2017 VOLKSWAGEN CC jump start

If the vehicle battery is dead, the electronic parking brake cannot
be released. Use a jump-start ⇒  Jump-starting.
You may hear noises when setting or releasing the electronic
parking brake.
If the electronic parking brake is not used for a while, an automat-
ic system check will occasionally run when the vehicle is parked. This
system check makes audible noises.
Parking

The engine coolant system is under pressure when the en-
gine is hot. Never unscrew the coolant expansion tank cap
when the engine is hot. Hot coolant can spray out and cause
severe burns and other serious injuries.
– Turn the cap slowly and very carefully in a counterclock-
wise direction while applying light downward pressure on the
top of the cap.
– Always protect your face, hands, and arms from hot escap-
ing coolant or steam by covering the cap with a large, thick
rag.
Never spill fluids on the engine or exhaust system when re-
filling. Spilling fluids onto hot parts of the engine or exhaust
system can cause a fire.
WARNING
High voltage systems in the engine compartment can cause
electrical shocks or even electrocution, severe burns, other se-
rious injuries, and even death!
Never short-circuit the electrical system. Be especially care-
ful when using jumper cables. The vehicle's battery could ex-
plode!
To reduce the risk of electrical shock and personal injury
while the engine is running or being started:
– Never touch ignition cables. Never touch other compo-
nents of the high voltage electronic ignition system.
– Never touch the wiring of the HID – High Intensity Dis-
charge (Xenon) headlights.
Read and heed the important information and warnings on
cleaning the engine compartment ⇒  Cleaning the engine com-
partment.

Practical tips
Frequently asked questions (FAQ)
If you suspect a malfunction or vehicle damage, read and follow the
following advice before contacting an authorized Volkswagen dealer
or an authorized Volkswagen Service Facility. You may also find help-
ful information under “Special considerations” or “Checklist” in the
index.

Description Possible causes,
among others Possible remedy
Engine does not
start.
Vehicle battery dead. – Perform jump-start
– Charge vehicle battery
The wrong vehicle
key is used. Use a valid vehicle key
Fuel level too low. Refuel
Vehicle cannot be
locked or un-
locked using ve-
hicle key.
– Battery in the re-
mote control vehicle
key is dead.
– Too far away from
the vehicle (out of
range).
– Buttons have been
pressed too many
times.
– Replace the battery in
the remote control vehicle
key
– Move closer to vehicle.
– Synchronize vehicle key
– Lock or unlock vehicle
manually
Unusual noises.
Cold engine, braking
assist systems, elec-
tronic steering col-
umn lock.
Check the “Noises” entry
in the index.
Odd driving
behavior.
Assistance systems
activated.
Check the “Assistance
systems” entry in the in-
dex.

Jump-starting

WARNING
Improper use of jumper cables when jump-starting a vehicle
with a dead battery can cause the battery to explode, leading to
serious personal injury. To help reduce the risk of battery ex-
plosion:
All work on the batteries or the electrical system in your ve-
hicle can cause serious acid burns, fires, or electrical shocks.
Always read and heed the following WARNINGS and safety pre-
cautions before working on the batteries or the electrical sys-
tem ⇒  Vehicle battery.
Always make sure that the battery providing starting assis-
tance (the booster battery) has the same voltage as the dead
battery (12 V) and about the same amperage capacity (see bat-
tery label).
Never jump-start a vehicle with a thawed or frozen vehicle
battery. The battery can explode. A dead battery can freeze at
temperatures around +32 °F (0 °C).
A battery that is frozen or was frozen, but has since thawed,
must be replaced.
When the vehicle battery is jump-started, it gives off hydro-
gen gas, which is highly explosive! Always keep fire, sparks,
open flame, and smoking materials far away from vehicle bat-
teries. Never use a mobile telephone while connecting or dis-
connecting jumper cables.
Jump-start batteries only in well-ventilated areas. Batteries
give off highly explosive hydrogen gas during jump-starting.
Always route the jumper cables so that they cannot get
caught in any moving parts in the engine compartment.
Never short out the battery terminals by connecting the posi-
tive (+) and negative (-) terminals with each other.
Never connect the negative cable from the other vehicle di-
rectly to the negative terminal of the dead battery, as this may
cause the hydrogen gas given off by the dead battery to ex-
plode.
Never attach the negative cable from the vehicle providing
starting assistance to any part of the fuel system or to the
brake hoses or brake lines.

Never allow the non-insulated parts of the battery clamps to
touch.
Never allow the jumper cable attached to the positive battery
terminal to contact metal parts of the vehicle.
Always follow the instructions of the jumper cable manufac-
turer.
NOTICE
To help prevent extensive damage to the vehicle electrical sys-
tem, read and heed the following:
Connecting jumper cables improperly can cause a short cir-
cuit and do expensive damage to the vehicle's electrical system.
Do not let the vehicles touch each other while the jumper ca-
bles are connected. If they do, electrical current may flow be-
tween the vehicles when the positive (+) terminals are connect-
ed, causing electrical system damage.
Positive jump start terminal, 3.6 liter engine

Fig. 210 In the engine compartment: Positive jump start terminal +.

jump-start terminal6 ⇒ Positive jump start terminal, 3.6 liter engine,
⇒ fig. 210 (+).
3. Attach one end of the red jumper cable to the positive terminal (+)
of the dead battery: (1) ⇒ .
4. Attach the other end of the red jumper cable to the positive termi-
nal (+) of the good battery (booster battery): (2).
5. Attach one end of the black jumper cable to the negative terminal
(-) of the booster battery: (2) ⇒ fig. 211.
6. Attach the other end of the black jumper cable (3) to a bare metal
part of the vehicle with the dead battery. This part should be
connected directly to the engine block. You may also attach the
cable to the engine block itself. Attach the clamp to a point that is
as far away as possible from the dead battery (1) ⇒ .
7. Route the jumper cables so that they cannot get caught in any
moving parts in the engine compartment of either vehicle.
Starting the engine
Start the engine of the vehicle with the good battery that is provid-
ing help and let it run at idle speed.
Turn on the ignition of the vehicle with the dead battery. If the en-
gine starts, wait 2 to 3 minutes until it “runs smoothly” before remov-
ing the jumper cables as described below ⇒ . If the engine does not
start within about 10 seconds, turn off the ignition and wait at least
1 minute; then try again.
Before removing the jumper cables
Switch off the headlights (if they are on).
In the vehicle with the dead battery, switch on the heater fan and
the rear window defroster. This helps to minimize voltage spikes
when the cables are disconnected.
Removing jumper cables
With the engine running, remove the jumper cables in reverse order
to the way they were connected.
1. Disconnect the black (-) cable from the vehicle with the dead bat-
tery.

6 For vehicles without a battery in the engine compartment, see ⇒ page 587, Positive jump start terminal, 3.6 liter engine

2. Disconnect the black (-) cable from the other vehicle (vehicle with
the good battery).
3. Disconnect the red (+) cable from the other vehicle (vehicle with the
good battery).
4. Disconnect the red (+) cable from the vehicle with the dead battery.
5. Close the battery cover or snap shut the cap on the positive jump-
start terminal6, as the case may be.
6. If necessary, unscrew the towing eye on the front of the vehicle ⇒ 
Installing the front towing eye.
