2018 CHEVROLET BOLT EV keyless entry

Chevrolet BOLT EV Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11434431) - 2018 - crc - 2/14/18
Driving and Operating 205
If the vehicle must be shut off in an
emergency:1. Brake using a firm and steady pressure. Do not pump the
brakes repeatedly. This may
deplete power assist, requiring
increased brake pedal force.
2. Shift the vehicle to N (Neutral). This can be done while the
vehicle is moving. After shifting
to N (Neutral), firmly apply the
brakes and steer the vehicle to
a safe location.
3. Come to a complete stop, shift to P (Park), and turn the vehicle
off by pressing POWER
O.
4. Set the parking brake.
{Warning
Turning off the vehicle while
moving may disable the airbags.
While driving, only shut the
propulsion system off in an
emergency. If the vehicle cannot be pulled over,
and must be shut off while driving,
press and hold POWER
Ofor
longer than two seconds, or press
twice in five seconds.
Starting and Stopping the
Vehicle
Starting Procedure
Press the P (Park) button on the
shift lever, or move the shift lever
into N (Neutral). The propulsion
system will not start in any other
position.
Caution
Do not try to shift to P (Park) if the
vehicle is moving or the electric
drive unit could be damaged.
Shift to P (Park) only when the
vehicle is stopped.
Caution
If you add electrical parts or
accessories, you could change
the way the vehicle operates. Any
resulting damage would not be
covered by the vehicle warranty.
The Remote Keyless Entry (RKE)
transmitter must be in the vehicle.
Press the brake pedal, then press
and release POWER
O.
If the RKE transmitter is not in the
vehicle or something is interfering
with the transmitter, a message
displays in the Driver Information
Center (DIC).
If the vehicle will not start due to a
low RKE transmitter battery, the
vehicle can still be driven. See
Remote Keyless Entry (RKE)
System Operation 033.

Chevrolet BOLT EV Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11434431) - 2018 - crc - 2/14/18
Driving and Operating 207
see the P (Park) indicator in
instrument cluster, it means that the
vehicle has not shifted to P (Park).
Shifting out of Park
To shift out of P (Park), the vehicle
must be on, the brake pedal must
be applied, and the charge cord
must be unplugged.
This vehicle is equipped with an
electric drive unit. The shift lock
release button is designed to
prevent inadvertent shifting out of
P (Park) unless the ignition is on,
the brake pedal is applied, and the
shift lock release button is pressed.Parking the vehicle in extreme cold
for several days without the charge
cord connected may cause the
vehicle not to start. The vehicle will
need to be plugged in to allow the
high voltage battery to be warmed
sufficiently.
The shift lock is always functional
except in the case of an uncharged
or low charged 12-volt battery (less
than 9 volts).
If the vehicle has an uncharged
12-volt battery or a 12-volt battery
with low voltage, try charging or
jump starting the 12-volt battery.
To shift out of P (Park):
1. Apply the brake pedal.
2. Press POWER
Oto start the
vehicle.
3. Verify that the vehicle is unplugged and the vehicle
ready light is on.
4. Press the shift lock release button on the side of the shift
lever. 5. Move the shift lever into the
desired position.
6. The P indicator will turn white and the gear indicator on the
shift lever will turn red when
the vehicle is no longer in
P (Park).
7. After releasing the shift lever, it will return to the center
position.
Extended Parking
It is best not to park with the vehicle
running. If the vehicle is left running,
be sure it will not move. See Shifting
Into Park 0206.
If the vehicle is left parked and
running with the Remote Keyless
Entry (RKE) transmitter outside the
vehicle, it will turn off after one hour.
If the vehicle is left parked and
running with the RKE transmitter
inside the vehicle, it will turn off after
two hours.
The timer will reset if the vehicle is
taken out of P (Park) while it is
running.

