2018 CHEVROLET CRUZE service indicator

Chevrolet Cruze Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11348462) - 2018 - crc - 5/15/17
Vehicle Care 277
Open the cap with the washer
symbol on it. Add washer fluid until
the tank is full. SeeEngine
Compartment Overview 0262 for
reservoir location.
Caution
. Do not use washer fluid that
contains any type of water
repellent coating. This can
cause the wiper blades to
chatter or skip.
. Do not use engine coolant
(antifreeze) in the
windshield washer. It can
damage the windshield
washer system and paint.
. Do not mix water with
ready-to-use washer fluid.
Water can cause the
solution to freeze and
damage the washer fluid
tank and other parts of the
washer system.
(Continued)
Caution (Continued)
.When using concentrated
washer fluid, follow the
manufacturer instructions for
adding water.
. Fill the washer fluid tank
only three-quarters full when
it is very cold. This allows
for fluid expansion if
freezing occurs, which could
damage the tank if it is
completely full.
Brakes
Disc brake pads have built-in wear
indicators that make a high-pitched
warning sound when the brake pads
are worn and new pads are needed.
The sound can come and go or be
heard all the time the vehicle is
moving, except when applying the
brake pedal firmly.
{Warning
The brake wear warning sound
means that soon the brakes will
not work well. That could lead to
a crash. When the brake wear
warning sound is heard, have the
vehicle serviced.
Caution
Continuing to drive with worn-out
brake pads could result in costly
brake repair.
Some driving conditions or climates
can cause a brake squeal when the
brakes are first applied or lightly
applied. This does not mean
something is wrong with the brakes.
Properly torqued wheel nuts are
necessary to help prevent brake
pulsation. When tires are rotated,
inspect brake pads for wear and
evenly tighten wheel nuts in the

Chevrolet Cruze Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11348462) - 2018 - crc - 5/15/17
278 Vehicle Care
proper sequence to torque
specifications inCapacities and
Specifications 0364.
If the vehicle has rear drum brakes,
they do not have wear indicators,
but if a rear brake rubbing noise is
heard, have the rear brake linings
inspected immediately. Rear brake
drums should be removed and
inspected each time the tires are
removed for rotation or changing.
Drum brakes have an inspection
hole to inspect lining wear during
scheduled maintenance. When the
front brake pads are replaced, have
the rear brakes inspected, too.
Brake linings should always be
replaced as complete axle sets.
Brake Pedal Travel
See your dealer if the brake pedal
does not return to normal height,
or if there is a rapid increase in
pedal travel. This could be a sign
that brake service may be required.
Replacing Brake System Parts
Always replace brake system parts
with new, approved replacement
parts. If this is not done, the brakes may not work properly. The braking
performance expected can change
in many other ways if the wrong
replacement brake parts are
installed or parts are improperly
installed.
Brake Fluid
The brake/clutch master cylinder
reservoir is filled with GM approved
DOT 3 brake fluid as indicated on
the reservoir cap. See
Engine
Compartment Overview 0262 for
the location of the reservoir.
Checking Brake Fluid
Place the vehicle in P (Park) or
Neutral with the parking brake
applied if equipped with a manual
transmission. On a level surface,
the brake fluid level should be between the minimum and
maximum marks on the brake fluid
reservoir.
There are only two reasons why the
brake fluid level in the reservoir may
go down:
.
Normal brake lining wear. When
new linings are installed, the
fluid level goes back up.
. A fluid leak in the brake/clutch
hydraulic system. Have the
brake/clutch hydraulic system
fixed. With a leak, the brakes will
not work well.
Always clean the brake fluid
reservoir cap and the area around
the cap before removing it.
Do not top off the brake/clutch fluid.
Adding fluid does not correct a leak.
If fluid is added when the linings are
worn, there will be too much fluid
when new brake linings are
installed. Add or remove fluid, as
necessary, only when work is done
on the brake/clutch hydraulic
system.

