CONTENTS
LOCATION OF THE WARNING AND
SPECIFICATION LABELS ....................... 1-1
SAFETY INFORMATION ......................... 2-1
DESCRIPTION......................................... 3-1Left view ............................................... 3-1
Right view ............................................. 3-2
Controls and instruments ..................... 3-3
INSTRUMENT AND CONTROL
FUNCTIONS............................................ 4-1 Main switch .......................................... 4-1
Indicator lights and warning lights ....... 4-2
Multi-function meter unit ...................... 4-6
Light switch ........................................ 4-10
On-Command drive knob “2WD/4WD/DIFF LOCK” .................. 4-11
Horn switch ....................................... 4-12
Accelerator pedal ............................... 4-12
Brake pedal ........................................ 4-12 Parking brake lever ............................ 4-13
Drive select lever ................................ 4-14
Fuel tank cap...................................... 4-14
Doors .................................................. 4-15
Seats .................................................. 4-15
Adjusting the driver seat position....... 4-16
Seat belts ........................................... 4-17
Glove compartment ........................... 4-18
Storage compartments ...................... 4-18
Cup holders ........................................ 4-20
Cargo bed .......................................... 4-21
The front and rear shock absorber
assemblies ....................................... 4-23
Trailer hitch bracket and receiver....... 4-23
Auxiliary DC jack ................................ 4-24
FOR YOUR SAFETY –
PRE-OPERATION CHECKS.................... 5-1 Front and rear brakes ........................... 5-3
Fuel....................................................... 5-3
Engine oil.............................................. 5-5
Coolant ................................................. 5-6
Final gear.............................................. 5-6UB427BE0.book Page 1 Friday, February 5, 2016 2:14 PM

Differential gear .................................... 5-6
Accelerator pedal ................................. 5-6
Seat belts ............................................. 5-6
Passenger handhold ............................ 5-7
Steering ................................................ 5-7
Fittings and fasteners ........................... 5-7
Instruments, lights and switches .......... 5-7
Control cables ...................................... 5-8
Tires ...................................................... 5-8
OPERATION ............................................ 6-1 Engine break-in .................................... 6-1
Starting the engine ............................... 6-2
Drive select lever operation and reverse driving .................................... 6-3
On-Command drive knob..................... 6-5
Parking ................................................. 6-7
Loading................................................. 6-7
BASIC GUIDE FOR SAFE USE .............. 7-1 KNOW YOUR VEHICLE........................ 7-1
LEARNING TO OPERATE YOUR
VEHICLE ........................................... 7-12 PERIODIC MAINTENANCE AND
ADJUSTMENT .........................................8-1
Owner’s manual and tool kit .................8-2
Periodic maintenance chart for the emission control system .....................8-4
General maintenance and lubrication chart ....................................................8-6
Hood ...................................................8-10
Engine oil and oil filter cartridge .........8-11
Final gear oil .......................................8-16
Differential gear oil ..............................8-19
Coolant ...............................................8-21
Axle boots ...........................................8-22
Spark plug inspection .........................8-23
Cleaning the air filter element .............8-25
Cleaning the air filter case/duct check hose........................................8-30
V-belt case drain plug.........................8-31
Cleaning the spark arrester ................8-31
Valve clearance...................................8-33
Brakes.................................................8-33
Checking the front and rear brake pads ..................................................8-33
UB427BE0.book Page 2 Friday, February 5, 2016 2:14 PM

