tread shoulder
and maximum section width. For
example:
Treadwear 200 Traction AA
Temperature A
All Passenger Car Tires Must
Conform to Federal Safety
Requirements In Addition To
These Grades.
Treadwear
The treadwear grade is a
comparative rating based on the
wear rate of the tire when tested
under controlled conditions on a
specified government test
course. For example, a tire
graded 150 would wear one and
one-half (1½) times as well on
the government course as a tire
graded 100. The relative
performance of tires depends

Chevrolet Malibu Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11348460) - 2018 - crc - 5/3/17
Vehicle Care 327
upon the actual conditions of
their use, however, and may
depart significantly from the
norm due to variations in driving
habits, service practices and
differences in road
characteristics and climate.
Traction
The traction grades, from
highest to lowest, are AA, A, B,
and C. Those grades represent
the tire's ability to stop on wet
pavement as measured under
controlled conditions on
specified government test
surfaces of asphalt and
concrete. A tire marked C may
have poor traction performance.
Warning: The traction grade
assigned to this tire is based on
straight-ahead braking traction
tests, and does not include
acceleration, cornering,
hydroplaning, or peak traction
characteristics.Temperature
The temperature grades are A
(the highest), B, and C,
representing the tire's resistance
to the generation of heat and its
ability to dissipate heat when
tested under controlled
conditions on a specified indoor
laboratory test wheel. Sustained
high temperature can cause the
material of the tire to degenerate
and reduce tire life, and
excessive temperature can lead
to sudden tire failure. The grade
C corresponds to a level of
performance which all
passenger car tires must meet
under the Federal Motor Safety
Standard No. 109. Grades B and
A represent higher levels of
performance on the laboratory
test wheel than the minimum
required by law. Warning: The
temperature grade for this tire is
established for a tire that is
properly inflated and not
overloaded. Excessive speed,underinflation, or excessive
loading, either separately or in
combination, can cause heat
buildup and possible tire failure.
Wheel Alignment and Tire
Balance
The tires and wheels were aligned
and balanced at the factory to
provide the longest tire life and best
overall performance. Adjustments to
wheel alignment and tire balancing
are not necessary on a regular
basis. Consider an alignment check
if there is unusual tire wear or the
vehicle is significantly pulling to one
side or the other. Some slight pull to
the left or right, depending on the
crown of the road and/or other road
surface variations such as troughs
or ruts, is normal. If the vehicle is
vibrating when driving on a smooth
road, the tires and wheels may need
to be rebalanced. See your dealer
for proper diagnosis.

Chevrolet Malibu Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11348460) - 2018 - crc - 5/3/17
336 Vehicle Care
SeeIf a Tire Goes Flat 0329 for
other important safety warnings.
1. Remove the compressor from its storage location. See
Storing the Tire Sealant and
Compressor Kit 0337.
2. Remove the air only hose (10) and the power plug (9) from the
bottom of the compressor.
3. Place the compressor on the ground near the flat tire.
Make sure the tire valve stem
is positioned close to the
ground so the hose will
reach it.
4. Remove the valve stem cap from the flat tire by turning it
counterclockwise.
5. Attach the air only hose (10) to the tire valve stem by turning it
clockwise until tight.
6. Plug the power plug (9) into the accessory power outlet in the
vehicle. Unplug all items from
other accessory power outlets.
See Power Outlets 0109. If the vehicle has an accessory
power outlet, do not use the
cigarette lighter.
If the vehicle only has a
cigarette lighter, use the
cigarette lighter.
Do not pinch the power plug
cord in the door or window.
7. Start the vehicle. The vehicle must be running while using
the air compressor.
8. Press the on/off button (5) to turn the tire sealant and
compressor kit on.
The compressor will inflate the
tire with air only.
9. Inflate the tire to the recommended inflation
pressure using the pressure
gauge (8). The recommended
inflation pressure can be found
on the Tire and Loading
Information label. See Tire
Pressure 0316.
The pressure gauge (8) may
read higher than the actual tire
pressure while the compressor
is on. Turn the compressor off to get an accurate pressure
reading. The compressor may
be turned on/off until the
correct pressure is reached.
