2017 YAMAHA WOLVERINE brake fluid

Valve clearance .................................. 8-38
Brakes ................................................ 8-38
Checking the front and rear brake pads.................................................. 8-39
Checking the brake fluid level ............ 8-39
Brake fluid replacement ..................... 8-41
Checking the brake pedal .................. 8-41
Parking brake ..................................... 8-42
Brake light switch adjustment ............ 8-42
Cable inspection and lubrication........ 8-42
Brake pedal and accelerator pedal
lubrication ......................................... 8-43
Checking the stabilizer bushes .......... 8-43
Rear knuckle upper and lower pivot
lubrication (left and right) .................. 8-44
Steering shaft lubrication ................... 8-44
Wheel removal.................................... 8-45
Tire replacement ................................ 8-45
Wheel installation ............................... 8-46
Battery ................................................ 8-47
Jump-starting ..................................... 8-50
Fuse replacement............................... 8-52
Replacing a headlight bulb................. 8-54 Headlight beam adjustment ...............8-57
Tail/brake light bulb replacement .......8-57
Troubleshooting ..................................8-58
Troubleshooting charts .......................8-59
CLEANING AND STORAGE ....................9-1 Cleaning................................................9-1
Storage .................................................9-2
SPECIFICATIONS..................................10-1
CONSUMER INFORMATION ................11-1 Identification number records.............11-1
INDEX ....................................................12-1
U2MB7BE0.book Page 3 Thursday, March 3, 2016 11:46 AM

3-1
3
EBU31170
DESCRIPTION
EBU31180Left view
138
67
9
10
12
11
4
2
5
1. Front shock absorber assembly
2. Radiator cap
3. Brake fluid reservoir
4. Air filter
5. Shoulder bolster
6. Driver seat belt
7. Cargo bed
8. Tail/brake light
9. Rear shock absorber assembly
10.Spark plug
11.Driver seat
12.DoorU2MB7BE0.book Page 1 Thursday, March 3, 2016 11:46 AM

5-1
5
EBU31573
FOR YOUR SAFETY – PRE-OPERATION CHECKS
EBU31582Inspect your vehicle each time you use it to make sure the vehicle is in safe operating condition.
Always follow the inspection and maintenance procedures and schedules described in the Own-
er’s Manual.
WARNING
EWB00482Failure to inspect or maintain the vehicle properly increases the possibility of an accident
or equipment damage. Do not operate the vehicle if you find any problem. If a problem can-
not be corrected by the procedures provided in this manual, have the vehicle inspected by
a Yamaha dealer. Before using this vehicle, check the following points:
ITEM ROUTINE PAGE
Brakes • Check operation, free play, fluid level, and fluid leakage.
• Fill with DOT 4 brake fluid if necessary. 5-3, 8-38, 8-42
Parking brake • Check for proper operation. 8-42
Fuel • Check fuel level.
• Fill with the recommended fuel if necessary. 5-3
Engine oil • Check oil level.
• Fill with oil to proper level if necessary. 5-5, 8-14
U2MB7BE0.book Page 1 Thursday, March 3, 2016 11:46 AM

5-3
5
EBU31731Front and rear brakesBrake pedal
Check that there is no free play in the brake
pedal. If there is free play, have a Yamaha
dealer check the brake system. (See page
8-41.)
 Check the operation of the brake pedal. It
should move smoothly and there should be
a firm feeling when the brakes are applied.
If not, have the vehicle inspected by a
Yamaha dealer.
Brake fluid level
Check the brake fluid level. Add fluid if neces-
sary. (See page 8-39.) Brake fluid leakage
Check to see if any brake fluid is leaking out
of the pipe joints or the brake fluid reservoir.
Apply the brakes firmly for one minute. If there
is any leakage, have the vehicle inspected by
a Yamaha dealer.
Brake operation
Check the operation of the brakes at the start
of every drive. Test the brakes at slow speed
after starting out to make sure they are work-
ing properly. If the brakes do not provide
proper braking performance, inspect the
brake system. (See page 8-38.)
EBU33200FuelMake sure there is suffi
cient fuel in the tank.
Specified brake fluid: DOT 4
U2MB7BE0.book Page 3 Thursday, March 3, 2016 11:46 AM

