2017 VAUXHALL COMBO D coolant temperature

Instruments and controls67Instruments and
controlsControls ....................................... 68
Steering wheel adjustment ........68
Steering wheel controls .............68
Horn ........................................... 68
Windscreen wiper/washer .........69
Rear window wiper/washer .......69
Headlamp washer .....................70
Outside temperature ..................70
Clock ......................................... 70
Power outlets ............................. 72
Cigarette lighter ......................... 73
Ashtrays .................................... 73
Warning lights, gauges and indi‐ cators ........................................... 74
Instrument cluster ......................74
Speedometer ............................. 74
Odometer .................................. 74
Trip odometer ............................ 74
Tachometer ............................... 74
Fuel gauge ................................ 75
Fuel selector .............................. 75
Engine coolant temperature gauge ....................................... 76
Service display .......................... 76Transmission display .................77
Control indicators ......................77
Generic warning ........................79
Turn signal ................................. 80
Seat belt reminder .....................80
Airbag and belt tensioners .........80
Airbag deactivation ....................81
Charging system .......................81
Malfunction indicator light ..........81
Brake system ............................. 82
Brake pad wear ......................... 82
Antilock brake system (ABS) .....82
Transmission ............................. 82
Gear shifting .............................. 83
Hill start assist ........................... 83
Ultrasonic parking assist ...........83
Electronic Stability Control ........83
Engine coolant temperature ......84
Preheating ................................. 84
Diesel particle filter ....................84
Tyre pressure monitoring system ...................................... 85
Engine oil pressure ....................85
Change engine oil .....................86
Low engine oil level ...................86
Low fuel ..................................... 86
Drain fuel filter ........................... 87
Immobiliser ................................ 87
Stop-start system ......................87
Exterior light .............................. 87High beam................................. 87
Fog light ..................................... 88
Rear fog light ............................. 88
Cruise control ............................ 88
Door open .................................. 88
Information displays .....................88
Driver Information Centre ..........88
Vehicle messages ........................93
Warning chimes .........................93
Fuel system messages ..............94
Trip computer ............................... 94

76Instruments and controls1 off:natural gas
operation1 illuminates:petrol operation
During natural gas operation, if
control indicator Y illuminates in the
Driver Information Centre 3 88, the
natural gas tanks are empty and
petrol operation is automatically
engaged.
Fuel for natural gas operation 3 130,
Refuelling 3 131.
Engine coolant temperature gauge
Displays the coolant temperature.
If control indicator $ illuminates, the
coolant temperature is too high.
Depending on version, a message
also appears in the Driver Information Centre 3 88. Seek the assistance of
a workshop.Caution
If engine coolant temperature is
too high, stop vehicle, switch off
engine. Danger to engine. Check
coolant level.
Service display
Service display is available in
vehicles with Multifunction version of the Driver Information Centre 3 88.
When the ignition is switched on, the remaining distance before the next
service is due may be shown briefly.
Based on driving conditions, the
interval at which a service will be
indicated can vary considerably.
When the remaining distance before
the next service is less than
1,250 miles, Serv. appears in the
Driver Information Centre. The
service reminder is repeated after
every additional 125 miles and
becomes more frequent when the
remaining distance is below
125 miles.
When the remaining distance has
reduced to zero, a warning message, e.g. Service coupon expired , appears
in the Driver Information Centre.
The vehicle needs a service. Seek the
assistance of a workshop.
The remaining distance to the next
service may also be viewed in the
Driver Information Centre by
selecting Service from the settings
menu options 3 88.

