2018.5 VAUXHALL VIVARO engine

100Instruments and controlsIlluminates when the engine is
running
If control indicator I illuminates
when the engine is running (together
with control indicator C and a
warning chime): Stop, switch off
engine.Caution
Engine lubrication may be
interrupted. This may result in
damage to the engine and / or
locking of the drive wheels.
1. Depress clutch.
2. Select neutral gear (or move selector lever to N).
3. Move out of the flow of traffic as quickly as possible without
impeding other vehicles.
4. Switch off ignition.
9 Warning
When the engine is off,
considerably more force is needed
to brake and steer.
Do not remove key until vehicle is stationary, otherwise the steeringwheel lock could engage
unexpectedly.
Check oil level before seeking
assistance of a workshop 3 166.
Fuel economy mode
ECO illuminates green when ECO
mode is engaged to reduce fuel
consumption.
ECO mode, driving economically
3 129.
Low fuel Y illuminates yellow.
Illuminates briefly when the ignition is
switched on.
Illuminates when level in fuel tank is
low (range of approx. 30 miles). Refuel immediately 3 159.
Catalytic converter 3 139.
Diesel fuel system bleeding 3 172.
Stop-start system D illuminates when engine is in an
Autostop.
\ illuminates when an Autostop is
inhibited when certain conditions are
not fulfilled.
Stop-start system 3 135.
Exterior light
9 illuminates green.
Illuminated when the headlights are
on.
8 illuminates green.
Illuminated when the sidelights are
on.
Lighting 3 108.
High beam
P illuminates blue.
Illuminated when high beam is on and during headlight flash 3 109.

102Instruments and controlsInfo Display
The Info Display displays
Infotainment system information, the
time and depending on version the
outside temperature.
Press X to switch the Infotainment
system on. Alternatively, it
automatically switches on when the
ignition is switched on.
Depending on system, the
Infotainment system is operated via
buttons and rotary knobs on the
Infotainment system fascia, the
steering column controls, the voice
recognition system (if available) or via
the touchscreen display.
Touchscreen operation
Make the appropriate selection from
the available menus and options by
touching the display screen with the
finger.
For further information, refer to the
Infotainment manual.Vehicle messages
Messages are displayed in the Driver Information Centre and may be
accompanied by illumination of
control indicator j or C in the
instrument cluster.
Information messages Information messages regarding, e.g.
engine starting conditions, stop-start
system, parking brake application,
central locking, steering wheel lock
etc. provide the current status of
certain vehicle functions and
instructions for use.
Fault messages Fault messages regarding, e.g. fuel
filter, airbags, exhaust emissions etc.
are displayed together with control
indicator j. Drive with caution and
seek the assistance of a workshop as
soon as possible.
To remove fault messages, e.g.
" CHECK INJECTION ", from the
display, press button on end of wiper
lever. After a few seconds the
message may disappear

Instruments and controls103automatically and j remains
illuminated. The fault will then be
stored in the on board system.
Warning messages
Warning messages regarding, e.g.
engine, battery or brake system
failure, are displayed together with
control indicator C and may be
accompanied by a warning chime.
Stop engine immediately and seek
the assistance of a workshop.
Warning messages, e.g. " BATTERY
CHARGING FAULT " disappear from
the display automatically when the cause of the fault has been remedied.
Fuel economy messages
Fuel economy messages provide tips to improve fuel efficiency. Journeys
can be saved in the system memory,
enabling you to compare
performances.
Refer to Infotainment manual for
further information.
Fuel economy rating 3 104.Warning chimes
If several warnings appear at thesame time, only one warning chime
will sound.
When starting the engine or whilst driving:
The warning chime regarding
unfastened seat belts has priority
over any other warning chime.
● If seat belt is not fastened 3 53.
● If the parking assist detects an object 3 154.
● If the vehicle speed briefly exceeds a set limit 3 151,
3 153.
● If a door or the bonnet is not properly closed when vehicle
exceeds a certain speed.
● During activation and deactivation of alarm monitoring
of vehicle inclination 3 36.
● If there is a fault in the brake system 3 97.
● If the vehicle battery is not charging 3 97.● If engine lubrication is interrupted
3 99.
● If AdBlue needs to be refilled or a
fault is present 3 140.
● If the electronic key is outside of the detection range.
Electronic key system 3 21.
Power button 3 131.
When the vehicle is parked and / or the driver's door is opened:
● If the key has been left in the ignition.
● If the electronic key has been left
in the card reader.
Electronic key system 3 21.
Power button 3 131.
● If the vehicle is in an Autostop. Stop-start system 3 135.
● If the exterior lights are on 3 108.

104Instruments and controlsEngine oil levelIf the minimum engine oil level is
reached, a message is displayed in
the Driver Information Centre 3 101
for 30 seconds after the engine is
started.
Check oil level 3 166.Trip computer
The trip computer provides
information on driving data, which is
continually recorded and evaluated
electronically.
Depending on vehicle, the following
functions can be selected by pressing button repeatedly on end of wiper
lever:
● fuel used
● average consumption
● instantaneous consumption
● range
● distance travelled
● average speed
● AdBlue percentage remaining 3 140
● distance before service 3 92
● clock 3 86
● outside temperature 3 85
● cruise control and speed limiter stored speed 3 151
● fuel economy rating (ecoScoring)
● fault and information messages
● odometer 3 90
● trip odometer 3 90
Fuel used Displays the amount of fuel
consumed since the last reset.
The measurement can be restarted at
any time by pressing and holding the
button.
Average consumption The value is displayed after driving a
distance of 0.25 miles.