8-6
8
EBU32112General maintenance and lubrication chartNO. ITEMROUTINE INITIAL
EVERY
Whichev- er comes
first month136612
km
(mi) 320
(200) 1200
(750) 2400
(1500) 2400
(1500) 4800
(3000)
hours 20 75 150 150 300
1 *Cooling system • Check coolant leakage.
• Repair if necessary.
√√√√√
• Change coolant. Every 2 years
2 Air filter element •Clean.
• Replace if necessary. Every 20–40 hours (more often in
wet or dusty areas)
3Engine oil • Change (warm engine before draining). √ √√√
4 Engine oil filter
cartridge • Replace.
√√√
5 Final gear oil/Dif-
ferential gear oil • Check oil level and for leakage.
√√√√√
•Change. √√
6 *Front brake • Check operation/brake pad wear/fluid leak-
age/see page 8-8.
• Correct if necessary. Replace pads if worn to the limit. √√√√√
7 *Rear brake • Check operation/brake pad wear/fluid leak-
age/see page 8-8.
• Correct if necessary. Replace pads if worn to the limit. √√√√√
U2MB7BE0.book Page 6 Thursday, March 3, 2016 11:46 AM

8-7
8
8*Parking brake • Check operation and adjust if necessary. √√√√√
9 *Brake fluid • Change. Every 2 years
10 *Accelerator pedal • Check operation and free play. √√√√√
11 *V-b e l t • Check operation.
• Check for wear, cracks, or damage. √√√
12 *Wheels • Check balance/damage/runout.
• Repair if necessary. √√√√
13 *Wheel bearings • Check bearing assemblies for loose-
ness/damage.
• Replace if damaged. √√√√
14 *Front and rear
suspension • Check operation and for oil leakage.
• Correct if necessary.
√√
15 *Steering system • Check operation and for looseness. Replace
if damaged.
• Check toe-in. Adjust if necessary. √√√√√
16 *Stabilizer bushes • Check for cracks or other damage, and re-
place if necessary. √√√
17 *Rear knuckle up-
per and lower piv-
ots
• Lubricate with lithium-soap-based grease.
√√√
NO. ITEM
ROUTINE INITIAL
EVERY
Whichev- er comes first month 1 3 6 6 12
km
(mi) 320
(200) 1200
(750) 2400
(1500) 2400
(1500) 4800
(3000)
hours 20 75 150 150 300
U2MB7BE0.book Page 7 Thursday, March 3, 2016 11:46 AM

8-8
8
EBU32331TIPSome maintenance items need more frequent serv ice if you drive in unusually wet, dusty, san-
dy or muddy areas, or at full throttle.
 Hydraulic brake service
• Regularly check and, if necessary, correct the brake fluid level.
• Every two years replace the internal components of the brake master cylinder and calipers,
and change the brake fluid.18 *Drive shaft uni-
versal joint • Lubricate with lithium-soap-based grease.
√√√
19 *Engine mount • Check for cracks or damage.
• Check bolt tightness.
√√√
20 *Front and rear
axle boots • Check for cracks or other damage, and re-
place if necessary. √√
21 *Fittings and fas-
teners • Check all chassis fittings and fasteners.
• Correct if necessary.
√√√√√
NO. ITEM ROUTINE
INITIAL EVERY
Whichev- er comes first month136612
km
(mi) 320
(200) 1200
(750) 2400
(1500) 2400
(1500) 4800
(3000)
hours 20 75 150 150 300U2MB7BE0.book Page 8 Thursday, March 3, 2016 11:46 AM

8-39
8
EBU32480Checking the front and rear brake padsEach brake pad is provided with wear indica-
tor grooves, which allow you to check the
brake pad wear without having to disassem-
ble the brake. To check the brake pad wear,
check the wear indicator grooves. If a brake
pad has worn to the point that the wear indi-
cator grooves have almost disappeared, have
a Yamaha dealer replace the brake pads as a
set.
The wheels need to be removed to check the
brake pads. (See pages 8-45, 8-46 for wheel
removal and installation procedures.)
EBU32501Checking the brake fluid levelBefore starting off, check that the brake fluid
is above the minimum level mark. Check the
brake fluid level with the top of the reservoir
level. Replenish the brake fluid if necessary.1. Brake pad wear indicator groove
1
