2018 CHEVROLET CORVETTE Memory features

Chevrolet Corvette Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11374030) - 2018 - CRC - 11/8/17
In Brief 5
In Brief
Instrument Panel
Instrument Panel . . . . . . . . . . . . . . . . 6
Initial Drive Information
Initial Drive Information . . . . . . . . . . 8
Remote Keyless Entry (RKE)System . . . . . . . . . . . . . . . . . . . . . . . . 8
Remote Vehicle Start . . . . . . . . . . . 9
Door Locks . . . . . . . . . . . . . . . . . . . . . 9
Trunk Release . . . . . . . . . . . . . . . . . 10
Windows . . . . . . . . . . . . . . . . . . . . . . . 11
Seat Adjustment . . . . . . . . . . . . . . . 12
Memory Features . . . . . . . . . . . . . . 13
Heated and Ventilated Seats . . . 13
Seat Belts . . . . . . . . . . . . . . . . . . . . . 14
Passenger Sensing System . . . 14
Mirror Adjustment . . . . . . . . . . . . . . 15
Steering Wheel Adjustment . . . . 16
Interior Lighting . . . . . . . . . . . . . . . . 16
Exterior Lighting . . . . . . . . . . . . . . . 16
Windshield Wiper/Washer . . . . . . 17
Climate Controls . . . . . . . . . . . . . . . 18
Transmission . . . . . . . . . . . . . . . . . . 19
Vehicle Features
Infotainment System . . . . . . . . . . . 20
Steering Wheel Controls . . . . . . . 20 Cruise Control . . . . . . . . . . . . . . . . . 20
Driver Information
Center (DIC) . . . . . . . . . . . . . . . . . 20
Curb View Camera . . . . . . . . . . . . 21
Rear Vision Camera (RVC) . . . . 21
Power Outlets . . . . . . . . . . . . . . . . . 21
Universal Remote System . . . . . 21
Roof Panel . . . . . . . . . . . . . . . . . . . . 22
Convertible . . . . . . . . . . . . . . . . . . . . 22
Performance and Maintenance
Traction Control/Electronic Stability Control . . . . . . . . . . . . . . 22
Tire Pressure Monitor . . . . . . . . . . 22
Performance Vehicle Features . . . . . . . . . . . . . . . . . . . . . 23
Fuel (LT1 6.2L V8 Engine) . . . . . 23
Fuel (LT4 6.2L Supercharged
V8 Engine) . . . . . . . . . . . . . . . . . . . 24
E85 or FlexFuel . . . . . . . . . . . . . . . . 24
Engine Oil Life System . . . . . . . . 24
Car Wash Guidelines . . . . . . . . . . 25
Driving for Better Fuel Economy . . . . . . . . . . . . . . . . . . . . . 25
Roadside Assistance Program . . . . . . . . . . . . . . . . . . . . . . 25

Chevrolet Corvette Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11374030) - 2018 - CRC - 11/8/17
In Brief 13
Memory Features
If equipped, memory seats allow two
drivers to store and recall their
unique seat positions for driving the
vehicle, and a shared exit position
for getting out of the vehicle. Other
feature positions may also be set,
such as power mirrors and power
steering wheel. Memory positions
are linked to RKE transmitter 1 or 2
for automatic memory recalls.Before storing, adjust all available
memory feature positions. Turn the
ignition on and then press and
release SET; a beep will sound.
Then immediately press and hold 1,
2, or
B(Exit) on the driver door
until two beeps sound. To manually
recall these positions, press and
hold 1, 2, or
Buntil the saved
position is reached.
When Auto Memory Recall is
enabled in the personalization
menu, positions previously stored to
memory buttons 1 and 2 are
recalled when the ignition is
changed from off to on or ACC/
ACCESSORY.
When Easy Exit Options is enabled
in the personalization menu, the
feature automatically recalls the
current driver ’s previously stored
exit position when exiting the
vehicle. See Memory Seats 060.
Heated and Ventilated
Seats
Driver and Passenger Controls
If equipped, the driver buttons are
on the center stack. To operate, the
ignition must be on.
Press
CorMon the left side of the
climate control panel to ventilate or
heat the driver seat. A ventilated
seat has a fan that pulls or pushes
air through the seat. The air is not
cooled.

Chevrolet Corvette Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11374030) - 2018 - CRC - 11/8/17
20 In Brief
Vehicle Features
Infotainment System
See the infotainment manual for
information on the radio, audio
players, phone, navigation system,
and voice or speech recognition.
It also includes information on
settings.
Steering Wheel Controls
The infotainment system can be
operated by using the steering
wheel controls. See "Steering
Wheel Controls" in the infotainment
manual.
Cruise Control
1:Press to turn cruise control on
or off. A white indicator comes on in
the instrument cluster when cruise
is turned on.
RES/+ : If there is a set speed in
memory, press briefly to resume to
that speed or press and hold to
accelerate. If cruise control is
already active, use to increase
vehicle speed. SET/–
:Press briefly to set the
speed and activate cruise control.
If cruise control is already active,
use to decrease vehicle speed.
*: Press to disengage cruise
control without erasing the set
speed from memory.
See Cruise Control 0205.
Driver Information
Center (DIC)
The DIC display is in the instrument
cluster. It shows the status of many
vehicle systems.