Instruments and controls79Control indicator in the roof
console
Airbag deactivation 3 51, 3 81.
Overview
9Generic warning 3 79OTurn signal 3 80XSeat belt reminder 3 80vAirbag and belt tensioners
3 80*Airbag deactivation 3 81pCharging system 3 81ZMalfunction indicator light
3 81RBrake system 3 82FBrake pad wear 3 82uAntilock brake system (ABS)
3 82sTransmission 3 82[ ÒGear shifting 3 83ZHill start assist 3 83rUltrasonic parking assist
3 83RElectronic Stability Control
3 83$Engine coolant temperature
3 84!Preheating 3 84%Diesel particle filter 3 84wTyre pressure monitoring
system 3 85IEngine oil pressure 3 85,
Change engine oil 3 86SLow engine oil level 3 86$Low fuel 3 86UDrain fuel filter 3 87dImmobiliser 3 87ÆStop-start system 3 878Exterior light 3 87µExterior light failure 3 87CHigh beam 3 87>Fog light 3 88øRear fog light 3 88mCruise control 3 88(Door open 3 88
Generic warning
9 illuminates yellow.
Depending on model variant, control
indicator 9 may illuminate
independently or in conjunction with
Æ 3 87, t 3 87, Z 3 83 or r
3 83.

84Instruments and controlsFlashes during driving
The system is actively engaged.
Engine output may be reduced and
the vehicle may be braked
automatically to a small degree.
Illuminates during driving A fault in the system is present.
Continued driving is possible. Driving
stability, however, may deteriorate
depending on road surface
conditions.
Have the cause of the fault remedied
by a workshop.
Depending on version, a
corresponding warning message,
e.g. ESP unavailable , may also be
displayed in the Driver Information Centre 3 88.
Electronic Stability Control (ESC)
3 125, Traction control system/Anti-
Slip Regulator (ASR) 3 124.
Engine coolant temperature
$ illuminates red.
Illuminates for a few seconds after the ignition is switched on.If control indicator $ illuminates, the
coolant temperature is too high. Depending on version, a warning
message may also be displayed in
the Driver Information Centre 3 88.
Seek the assistance of a workshop.Caution
If engine coolant temperature is
too high, stop vehicle, switch off
the ignition. Danger to engine.
Check coolant level.
If the control indicator remains on, seek the assistance of your
workshop.
Engine coolant temperature gauge
3 76.
Preheating
! illuminates yellow.
Preheating of diesel engine is
activated. Only activates when
outside temperature is low.
Notice
In very hot outside
temperatures, ! may illuminate
briefly when the ignition is switched
on.
The engine can be started when !
extinguishes.
Starting the engine 3 111.
Flashes
A fault is detected in the engine
preheating system. Depending on
version, a corresponding warning
message, e.g. Check glow plugs ,
may also be displayed in the Driver
Information Centre 3 88.
If ! does not extinguish, consult a
workshop.
Diesel particle filter % illuminates yellow.
Illuminates for a few seconds after the ignition is switched on.
If it does not extinguish after a brief
delay or illuminates whilst driving, the
diesel particle filter requires cleaning.

114Driving and operatingAutostop
If the vehicle is at a low speed or at a standstill, activate an Autostop as
follows:
● depress the clutch pedal● set the lever to neutral
● release the clutch pedal
The engine will be switched off while the ignition stays on.
An Autostop is indicated when control
indicator ^ flashes in the Driver
Information Centre 3 88.
During an Autostop, the heating,
power steering and brake
performance will be maintained.
Caution
The steering assist may be
reduced during an Autostop.
Conditions for an Autostop
The stop-start system checks if each
of the following conditions is fulfilled.
Otherwise an Autostop will be
inhibited.
● the stop-start system is not manually deactivated
● the bonnet is fully closed
● the driver's door is closed and the
driver's seat belt is fastened
● the vehicle battery is sufficiently charged and in good condition
● the engine is warmed up
● the engine coolant temperature is
not too high
● the engine exhaust temperature is not too high, e.g. after driving
with high engine load
● the ambient temperature is not too low
● the climate control system allows
an Autostop
● the self-cleaning function of the diesel particle filter is not active
● the vehicle has moved since the last Autostop
● the brake vacuum is sufficient ● the windscreen wipers are not operating at fast speed
● reverse gear is not selected
● heated rear window is not operating
Ambient temperature near to the
freezing point can inhibit an
Autostop.
For manual transmission automated
vehicles, an Autostop may be
inhibited until a speed of approx.
6 mph is reached.
Immediately after motorway driving
an Autostop may be inhibited.
New vehicle running-in 3 111.
Vehicle battery discharge protection
To ensure reliable engine restarts,
several vehicle battery discharge
protection features are implemented
as part of the stop-start system.

