2017 TOYOTA PRIUS PRIME high beam

PRIUS PRIME_OM_OM47A88U_(U)
3455-3. Operating the lights and wipers
5
Driving
■High beam automatic turning on or off conditions
●When all of the following conditions are fulfilled, the high beam will be auto-
matically turned on (after approximately 1 second):
• Vehicle speed is above approximately 21 mph (34 km/h).
• The area ahead of the vehicle is dark.
• There are no vehicles ahead with headlights or tail lights turned on.
• There are few streetlights on the road ahead.
● If any of the following conditions are fulfilled, the high beam will be automat-
ically turned off:
• Vehicle speed drops below approximately 17 mph (27 km/h).
• The area ahead of the vehicle is not dark.
• Vehicles ahead have headlights or tail lights turned on.
• There are many streetlights on the road ahead.
■ Camera sensor detection information
●The high beam may not be automatically turned off in the following situa-
tions:
• When oncoming vehicles suddenly appear from a curve
• When the vehicle is cut in front of by another vehicle
• When vehicles ahead are hidden from sight due to repeated curves, road
dividers or roadside trees
• When vehicles ahead appear from the faraway lane on wide road
• When vehicles ahead vehicles have no lights
● The high beam may be turned off if a vehicle ahead that is using fog lights
without using the headlights is detected.
● House lights, street lights, traffic signals, and illuminated billboards or signs
may cause the high beam to switch to the low beams, or the low beams to
remain on.
● The following factors may affect the amount of time taken to turn the high
beam on or off:
• The brightness of headlights, fog lights, and tail lights of vehicles ahe\
ad
• The movement and direction of vehicles ahead
• When a vehicle ahead only has operational lights on one side
• When a vehicle ahead is a two-wheeled vehicle
• The condition of the road (gradient, curve, condition of the road surface
etc.)
• The number of passengers and amount of luggage
● The high beam may be turned on or off when the driver does not expect it.
● Bicycles or similar objects may not be detected.

346
PRIUS PRIME_OM_OM47A88U_(U)
5-3. Operating the lights and wipers
●In the situations shown below, the system may not be able to accurately
detect surrounding brightness levels. This may cause the low beams to
remain on or the high beams to cause problems for pedestrians, vehicles
ahead or other parties. In these cases, manually switch between the high
and low beams.
• In bad weather (rain, snow, fog, sandstorms etc.)
• The windshield is obscured by fog, mist, ice, dirt etc.
• The windshield is cracked or damaged.
• The camera sensor is deformed or dirty.
• The camera sensor temperature is extremely high.
• Surrounding brightness levels are equal to those of headlights, tail lights
or fog lights.
• Vehicles ahead have headlights that are either switched off, dirty, are
changing color, or are not aimed properly.
• When driving through an area of in termittently changing brightness and
darkness.
• When frequently and repeatedly driving ascending/descending roads, or roads with rough, bumpy or uneven surfaces (such as stone-paved
roads, gravel tracks etc.).
• When frequently and repeatedly taking curves or driving on a winding road.
• There is a highly reflective object ahead of the vehicle, such as a sign or
a mirror.
• The back of a vehicle ahead is highly reflective, such as a container on a truck.
• The vehicle’s headlights are damaged or dirty.
• The vehicle is listing or tilting, due to a flat tire, a trailer being towed etc.
• The high beam and low beam are repeatedly being switched between in an abnormal manner.
• The driver believes that the high beam may be causing problems or dis-
tress to other drivers or pedestrians nearby.

PRIUS PRIME_OM_OM47A88U_(U)
3475-3. Operating the lights and wipers
5
Driving
■Temporarily lowering sensor sensitivity
The sensitivity of the sensor can be temporarily lowered.
Turn the power switch off while the following conditions are met.
• The headlight switch is in or .
• The headlight switch lever is in high beam position.
• Automatic High Beam switch is on.
Turn the power switch to ON mode.
Within 30 seconds after step , repeat pulling the headlight switch lever to
the original position then pushing it to the high beam position quickly 10
times, then leave the lever in high beam position.
If the sensitivity is changed, the Automatic High Beam indicator is turn on
and off 3 times.
Automatic High Beam (headlights) may turn on even the vehicle is stopped.
■ If “Headlight System Ma lfunction Visit Your Dealer” is displayed on the
multi-information display
The system may be malfunctioning. Have the vehicle inspected by your Toy-
ota dealer.
1
2
32
4

