2018.5 VAUXHALL CASCADA dimensions

Technical data237Technical dataVehicle identification..................237
Vehicle Identification Number ..237
Identification plate ...................237
Engine identification ................238
Vehicle data ............................... 239
Recommended fluids and lubricants ................................ 239
Engine data ............................. 242
Performance ............................ 243
Vehicle weight ......................... 243
Vehicle dimensions .................244
Capacities ................................ 245
Tyre pressures ........................ 246Vehicle identification
Vehicle IdentificationNumber
The Vehicle Identification Number
may be stamped on the identification plate and on the floor pan, under thefloor covering, visible under a cover.
The Vehicle Identification Number
may be embossed on the instrument
panel, visible through the windscreen,
or in the engine compartment on the
right body panel.
Identification plate
The identification plate is located on
the front left or right door frame.

244Technical dataVehicle dimensionsLength [mm]4696Length max. when operating soft top [mm]4760Width without exterior mirrors [mm]1839Width with two exterior mirrors [mm]2020Height (without antenna) [mm]1443Height max. when operating soft top [mm]2103Length of load compartment floor [mm]1121Length of load compartment with folded rear seats [mm]1818Load compartment width [mm]978Load compartment height [mm] with opened soft top246Load compartment height [mm] with closed soft top453Wheelbase [mm]2695Turning circle diameter [m]12.2

262VVehicle battery ........................... 194
Vehicle checks............................ 190
Vehicle data ................................ 239
Vehicle data recording and privacy ..................................... 254
Vehicle detected ahead ................94
Vehicle dimensions .................... 244
Vehicle Identification Number ....237
Vehicle jack ................................ 210
Vehicle messages .....................101
Vehicle personalisation .............102
Vehicle security ............................ 26
Vehicle specific data ......................3
Vehicle storage ........................... 189
Vehicle tools ............................... 210
Vehicle unlocking ........................... 6
Vehicle weight ........................... 243
Ventilating ..................................... 53
Ventilation ................................... 125
W
Warning chimes .........................101
Warning lights ............................... 83
Warning triangle .......................... 74
Washer and wiper systems .........14
Washer fluid ............................... 193
Wheel changing .........................220
Wheel covers ............................. 217
Wheels and tyres .......................211Wind deflector............................... 41
Windows ....................................... 31
Windscreen................................... 31
Windscreen wiper and washer ....78
Winter tyres ............................... 211
Wiper blade replacement ..........196
