Driver side overview

Fig. 5 Driver side overview.
Key to ⇒ fig. 5:
(1) Instrument cluster:
– Instruments
– Display
– Warning and indicator lights
(2) Headlight switch

Warning and information texts
The status of various vehicle functions and components is monitored
when the ignition is switched on and while driving. Malfunctions are
indicated by red and yellow warning symbols with text messages in
the instrument cluster display (⇒ Warning and indicator lights). In
some cases, they may also be signaled acoustically. The display can
vary depending on the instrument cluster model.

Type of
notification
Symbol
color
Explanation
Priority 1
warning
message
Red Symbol flashing or lit – sometimes with
acoustic warnings.

The trip odometer (trip) shows the distance driven since the last time
the trip odometer was reset. The last digit indicates 1/10 mile
(100 meters).
Outside temperature display
At outside temperatures below about +39 °F (+4 °C), a “snowflake
symbol” (icy road warning) appears in the display. The symbol flashes
at first, then stays on until the outside temperature rises above +43 °F
(+6 °C) ⇒ .
When the vehicle is not moving or when you are driving at very low
speeds, the temperature displayed may be slightly higher than the
actual outside temperature.
The measurement range is from -40 °F (-40 °C) to +122 °F (+50 °C).
Compass display (if applicable)
On vehicles equipped with compass display, the current compass
direction is indicated in the instrument cluster display when the igni-
tion and navigation system are switched on ⇒  Compass.
Selector lever positions
The selector lever position is shown both on the side of the selector
lever and in the instrument cluster display. The respective gear may
also be shown in the instrument cluster display in Drive D and Sport
Drive S, as well as in Tiptronic® mode.
Gear recommendation (manual transmission)
When the vehicle is moving, a fuel economy gear recommendation
may appear in the instrument cluster display ⇒  Shifting.

WARNING
Failure to heed warning lights and instrument cluster text mes-
sages can cause the vehicle to break down in traffic and result
in a collision and serious personal injury.
Never ignore warning lights or text WARNINGS.
Always stop the vehicle as soon as it is safe to do so.
Park the vehicle at a safe distance from moving traffic and
where no part of the hot catalytic converter and exhaust system
can come into contact with flammable materials under the vehi-
cle, such as dry grass, brush, spilled fuel, etc.
A broken down vehicle presents a high accident risk for itself
and others. Switch on emergency flashers and set up a warning
triangle to warn oncoming traffic.
WARNING
Roads and bridges may be dangerously icy even if the outside
air temperature is above freezing.
If you use the outside temperature display to tell you about
frost conditions, remember that roads can even ice over at
temperatures above +39 °F (+4 °C). Always remember: even if
the “snowflake symbol” (icy road warning) is not displayed,
there could still be black ice on the road.
Never rely exclusively on the outside temperature display.
NOTICE
Failure to heed warning lights or text WARNINGS can result in
vehicle damage.
The instrument cluster displays and their arrangement may vary
depending on the vehicle model and engine. For displays without
warning and information messages, malfunctions are only signaled
with indicator lights.
If there are multiple warning messages, the symbols are dis-
played for several seconds in order of importance. The symbols are
displayed until the cause has been corrected.

Menu Function See
Vehicle
status
Current warning and information
messages.
This menu item is only displayed
when warning or information
messages are available. The
number of available messages is
shown in the display. Example:
1/1 or 2/2.

Settings Includes the Convenience and
Lights & Vision submenus, as
well as many settings such as
time, speed warning for winter
tires, language, and units.

MFI menu (Multi-Function Indicator)

Settings
menu
Function
Lights &
Vision
Vehicle lighting settings
Time Set hours and minutes for the instrument cluster
clock, the Radio & Navigation System clock, and the
analog clock. The digital clocks can be set to show
the time in 12 or 24 hour format, and can also be set
to daylight savings time.
Snow tires Set up a visual and acoustic speed warning. Use the
feature only when winter tires are installed that have
a speed rating less than top vehicle speed.
Compass Calibrate the compass on vehicles without a factory-
installed navigation system. To calibrate, follow the
instructions in the instrument cluster display
Units Set the units in which temperature, fuel consumption,
and distances should be displayed (for example,
whether to show distance driven in miles or kilome-
ters).
Service View the service reminder display
Factory
setting
Reset the functions in the Settings menu back to the
factory settings.

Lights & Vision submenu

WARNING
Vehicle health reports do not replace the information provided
by the vehicle warning and indicator lights. Failure to heed
warning lights and instrument cluster text messages can cause
the vehicle to break down in traffic and result in a collision and
serious personal injury.
Never ignore warning lights or text WARNINGS.
Always stop the vehicle as soon as it is safe to do so.
Park the vehicle at a safe distance from moving traffic and
where no part of the hot catalytic converter and exhaust system
can come into contact with flammable materials under the vehi-
cle, such as dry grass, brush, spilled fuel, etc.
A broken down vehicle presents a high accident risk for itself
and others. Switch on emergency flashers and set up a warning
triangle to warn oncoming traffic.
Before opening the engine hood, always switch off the en-
gine and let the engine cool down.
Always be very careful when working in the engine compart-
ment, which is a potentially dangerous area in any motor vehi-
cle and can cause serious personal injury.
NOTICE
Failure to heed warning lights or text WARNINGS can result in
vehicle damage.
Volkswagen collects, processes, transmits, uses and shares in-
formation about you and your vehicle in accordance with the
Volkswagen Car-Net Terms of Service and Privacy Policy. See the
Volkswagen Car-Net Terms of Service and Privacy Policy at
http://www.vw.com/carnet for more details.
Volkswagen Car-Net services use a system based on a wireless
communication network. If all technical and other conditions are met
and Volkswagen Car-Net still does not work properly, please try using
the service again later.

WARNING
Refer to your vehicle's warning and indicator lights for the most
current diagnostic information. Always consult this manual for
maintenance guidelines. Failure to heed warning lights and in-
strument cluster text messages can cause the vehicle to break
down in traffic and result in a collision and serious personal
injury.
Never ignore warning lights or text WARNINGS.
Always stop the vehicle as soon as it is safe to do so.
Park the vehicle at a safe distance from moving traffic and
where no part of the hot catalytic converter and exhaust system
can come into contact with flammable materials under the vehi-
cle, such as dry grass, brush, spilled fuel, etc.
A broken down vehicle presents a high accident risk for itself
and others. Switch on emergency flashers and set up a warning
triangle to warn oncoming traffic.
The Volkswagen Car-Net website (http:// www.vw.com/carnet)
contains the most up-to-date information and instructions about
Volkswagen Car-Net services.
Please regularly visit the website to learn about changes to ser-
vices and new features.
Volkswagen Car-Net features can be modified, discontinued, deac-
tivated, reactivated or expanded without any further notice.
Application software (“apps”)
