508 5-2. Steps to take in an emergency
NOTICE
■To avoid damaging the transmission and other components
●Avoid spinning the wheels and do not rev the engine.
● If the vehicle remains stuck after trying these procedures, the vehicle may
require towing to be freed.
● When the automatic transmission fluid temperature warning light comes
on while attempting to free a stuck vehicle, immediately remove your foot
from the accelerator pedal and wait until the warning light turns off. Other-
wise, the transmission may become damaged. (vehicles without multi-
information display) ( →P. 471)
● When a warning message for the automatic transmission fluid temperature
is displayed while attempting to free a stuck vehicle, immediately remove
your foot from the accelerator pedal and wait until the warning message
disappears. Otherwise, the transmission may become damaged. (vehicles
with multi-information display) ( →P. 481)

519
6-1. Specifications
6
Vehicle specifications
Automatic transmission
*: The fluid capacity is the quantity of reference. If replacement is necessary,
contact your Toyota dealer.
Transfer (4WD models)
Fluid capacity*11.7 qt. (11.1 L, 9.8 Imp.qt.)
Fluid type Toyota Genuine ATF WS
NOTICE
■Automatic transmission fluid type
Using automatic transmission fluid other than “Toyota Genuine ATF WS”
may cause deterioration in shift quality, locking up of your transmission
accompanied by vibration, and ultimately damage the automatic transmis-
sion of your vehicle.
Oil capacity 1.43 qt. (1.35 L, 1.19 Imp.qt.)
Oil typeGear oil API GL-5
Recommended oil viscosity SAE 75W-90

520 6-1. Specifications
Brakes
*1: Minimum pedal clearance when depressed with a force of 110 lbf (490 N, 50kgf) with the engine running.
*2: Parking brake pedal travel when depressed with a force of 67.1 lbf (300 N,30.6 kgf).
Chassis lubrication (4WD models)
Steering
Pedal clearance*14.1 in. (104 mm) Min.
Pedal free play 0.04 ⎯ 0.24 in. (1 ⎯ 6 mm)
Brake pad wear limit 0.04 in. (1.0 mm)
Parking brake lining wear limit 0.04 in. (1.0 mm)
Parking brake pedal travel*26 — 9 clicks
Fluid type FMVSS No. 116 DOT 3 or SAE J1703
Propeller shafts Spider Lithium base chassis grease, NLGI No.2
Free playLess than 1.2 in. (30 mm)
Power steering fluid type Automatic transmission fluid DEXRON® II
or III

575
What to do if...
■
Warning lights
P. 473
or
P. 469 P. 470
P. 469 P. 474
P. 470
or
P. 470 P. 472
P. 471
or
P. 4 7 0P. 473
P. 4 7 3P. 471
P. 4 7 0P. 471
P. 4 7 2
Brake system warning
lightLow washer fluid
warning light
Power steering warning
light
Charging system warning
light
Tire pressure warning
light
ABS warning lightOpen door warning light
Low fuel level warning
light
Maintenance required
reminder lightDriver’s seat belt reminder
light
SRS warning lightFront passenger’s seat belt
reminder light
Master warning light
Slip indicator
Automatic transmission
fluid temperature
warning light
Malfunction indicator
lamp
The warning message is displayedP. 480If a warning message is displayed