Chevrolet Corvette Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11374030) - 2018 - CRC - 11/8/17
Seats and Restraints 61
the first few ignition cycles following
a transmitter change. For Auto
Memory Recall to work properly,
save the positions to the memory
button (1 or 2) matching the RKE
transmitter number displayed in the
DIC welcome message. Carry the
linked RKE transmitter when
entering the vehicle.
Vehicle Personalization Settings
.To have the Auto Memory Recall
movement begin when the
vehicle is started, select the
Settings menu, then Vehicle,
then Comfort and Convenience,
and then Auto Memory Recall.
Select On or Off. See “Auto
Memory Recall” later in this
section.
. To begin Easy Exit Recall
movement when the ignition is
turned off and the driver door is
opened, or when the ignition is
turned off with the driver door
already opened, select the
Settings menu, then Vehicle,
then Comfort and Convenience, and then Easy Exit Options.
Select On or Off. See
“Easy Exit
Recall” later in this section.
. See Vehicle Personalization
0 126 for additional setting
information.
Identifying Driver Number
To identify the driver number: 1. Start the vehicle with the other key or RKE transmitter. The
DIC should display the driver
number; 1 or 2. Turn the
ignition off and remove the key
or RKE transmitter from the
vehicle.
2. Start the vehicle with the initial key or RKE transmitter. The
DIC should display the other
driver number not shown in
step 1.
Saving Memory Positions
Read these instructions completely
before saving memory positions. To save preferred driving positions
1 and 2:
1. Turn the ignition on or to ACC/ ACCESSORY.
A DIC welcome message may
be displayed indicating number
1 or 2 for memory recalls.
2. Adjust all available memory features to the desired driving
position.
3. Press and release SET; a beep will sound.
4. Immediately press and hold the 1 or 2 memory button matching
the above DIC welcome
message until two beeps
sound.
If too much time passes
between releasing SET and
pressing 1, the memory
position will not be saved and
two beeps will not sound,
repeat steps 3 and 4.
1 or 2 corresponds to the driver
number. See “Identifying Driver
Number” in this section.

Chevrolet Corvette Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11374030) - 2018 - CRC - 11/8/17
62 Seats and Restraints
5. Repeat Steps 1–4 for a seconddriver using 1 or 2.
To save positions for
Band easy
exit features, repeat Steps 1–4
using
B. This stores the positions
for getting out of the vehicle.
Manually Recalling Memory
Positions
Press and hold 1, 2, or
Bto recall
the previously stored memory
positions.
To stop manual recall movement,
release 1, 2, or
B. Recall can also
be stopped by pressing a power
seat, SET, power mirror, or power
steering wheel control, if memory
equipped. The driver or passenger
side mirror must be selected.
Auto Memory Recall
The vehicle identifies the number of
the current driver ’s RKE transmitter
(1–8). See Remote Keyless Entry
(RKE) System Operation 028. If the
RKE transmitter is 1 or 2, and Auto
Memory Recall is programmed on in
vehicle personalization, the positions saved to the same
memory button number 1 or 2 are
automatically recalled when the
ignition is turned on, or turned from
off to ACC/ACCESSORY. RKE
transmitters 3–8 will not provide
automatic memory recalls.
To turn Auto Memory Recall on or
off, see "Vehicle Personalization
Settings" previously in this section
and
Vehicle Personalization 0126.
For vehicles equipped with an
automatic transmission, the
transmission must be in P (Park) to
initiate Auto Memory Recall. Auto
Memory Recall will complete if the
vehicle is shifted out of P (Park)
prior to reaching the stored memory
position.
For vehicles equipped with a
manual transmission, the parking
brake must be set to initiate Auto
Memory Recall. Auto Memory
Recall will complete if the parking
brake is released prior to reaching
the stored memory position. To stop Auto Memory Recall
movement, turn the ignition off or
press any of the following memory
controls:
.
Power seat
. Memory SET, 1, 2, or
B
.Power mirror, with the driver or
passenger side mirror selected
. Power steering wheel
If the stored memory seat position
does not automatically recall or
recalls to the wrong positions, the
driver ’s RKE transmitter number (1
or 2) may not match the memory
button number that positions were
saved to. Try storing the position to
the other memory button or try the
other RKE transmitter.
Easy Exit Recall
Easy Exit Recall is not linked to an
RKE transmitter. The position stored
to
Bis used for all drivers. To turn
Easy Exit Recall on or off, see
"Vehicle Personalization Settings"
previously in this section and
Vehicle Personalization 0126.

