2017 VOLKSWAGEN CC warning

WARNING
Improperly lifting your vehicle with a workshop hoist or a floor
jack can cause the vehicle to fall off and cause serious person-
al injury.
Always read and heed the operating instructions from the
floor jack manufacturer and legal regulations if necessary be-
fore using the floor jack to lift the vehicle.
Never let anyone stay in the vehicle when it is being lifted or
when it is off the ground.
Always lift your vehicle only at the designated lift points
shown in the illustrations ⇒ fig. 173 and ⇒ fig. 174. Not using the
designated lift points can cause the vehicle to fall off the floor
jack when heavy parts such as the engine or transmission are
removed.
Always make sure that the vehicle's lift points lie as flat as
possible and centered on the carrier plates of the floor jack.
Never start the engine when you have raised the vehicle on
the floor jack. The engine vibrations and vehicle movements
could knock the vehicle off the floor jack.
If you must work under a vehicle raised on a floor jack, al-
ways make sure that the vehicle is safely supported on safety
stands intended for that purpose that are strong enough to
support the weight of the vehicle.
Never use the floor jack as a ladder or step ladder.
Always make sure that the weight of the vehicle is not heavi-
er than the lifting capacity of the floor jack and safety stands
being used.
NOTICE
To help prevent serious vehicle damage, never lift the vehicle
by the engine oil pan, transmission housing, or by the front or
rear axles or suspension.
To help prevent damage to the underbody or chassis, always
insert a rubber pad between the hoist and the lifting points. In
addition make sure the lifting arms have enough clearance.
The lifting arms should not touch side sills or other parts of
the vehicle.

8. Set up a warning triangle or other warning device in order to alert
other motorists and cyclists.
9. Let the engine cool down and get expert assistance if necessary.
If the emergency flashers are on, use the turn signal lever to indicate
a direction or lane change, for example when the vehicle is being
towed. This temporarily interrupts the emergency flashers.
Switch on the emergency flashers when:
Traffic suddenly slows down or stops in front of you to warn those
approaching from behind.
In any emergency situation.
If the vehicle breaks down.
When being towed.
Always obey traffic laws that govern the use of emergency flashers
where you are driving.
If the emergency flashers are not working, a different method – as
permitted by law – must be used to alert other motorists and cyclists
to the breakdown.
WARNING
Disregarding the safety-related checklist may lead to accidents
and serious personal injuries.
Always review and follow the checklist. Follow accepted safe-
ty practices and use common sense.
WARNING
The vehicle exhaust system and the catalytic converter get very
hot. They can cause fires and serious personal injury.
Never park where parts of the hot exhaust system or catalytic
converter could ignite flammable materials, such as dry grass,
brush, leaves, spilled fuel, etc.
The vehicle battery will be drained if the emergency flashers are
on for a long time – even if the ignition is switched off.

WARNING
Serious injuries can result if the emergency closing and open-
ing procedures are used carelessly.
Never leave children, disabled persons, or anyone who can-
not help themselves in the vehicle. The doors can be locked
with the remote control vehicle key. This could result in people
being trapped in the vehicle in an emergency.
A closed vehicle can become very hot or very cold, depend-
ing on the season. Particularly in the summer, heat buildup in
the passenger and luggage compartment of a parked vehicle
can result in temperatures in the vehicle that are much higher
than the outside temperatures. Temperatures can quickly reach
levels that can cause unconsciousness and death, particularly
to small children.
WARNING
Careless opening and closing of the doors, the luggage com-
partment lid, and the power sunroof is dangerous and can
cause serious personal injury.
Open or close the doors, the luggage compartment lid, and
the power sunroof only when no one is in the way.
NOTICE
If the vehicle's battery fails or the power windows won't work,
the door windows are not lowered when the door is opened or
closed. Always close and open the door carefully to help prevent
damage to the window, the paint, or the rubber seal.
NOTICE
To help prevent vehicle damage, carefully remove and properly
reinstall parts after emergency locking or unlocking.

Preparations
Set the electronic parking brake. If the electronic parking brake
cannot be set, you must find another way to help prevent the vehicle
from moving.
Switch off the ignition.
Removing the selector gate cover
Pull upward on the cover around the selector lever sleeve
⇒ fig. 182.
Slip the cover up and over the selector lever ⇒ .
Emergency release for the selector lever (Version A)
With the screwdriver from the vehicle tool kit, carefully push the
release lever ⇒ fig. 183 A in the direction of the arrow and hold it in
this position.
Press the release button in the selector lever handle and shift the
selector lever to Neutral (N).
Carefully press the selector gate cover back in place, making sure
that the electrical wiring stays in the correct position and is not
pinched or damaged.
Emergency release for the selector lever (Version B)
Push the release lever ⇒ fig. 183 B in the direction of the arrow and
hold it in this position.
Press the release button in the selector lever handle and shift the
selector lever to Neutral (N).
Carefully press the selector gate cover back in place, making sure
that the electrical wiring stays in the correct position and is not
pinched or damaged.
WARNING
Never shift the transmission out of Park (P) without first setting
the electronic parking brake. Otherwise, the vehicle can start to
roll unexpectedly, especially on hills or inclines, and cause an
accident and serious injuries.

