2018 Alfa Romeo 4C Spider service indicator

DEALER SERVICE
The pages that follow contain therequiredmaintenance
services determined by the engineers who designed
your vehicle.
Besides those maintenance items specified in the fixed
maintenance schedule, there are other components
which may require servicing or replacement in the
future.
CAUTION!
• Failure to properly maintain your vehicle or per-
form repairs and service when necessary could
result in more costly repairs, damage to other
components or negatively impact vehicle perfor-
mance. Immediately have potential malfunctions
examined by an authorized dealer or qualified
repair center.
• Your vehicle has been built with improved fluids
that protect the performance and durability of
your vehicle and also allow extended mainte-
nance intervals. Do not use chemical flushes in
these components as the chemicals can damage
(Continued)
CAUTION! (Continued)
your engine, transmission, or air conditioning.
Such damage is not covered by the New Vehicle
Limited Warranty. If a flush is needed because of
component malfunction, use only the specified
fluid for the flushing procedure.
Engine Oil
Change Engine Oil
The oil change indicator system will remind you that it
is time to take your vehicle in for scheduled mainte-
nance. Refer to the “Maintenance Plan” for further
information.
NOTE:The actual interval for changing the oil and
replacing the engine oil filter depends on the vehicle
usage conditions and is signalled by the warning light
or message (if present) on the instrument panel or every
12 months.
Engine Oil Selection
For best performance and maximum protection for
turbocharged engines under all types of operating
conditions, the manufacturer recommends synthetic
212 SERVICING AND MAINTENANCE

Consult an authorized tire dealer for tire repairs and
additional information.
Damaged Run Flat tires, or Run Flat tires that have
experienced a loss of pressure should be replaced
immediately with another Run Flat tire of identical size
and service description (Load Index and Speed Sym-
bol).
Run Flat Tires — If Equipped
Run Flat tires allow you the capability to drive 50 miles
(80 km) at 50 mph (80 km/h) after a rapid loss of
inflation pressure. This rapid loss of inflation is referred
to as the Run Flat mode. A Run Flat mode occurs when
the tire inflation pressure is of/or below 14 psi (96 kPa).
Once a Run Flat tire reaches the run flat mode it has
limited driving capabilities and needs to be replaced
immediately. A Run Flat tire is not repairable.
It is not recommended driving a vehicle loaded at full
capacity or to tow a trailer while a tire is in the run flat
mode.
See the tire pressure monitoring section for more infor-
mation.
Tire Spinning
When stuck in mud, sand, snow, or ice conditions, do
not spin your vehicle’s wheels above 30 mph (48 km/h)
or for longer than 30 seconds continuously without
stopping.
Refer to “Freeing A Stuck Vehicle” in “In Case Of
Emergency” for further information.
WARNING!
Fast spinning tires can be dangerous. Forces gener-
ated by excessive wheel speeds may cause tire
damage or failure. A tire could explode and injure
someone. Do not spin your vehicle’s wheels faster
than 30 mph (48 km/h) for more than 30 seconds
continuously when you are stuck, and do not let
anyone near a spinning wheel, no matter what the
speed.
Tread Wear Indicators
Tread wear indicators are in the original equipment
tires to help you in determining when your tires should
be replaced.
242 SERVICING AND MAINTENANCE

These indicators are molded into the bottom of the tread
grooves. They will appear as bands when the tread
depth becomes a 1/16 of an inch (1.6 mm). When the
tread is worn to the tread wear indicators, the tire
should be replaced. Refer to “Replacement Tires” in this
section for further information.
Life Of Tire
The service life of a tire is dependent upon varying
factors including, but not limited to:
•Driving style.
• Tire pressure - Improper cold tire inflation pressures
can cause uneven wear patterns to develop across the
tire tread. These abnormal wear patterns will reduce
tread life, resulting in the need for earlier tire replace-
ment.
• Distance driven.
• Performance tires, tires with a speed rating of V or
higher, and Summer tires typically have a reduced
tread life. Rotation of these tires per the vehicle
scheduled maintenance is highly recommended.
WARNING!
Tires and the spare tire should be replaced after six
years, regardless of the remaining tread. Failure to
follow this warning can result in sudden tire fail-
ure. You could lose control and have a collision
resulting in serious injury or death.
Tire Tread
1—WornTire
2—NewTire8
SERVICING AND MAINTENANCE 243