Caution
If the recommended pressure
cannot be reached after
approximately 25 minutes, the
vehicle should not be driven
farther. The tire is too severely
damaged and the tire sealant and
compressor kit cannot inflate the
tire. Remove the power plug from
the accessory power outlet and
unscrew the inflating hose from
the tire valve. See
Roadside
Assistance Program 0379.
10. Press the on/off button (5) to turn the tire sealant and
compressor kit off.
Be careful while handling the
compressor as it could be
warm after usage.
11. Unplug the power plug (9) from the accessory power outlet in
the vehicle.

Chevrolet Malibu Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11348460) - 2018 - crc - 5/3/17
Vehicle Care 345
manual transmission in Neutral
before setting the parking
brake.
Caution
If any accessories are left on or
plugged in during the jump
starting procedure, they could be
damaged. The repairs would not
be covered by the vehicle
warranty. Whenever possible, turn
off or unplug all accessories on
either vehicle when jump starting.
4. Turn the ignition off and switch off all lights and accessories in
both vehicles, except the
hazard warning flashers if
needed.
{Warning
An electric fan can start up even
when the engine is not running
and can injure you. Keep hands,
clothing, and tools away from any
underhood electric fan.
{Warning
Using a match near a battery can
cause battery gas to explode.
People have been hurt doing this,
and some have been blinded.
Use a flashlight if you need more
light.
Battery fluid contains acid that
can burn you. Do not get it on
you. If you accidentally get it in
your eyes or on your skin, flush
the place with water and get
medical help immediately.
{Warning
Fans or other moving engine
parts can injure you badly. Keep
your hands away from moving
parts once the engine is running.
6. Connect the red positive (+) cable to the positive (+) or
remote positive (+) terminal of
the discharged battery. 7. Connect the other end of the
positive (+) cable to the
positive (+) terminal of the
good battery. Use a remote
positive (+) terminal if the
vehicle has one.
8. Connect one end of the black negative (−) cable to the
negative (−) terminal of the
good battery.
9. Connect the other end of the negative (−) cable to the
negative (–) ground terminal for
the discharged battery.
10. Start the vehicle with the good battery and run the engine at
idle speed for at least
four minutes.
11. Try to start the vehicle that had the dead battery. If it will not
start after a few tries, it
probably needs service.
For hybrid vehicles, the engine will
only start if needed after pressing
ENGINE START/STOP. The vehicle
ready light will come on when the
propulsion system is on and ready.

Chevrolet Malibu Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11348460) - 2018 - crc - 5/3/17
400 Index
IndexA
Accessories andModifications . . . . . . . . . . . . . . . . . . 270
Accessory Power . . . . . . . . . . . . . . . 221
Adaptive Cruise Control . . . . . . . . 235
Add-On Electrical Equipment . . . 267
Additional Information OnStar . . . . . . . . . . . . . . . . . . . . . . . 395
Additional Maintenance and Care . . . . . . . . . . . . . . . . . . . . . . 366
Adjustments Lumbar, Front Seats . . . . . . . . . . . . 57
Agreements Trademarks and License . . . . . 194
Air Cleaner/Filter, Engine . . . . . . . 282
Air Conditioning . . . . . . . . . . . 196, 199
Air Filter, Passenger Compartment . . . . . . . . . . . . . . . . . 203
Air Vents . . . . . . . . . . . . . . . . . . . . . . . 203
Airbag System
Check . . . . . . . . . . . . . . . . . . . . . . . . . . 83
How Does an AirbagRestrain? . . . . . . . . . . . . . . . . . . . . . 76
Passenger Sensing System . . . . 78
What Makes an Airbag
Inflate? . . . . . . . . . . . . . . . . . . . . . . . . 76 Airbag System (cont'd)
