2018.5 OPEL MOVANO_B key

Introduction.................................... 2
In brief ............................................ 6
Keys, doors and windows ............22
Seats, restraints ........................... 47
Storage ........................................ 76
Instruments and controls .............87
Lighting ...................................... 112
Climate control ........................... 120
Driving and operating .................136
Vehicle care ............................... 180
Service and maintenance ..........226
Technical data ........................... 230
Customer information ................254
Index .......................................... 262Contents

6In briefIn briefInitial drive informationVehicle unlockingUnlocking with key
Turn the key in the driver's door lock.
Open the doors by pulling the
handles.
Unlocking with remote control
Depending on vehicle configuration:
Press c to unlock the front doors.
Press again to unlock entire vehicle.
Open the doors by pulling the
handles.
With 3-button remote control, press
G . Only the load compartment is
unlocked.
Radio remote control 3 23.
Central locking system 3 26.
Anti-theft alarm system 3 38.

In brief7Unlocking with electronic key
Press the button on any exterior door
handle when the electronic key is
within range of the detection zone
(approx. 1 m of the front doors or load compartment) and pull the handle to
open.
Electronic key system 3 24.
Seat adjustment
Longitudinal adjustment
Pull handle, slide seat, release
handle.
Try to move the seat back and forth to ensure that the seat is locked in place.
Seat position 3 48.
Seat adjustment 3 49.
Backrests inclination
Pull lever, adjust inclination and
release lever. Allow the seat to
engage audibly.
Seat position 3 48.
Seat adjustment 3 49.

In brief19Manual transmission automatedN:neutralo:drive position+:higher gear-:lower gearA/M:switch between automatic and
manual modeR:reverse gear. Engage only
when vehicle is stationary.
Manual transmission automated
3 155.
Starting off
Check before starting off ● Tyre pressure 3 206 and
condition 3 252.
● Engine oil level and fluid levels 3 183.
● All windows, mirrors, exterior lighting and number plates are
free from dirt, snow and ice and
are operational.
● Proper position of mirrors 3 41,
seats 3 48 and seat belts
3 58.
● Brake function at low speed, particularly if the brakes are wet.Starting the engine
● Turn key to position 1.
● Move the steering wheel slightly to release the steering wheel
lock.
● Operate clutch and brake.
● Do not operate accelerator pedal.
● Turn the key to position 2 for
preheating and wait until control
indicator ! extinguishes in the
Driver Information Centre.
● Turn key to position 3 and
release.
Starting the engine 3 139.

In brief21● Close the windows.
● Remove the ignition key from the ignition switch. Turn the
steering wheel until the
steering wheel lock is felt to
engage.
● Lock the vehicle by pressing e on
the remote control 3 26.
● Activate the anti-theft alarm system 3 38.
● The engine cooling fans may run
after the engine has been
switched off 3 182.
Caution
After running at high engine
speeds or with high engine loads,
operate the engine briefly at a low load or run in neutral for approx.30 seconds before switching off, in
order to protect the turbocharger.
Keys, locks 3 22.
Laying the vehicle up for a long period
of time 3 181.

22Keys, doors and windowsKeys, doors and
windowsKeys, locks ................................... 22
Keys .......................................... 22
Car Pass .................................... 23
Radio remote control .................23
Electronic key system ................24
Door locks ................................. 25
Manual door locks .....................25
Central locking system ..............26
Power door locks .......................30
Automatic locking ......................31
Child locks ................................. 31
Doors ........................................... 32
Sliding door ............................... 32
Rear doors ................................. 35
Vehicle security ............................ 37
Anti-theft locking system ...........37
Anti-theft alarm system ..............38
Immobiliser ................................ 40
Exterior mirrors ............................ 40
Convex shape ........................... 40
Manual adjustment ....................40
Electric adjustment ....................41Folding mirrors .......................... 41
Heated mirrors ........................... 41
Interior mirrors ............................. 42
Manual anti-dazzle ....................42
Windows ...................................... 43
Windscreen ............................... 43
Manual windows ........................43
Power windows ......................... 43
Rear windows ............................ 44
Heated rear window ..................45
Sun visors .................................. 45
Roof ............................................. 46
Glass panel ............................... 46Keys, locks
KeysCaution
Do not attach heavy or bulky itemsto the ignition key.
Replacement keys
The key number is specified in the
Car Pass or on a detachable tag.
The key number must be quoted
when ordering replacement keys as it
is a component of the immobiliser
system.
If the electronic key needs to be
replaced, the vehicle must be taken to a workshop.
Locks 3 223.
Radio remote control 3 23.
Electronic key system 3 24.
Central locking system 3 26.
Starting the engine 3 139.

Keys, doors and windows23Car Pass
The Car Pass contains security
related vehicle data and should
therefore be kept in a safe place.
When the vehicle is taken to a
workshop, this vehicle data is needed
in order to perform certain operations.
Radio remote control
Used to operate: ● central locking system
● anti-theft locking system
● anti-theft alarm system
Depending on model, the vehicle may use a 2-button or 3-button remote
control.
The remote control has a range of
approx. 5 m. It can be affected by
external influences. The hazard
warning flashers confirm operation.
Handle with care, protect it from
moisture and high temperatures and
avoid unnecessary operation.
Fault
If the central locking system cannot
be operated with the remote control,
it may be due to the following:
● The range is exceeded.
● The battery voltage is too low.
● Frequent, repeated operation of the remote control while not in
range, which will require
reprogramming by a workshop.
● Overload of the central locking system by operating at frequent
intervals; the power supply is
interrupted for a short time.
● Interference from higher-power radio waves from other sources.Unlocking 3 26.
Remote control battery
replacement
Replace the battery as soon as the
range reduces.
Batteries do not belong in household
waste. They must be disposed of at
an appropriate recycling collection
point.

24Keys, doors and windowsRemove screw and open battery
compartment by inserting a coin into
the slot and twisting.
Replace the battery (battery type
CR2016), paying attention to the
installation position.
Reattach both halves of cover
ensuring it engages correctly.
Replace screw and tighten.
Electronic key system
Enables a hands-free operation of thecentral locking system 3 26.
The electronic key simply needs to be on the driver's person.
Note
Always take the electronic key with
you when exiting the vehicle.
For hands-free operation, the
electronic key must be outside the
vehicle, within a range of approx.
1 m of the front doors or load
compartment.
Hands-free operation is automatically
disabled when the central locking
switch e 3 26 is pressed. To re-
enable hands-free operation, restart
the engine.
Electronic key battery
replacement
Replace the battery as soon as the
system no longer operates properly
or the range is reduced.
Batteries do not belong in household
waste. They must be disposed of at
an appropriate recycling collection
point.