361
PRIUS PRIME_OM_OM47A88U_(U)
5-5. Using the driving support systems
5
Driving
Toyota Safety Sense P
◆PCS (Pre-Collision System)
→P. 3 6 9
◆LDA (Lane Departure Alert with steering control)
→P. 3 8 1
◆Automatic High Beam
→P. 3 4 3
◆Dynamic radar cruise cont rol with full-speed range
→ P. 3 9 1
The Toyota Safety Sense P consists of the following drive assist
systems and contributes to a safe and comfortable driving expe-
rience:
WARNING
■Toyota Safety Sense P
The Toyota Safety Sense P is designed to operate under the assumption
that the driver will drive safely, and is designed to help reduce the impact to
the occupants and the vehicle in the case of a collision or assist the driver in
normal driving conditions.
As there is a limit to the degree of recognition accuracy and control perfor-
mance that this system can provide, do not overly rely on this system. The
driver is always responsible for paying attention to the vehicle’s surround-
ings and driving safely.

6688-2. Steps to take in an emergency
PRIUS PRIME_OM_OM47A88U_(U)■
If “Shift to Position When Parked” is shown
Message is displayed when the driver’s door is opened without turning the
power switch to off with the shift position in any position other than P.
Shift the shift position to P.
■ If “Shift is in Release Acceler ator Before Shifting” is shown
Message is displayed when the accelerator pedal has been depressed and
the shift position is in N.
Release the accelerator pedal and shift the shift position to D or R.
■ If “Depress Brake When Vehicle is Stopped. Hybrid System may Over-
heat.” is shown
The message may be shown when the accelerator pedal is depressed to hold
the vehicle while the vehicle is stopped on an uphill, etc.
The hybrid system may overheat. Release the accelerator pedal and depress
the brake pedal.
■ If “Shifted to Stop Vehicle to Shift to ” is shown
If the P position switch is pressed while driving, the shift position is changed
to N and the message is shown. ( →P. 332)
■ If “Auto Power OFF to Conserve Battery” is shown
The power switch has been turned off by the automatic power off function.
When starting the hybrid system next time, operate the hybrid system for
approximately 5 minutes to recharge the 12-volt battery.
■ If “Forward Camera System Unavaila ble” or “Forward Camera System
Unavailable Clean Windshield” is displayed.
The following systems may be suspended until the problem shown in the
message is resolved.
● PCS (Pre-Collision System)
● LDA (Lane Departure Alert with steering control)
● Dynamic radar cruise control with full-speed range
● Automatic High Beam

767Alphabetical index
PRIUS PRIME_OM_OM47A88U_(U)
Approach warning ................... 400
Assist grips .............................. 540
Audio input
*
Audio system*
Automatic air conditioning system ..... 488, 498 Air conditioning eco mode .......................... 490, 501
Air conditioning filter ............. 620
Automatic air conditioning system .... 488, 498
Eco score (A/C score)........... 228
Humidity sensor ............ 494, 505
Remote Air Conditioning System ............................... 509
S-FLOW mode .............. 489, 500
Automatic door locking
and unlocking systems ........ 270
Automatic High Beam ............. 343
Automatic light control system .................................... 341
AUX port
*
Auxiliary boxes ........................ 522
Back door ................................. 273
Back-up lights .......................... 635 Replacing light bulbs............. 636
Wattage ................................ 717
Battery (12-volt battery) .......... 587
Battery checking ................... 587
Exchanging ........................... 697
If the 12-volt battery is discharged .......................... 694
Preparing and checking before winter....................... 482
Warning light ......................... 653 Battery (traction battery) .......... 90
Air intake vent ......................... 91
Charging ............................... 102
Location .................................. 90
Specification ......................... 711
Status indicator ..................... 104
Blind Spot Monitor (BSM) ....... 408 Blind Spot Monitor function... 412
Rear Cross Traffic Alert
function............................... 415
Bluetooth
®*
Bottle holders .......................... 521
Brake Fluid ...................................... 716
Parking brake ....................... 337
Regenerative braking ............. 86
Warning light......................... 653
Brake assist ............................. 476
Brake Override System ........... 308
Break-in tips............................. 309
Brightness control Instrument cluster light control ......................... 182
BSM (Blind Spot Monitor) ....... 408 Blind Spot Monitor function... 412
Rear Cross Traffic Alert function............................... 415
Care .................................. 556, 561 Aluminum wheels ................. 557
Camera sensor ..................... 365
Exterior ................................. 556
Interior .................................. 561
Radar sensor ........................ 364
Seat belts.............................. 564
Water-repellent coating ........ 557
B
C
*: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.