WARNING
Changing a wheel, especially on the side of the road, can be
dangerous. To help reduce the risk of serious personal injury:
Always stop the vehicle as soon as it is safe to do so. Move
the vehicle a safe distance off the road where it is safe to
change the wheel.
Always make sure that all passengers, especially children,
are in a safe place outside the vehicle and away from the vehi-
cle and traffic (such as behind a guard rail).
Turn on the emergency flashers and set up another warning
device about 25 yards (25 meters) behind the vehicle to warn
approaching traffic.
Change a wheel by yourself only if you are familiar with the
necessary steps. Otherwise, get expert assistance.
Always switch the engine off, set the electronic parking
brake, and shift the transmission into Park (P) (automatic
transmission) or any gear (manual only) to help prevent the ve-
hicle from moving suddenly and slipping off the jack.
Always make sure that the ground is level and firm. If neces-
sary, place the jack on a large and sturdy board or on a similar
ground support.
Always block the wheel diagonally opposite the wheel being
changed with chocks or other similar things.
If you are towing a trailer, always unhitch it from your vehicle
before starting to change the wheel. Always apply the trailer
brakes firmly and make sure the trailer cannot move uninten-
tionally.
Always use proper and undamaged tools when changing a
wheel.
Once a wheel is lifted off the ground, having the transmission
in Park (P) or in gear will not prevent sudden vehicle move-
ment.
Always use a jack that has been approved by the manufac-
turer for your vehicle. Never use other jacks, even if they have
been approved for use on other Volkswagen models.
To reduce the risk of losing control, crashes, and serious
personal injuries, never loosen the screws on rims with thread-
ed rim rings.

WARNING
Disregarding the safety-related checklist may lead to accidents
and serious personal injuries.
Always review and follow the checklist. Follow accepted safe-
ty practices and use common sense.
Wheel bolts

Fig. 190 Changing a wheel: Loosening wheel bolts.

length and bolt head shape must be used. The attachment of the
wheels and function of the brake system depend on this.
It may not be possible to use wheel bolts from different vehicles of the
same model.
Wheel bolt tightening torque
Correctly tightened bolts for steel and alloy wheel rims should have a
torque of 88 ft-lbs. (120 Nm). After changing a wheel, have the wheel
bolt tightening torque checked right away with an accurate torque
wrench.
Before you check the tightening torque, replace corroded and diffi-
cult-to-turn wheel bolts and clean the threads in the wheel hub.
Never grease or oil the wheel bolts and the threads in the wheel
hubs. The bolts can come loose while driving if greased or oiled, even
if tightened to the required torque.
WARNING
Improperly tightened wheel bolts can come loose while driving
and cause you to lose control over the vehicle, resulting in ac-
cidents and serious injuries.
Only use wheel bolts that belong your vehicle and to the
wheel being installed.
Never use different wheel bolts.
Wheel bolts and wheel hub threads must always be clean,
easy-to-turn and free of oil and grease.
Only use the lug wrench that is supplied with the vehicle to
loosen the wheel bolts.
Loosen the wheel bolts only about 1 turn before lifting the
vehicle with the jack.
Never grease or oil the wheel bolts and the threads in the
wheel hubs. The bolts can come loose while driving if greased
or oiled, even if tightened to the required torque.
Never loosen bolted connections on wheel rims with bolted
rim rings.
If the wheel bolts are not tightened to the proper torque, the
wheel can come off the vehicle when it is moving. Extremely
high torque can damage the wheel bolts and/or their threads.

WARNING
Improper use of your vehicle jack can cause the vehicle to fall
off the jack leading to serious personal injury. To help reduce
the risk of serious personal injury:
Use only jacks approved by Volkswagen for the vehicle. Oth-
er jacks might slip, even those approved for other Volkswagen
models, but not for your vehicle.
Always set up the jack on firm and level ground. The vehicle
may slip off the jack if the jack is resting on soft or sloping
ground. If necessary, place a sturdy board under the jack.
On a hard, slippery surface (such as a tiled floor), use an anti-
skid rubber mat or something similar to help prevent the jack
from slipping.
Position the jack only at the described vehicle lift points. Be-
fore you raise your vehicle, always make sure the jack claw
properly grips the vertical rib under the sill so that the jack
does not slip off when you are raising the vehicle ⇒ fig. 192.
Never have any part of your body (such as your arm or leg)
under the vehicle when it is supported by the jack. Never let
other persons have any part of their body under the vehicle,
either!
If you must work under a vehicle raised on a floor jack, al-
ways make sure that the vehicle is safely supported on safety
stands intended for that purpose that are strong enough to
support the weight of the vehicle.
Never lift the vehicle when it is tilted or inclined to one side
or the engine is running.
Never lift the vehicle when more than 1 tire is flat or dam-
aged.
Do not start the engine while the vehicle is supported by a
jack. Engine vibrations may cause the vehicle to slip off the
jack.