140Vehicle care
We recommend the use of the same
grade of engine oil that was used at
last change.
The engine oil level must not exceed
the MAX mark on the dipstick.
Caution
Overfilled engine oil must be
drained or suctioned out.
Capacities 3 184.
Fit the cap on straight and tighten it.
Engine coolant
The coolant provides freeze
protection down to approx. -28 °C. In
cold regions with very low
temperatures, the factory filled
coolant provides frost protection
down to approx. -37 °C.Caution
Only use approved antifreeze.
Coolant level
Caution
Too low a coolant level can cause engine damage.
If the cooling system is cold, the
coolant level should be between the
MIN and MAX mark. Top up if the
level is low.
9 Warning
Allow the engine to cool before
opening the cap. Carefully open
the cap, relieving the pressure
slowly.
To top up, use a 1:1 mixture of
approved coolant concentrate mixed
with clean tap water. If no coolant
concentrate is available, use clean
tap water. Install the cap tightly. Have

Vehicle care141the coolant concentration checked
and have the cause of the coolant
loss remedied by a workshop.
Coolant and antifreeze 3 173.
Power steering fluidCaution
Extremely small amounts of
contamination can cause steering
system damage and cause it to not
work properly. Do not allow
contaminates to contact the fluid
side of the reservoir cap/dipstick or
from entering the reservoir.
If the fluid level in the reservoir falls
below the MIN mark consult a
workshop.
If an unusual noise sounds during
steering or the power steering reacts
conspicuously, seek the assistance of
a workshop.
Washer fluid
Fill with clean water mixed with a
suitable quantity of approved
windscreen washer fluid which
contains antifreeze.
Caution
Only washer fluid with a sufficient
antifreeze concentration provides
protection at low temperatures or
a sudden drop in temperature.
Use of washer fluid containing
isopropanol can damage exterior
lamps.
Washer fluid 3 173.
Brakes A squealing noise, or illumination of
brake pad wear control indicator F
indicates that the brake lining is at its
minimum thickness.
Continued driving is possible but
have the brake linings replaced as
soon as possible.
Once new brake linings are installed,
do not brake unnecessarily hard for
the first few journeys.
Brake pad wear indicator F 3 82.

174Service and maintenanceAdditional engine oil additives
The use of additional engine oil
additives could cause damage and
invalidate the warranty.
Engine oil viscosity
The SAE viscosity grade gives
information on the thickness of the oil.
Multigrade oil is indicated by two
figures, e.g. SAE 5W-30. The first
figure, followed by a W, indicates the
low temperature viscosity and the
second figure the high temperature
viscosity.
Select the appropriate viscosity grade depending on the minimum ambient
temperature 3 177.
All of the recommended viscosity
grades are suitable for high ambient
temperatures.
Coolant and antifreeze
Use only antifreeze approved for the
vehicle. Consult a workshop.
The system is factory filled with
coolant designed for excellent
corrosion protection and frost
protection down to approx. -28 °C. In
regions with very low temperatures,the factory filled coolant provides frost
protection down to approx. -37 °C.
This concentration should be
maintained all year round.
The use of additional coolant
additives that intend to give additional
corrosion protection or seal against
minor leaks can cause function
problems. Liability for consequences
resulting from the use of additional
coolant additives will be rejected.
Washer fluid
Use only washer fluid approved for
the vehicle to prevent damage of
wiper blades, paintwork, plastic and
rubber parts. Consult a workshop.
Brake and clutch fluidOver time, brake fluid absorbs
moisture which will reduce braking
effectiveness. The brake fluid should
therefore be replaced at the specified interval.