Chevrolet BOLT EV Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11434431) - 2018 - crc - 2/14/18
256 Vehicle Care
California Perchlorate
Materials Requirements
Certain types of automotive
applications, such as airbag
initiators, seat belt pretensioners,
and lithium batteries contained in
Remote Keyless Entry transmitters,
may contain perchlorate materials.
Special handling may be necessary.
For additional information, see
www.dtsc.ca.gov/hazardouswaste/
perchlorate.
Accessories and
Modifications
Adding non-dealer accessories or
making modifications to the vehicle
can affect vehicle performance and
safety, including such things as
airbags, braking, stability, ride and
handling, emissions systems,
aerodynamics, durability, and
electronic systems like antilock
brakes, traction control, and stability
control. These accessories or
modifications could even cause
malfunction or damage not covered
by the vehicle warranty.Damage to suspension components
caused by modifying vehicle height
outside of factory settings will not be
covered by the vehicle warranty.
Damage to vehicle components
resulting from modifications or the
installation or use of non-GM
certified parts, including control
module or software modifications, is
not covered under the terms of the
vehicle warranty and may affect
remaining warranty coverage for
affected parts.
GM Accessories are designed to
complement and function with other
systems on the vehicle. See your
dealer to accessorize the vehicle
using genuine GM Accessories
installed by a dealer technician.
Also, see
Adding Equipment to the
Airbag-Equipped Vehicle 081.
Vehicle Checks
Doing Your Own
Service Work
{Warning
Never try to do your own service
on high voltage battery
components. You can be injured
and the vehicle can be damaged
if you try to do your own service
work. Service and repair of these
high voltage battery components
should only be performed by a
trained dealer technician with the
proper knowledge and tools.
Exposure to high voltage can
cause shock, burns, and even
death. The high voltage
components in the vehicle can
only be serviced by technicians
with special training.
(Continued)

Chevrolet BOLT EV Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11434431) - 2018 - crc - 2/14/18
362 Index
General InformationService and Maintenance . . . . . 321
Towing . . . . . . . . . . . . . . . . . . . . . . . . 252
Vehicle Care . . . . . . . . . . . . . . . . . . 255
GM Mobility Reimbursement Program . . . . . . . . . . . . . . . . . . . . . . . 336
H
Halogen Bulbs . . . . . . . . . . . . . . . . . . 269
Hands-Free Phone . . . . . . . . . . . . . 178
Hazard Warning Flashers . . . . . . . 153
Head Restraints . . . . . . . . . . . . . . . . . 57
HeadlampsAiming . . . . . . . . . . . . . . . . . . . . . . . . 269
Automatic . . . . . . . . . . . . . . . . . . . . . 153
Bulb Replacement . . . . . . . . . . . . 269
Daytime RunningLamps (DRL) . . . . . . . . . . . . . . . . 152
Flash-to-Pass . . . . . . . . . . . . . . . . . 152
High Intensity Discharge (HID) Lighting . . . . . . . . . . . . . . . 269
High-Beam On Light . . . . . . . . . . 130
High/Low Beam Changer . . . . . 152
Lamps On Reminder . . . . . . . . . 130
Heated Rear Seats . . . . . . . . . . . . . . . . . . . . . 64
Steering Wheel . . . . . . . . . . . . . . . .110
Heated Front Seats . . . . . . . . . . . . . . 60 Heating . . . . . . . . . . . . . . . . . . . . . . . . . 186
High Voltage Battery Gauge . . . . 122
High Voltage Devices and
Wiring . . . . . . . . . . . . . . . . . . . . . . . . . 271
High-Beam On Light . . . . . . . . . . . . 130
Hill and Mountain Roads . . . . . . . . 198
Hill Start Assist (HSA) . . . . . . . . . . 215
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . 257
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
How to Wear Seat Belts Properly . . . . . . . . . . . . . . . . . . . . . . . . 66
HVAC . . . . . . . . . . . . . . . . . . . . . . . . . . . 186
I
Immobilizer . . . . . . . . . . . . . . . . . . . . . . 48
Indicator Pedestrian Ahead . . . . . . . . . . . . 128
Vehicle Ahead . . . . . . . . . . . . . . . . 128
Infants and Young Children, Restraints . . . . . . . . . . . . . . . . . . . . . . 85
Information
Energy . . . . . . . . . . . . . . . . . . . . . . . 138
Instrument Cluster . . . . . . . . . . . . . . 118
Instrument Panel Storage Area . . . . . . . . . . . . . . . . . 105
Interior Rearview Mirrors . . . . . . . . . 51
Introduction . . . . . . . . . . . . . . . . . . 2, 157
J
Jump Starting - North
America . . . . . . . . . . . . . . . . . . . . . . . 304
K
Keyless EntryRemote (RKE) System . . . . . . . . . 33
KeyPass . . . . . . . . . . . . . . . . . . . . . . . . . 45
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
L
Labeling, Tire Sidewall . . . . . . . . . . 280
Lamps Courtesy . . . . . . . . . . . . . . . . . . . . . . 155
Daytime Running (DRL) . . . . . . 152
Dome . . . . . . . . . . . . . . . . . . . . . . . . . 155
Exterior Controls . . . . . . . . . . . . . . 150
Exterior Lamps OffReminder . . . . . . . . . . . . . . . . . . . 152
Exterior Lighting Battery Saver . . . . . . . . . . . . . . . . . . . . . . . 156
License Plate . . . . . . . . . . . . . . . . . 270
On Reminder . . . . . . . . . . . . . . . . . 130
Reading . . . . . . . . . . . . . . . . . . . . . . 155
Lane Change Alert (LCA) . . . . . . . 231
Lane Departure
Warning (LDW) . . . . . . . . . . . . . . . . 233
Lane Keep Assist (LKA) . . . . . . . . 233
Lane Keep Assist Light . . . . . . . . . 127