Instruments and controls105Average consumption is displayed,
taking into consideration the distance
travelled and the fuel used since the
last reset.
The measurement can be restarted at
any time.
Instantaneous consumption The value is displayed after reachinga speed of 20 mph.
Range The value is displayed after driving adistance of 0.25 miles.
The range is calculated from the
current contents of the fuel tank and
the average consumption since the
last reset.
The range will not be displayed if
control indicator Y is illuminated in the
Driver Information Centre 3 100.
Distance travelled Displays the distance driven since the
last reset.
The measurement can be restarted at
any time.Average speed
The value is displayed after driving a
distance of 0.25 miles.
The average speed since the last
reset is displayed.
The measurement can be restarted at
any time.
Interruptions in the journey with the
ignition off are not included in the
calculations.
Reset trip computer information
To reset the trip computer, select one of its functions then press and hold
the button on the end of the wiper
lever.
The following trip computer
information can be reset:
● fuel used
● average consumption
● distance travelled
● average speed
The trip computer will reset
automatically when the maximum
value of any of the parameters is
exceeded.Fuel economy rating (ecoScoring)
If equipped, a rating of 0 to 100 is
shown in the Driver Information
Centre to help evaluate fuel
efficiency, based on your driving
style.
Higher ratings indicate better fuel economy.
Tips to improve fuel economy are also
given in the Driver Information
Centre. Journeys can be saved in the system memory, enabling you to
compare performances. Refer to Infotainment manual for further
information.
Vehicle messages 3 102.
Journey record
When the engine is switched off, a record of the last journey may be
shown in the Driver Information
Centre.
The following information is
displayed:
● average fuel consumption
● total fuel consumption

106Instruments and controls● trip odometer
● fuel saved in miles
Unit of measurement To change the unit of measurement
for the duration of a journey:
Vehicles with power button:
With ignition off, simultaneously press and hold button on end of wiper lever
and press the power button 3 131.
The Driver Information Centre flashes
for approx. 10 seconds until the new
unit is displayed. Release button on end of wiper lever when the display
stops flashing.
Vehicles without power button:
With ignition off, simultaneously press and hold button on end of wiper lever
and switch on the ignition. The Driver Information Centre flashes for
approx. 10 seconds until the new unit
is displayed. Release button on end
of wiper lever when the display stops
flashing.
When the engine is switched off, the
trip computer automatically returns to
the original unit of measurement.Interruption of power supply
If the power supply has been
interrupted or if the vehicle battery
voltage has dropped too low, the
values stored in the trip computer will be lost.Tachograph
The tachograph is operated as
described in the operating
instructions supplied. Observe
regulations regarding use.
Depending on equipment, the
tachograph may be fitted in a console located above the Infotainment
system in the instrument panel.

108LightingLightingExterior lighting.......................... 108
Light switch .............................. 108
Automatic light control .............109
High beam ............................... 109
Headlight flash ......................... 109
Headlight range adjustment ....109
Headlights when driving abroad .................................... 110
Daytime running lights .............110
Cornering lights .......................110
Hazard warning flashers ..........111
Turn lights ................................ 111
Front fog lights ......................... 111
Rear fog lights ......................... 112
Reversing lights .......................112
Misted light covers ...................112
Interior lighting ........................... 112
Instrument panel illumination control ..................................... 112
Interior lights ............................ 112
Load compartment lighting ......114
Reading lights .......................... 114
Glove box lighting ....................114
Lighting features ........................114
Entry lighting ............................ 114Exit lighting.............................. 114
Battery discharge protection ....115Exterior lighting
Light switch
Turn outer switch:
7:off8:sidelights9P:headlights
High beam control indicator P
3 100.
Low beam control indicator 9 3 100.
Notice
If the headlights have been switched
on manually, a warning chime will
sound when the engine is switched

Lighting109off and when the driver's door is
opened as a reminder that the lights
are still on.
Tail lights
Tail lights are illuminated together
with low beam and sidelights.
Automatic light controlAUTO:automatic light control
When the automatic light control
function is activated and the engine is
running, the system switches
between daytime running lights and headlights depending on the external lighting conditions.
For reasons of safety, it is advisable
to have the automatic light control
function activated.
Automatic headlight activation During poor lighting conditions the
headlights are switched on.
Additionally, headlights are switched
on if the windscreen wiper has been
activated for several wipes.
Daytime running lights 3 110.
High beam
To switch from low to high beam,
push stalk.
To switch back to low beam, push
stalk again or pull.
Headlight flash
To activate the headlight flash, pull
stalk.
Headlight range adjustment Manual headlight range
adjustment
Adapt headlight range to the vehicle
load to prevent dazzling of oncoming
traffic.
