2017 TOYOTA YARIS windshield wipers

3
1
8 7 5 4
3
2
9
6
4-2. Driving proceduresEngine (ignition) switch ..... 136
Automatic transmission ..... 139
Manual transmission ......... 142
Turn signal lever................ 143
Parking brake .................... 144
4-3. Operating the lights
and wipers
Headlight switch ................ 145
Fog light switch ................. 148
Windshield wipers and washer ..................... 150
Rear window wiper and washer ..................... 153
4-4. Refueling
Opening the fuel tank cap .................................. 156
4-5. Toyota Safety Sense C
Toyota Safety Sense C ..... 159
PCS (Pre-Collision System) .... 165
LDA (Lane Departure Alert) .... 178
Automatic High Beam ....... 183
4-6. Using the driving support
systems
Cruise control .................... 188
Driving assist systems....... 192
4-7. Driving tips
Winter driving tips.............. 197 5-1. Using the air conditioning
system and defogger
Air conditioning system...... 202
5-2. Using the audio system Steering wheel audio switches........................... 210
AUX port/USB port ............ 211
5-3. Using the interior lights Interior lights list................. 212• Interior light ................... 212
• Personal lights............... 213
5-4. Using the storage features List of storage features ...... 214• Glove box ...................... 215
• Cup holders ................... 215
• Bottle holders ................ 216
• Auxiliary box .................. 217
Luggage compartment features ........................... 218
5-5. Using the other interior features
Other interior features........ 220 • Sun visors ..................... 220
• Vanity mirrors ................ 220
• Power outlet .................. 221
• Assist grips .................... 2225Interior features

115
4Driving
4-1. Before drivingDriving the vehicle ............. 116
Cargo and luggage ........... 127
Vehicle load limits ............. 131
Trailer towing..................... 132
Dinghy towing (vehicles with an automatic
transmission)................... 133
Dinghy towing (vehicles with a manual
transmission)................... 134
4-2. Driving procedures Engine (ignition) switch ..... 136
Automatic transmission ..... 139
Manual transmission ......... 142
Turn signal lever................ 143
Parking brake .................... 144 4-3. Operating the lights
and wipers
Headlight switch ................ 145
Fog light switch ................. 148
Windshield wipers and washer ..................... 150
Rear window wiper and washer ..................... 153
4-4. Refueling Opening the fuel tank cap .................................. 156
4-5. Toyota Safety Sense C Toyota Safety Sense C ..... 159
PCS (Pre-Collision System) .... 165
LDA (Lane Departure Alert) .... 178
Automatic High Beam ....... 183
4-6. Using the driving support systems
Cruise control .................... 188
Driving assist systems ...... 192
4-7. Driving tips Winter driving tips ............. 197

1504-3. Operating the lights and wipers
Windshield wipers and washer
Operate the lever as follows to operate the wipers.
Ty p e AIntermittent windshieldwiper operation
Low speed windshield wiper operation
High speed windshield wiper operation
Temporary operation
Washer/wiper dual operation
The wipers will automatically oper-
ate a couple of times after the
washer squirts.
Operating the wiper lever
1
2
3
4
5

1514-3. Operating the lights and wipers
4
Driving
Ty p e BIntermittent windshieldwiper operation
Low speed windshield wiper operation
High speed windshield wiper operation
Temporary operation
Washer/wiper dual operation
The wiper will automatically
operate a couple of times after
the washer squirts.
■ The windshield wiper and washer can be operated when
The engine switch is in the “ON” position.
■ If no windshield washer fluid sprays
Check that the washer nozzles are not blocked, if there is washer fluid in the
windshield washer fluid reservoir.
1
2
3
4
5

1524-3. Operating the lights and wipers
NOTICE
■When the windshield is dry
Do not use the wiper, as they may damage the windshield.
■ When the washer fluid tank is empty
Do not operate the switch continually as the washer fluid pump may over-
heat.
■ When a nozzle becomes blocked
In this case, contact your Toyota dealer.
Do not try to clear it with a pin or other object. The nozzle will be damaged.