Brake System....................... .224, 262
Anti-Lock (ABS) ........................90
Master Cylinder ...................... .225
Parking ............................ .141
Warning Light .........................77
Break-In Recommendations, New Vehicle .......141
Bulb Replacement ....................... .166
Bulbs, Light ........................ .135, 166
Capacities, Antifreeze (Engine Coolant) .........266
Capacities, Fluid ........................ .266
Caps, Filler Oil (Engine) ...................... .207, 213
Radiator (Coolant Pressure) ...............223
Carbon Monoxide Warning ..............132, 265
Car Washes ........................... .254
Cellular Phone ......................... .272
Chains, Tire ........................... .250
Changing A Flat Tire ..................... .229
Chart, Tire Sizing ....................... .231
Check Engine Light (Malfunction Indicator Light) . .86
Checking Your Vehicle For Safety .............132
Checks, Safety ......................... .132
Child Restraint ......................... .123Child Restraints
Booster Seats ........................ .127
Child Restraints ...................... .123
Child Seat Installation ...................129
Infants And Child Restraints ..............125
Older Children And Child Restraints ........126
Clean Air Gasoline ...................... .262
Cleaning Wheels ............................ .249
Windshield Wiper Blades .................216
Climate Control ..........................36
Manual ..............................36
Compact Spare Tire ...................... .247
Contract, Service ........................ .276
Coolant (Antifreeze) ..................... .266
Coolant Pressure Cap (Radiator Cap) ..........223
Cooling
System......................... .220
Adding Coolant (Antifreeze) ..............221
Coolant Level .....................220, 223
Disposal Of Used Coolant ................223
Drain, Flush, And Refill ..................220
Inspection .......................... .223
Points To Remember ....................224
Pressure Cap ........................ .223
12
INDEX 281

Lights............................. .31, 135
AirBag........................79, 111, 133
Brake Warning .........................77
Bulb Replacement ..................... .166
Cruise ...............................84
Engine Temperature Warning ..............80
Exterior ............................ .135
Hazard Warning Flasher .................166
Interior ..............................32
Malfunction Indicator (Check Engine) ........83
Park ............................. .31, 84
Passing ..............................31
Seat Belt Reminder ......................79
Service ............................. .166
Tire Pressure Monitoring (TPMS) .........80, 96
Turn Signal ....................... .84, 135
Warning (Instrument Cluster Description) . . .80, 84
Loading Vehicle Tires .............................. .235
Locks Power Door ...........................22
Low Tire Pressure System ...................96
Lubrication, Body ....................... .215
Lug Nuts ............................. .260Maintenance Free Battery
...................211
Maintenance, General .....................212
Maintenance Procedures ...................212
Maintenance Schedule .....................199
Malfunction Indicator Light (Check Engine) . . . .83, 86
Manual, Service ........................ .278
Manual Transmission Lubricant Selection .....................268
Master Cylinder (Brakes) ...................225
Memory Feature (Memory Seat) ...............24
Memory Seat ............................24
Memory Seats And Radio ...................24
Methanol ............................. .263
Mirrors ................................28
Electric Remote ........................29
Heated ..............................30
Outside .......................... .28, 29
Rearview .............................28
Modifications/Alterations, Vehicle ..............6
Monitor, Tire Pressure System ................96
Mopar

Parts ........................... .277
MTBE/ETBE .......................... .263
Multi-Function Control Lever ................3112
INDEX 285