Chevrolet Corvette Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11374030) - 2018 - CRC - 11/8/17
256 Vehicle Care
You can remove fuses using the
fuse puller.
The vehicle may not be equipped
with all of the fuses, relays, and
features shown.Fuses Usage
1 Window
2 Driver power seat
3 Passive entry/ Passive start 2
4 Passive entry/ Passive start 1
5 Engine control module
6 Heated mirrors
7 Body control module 4
8 Rear window defogger
9 GBS
10 Body control module 2
11 Steering wheel Fuses Usage
12 Passenger power seat
13 –
14 Exterior rearview mirror
15 Body control module 1
16 Body control module 3
17 Sensing diagnostic module/Automatic
occupant sensing
18 Logistics 2
19 Body control module 8
20 Integrated chassis control module
21 Amplifier
22 Rear accessory power outlet
24 Memory seat module/
Convertible top Fuses Usage
25 Theft deterrent PSM
26 Trunk release module
27 OnStar (if equipped)
28 Camera module
29 –
30 Fuel pump power module
31 Trunk release module latch
32 Battery regulated voltage control
33 –
34 Convertible top solenoid
35 –
36 Passenger window switch
37 Front accessory power outlet

Chevrolet Corvette Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11374030) - 2018 - CRC - 11/8/17
350 Index
Electrical SystemEngine Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 252
Fuses . . . . . . . . . . . . . . . . . . . . . . . . 251
Overload . . . . . . . . . . . . . . . . . . . . . 251
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 254
Electronic Stability Control (ESC) Off Light . . . . . . . . . . . . . . . . 115
Emergency OnStar . . . . . . . . . . . . . . . . . . . . . . . 337
Engine Air Cleaner/Filter . . . . . . . . . . . . . 233
Check Light (MalfunctionIndicator) . . . . . . . . . . . . . . . . . . . . . 111
Compartment Overview . . . . . . . 221
Coolant Temperature
Gauge . . . . . . . . . . . . . . . . . . . . . . 108
Coolant Temperature Warning Light . . . . . . . . . . . . . . . .115
Cooling System . . . . . . . . . . 236, 239
Drive Belt Routing . . . . . . . . . . . . 320
Exhaust . . . . . . . . . . . . . . . . . . . . . . 184
Oil Life System . . . . . . . . . . . . . . . 231
Oil Pressure Light . . . . . . . . . . . . .116
Overheating . . . . . . . . . . . . . . . . . . 240
Power Messages . . . . . . . . . . . . . 125
Running While Parked . . . . . . . . 185 Engine (cont'd)
Starting . . . . . . . . . . . . . . . . . . . . . . . 180
Entry Lighting . . . . . . . . . . . . . . . . . . . 141
Event Data Recorders . . . . . . . . . . 333
Exit Lighting . . . . . . . . . . . . . . . . . . . . 141
Extended Parking . . . . . . . . . . . . . . . 184
Extender, Seat Belt . . . . . . . . . . . . . . 70
Exterior Lamp Controls . . . . . . . . . 137
Exterior Lamps Off Reminder . . . 137
Exterior Lighting Battery Saver . . . . . . . . . . . . . . . . . . . . . . . . . 142
F
FeaturesMemory . . . . . . . . . . . . . . . . . . . . . . . . . 13
Filter, Engine Air Cleaner . . . . . . . . . . . 233
Flash-to-Pass . . . . . . . . . . . . . . . . . . . 138
Flashers, Hazard Warning . . . . . . 140
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . 278
Floor Mats . . . . . . . . . . . . . . . . . . . . . . 300
Fluid Automatic Transmission . . . . . . 232
Brakes . . . . . . . . . . . . . . . . . . . . . . . . 243
Washer . . . . . . . . . . . . . . . . . . . . . . . 241
Folding Mirrors . . . . . . . . . . . . . . . . . . 45
Frequency Statement Radio . . . . . . . . . . . . . . . . . . . . . . . . . 331 Front Air Dam . . . . . . . . . . . . . . . . . . 178
Front Seats
Heated and Ventilated . . . . . . . . . . 64
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 210 Additives . . . . . . . . . . . . . . . . . . . . . .211
Economy Driving . . . . . . . . . . . . . . . 25
Filling a Portable FuelContainer . . . . . . . . . . . . . . . . . . . 213
Filling the Tank . . . . . . . . . . . . . . . 212
Foreign Countries . . . . . . . . . . . . .211
Gauge . . . . . . . . . . . . . . . . . . . . . . . . 106
Low Fuel Warning Light . . . . . . . .117
Management, Active . . . . . . . . . . 184
Requirements, California . . . . . .211
Fuses . . . . . . . . . . . . . . . . . . . . . . . . . . 251 Engine Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 252
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 254
G
Garage Door Opener . . . . . . . . . . . 133Programming . . . . . . . . . . . . . . . . . 133
Gas Strut(s) . . . . . . . . . . . . . . . . . . . . 248
Gauges Boost . . . . . . . . . . . . . . . . . . . . . . . . . 107
Engine Coolant
Temperature . . . . . . . . . . . . . . . . 108

