8-45
8
Tapered nuts are used for both the front and
rear wheels. Install the nuts with their tapered
side towards the wheel.
2. Lower the ATV to the ground.
3. Tighten the wheel nuts to the specified
torques.
1. Arrow mark
1. Tapered nutTightening torques:Front wheel nut:55 N·m (5.5 kgf·m, 40 lb·ft)
Rear wheel nut: 55 N·m (5.5 kgf·m, 40 lb·ft)