What Will You See after an
Airbag Inflates? . . . . . . . . . . . . . . . 77
When Should an Airbag
Inflate? . . . . . . . . . . . . . . . . . . . . . . . . 75
Where Are the Airbags? . . . . . . . . 74
Airbags Adding Equipment to theVehicle . . . . . . . . . . . . . . . . . . . . . . . . 83
Passenger Status Indicator . . . 121
Readiness Light . . . . . . . . . . . . . . 120
Servicing Airbag-Equipped Vehicles . . . . . . . . . . . . . . . . . . . . . . . 82
System Check . . . . . . . . . . . . . . . . . . 72
Alarm Vehicle Security . . . . . . . . . . . . . . . . 46
Alert Lane Change . . . . . . . . . . . . . . . . . 253
Side Blind Zone (SBZA) . . . . . . 253
All-Season Tires . . . . . . . . . . . . . . . . 309
AM-FM Radio . . . . . . . . . . . . . . . . . . . 170
Antenna Backglass . . . . . . . . . . . . . . . . . . . . 175
Multi-band . . . . . . . . . . . . . . . . . . . . 175
Antilock Brake System (ABS) . . . 227 Warning Light . . . . . . . . . . . . . . . . . 125

Chevrolet Malibu Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11348460) - 2018 - crc - 5/3/17
Index 401
Appearance CareExterior . . . . . . . . . . . . . . . . . . . . . . . 349
Interior . . . . . . . . . . . . . . . . . . . . . . . . 354
Apple CarPlay and Android Auto . . . . . . . . . . . . . . . . . . 191
Armrest Rear Seat . . . . . . . . . . . . . . . . . . . . . . 65
Assistance Program, Roadside . . . . . . . . . . . . . . . . . . . . . . 379
Assistance Systems for Driving . . . . . . . . . . . . . . . . . . . . . . . . 247
Assistance Systems for Parking and Backing . . . . . . . . . . 243
Audio Theft-Deterrent Feature . . . . . . . 163
Automatic
Door Locks . . . . . . . . . . . . . . . . . . . . . 43
Forward Braking . . . . . . . . . . . . . . 249
Headlamp System . . . . . . . . . . . . 157
Transmission . . . . . . . . . . . . . . . . . 224
Transmission Fluid . . . . . . . . . . . 282
Automatic Transmission Manual Mode . . . . . . . . . . . . . . . . . 225
Shift Lock Control FunctionCheck . . . . . . . . . . . . . . . . . . . . . . . 293
Avoiding Untrusted Media Devices . . . . . . . . . . . . . . . . . . . . . . . 176B
Backglass Antenna . . . . . . . . . . . . . 175
BatteryExterior Lighting BatterySaver . . . . . . . . . . . . . . . . . . . . . . . 161
Load Management . . . . . . . . . . . . 160
Power Protection . . . . . . . . . . . . . 161
Battery - North America . . . . 291, 343
Blade Replacement, Wiper . . . . . 294
Bluetooth Overview . . . . . . . . . . . 182, 183, 187
Brake Parking, Electric . . . . . . . . . . . . . . 228
System Warning Light . . . . . . . . 124
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . 289 Antilock . . . . . . . . . . . . . . . . . . . . . . . 227
Assist . . . . . . . . . . . . . . . . . . . . . . . . . 229
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 290
Parking . . . . . . . . . . . . . . . . . . . . . . . 227
Regenerative Braking . . . . . . . . . 230
Braking . . . . . . . . . . . . . . . . . . . . . . . . . 207 Automatic Forward . . . . . . . . . . . 249
Braking System Front Pedestrian (FPB) . . . . . . . 251
Break-In, New Vehicle . . . . . . . . . . 216
Bulb Replacement Halogen Bulbs . . . . . . . . . . . . . . . . 296
Headlamp Aiming . . . . . . . . . . . . . 296 Bulb Replacement (cont'd)
Headlamps . . . . . . . . . . . . . . . . . . . 296
Headlamps, Front Turn
Signal, Sidemarker, and
Parking Lamps . . . . . . . . . . . . . . 297
License Plate Lamps . . . . . . . . . 300
Taillamps, Turn Signal, Stoplamps, and
Back-up Lamps . . . . . . . . 298, 299
Buying New Tires . . . . . . . . . . . . . . . 324
C
Calibration . . . . . . . . . . . . . . . . . . . . . . 107
California Fuel Requirements . . . . . . . . . . . 258
Perchlorate MaterialsRequirements . . . . . . . . . . . . . . . 270
California Proposition
65 Warning . . . . . . . . . .269, 291, 343,
