2017 YAMAHA YXZ1000R check engine

8-8
8
14*Wheel bearings • Check bearing assemblies for loose-
ness/damage.
• Replace if damaged. √ √√√
15 *Front and rear
suspension • Check operation and for oil leakage.
• Correct if necessary.
√√
16 *Steering system • Check operation and for looseness. Replace
if damaged.
• Check toe-in. Adjust if necessary. √√√√√
17 *Stabilizer bushes • Check for cracks or other damage, and re-
place if necessary. √√√
18 *Upper and lower
arm pivots
• Lubricate with lithium-soap-based grease.
√√√
19 *Rear knuckle up-
per and lower piv-
ots
• Lubricate with lithium-soap-based grease.
√√√
20 *Drive shaft uni-
versal joint • Lubricate with lithium-soap-based grease.
√√√
21 *Engine mount • Check for cracks or damage.
• Check bolt tightness. √√√
NO. ITEM
ROUTINE INITIAL
EVERY
Whichev- er comes first month136612
km
(mi) 320
(200) 1300
(800) 2500
(1600) 2500
(1600) 5000
(3200)
hours 20 80 160 160 320UB577AE0.book Page 8 Wednesday, June 8, 2016 9:35 AM

8-15
8
To install the panelPlace the panel in the original position, and
then install the quick fastener screws.EBU35434Engine oil and oil filterCheck the engine oil level before each opera-
tion. In addition, change the oil and replace
the filter at the intervals specified in the gen-
eral maintenance and lubrication chart.
To check the engine oil level1. Park the vehicle on a level surface.
2. Remove panel C (page 8-10). 3. Start the engine and warm it up to a nor-
mal operating temperature (the engine oil
temperature should reach 60 °C [140 °F]),
then let the engine idle for a minimum of
ten seconds before turning the engine off.
TIPIf the engine is cold, take the vehicle for a
short drive or let it idle for approximately ten
minutes before checking the engine oil level. 4. Remove the engine oil tank filler cap and
wipe the dipstick with a clean rag.
5. Insert the dipstick back into the oil tank
(without screwing it in), and then remove
it again to check the oil level.TIPThe engine oil level should be between the tip
of the dipstick and the maximum level mark.
UB577AE0.book Page 15 Wednesday, June 8, 2016 9:35 AM

8-16
8
6. If the oil level is not between the tip of thedipstick and the maximum level mark,
add sufficient oil of the recommended
type to raise it to the correct level.
7. Check the O-ring for damage, and re-
place it if necessary.
8. Install the engine oil tank filler cap.
9. Install the panel. To change the engine oil
1. Park the vehicle on a level surface.
2. Remove panel C. (See page 8-10.)
3. Remove the engine oil tank cover by re- moving the bolts.
4. Start the engine, warm it up for several minutes, and then turn it off.
5. Place an oil pan (or use a trough or funnel)
beneath the oil tank to collect the used
engine oil.1. Engine oil tank filler cap
2. O-ring
3. Engine oil dipstick
4. Maximum level mark
5. Tip of the engine oil dipstick
1
4
5
32
1. Engine oil tank cover
2. Bolt
1
2
UB577AE0.book Page 16 Wednesday, June 8, 2016 9:35 AM

8-17
8
6. Remove the engine oil tank filler cap andthe cylinder head cap. 7. Check the O-ring for damage, and re-
place it if necessary.
8. Remove the oil tank drain bolt and its gasket to drain the engine oil from the oil
tank.1. Engine oil tank filler cap
1. Cylinder head cap
1
1
1. Engine oil tank filler cap
2. O-ring
3. Cylinder head cap
3
2
1
2
UB577AE0.book Page 17 Wednesday, June 8, 2016 9:35 AM

8-20
8
15. Install and tighten the engine oil tank fillercap.
16. Start the engine, and then let it idle for several minutes while checking it for oil
leakage. If oil is leaking, immediately turn
the engine off and check for the cause.
17. Turn the engine off, wait at least ten mi- nutes, and then check the oil level and
correct it if necessary.
18. Install the engine oil tank cover by install- ing the bolts.
19. Install the panel.
To change the engine oil and oil filter 1. Park the vehicle on a level surface.
2. Loosen the left and right side panels by removing the bolt as shown. 3. Remove the rear bottom panel by remov-
ing the bolts.
1. Left side panel
2. Right side panel
3. Bolt
3
1
3
2
UB577AE0.book Page 20 Wednesday, June 8, 2016 9:35 AM

8-23
8
9. Install the drain bolts, and then add thespecified amount of the recommended
engine oil. Check the engine oil level and
the vehicle for oil leakage. Install the en-
gine oil tank cover and panel C.TIPRefer to steps 11–19 of the “To change the
engine oil” section for the oil filling procedure.
10. Slide the front portion of the center bot- tom panel into place as shown, and then
hook the left and right sides of the center
bottom panel into place.
1. Torque wrench
1
1. Center bottom panel
1
UB577AE0.book Page 23 Wednesday, June 8, 2016 9:35 AM

8-29
8
8. Start the engine and drive the vehicle fora few minutes to circulate the transmis-
sion oil.
9. Park the vehicle on a level surface, stop the engine, and then check the transmis-
sion case for oil leakage.TIPIf oil is leaking confirm that the transmission
oil filler cap is properly installed and then have
a Yamaha dealer check the transmission. 10. Check the transmission oil level and cor- rect if necessary.
11. Install the panel.EBU36050Final gear oilCheck the oil level and change the final gear
oil at the intervals specified in the general
maintenance and lubrication chart.
Checking the final gear oil level 1. Park the vehicle on a level surface. 2. Remove the final gear oil filler bolt and its
gasket, and then check the oil level in the
final gear case. The oil level should be at
the brim of the filler hole.
3. If the oil is below the brim of the filler hole, add sufficient oil of the recommended
type to raise it to the correct level.
NOTICE: Be sure no foreign material
enters the final gear case.
[ECB00422]
1. Final gear oil
2. Gasket
3. Final gear oil filler bolt
4. Correct oil level
24
3
1
UB577AE0.book Page 29 Wednesday, June 8, 2016 9:35 AM

8-34
8
3. Check the coolant level when the engineis cold (the coolant level will vary with en-
gine temperature).TIPThe coolant level in the coolant reservoir
should be between the minimum and maxi-
mum level marks. 4. If the coolant level is at or below the mini-
mum level mark, remove the coolant res-
ervoir cap and add coolant to the maximum level mark.
NOTICE: If cool-
ant is not available, use distilled water
or soft tap water instead. Do not use
hard water or salt water since they are
harmful to the engine. If water has
been used instead of coolant, replace
it with coolant as soon as possible,
otherwise the cooling system will not
be protected against frost and corro-
sion. If water has been added to the
coolant, have a Yamaha dealer check
the antifreeze content of the coolant
as soon as possible, otherwise the ef-
fectiveness of the coolant will be re-
duced.
[ECB01012]
5. Install the reservoir cap.
6. Install the hood when finished servicing
the vehicle.
1. Coolant reservoir cap
2. Maximum level mark
3. Minimum level mark
1
32
Coolant reservoir capacity
(up to the maximum level mark):0.31 L (0.33 US qt, 0.28 Imp.qt)
UB577AE0.book Page 34 Wednesday, June 8, 2016 9:35 AM
