Driving and operating151KickdownIf the accelerator pedal is pressed
down completely in automatic mode,
the transmission shifts to a lower gear
depending on engine speed.
Fault
In the event of a fault, a vehicle message is displayed in the Driver
Information Centre. Vehicle
messages 3 103.
The transmission no longer shifts automatically. Continued travel is
possible with manual shifting.
Only the highest gear is available.
Depending on the fault, 2nd gear may also be available in manual mode.
Shift only when vehicle is at a
standstill.
Have the cause of the fault remedied by a workshop.Interruption of power supply
In the event of an interruption of
power supply, the selector lever
cannot be moved out of the P
position. The ignition key cannot be removed from the ignition switch.
If the vehicle battery is discharged,
start the vehicle using jump leads
3 228.
If the vehicle battery is not the cause
of the fault, release the selector lever.
1. Apply the parking brake.
2. Release the selector lever trim from the centre console at the
front, fold it upwards and rotate it
to the left.
3. Insert a screwdriver into the opening as far as it will go and
move the selector lever out of P or
N . If P or N is engaged again, the
selector lever will be locked in
position again. Have the cause of
the power supply interruption
remedied by a workshop.
4. Mount the selector lever trim onto
the centre console and refit.

190Vehicle careVehicle careGeneral Information...................191
Accessories and vehicle modifications .......................... 191
Vehicle storage ........................191
End-of-life vehicle recovery .....192
Vehicle checks ........................... 192
Performing work ......................192
Bonnet ..................................... 192
Engine oil ................................. 193
Engine coolant ......................... 194
Washer fluid ............................ 195
Brakes ..................................... 195
Brake fluid ............................... 196
Vehicle battery ......................... 196
Diesel fuel system bleeding .....197
Wiper blade replacement ........198
Bulb replacement .......................198
Halogen headlights ..................198
Adaptive forward lighting .........200
Fog lights ................................. 201
Front turn lights .......................202
Tail lights ................................. 203
Side turn lights ......................... 204
Number plate light ...................205Interior lights ............................ 206
Instrument panel illumination ...206
Electrical system ........................206
Fuses ....................................... 206
Engine compartment fuse box . 207
Instrument panel fuse box .......209
Load compartment fuse box ....210
Vehicle tools .............................. 212
Tools ........................................ 212
Wheels and tyres .......................213
Winter tyres ............................. 213
Tyre designations ....................213
Tyre pressure monitoring
system .................................... 213
Tyre pressure .......................... 217
Tread depth ............................. 218
Changing tyre and wheel size . 218
Wheel covers ........................... 219
Tyre chains .............................. 219
Tyre repair kit .......................... 219
Wheel changing .......................222
Spare wheel ............................ 225
Jump starting ............................. 228
Towing ....................................... 230
Towing the vehicle ...................230
Towing another vehicle ...........231Appearance care .......................232
Exterior care ............................ 232
Interior care ............................. 234

Vehicle care197We recommend that you have the
vehicle battery replaced by a
workshop.
Stop-start system 3 140.
Charging the vehicle battery9 Warning
On vehicles with stop-start
system, ensure that the charging potential does not exceed
14.6 volts when using a battery
charger. Otherwise the vehicle
battery may be damaged.
Jump starting 3 228.
Warning label
Meaning of symbols:
● No sparks, naked flames or smoking.
● Always shield eyes. Explosive gases can cause blindness or
injury.
● Keep the vehicle battery out of reach of children.
● The vehicle battery contains sulphuric acid which could cause
blindness or serious burn
injuries.
● See the Owner's Manual for further information.
● Explosive gas may be present in the vicinity of the vehicle battery.
Diesel fuel system bleeding If the tank has been run dry, the diesel
fuel system must be bled. Switch on
the ignition three times for
15 seconds at a time. Then crank the
engine for a maximum of 40 seconds. Repeat this process after
no less than 5 seconds. If the engine fails to start, seek the assistance of a
workshop.

228Vehicle careTemporary spare wheelCaution
The use of a spare wheel that issmaller than the other wheels or in combination with winter tyres
could affect driveability. Have the defective tyre replaced as soon as
possible.
Only mount one temporary spare
wheel. Do not drive faster than
80 km/h. Take curves slowly. Do not use for a long period of time.
If your vehicle gets a flat tyre on the
rear while towing another vehicle,
mount the temporary spare wheel at
the front and the full size tyre at the
rear.
Tyre chains 3 219.
Spare wheel with directional tyre
Fit directional tyres such that they roll in the direction of travel. The rolling
direction is indicated by a symbol
(e.g. an arrow) on the sidewall.
The following applies to tyres fitted
opposing the rolling direction:
● Driveability may be affected. Have the defective tyre renewed
or repaired as soon as possible
and fit it instead of the spare
wheel.
● Drive particularly carefully on wet
and snow-covered road
surfaces.Jump starting
Do not start with quick charger.
A vehicle with a discharged vehicle
battery can be started using jump
leads and the vehicle battery of
another vehicle.9 Warning
Be extremely careful when starting
with jump leads. Any deviation
from the following instructions can
lead to injuries or damage caused
by battery explosion or damage to the electrical systems of both
vehicles.
9 Warning
Avoid contact of the battery with
eyes, skin, fabrics and painted
surfaces. The fluid contains
sulphuric acid which can cause
injuries and damage in the event
of direct contact.
● Never expose the battery to naked flames or sparks.