1644-5. Toyota Safety Sense C
WARNING
●If the area of the windshield in front of the front sensor is covered with
water droplets, use the windshield wipers to remove them.
If the water droplets are not sufficiently removed, the performance of the
front sensor may be reduced.
● If water droplets cannot be properly removed from the area of the wind-
shield in front of the front sensor by the windshield wipers, replace the
wiper insert or wiper blade.
If the wiper inserts or wiper blades need to be replaced, contact your Toy-
ota dealer.
● Do not attach window tinting to the windshield.
● Replace the windshield if it is damaged or cracked.
If the windshield needs to be replaced, contact your Toyota dealer.
● Do not install an antenna in front of the sensor.
● Do not get the front sensor wet.
● Do not allow bright lights to shine into the front sensor.
● Do not dirty or damage the front sensor.
When cleaning the inside of the windshield, do not allow glass cleaner to
contact the lens. Also, do not touch the lens.
If the lens is dirty or damaged, contact your Toyota dealer.
● Do not subject the front sensor to a strong impact.
● Do not change the installation position or direction of the front sensor or
remove it.
● Do not disassemble the front sensor.
● Do not install an electronic device or device that emits strong electric
waves near the front sensor.
● Do not modify any components of the vehicle around the front sensor
(inside rear view mirror, sun visors, etc.) or ceiling.
● Do not attach any accessories that may obstruct the front sensor to the
hood, front grille or front bumper. Contact your Toyota dealer for details.
● If a surfboard or other long object is to be mounted on the roof, make sure
that it will not obstruct the front sensor.
● Do not modify the headlights or other lights.
● Do not attach anything to or place anything on the dashboard.
■ Installation area of front sensor on windshield
When the windshield is fogging up easily, the glass around the front sensor
may be hot due to the heater running. If the glass is touched, it may re\
sult in
burns.

393Alphabetical index
Shift lever ......................... 139, 142Automatic transmission......... 139
If the shift lever cannot be shifted from P ................ 140
Manual transmission ............. 142
Shift lock system ..................... 140
Side airbags ............................... 34
Side doors .................................. 89
Side mirrors ............................. 111 Adjusting and folding ............ 111
Snow tires ................................ 197
Spare tire .................................. 313 Inflation pressure .................. 345
Storage location .................... 313
Spark plug ................................ 342
Specifications .......................... 336
Speedometer .............................. 77
Steering lock ............................ 137
Steering wheel ......................... 107 Adjustment ............................ 107
Audio switches ...................... 210
Stop lights
Replacing light bulbs............. 285
Wattage ................................ 346
Storage feature ........................ 214
Stuck
If the vehicle becomes stuck ................................... 333
Sun visors ................................ 220 Switches
Audio remote control switches ............................. 210
Automatic High Beam switch ................................. 183
Cruise control switch ............ 188
Door lock switches.................. 91
Emergency flashers switch ... 292
Engine switch ....................... 136
Fog light switch ..................... 148
Hazard switch ....................... 292
Ignition switch ....................... 136
LDA (Lane Departure Alert) switch........................ 178
Light switch ........................... 145
Outside rear view mirror switches ............................. 111
PCS (Pre-Collision System) switch ................... 168
Power door lock switch ........... 91
Power window switches........ 113
Rear window defogger switch ................................. 206
Rear window wiper and washer switch..................... 153
Tire pressure warning reset switch ........................ 255
VSC OFF switch ................... 193
Window lock switch .............. 113
Windshield wipers and washer switch..................... 150

395Alphabetical index
Warning buzzersBrake system ....... ................. 302
Key reminder ........................ 137
Open door ............................. 304
PCS (Pre-Collision System).. 165
Seat belt reminder ................ 304
Warning lights............................ 73
ABS....................................... 303
Automatic High Beam indicator .............................. 304
Brake system ....... ................. 302
Charging system ................... 302
Cruise control indicator ......... 304
Driver’s and front passenger’s seat belt reminder light ....... 304
Electric power steering
system ......... ....................... 303
High engine coolant temperature ........................ 302
LDA (Lane Departure Alert) indicator .............................. 304
Low engine oil pressure ........ 302
Low fuel level ........................ 304
Low windshield washer fluid ..................................... 305
Maintenance required reminder light...................... 306
Malfunction indicator lamp .... 302
Open door ............................. 304
PCS (Pre-Collision System).. 303
Slip indicator ......................... 304
SRS ...................................... 303
Tire pressure......................... 305 Washer ............................. 150, 153
Checking............................... 251
Preparing and checking before winter ...................... 197
Switch ........................... 150, 153
Washing and waxing ............... 224
Weight ...................................... 336
Wheels ...................................... 265 Replacing.............................. 265
Size....................................... 345
Window glasses ...................... 113
Window lock switch ................ 113
Windows................................... 113 Power windows..................... 113
Rear window defogger.......... 206
Washer ................................. 150
Windshield wipers ................... 150
Winter driving tips ................... 197
Wireless remote control key ............................................ 85 Locking/Unlocking .................. 85
Replacing the battery............ 270
W
