5997-3. Do-it-yourself maintenance
7
Maintenance and care
■Situations in which the tire pressure warning system may not oper-
ate properly
●In the following cases, the tire pressure warning system may not operate
properly.
• If non-genuine Toyota wheels are used.
• When a replacement tire is used , the system may not operate cor-
rectly due to the structure of the replacement tire.
• A tire has been replaced with a tire that is not of the specified size.
• Tire chains etc. are equipped.
• An auxiliary-supported run- flat tire is equipped.
• If a window tint that affects the radio wave signals is installed.
• If there is a lot of snow or ice on the vehicle, particularly around the wheels or wheel housings.
• If the tire inflation pressure is extremely higher than the specified level.
• If wheel without the tire pressure warning valve and transmitter is
used.
• If the ID code on the tire pressure warning valves and transmitters is not registered in the tire pressure warning computer.
●Performance may be affected in the following situations.
• Near a TV tower, electric power plant, gas station, radio station, largedisplay, airport or other facility that generates strong radio waves or
electrical noise
• When carrying a portable radio, cellular phone, cordless phone or other wireless communication device
●When the vehicle is parked, the time taken for the warning to start or go
off could be extended.
●When tire inflation pressure declines rapidly for example when a tire has
burst, the warning may not function.
■The initialization operation
●Make sure to carry out in itialization after adjusting the tire inflation pres-
sure.
Also, make sure the tires are cold be fore carrying out initialization or tire
inflation pressure adjustment.
●If you have accidentally turned the po wer switch off during initialization,
it is not necessary to press the reset switch again as initialization will
restart automatically when the powe r switch has been turned to ON
mode for the next time.
●If you accidentally press the reset s witch when initialization is not neces-
sary, adjust the tire inflation pressu re to the specified level when the
tires are cold, and conduct initialization again.

640
PRIUS PRIME_OM_OM47A88U_(U)
7-3. Do-it-yourself maintenance
■Replacing the following bulbs
If any of the lights listed below has burnt out, have it replaced by
your Toyota dealer.
● Headlights and daytime running lights
● Front side marker lights
● Parking lights
● Fog lights (if equipped)
● LED accent lights (if equipped)
● Front turn signal lights
● Rear turn signal lights
● Rear side marker lights
● Tail lights
● Stop lights
● High mounted stoplight
● License plate lights
■LED lights
The lights other than the back-up lights each consist of a number of LEDs. If
any of the LEDs burn out, take your vehicle to your Toyota dealer to have the
light replaced.
■ Condensation build-up on the inside of the lens
Temporary condensation build-up on the inside of the headlight lens does not
indicate a malfunction. Contact your Toyota dealer for more information in the
following situations:
●Large drops of water have built up on the inside of the lens.
● Water has built up inside the headlight.
■ When replacing light bulbs
→P. 632

644
PRIUS PRIME_OM_OM47A88U_(U)
8-1. Essential information
Emergency flashers
Press the switch.
All the turn signal lights will flash. To turn them off, press the switch once
again.
■Emergency flashers
If the emergency flashers are used for a long time while the hybrid system is
not operating (while the “READY” indicator is not illuminated), the 12-volt \
bat-
tery may discharge.
The emergency flashers are used to warn other drivers when the
vehicle has to be stopped in th e road due to a breakdown, etc.
Vehicles with 7-inch displayVehicles with 11.6-inch display

PRIUS PRIME_OM_OM47A88U_(U)
7379-2. Customization
9
Vehicle specifications
■Power windows (→P. 300)
■Reverse warning buzzer (→ P. 333)
■Turn signal lever (→P. 336)
FunctionDefault
settingCustomized setting
Mechanical key linked opera-
tion (open)OffOn––O
Mechanical key linked opera-
tion (close)OffOn––O
Wireless remote control linked
operation (open only)OffOn––O
Mechanical key, wireless
remote control linked opera-
tion signal (buzzer)
OnOff––O
123
FunctionDefault settingCustomized setting
Signal (buzzer) when the shift
position is in RIntermittentSingle––O
123
FunctionDefault settingCustomized setting
Times of flashing of the lane
change signal flashers3
Off
––O5
7
123