Vehicle care229● A discharged vehicle battery canalready freeze at a temperature
of 0 °C. Defrost the frozen battery before connecting jump leads.
● Wear eye protection and protective clothing when
handling a battery.
● Use a booster battery with the same voltage (12 Volts). Its
capacity (Ah) must not be much
less than that of the discharged
battery.
● Use jump leads with insulated terminals and a cross section of
at least 16 mm 2
(25 mm 2
for
diesel engines).
● Do not disconnect the discharged
battery from the vehicle.
● Switch off all unnecessary electrical consumers.
● Do not lean over the battery during jump starting.
● Do not allow the terminals of one
lead to touch those of the other
lead.
● The vehicles must not come into contact with each other during
the jump starting process.● Apply the parking brake, transmission in neutral,
automatic transmission in P.
● Open the positive terminal protection caps of both batteries.
Lead connection order:
1. Connect the red lead to the positive terminal of the booster
battery.
2. Connect the other end of the red lead to the positive terminal of the
discharged battery.
3. Connect the black lead to the negative terminal of the booster
battery.
4. Connect the other end of the black
lead to a vehicle grounding point,
such as the engine block or an
engine mounting bolt. Connect as far away from the discharged
battery as possible, however at
least 60 cm.
Route the leads so that they cannot
catch on rotating parts in the engine
compartment.
To start the engine: 1. Start the engine of the vehicle providing the jump.
2. After 5 minutes, start the other engine. Start attempts should be
made for no longer than
15 seconds at an interval of
1 minute.
3. Allow both engines to idle for approx. 3 minutes with the leads
connected.

230Vehicle care4. Switch on electrical consumers(e.g. headlights, heated rear
window) of the vehicle receiving
the jump start.
5. Reverse above sequence exactly when removing leads.Towing
Towing the vehicle
Wrap a cloth around the tip of a flat
screwdriver to prevent paint damage.
Insert the screwdriver in the slot at the
lower part of the cap. Release the cap by carefully moving the screwdriver
downwards.
The towing eye is stowed with the
vehicle tools 3 212.
Screw in the towing eye anticlockwise
as far as it will go until it stops in a
horizontal position.
Attach a tow rope – or better still a tow
rod – to the towing eye.
The towing eye must only be used for
towing and not for recovering the
vehicle.
Switch on ignition to release steering wheel lock and to permit operation of
brake lights, horn and windscreen
wiper.
Switch the selector lever to neutral.
Release the parking brake.

262Head restraint adjustment .............8
Head restraints ............................ 47
Heated mirrors ............................. 31
Heated rear window ..................... 35
Heated steering wheel .................79
Heating ........................................ 55
Heating and ventilation system . 127
High beam ........................... 95, 116
High beam assist ..................96, 116
Hill start assist ........................... 155
Horn ....................................... 15, 80
I
Identification plate .....................239
Ignition switch positions .............139
Immobiliser ............................ 30, 95
Indicators ...................................... 85
Info Display ................................. 101
Information displays...................... 96
Instrument cluster ........................85
Instrument panel fuse box .........209
Instrument panel illumination .....206
Instrument panel illumination control .................................... 123
Instrument panel overview ........... 10
Interactive driving system ...........157
Interior care ............................... 234
Interior lighting ............................ 123
Interior lights ...................... 124, 206
Interior mirrors .............................. 32Interruption of power supply ......151
Introduction .................................... 3
J Jump starting ............................. 228
K Key, memorised settings ..............23
Keys ............................................. 21
Keys, locks ................................... 21
L Lane departure warning .......93, 179
Lashing eyes ............................... 76
Light switch ................................ 114
Load compartment ................26, 73
Load compartment fuse box ......210
Loading information .....................77
Low fuel ....................................... 95
M Malfunction indicator light ............92
Manual anti-dazzle ......................32
Manual mode ............................. 150
Manual seat adjustment ...............50
Manual transmission .................. 152
Memorised settings ......................23
Mirror adjustment ........................... 8 Misted light covers .....................123N
New vehicle running-in ..............139
Number plate light .....................205
O Object detection systems ...........165
Odometer ..................................... 85
Oil, engine .......................... 236, 241
OnStar ........................................ 109
Operate pedal ............................... 92
Outside temperature ....................81
Overrun cut-off ........................... 140
P
Parking ................................ 19, 142
Parking assist ............................ 165
Parking brake ............................ 153
Parking lights ............................. 123
Particulate filter ........................... 144
Performance .............................. 245
Performing work ........................192
Pollen filter ................................. 135
Power outlets ............................... 83
Power seat adjustment ................53
Power steering.............................. 93
Power windows ............................ 33
Preheating ................................... 94
Puncture ..................................... 222
Q Quickheat ................................... 134
