2017 VOLKSWAGEN CC center console

Opening the socket cover

Fig. 131 Rear center console: Open by pushing a button.

Fig. 132 Rear center console: Open by pushing the cover up.

Starter button

Fig. 134 In the center console: Starter button for the Keyless Access
locking and starting system.

Electronic parking brake

Fig. 144 In the lower section of the center console: Electronic parking
brake button.

WARNING
The effectiveness of ESC can be significantly reduced if other
components and systems that affect vehicle dynamics, includ-
ing but not limited to brakes, tires, and other systems men-
tioned above, are not properly maintained or functioning.
Always remember that vehicle alterations or modifications
can affect the functioning of the ABS, BAS, ASR, EDL, and ESC
systems.
Changing the vehicle suspension or using an unapproved
tire/wheel combination can change the way the ABS, BAS, ASR,
EDL, and ESC systems work and reduce their effectiveness.
The effectiveness of ESC is also determined by the tires fitted
⇒  Tires and wheels.
All 4 wheels must be equipped with identical tires in order for
ESC and ASR to work properly. Differences in the tread circumfer-
ence of the tires can cause the system to reduce the engine power
when it is not expected.
If ABS is not working, ESC, ASR, and EDL will also not work.
You may hear noises when these systems are active.
Switching Anti-Slip Regulation (ASR) on and off

Fig. 145 In the center console: Button for switching ASR on and off
manually.

Fig. 157 In the center console: Button to switch the Park Distance
Control system on or off.