PRIUS PRIME_OM_OM47A88U_(U)
7419-2. Customization
9
Vehicle specifications
■Seat belt reminder (→P. 658)
■Vehicle customization
●When the Speed linked door locking function and the Shift position linked
door locking function are both on, the door lock operates as follows.
• When shifting the shift position to any position other than P, all the doors
will be locked.
• If the vehicle is started with all the doors locked, the Speed linked door locking function would not operate.
• If the vehicle is started with any door unlocked, the Speed linked door
locking function will operate.
● When the smart key system is off, Smart door unlocking cannot be custom-
ized.
● When the doors remain closed after unlocking the doors and the automatic
door lock function is activated, the signals will be generated in accordance
with the operation signal (buzzer) and the operation signal (emergency
flashers) settings.
■ In the following situati ons, customize mode in which the settings can be
changed through the mu lti-information display will automatically be
turned off.
● The power switch is turned off.
● The vehicle begins to move while the customize mode screen is displayed.
FunctionDefault
settingCustomized setting
Vehicle speed linked seat belt
reminder buzzerOnOff––O
WARNING
■Cautions during customization
As the hybrid system needs to be oper ating during customization, ensure
that the vehicle is parked in a place with adequate ventilation. In a closed
area such as a garage, exhaust gases including harmful carbon monoxide
(CO) may collect and enter the vehicle. This may lead to death or a serious
health hazard.
NOTICE
■ During customization
To prevent 12-volt battery discharge, ensure that the hybrid system is oper-
ating while customizing features.
123

771Alphabetical index
PRIUS PRIME_OM_OM47A88U_(U)
Engine coolant ......................... 584Capacity ................................ 714
Checking ............................... 584
Preparing and checking before winter....................... 482
Engine oil ................................. 581 Capacity ................................ 712
Checking ............................... 581
Oil pressure warning light ..... 653
Preparing and checking before winter....................... 482
Engine switch .......................... 324 Auto power off function ......... 326
Changing the power switch modes...................... 326
If your vehicle has to be stopped in an emergency ... 645
Starting the hybrid system .... 324
EPS (Electronic Power Steering)................................. 477
Function ................................ 477
Warning light ......................... 654
EV auto mode............................. 79
EV driving range ...................... 100
EV mode ..................................... 79
EV/HV mode selection switch ....................................... 82
Event data recorder (EDR) ........ 11
Exhaust gas precautions .......... 56
Flat tire...................................... 671
Floor mats .................................. 26
Fluid Brake .................................... 716
Transmission ........................ 715
Washer ................................. 592
Fog lights ................................. 348 Replacing light bulbs............. 640
Switch ................................... 348 Footwell lights ......................... 515
Front doors .............................. 267
Front passenger occupant
classification system .............. 50
Front passenger’s seat
belt reminder light................. 656
Front seats ............................... 287 Adjustment............................ 287
Cleaning ............................... 561
Correct driving posture ........... 28
Head restraints ..................... 291
Seat heaters ......................... 513
Front side marker lights ......... 338 Light switch ........................... 338
Replacing light bulbs ............ 640
Front turn signal lights ........... 336 Replacing light bulbs ............ 640
Turn signal lever ................... 336
Fuel ........................................... 356 Capacity................................ 710
Fuel gauge............................ 196
Information............................ 718
Refueling .............................. 356
Type...................................... 710
Warning light......................... 655
Fuel consumption ... 218, 250, 256 Average fuel consumption .... 218
Current fuel consumption ..... 256
Fuel filler door ......................... 356 Opener.................................. 358
Refueling .............................. 356
When the fuel filler door cannot be opened .............. 359
Fuses ........................................ 630
Garage door opener ................ 541
Glove box ................................. 519
F
G