Chevrolet Cruze Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11348462) - 2018 - crc - 5/15/17
358 Service and Maintenance
of leaking, blown seals,
or damage, and can advise
when service is needed.
Tires
Tires need to be properly inflated,
rotated, and balanced. Maintaining
the tires can save money and fuel,
and can reduce the risk of tire
failure.
. Signs that the tires need to be
replaced include three or more
visible treadwear indicators; cord
or fabric showing through the
rubber; cracks or cuts in the
tread or sidewall; or a bulge or
split in the tire.
. Trained dealer technicians can
inspect and recommend the right
tires. Your dealer can also
provide tire/wheel balancing
services to ensure smooth
vehicle operation at all speeds.
Your dealer sells and services
name brand tires.
Vehicle Care
To help keep the vehicle looking like
new, vehicle care products are
available from your dealer. For information on how to clean and
protect the vehicle’s interior and
exterior, see
Interior Care 0344 and
Exterior Care 0339.
Wheel Alignment
Wheel alignment is critical for
ensuring that the tires deliver
optimal wear and performance.
. Signs that the alignment may
need to be adjusted include
pulling, improper vehicle
handling, or unusual tire wear.
. Your dealer has the required
equipment to ensure proper
wheel alignment.
Windshield
For safety, appearance, and the
best viewing, keep the windshield
clean and clear.
. Signs of damage include
scratches, cracks, and chips.
. Trained dealer technicians can
inspect the windshield and
recommend proper replacement
if needed. Wiper Blades
Wiper blades need to be cleaned
and kept in good condition to
provide a clear view.
.
Signs of wear include streaking,
skipping across the windshield,
and worn or split rubber.
. Trained dealer technicians can
check the wiper blades and
replace them when needed.

Chevrolet Cruze Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11348462) - 2018 - crc - 5/15/17
396 Index
Fuel (cont'd)Cold Weather Operation . . . . . . 250
Diesel Engines . . . . . . . . . . . . . . . 246
Economy Driving . . . . . . . . . . . . . . . 28
Filling a Portable Fuel
Container . . . . . . . . . . . . . . . . . . . 256
Filling the Tank . . . . . . . . . . . . . . . 254
Filter . . . . . . . . . . . . . . . . . . . . . . . . . . 280
Filter Replacement . . . . . . . . . . . 254
Foreign Countries . . . . . . . . . . . . 245
Gauge . . . . . . . . . . . . . . . . . . . . . . . . 126
Low Fuel Warning Light . . . . . . . 136
Requirements, California . . . . . 245
Running out of Fuel . . . . . . . . . . . 253
Water in Fuel . . . . . . . . . . . . . . . . . 250
What to Use in the U.S. . . . . . . 246
Fuel for Diesel Engines . . . . . . . . . 246
Fuses Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . 291
Fuses and Circuit Breakers . . . 290
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 295
G
Gas Strut(s) . . . . . . . . . . . . . . . . . . . . 283
GaugesEngine Coolant
Temperature . . . . . . . . . . . . . . . . 127 Gauges (cont'd)
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Odometer . . . . . . . . . . . . . . . . . . . . . 125
Speedometer . . . . . . . . . . . . . . . . . 125
Tachometer . . . . . . . . . . . . . . . . . . . 125
Trip Odometer . . . . . . . . . . . . . . . . 125
Warning Lights and
Indicators . . . . . . . . . . . . . . . . . . . .119
General Information
Service and Maintenance . . . . . 349
Towing . . . . . . . . . . . . . . . . . . . . . . . . 257
Vehicle Care . . . . . . . . . . . . . . . . . . 259
Glove Box . . . . . . . . . . . . . . . . . . . . . . 107
GM Mobility Reimbursement Program . . . . . . . . . . . . . . . . . . . . . . . 371
H
Halogen Bulbs . . . . . . . . . . . . . . . . . . 284
Hands-Free Phone . . . . . . . . . . . . . 181
Hazard Warning Flashers . . . . . . . 156
Head Restraints . . . . . . . . . . . . . . . . . 61
HeadlampsAiming . . . . . . . . . . . . . . . . . . . . . . . . 284
Automatic . . . . . . . . . . . . . . . . . . . . . 155
Bulb Replacement . . . . . . . 284, 285
Daytime RunningLamps (DRL) . . . . . . . . . . . . . . . . 155
Flash-to-Pass . . . . . . . . . . . . . . . . . 155 Headlamps (cont'd)
High Intensity Discharge
(HID) Lighting . . . . . . . . . . . . . . . 285
High-Beam On Light . . . . . . . . . . 137
High/Low Beam Changer . . . . . 155
Lamps On Reminder . . . . . . . . . 137
Heated Rear Seats . . . . . . . . . . . . . . . . . . . . . 68
Steering Wheel . . . . . . . . . . . . . . . . 111
Heated Front Seats . . . . . . . . . . . . . . 64
Heated Mirrors . . . . . . . . . . . . . . . . . . . 55
Heater Engine . . . . . . . . . . . . . . . . . . . . . . . . 213
Heating . . . . . . . . . . . . . . .186, 188, 190
High-Beam On Light . . . . . . . . . . . . 137
High-Speed Operation . . . . . . . . . . 306
Hill and Mountain Roads . . . . . . . . 200
Home Page . . . . . . . . . . . . . . . . . . . . . 164
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . 261
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
How to Wear Seat Belts
Properly . . . . . . . . . . . . . . . . . . . . . . . . 70
HVAC . . . . . . . . . . . . . . . . .186, 188, 190
Hydraulic Clutch . . . . . . . . . . . . . . . . 270