Chevrolet Corvette Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11374030) - 2018 - CRC - 11/8/17
352 Index
Lamps (cont'd)Reading . . . . . . . . . . . . . . . . . . . . . . 141
Lap-Shoulder Belt . . . . . . . . . . . . . . . 68
LATCH, Lower Anchors and Tethers for Children . . . . . . . . . . . . 88
Latches, Seatback . . . . . . . . . . . . . . . 63
LED Lighting . . . . . . . . . . . . . . . . . . . . 250
Lifting the Vehicle, Tires . . . . . . . . 217
Lighting Entry . . . . . . . . . . . . . . . . . . . . . . . . . 141
Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
Illumination Control . . . . . . . . . . . 141
LED . . . . . . . . . . . . . . . . . . . . . . . . . . 250
Lights
Airbag Readiness . . . . . . . . . . . . . 109
Antilock Brake System(ABS) Warning . . . . . . . . . . . . . . .114
Brake System Warning . . . . . . . .113
Charging System . . . . . . . . . . . . . . 111
Check Engine (Malfunction
Indicator) . . . . . . . . . . . . . . . . . . . . . 111
Cruise Control . . . . . . . . . . . . . . . . .118
Door Ajar . . . . . . . . . . . . . . . . . . . . . .118
Electric Parking Brake . . . . . . . . .113
Electronic Stability Control (ESC), Off . . . . . . . . . . . . . . . . . . . .115
Engine Coolant Temperature Warning . . . . . . . .115 Lights (cont'd)
Engine Oil Pressure . . . . . . . . . . .116
Flash-to-Pass . . . . . . . . . . . . . . . . . 138
High-Beam On . . . . . . . . . . . . . . . . .117
High/Low Beam Changer . . . . . 138
Low Fuel Warning . . . . . . . . . . . . .117
Seat Belt Reminders . . . . . . . . . . 109
Security . . . . . . . . . . . . . . . . . . . . . . .117
Service Electric Parking
Brake . . . . . . . . . . . . . . . . . . . . . . . .114
Tire Pressure . . . . . . . . . . . . . . . . . .116
Traction Off . . . . . . . . . . . . . . . . . . . .114
Limited-Slip Differential . . . . . . . . . 205
Locks Automatic Door . . . . . . . . . . . . . . . . . 38
Delayed Locking . . . . . . . . . . . . . . . . 38
Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Lockout Protection . . . . . . . . . . . . . . 38
Power Door . . . . . . . . . . . . . . . . . . . . . 37
Loss of Control . . . . . . . . . . . . . . . . . 159
Low Fuel Warning Light . . . . . . . . . 117
Low-Profile Tires . . . . . . . . . . . . . . . . 259
Lower Anchors and Tethers for Children (LATCH
System) . . . . . . . . . . . . . . . . . . . . . . . . 88
Lumbar Adjustment . . . . . . . . . . . . . . 59 Front Seats . . . . . . . . . . . . . . . . . . . . . 59M
MaintenanceRecords . . . . . . . . . . . . . . . . . . . . . . 316
Maintenance and Care Additional . . . . . . . . . . . . . . . . . . . . . 310
Maintenance Schedule . . . . . . . . . 304 Recommended Fluids andLubricants . . . . . . . . . . . . . . . . . . . 313
Malfunction Indicator Lamp . . . . . 111
Manual Mode . . . . . . . . . . . . . . . . . . . 187
Manual Transmission . . . . . . . . . . . 190 Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 233
Matching Active Rev . . . . . . . . . . . . . . . . . . . . 191
Memory Features . . . . . . . . . . . . . . . . 13
Memory Seats . . . . . . . . . . . . . . . . . . . 60
Messages Engine Power . . . . . . . . . . . . . . . . 125
Vehicle . . . . . . . . . . . . . . . . . . . . . . . 125
Vehicle Speed . . . . . . . . . . . . . . . . 126
Mirrors Automatic Dimming . . . . . . . . . . . . . 45
Automatic DimmingRearview . . . . . . . . . . . . . . . . . . . . . . 46
Convex . . . . . . . . . . . . . . . . . . . . . . . . . 44
Folding . . . . . . . . . . . . . . . . . . . . . . . . . 45
Heated . . . . . . . . . . . . . . . . . . . . . . . . . 45
Manual Rearview . . . . . . . . . . . . . . . 46