Back Cover
Canadian Vehicle Owners . . . . . . . . 2
Capacities and Specifications . . . . . . . . . . . . . . . . . 373
Carbon Monoxide Engine Exhaust . . . . . . . . . . . . . . . 223
Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Winter Driving . . . . . . . . . . . . . . . . .211

Chevrolet Malibu Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11348460) - 2018 - crc - 5/3/17
402 Index
CargoTie-Downs . . . . . . . . . . . . . . . . . . . . 103
Caution, Danger, and Warning . . . . 2
Center Console Storage . . . . . . . . 103
Chains, Tire . . . . . . . . . . . . . . . . . . . . 328
Charging Wireless . . . . . . . . . . . . . . . . . . . . . . .110
Charging System Light . . . . . . . . . 122
Check Engine Light (MalfunctionIndicator) . . . . . . . . . . . . . . . . . . . . 122
Child Restraints Infants and Young Children . . . . . 86
Lower Anchors and Tethersfor Children . . . . . . . . . . . . . . . . . . . 91
Older Children . . . . . . . . . . . . . . . . . . 84
Securing . . . . . . . . . . . . . . . . . . . . 97, 99
Systems . . . . . . . . . . . . . . . . . . . . . . . . 88
Circuit Breakers . . . . . . . . . . . . . . . . 301
Cleaning Exterior Care . . . . . . . . . . . . . . . . . 349
Interior Care . . . . . . . . . . . . . . . . . . 354
Climate Control Systems . . . . . . . 196 Air Conditioning . . . . . . . . . . . . . . 196
Dual Automatic . . . . . . . . . . . . . . . 199
Heating . . . . . . . . . . . . . . . . . . . . . . . 196
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Cluster, Instrument . . . . . . . . 112, 114 Collision Damage Repair . . . . . . . 382
Compact Spare Tire . . . . . . . . . . . . 342
Compartments
Storage . . . . . . . . . . . . . . . . . . . . . . . 102
Compass . . . . . . . . . . . . . . . . . . . . . . . 107
Compressor Kit, Tire Sealant . . . 331
Connections OnStar . . . . . . . . . . . . . . . . . . . . . . . 392
Control Traction and ElectronicStability . . . . . . . . . . . . . . . . . . . . . 231
Control of a Vehicle . . . . . . . . . . . . . 207
Convenience Net . . . . . . . . . . . . . . . 103
Convex Mirrors . . . . . . . . . . . . . . . . . . 48
Coolant Engine Temperature Gauge . . .119
Cooling . . . . . . . . . . . . . . . . . . . . 196, 199
Cooling System . . . . . . . . . . . . 283, 287
Courtesy Lamps . . . . . . . . . . . . . . . . 159
Courtesy Transportation Program . . . . . . . . . . . . . . . . . . . . . . . 381
Cruise Control . . . . . . . . . . . . . . . . . . 233 Light . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Cruise Control, Adaptive . . . . . . . . 235
Cupholders . . . . . . . . . . . . . . . . . . . . . 102
Customer Assistance . . . . . . . . . . . 378 Offices . . . . . . . . . . . . . . . . . . . . . . . . 377 Customer Assistance (cont'd)
Text Telephone (TTY)
Users . . . . . . . . . . . . . . . . . . . . . . . 378
Customer Information
Service PublicationsOrdering Information . . . . . . . . 384
Customer Satisfaction Procedure . . . . . . . . . . . . . . . . . . . . . 375
D
Damage Repair, Collision . . . . . . . 382
Danger, Warning, and Caution . . . . 2
Data CollectionInfotainment System . . . . . . . . . . 388
OnStar . . . . . . . . . . . . . . . . . . . . . . . 388
Data Recorders, Event . . . . . . . . . 387
Daytime Running Lamps (DRL) . . . . . . . . . . . . . . . . . . 156
Defensive Driving . . . . . . . . . . . . . . . 207
Delayed Locking . . . . . . . . . . . . . . . . . 42
Diagnostics
OnStar . . . . . . . . . . . . . . . . . . . . . . . 394
Distracted Driving . . . . . . . . . . . . . . . 206
Dome Lamps . . . . . . . . . . . . . . . . . . . 159
Door Ajar Light . . . . . . . . . . . . . . . . . . . . . 130
Delayed Locking . . . . . . . . . . . . . . . . 42
Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Power Locks . . . . . . . . . . . . . . . . . . . . 42