Chevrolet Cruze Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11348462) - 2018 - crc - 5/15/17
398 Index
LocksAutomatic Door . . . . . . . . . . . . . . . . . 46
Delayed Locking . . . . . . . . . . . . . . . . 46
Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Lockout Protection . . . . . . . . . . . . . . 47
Power Door . . . . . . . . . . . . . . . . . . . . . 46
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Loss of Control . . . . . . . . . . . . . . . . . 199
Low Fuel Warning Light . . . . . . . . . 136
Low-Profile Tires . . . . . . . . . . . . . . . . 299
Lower Anchors and Tethers for Children (LATCH
System) . . . . . . . . . . . . . . . . . . . . . . . . 94
M
MaintenanceRecords . . . . . . . . . . . . . . . . . . . . . . 362
Maintenance and Care Additional . . . . . . . . . . . . . . . . . . . . . 356
Maintenance Schedule . . . . . . . . . 350 Recommended Fluids and
Lubricants . . . . . . . . . . . . . . . . . . . 359
Malfunction Indicator Lamp . . . . . 130
Manual Mode . . . . . . . . . . . . . . . . . . . 226
Manual Transmission . . . . . . . . . . . 227 Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 270
Media Avoiding Untrusted Devices . . 169 Messages
Engine Power . . . . . . . . . . . . . . . . 144
Vehicle . . . . . . . . . . . . . . . . . . . . . . . 144
Vehicle Speed . . . . . . . . . . . . . . . . 144
Mirrors Automatic DimmingRearview . . . . . . . . . . . . . . . . . . . . . . 55
Convex . . . . . . . . . . . . . . . . . . . . . . . . . 54
Folding . . . . . . . . . . . . . . . . . . . . . . . . . 55
Heated . . . . . . . . . . . . . . . . . . . . . . . . . 55
Manual Rearview . . . . . . . . . . . . . . . 55
Power . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Mirrors, Interior Rearview . . . . . . . . 55
Monitor System, Tire Pressure . . . . . . . . . . . . . . . . . . . . . . 307
Multi-band Antenna . . . . . . . . . . . . . 169
N
Navigation
OnStar . . . . . . . . . . . . . . . . . . . . . . . 383
New Vehicle Break-In . . . . . . . . . . . 206
O
Odometer . . . . . . . . . . . . . . . . . . . . . . . 125
Trip . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Off-Road Recovery . . . . . . . . . . . . . . . . . . . . . 198
Oil Engine . . . . . . . . . . . . . . . . . . . . . . . . 265 Oil (cont'd)
Engine Oil Life System . . . . . . . 268
Pressure Light . . . . . . . . . . . . . . . . 135
Older Children, Restraints . . . . . . . 87
Online Owner Center . . . . . . . . . . . 370
OnStar Additional
Information . . . . . . . . . . . . . . . . . . . . 387
OnStar Connections . . . . . . . . . . . . 384
OnStar Diagnostics . . . . . . . . . . . . . 386
OnStar Emergency . . . . . . . . . . . . . 382
OnStar Navigation . . . . . . . . . . . . . . 383
OnStar Overview . . . . . . . . . . . . . . . 381
OnStar Security . . . . . . . . . . . . . . . . 383
Operation Fog Lamps . . . . . . . . . . . . . . . . . . . 157
Infotainment System . . . . . . . . . . 164
Ordering Service Publications . . . . . . . . . . 376
Outlets Power . . . . . . . . . . . . . . . . . . . . . . . . .115
Overheating, Engine . . . . . . . . . . . . 275
Overview . . . . . . . . . . . . . . . . . . . . . . . 163P
Park Shifting Into . . . . . . . . . . . . . . . . . . . 215
Shifting Out of . . . . . . . . . . . . . . . . 215
Parking . . . . . . . . . . . . . . . . . . . . . . . . . 216
Brake . . . . . . . . . . . . . . . . . . . . . . . . . 229