Chevrolet BOLT EV Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11434431) - 2018 - crc - 2/14/18
Index 365
R
Radio Frequency Statement . . . . 342
RadiosAM-FM Radio . . . . . . . . . . . . . . . . . 162
Satellite . . . . . . . . . . . . . . . . . . . . . . . 164
Reading Lamps . . . . . . . . . . . . . . . . . 155
Ready Indicator . . . . . . . . . . . . . . . . . 130
Rear Camera Mirror . . . . . . . . . . . . . 51
Rear Seat Armrest . . . . . . . . . . . . . . . 64
Rear Seats . . . . . . . . . . . . . . . . . . . . . . 62 Heated . . . . . . . . . . . . . . . . . . . . . . . . . 64
Rear Vision Camera (RVC) . . . . . 222
Rear Window Washer/Wiper . . . . 112
Rearview Mirrors . . . . . . . . . . . . . . . . 51 Automatic Dimming . . . . . . . . . . . . . 51
Reclining Seatbacks . . . . . . . . . . . . . 59
Recommended Fluids and Lubricants . . . . . . . . . . . . . . . . . . . . . 327
Records
Maintenance . . . . . . . . . . . . . . . . . . 329
Recreational Vehicle Towing . . . . 309
Regenerative Braking . . . . . . . . . . . 215
Reimbursement Program, GM Mobility . . . . . . . . . . . . . . . . . . . 336
Remote Keyless Entry (RKE) System . . . . . . . . . . . . . . . . . . . . . . . . . 33
Remote Start . . . . . . . . . . . . . . . . . . . . 39 Replacement Parts
Airbags . . . . . . . . . . . . . . . . . . . . . . . . . 82
Maintenance . . . . . . . . . . . . . . . . . . 328
Replacing Airbag System . . . . . . . . 82
Replacing LATCH System Parts after a Crash . . . . . . . . . . . . . 99
Replacing Seat Belt System
Parts after a Crash . . . . . . . . . . . . . 70
Reporting Safety Defects Canadian Government . . . . . . . . 343
General Motors . . . . . . . . . . . . . . . 343
U.S. Government . . . . . . . . . . . . . 342
Requirements Electrical Battery Charging . . . 251
Restraints Where to Put . . . . . . . . . . . . . . . . . . . 89
Retained Accessory Power (RAP) . . . . . . . . . . . . . . . . . . 206
Roads Driving, Wet . . . . . . . . . . . . . . . . . . 197
Roadside Assistance
Program . . . . . . . . . . . . . . . . . . . . . . . 336
Rotation, Tires . . . . . . . . . . . . . . . . . . 290
S
Safety Defects Reporting Canadian Government . . . . . . . . 343
General Motors . . . . . . . . . . . . . . . 343 Safety Defects Reporting (cont'd)
U.S. Government . . . . . . . . . . . . . 342
Safety Locks . . . . . . . . . . . . . . . . . . . . . 44
Safety Signal Pedestrian . . . . . . . . . . . . . . . . . . . . .110
Safety System Check . . . . . . . . . . . . 69
Satellite Radio . . . . . . . . . . . . . . . . . . 164
Scheduling Appointments . . . . . . . 338
Sealant Kit, Tire . . . . . . . . . . . . . . . . 297
Seat Belts . . . . . . . . . . . . . . . . . . . . . . . 65 Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Extender . . . . . . . . . . . . . . . . . . . . . . . . 69
How to Wear Seat BeltsProperly . . . . . . . . . . . . . . . . . . . . . . . 66
Lap-Shoulder Belt . . . . . . . . . . . . . . 67
Reminders . . . . . . . . . . . . . . . . . . . . 123
Replacing after a Crash . . . . . . . . 70
Use During Pregnancy . . . . . . . . . . 69
Seats Adjustment, Front . . . . . . . . . . . . . . . 59
Head Restraints . . . . . . . . . . . . . . . . 57
Heated Front . . . . . . . . . . . . . . . . . . . 60
Heated, Rear . . . . . . . . . . . . . . . . . . . 64
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Reclining Seatbacks . . . . . . . . . . . . 59
Securing Child Restraints . . . 99, 101
Security Light . . . . . . . . . . . . . . . . . . . . . . . . . . 130