Checking the parking brake pads ...... 8-34
Checking the brake fluid level ............ 8-34
Brake fluid replacement ..................... 8-36
Checking the brake pedal .................. 8-36
Parking brake lever free play adjustment........................................ 8-36
Brake light switch adjustment ............ 8-38
Cable inspection and lubrication........ 8-38
Brake pedal and accelerator pedal lubrication ......................................... 8-38
Checking the stabilizer bushes .......... 8-39
Rear knuckle upper and lower pivot lubrication (left and right) .................. 8-39
Steering shaft lubrication ................... 8-40
Wheel removal.................................... 8-40
Tire replacement ................................ 8-41
Wheel installation ............................... 8-42
Battery ................................................ 8-42
Jump-starting ..................................... 8-46
Fuse replacement............................... 8-47
Replacing a headlight bulb................. 8-50
Headlight beam adjustment ............... 8-52
Tail/brake light bulb replacement ....... 8-53 Troubleshooting ..................................8-54
Troubleshooting charts .......................8-56
CLEANING AND STORAGE ....................9-1 Cleaning................................................9-1
Storage .................................................9-2
SPECIFICATIONS..................................10-1
CONSUMER INFORMATION ................11-1 Identification number records.............11-1
INDEX ....................................................12-1
UB427BE0.book Page 3 Friday, February 5, 2016 2:14 PM

3-1
3
EBU31170
DESCRIPTION
EBU31180Left view
138
7
9101112
14
13 64
2
5
1. Front shock absorber assembly
2. Radiator cap
3. Brake fluid reservoir
4. Driver seat
5. Shoulder bolster
6. Driver seat belt
7. Cargo bed
8. Tail/brake light
9. Spark arrester
10.Rear shock absorber assembly
11.Spark plug
12.Cargo bed release lever
13.Storage compartment (for YXM70VPSH)
14.DoorUB427BE0.book Page 1 Friday, February 5, 2016 2:14 PM

3-2
3
EBU31190Right view
11 10
9856
4321
7
1. Engine oil dipstick
2. Passenger seat belt
3. Passenger seat
4. Air filter
5. Battery
6. Fuses
7. Headlight
8. Coolant reservoir
9. Storage compartment
10.Fuel tank cap
11.Oil filter cartridgeUB427BE0.book Page 2 Friday, February 5, 2016 2:14 PM

3-3
3
EBU31200Controls and instrumentsThe vehicle you have purchased may differ slightly from those shown in the figures of this man-
ual.
11
10
2
3
4
5
6,7
8
9
1
16
14
12
1315
1. Light switch
2. On-Command drive knob
3. Steering wheel
4. Main switch
5. Parking brake lever
6. Helmet indicator light
7. Seat belt indicator light
8. Drive select lever
9. Horn switch
10.Accelerator pedal
11.Brake pedal
12.Multi-function meter unit
13.Passenger handhold
14.Glove compartment
15.Auxiliary DC jack
16.Storage compartmentUB427BE0.book Page 3 Friday, February 5, 2016 2:14 PM

4-1
4
EBU31213INSTRUMENT AND CONTROL FUNCTIONSEBU31220Main switchFunctions of the respective switch positions
are as follows:
EBU31230“” (on):
All electrical circuits are supplied with power.
The key cannot be removed.TIPThe helmet indicator light comes on and stays
on while the key is turned to “ ” (on). EBU31240“ ” (off):
All electrical circuits are switched off. The key
can be removed.EBU31250“” (start):
The electric starter is engaged by turning and
holding the key in this position. Release the
key when the engine starts.
1. Main switch
2. “ ” (off)
3. “ ” (on)
4. “ ” (start)
1
2
34
UB427BE0.book Page 1 Friday, February 5, 2016 2:14 PM

4-2
4
EBU31262Indicator lights and warning lights
EBU31270Low-range indicator light “L”
This indicator light comes on when the drive
select lever is in the “L” position.EBU31280High-range indicator light “H”
This indicator light comes on when the drive
select lever is in the “H” position.
1. On-Command differential gear lock indicator light “DIFF. LOCK”
2. Low-range indicator light “L”
3. High-range indicator light “H”
4. Neutral indicator light “N”
5. Reverse indicator light “R”
6. Parking brake indicator light “ ”
7. On-Command four-wheel-drive/differential gear lock indicator “ ”/“ ”
8. Engine trouble warning light “ ”
9. Coolant temperature warning light “ ”
10.Electric Power Steering warning light “EPS”356421
7
8109
1. Helmet indicator light “ ”
2. Seat belt indicator light “ ”
21
UB427BE0.book Page 2 Friday, February 5, 2016 2:14 PM