774Alphabetical index
PRIUS PRIME_OM_OM47A88U_(U)
Language (multi-information display)................................... 233
LATCH system ........................... 60
LDA (Lane Departure Alert with steering control)............ 381
Lever Auxiliary catch lever .............. 577
Hood lock release lever ........ 577
Shift lever .............................. 330
Tilt and telescopic steering lock release lever ............... 294
Turn signal lever ................... 336
Wiper lever............................ 350
License plate lights ................. 338
Light switch ........................... 338
Replacing light bulbs............. 640
Light
Automatic High Beam system ......... ....................... 343
Door courtesy lights .............. 515
Emergency flasher switch ..... 644
Fog light switch ..................... 348
Headlight switch.................... 338
Illuminated entry system ....... 517
Interior lights ................. 516, 517
Interior light list...................... 515
Luggage compartment
light ..................................... 274
Personal lights ...................... 516
Replacing light bulbs............. 635
Shift lever light ...................... 515
Turn signal lever ................... 336
Vanity lights .......................... 530
Wattage ................................ 717
Light bulbs Replacing .............................. 635
Wattage ................................ 717
Load capacity........................... 321
Luggage cover ......................... 525 Main display ............................. 196
Maintenance
Do-it-yourself maintenance... 574
General maintenance ........... 570
Maintenance data ................. 708
Maintenance requirements ... 567
Malfunction indicator lamp..... 653
Master warning light ............... 663
Meter ......................................... 180 Clock adjustment .................. 185
Combination meter ............... 180
Head-up display.................... 238
Indicators .............................. 191
Instrument cluster light control ................................ 182
Main display.......................... 196
Multi-information display ....... 205
Warning lights ....................... 189
Warning messages ............... 663
Microphone
*............................ 548
Mirrors Inside rear view mirror .......... 296
Outside rear view mirror defoggers ................... 491, 502
Outside rear view mirrors ..... 298
Vanity mirrors ....................... 530
MP3 disc
*
Multi-information display........ 205
Air conditioning system settings screen ................... 226
Audio system-linked display ................................ 225
BSM (Blind Spot Monitor) ..... 408
Display contents ................... 205
Drive information .................. 207
Driving assist system
information ......................... 230
Dynamic radar cruise control with full-speed range .......... 391
LM

776Alphabetical index
PRIUS PRIME_OM_OM47A88U_(U)
Power control unit coolant ..... 584Capacity ................................ 714
Checking ............................... 584
Preparing and checking before winter....................... 482
Radiator ................................ 586
Power outlets ........................... 531
Power sources ......................... 122
Power steering (Electric Power Steering system) ....... 477 Function ................................ 477
Warning light ......................... 654
Power switch............................ 324 Auto power off function ......... 326
Changing the power
switch modes...................... 326
If your vehicle has to be
stopped in an emergency ... 645
Starting the hybrid system .... 324
Power windows........................ 300
Catch protection function ...... 301
Door lock linked window operation ............................ 302
Jam protection function......... 301
Operation .............................. 300
Window lock switch............... 300
Pre-Collision System (PCS) .... 369
Enabling/disabling the system ......... ....................... 373
Function ................................ 369
Warning light ......................... 654 Radar cruise control
(dynamic radar cruise
control with full-speed
range) ..................................... 391
Radiator .................................... 586
Radio
*
Rear passengers’ seat belt reminder light ........................ 656
Rear seat .................................. 289
Rear side marker lights........... 338 Light switch ........................... 338
Replacing light bulbs ............ 640
Rear turn signal lights ............ 336 Replacing light bulbs ............ 640
Turn signal lever ................... 336
Rear view mirror Inside rear view mirror .......... 296
Outside rear view mirrors ..... 298
Rear view monitor system
*
Rear window defogger .... 491, 502
Refueling .................................. 356 Capacity................................ 710
Fuel types ............................. 710
Opening the fuel tank cap..... 358
When the fuel filler door cannot be opened .............. 359
Regenerative braking ................ 86
Remote Air Conditioning
System ................................... 509
Replacing
Electronic key battery ........... 627
Fuses .................................... 630
Light bulbs ............................ 635
Tires...................................... 609
Wiper rubber ......................... 624
Reporting safety defects
for U.S. owners...................... 746
Resetting the message indicating maintenance is
required.................................. 568
Road accident cautions ............ 94
R