772Alphabetical index
PRIUS PRIME_OM_OM47A88U_(U)
Hands-free system (for cellular phone)
*
Head restraints ........................ 291
Head-up display ....................... 238
Headlights ................................ 338
Automatic High Beam system ......... ....................... 343
Headlight aim ................ 633, 758
Light switch ........................... 338
Replacing light bulbs............. 640
Heated steering wheel............. 514
Heaters
Automatic air conditioning system .... 488, 498
Heated steering wheel .......... 514
Outside rear view mirrors ........................ 491, 502
Seat heaters ......................... 513
High coolant temperature
warning light .......................... 655
High mounted stoplight Replacing .............................. 640
High-voltage components ........ 90
Hill-start assist control............ 477
Hood ......................................... 577
Hooks Coat hooks............................ 540
Grocery bag hook ................. 524
Retaining hooks (floor mat)..... 26
Horn .......................................... 294
HV mode ..................................... 79 Hybrid battery
(traction battery) ..................... 90
Air intake vent ......................... 91
Charging ............................... 102
Location .................................. 90
Specification ......................... 711
Status indicator ..................... 104
Hybrid battery (traction battery)
air intake vent .......................... 91
Hybrid system............................ 78 Brake Override System ........ 308
Consumption
screen ................ 218, 250, 256
Drive-Start Control ................ 308
Emergency shut off system .... 91
Energy monitor ..... 208, 247, 253
High voltage components ....... 90
Hybrid System Indicator ....... 210
If the hybrid system will not start .............................. 688
Overheating .......................... 700
Plug-in hybrid system precautions........................... 90
Plug-in hybrid vehicle driving tips........................................ 97
Power switch ........................ 324
Regenerative braking ............. 86
Starting the hybrid system .... 324
Vehicle proximity notification system................ 85
Hybrid System Indicator ......... 210
Hybrid transmission................ 330
H

774Alphabetical index
PRIUS PRIME_OM_OM47A88U_(U)
Language (multi-information display)................................... 233
LATCH system ........................... 60
LDA (Lane Departure Alert with steering control)............ 381
Lever Auxiliary catch lever .............. 577
Hood lock release lever ........ 577
Shift lever .............................. 330
Tilt and telescopic steering lock release lever ............... 294
Turn signal lever ................... 336
Wiper lever............................ 350
License plate lights ................. 338
Light switch ........................... 338
Replacing light bulbs............. 640
Light
Automatic High Beam system ......... ....................... 343
Door courtesy lights .............. 515
Emergency flasher switch ..... 644
Fog light switch ..................... 348
Headlight switch.................... 338
Illuminated entry system ....... 517
Interior lights ................. 516, 517
Interior light list...................... 515
Luggage compartment
light ..................................... 274
Personal lights ...................... 516
Replacing light bulbs............. 635
Shift lever light ...................... 515
Turn signal lever ................... 336
Vanity lights .......................... 530
Wattage ................................ 717
Light bulbs Replacing .............................. 635
Wattage ................................ 717
Load capacity........................... 321
Luggage cover ......................... 525 Main display ............................. 196
Maintenance
Do-it-yourself maintenance... 574
General maintenance ........... 570
Maintenance data ................. 708
Maintenance requirements ... 567
Malfunction indicator lamp..... 653
Master warning light ............... 663
Meter ......................................... 180 Clock adjustment .................. 185
Combination meter ............... 180
Head-up display.................... 238
Indicators .............................. 191
Instrument cluster light control ................................ 182
Main display.......................... 196
Multi-information display ....... 205
Warning lights ....................... 189
Warning messages ............... 663
Microphone
*............................ 548
Mirrors Inside rear view mirror .......... 296
Outside rear view mirror defoggers ................... 491, 502
Outside rear view mirrors ..... 298
Vanity mirrors ....................... 530
MP3 disc
*
Multi-information display........ 205
Air conditioning system settings screen ................... 226
Audio system-linked display ................................ 225
BSM (Blind Spot Monitor) ..... 408
Display contents ................... 205
Drive information .................. 207
Driving assist system
information ......................... 230
Dynamic radar cruise control with full-speed range .......... 391
LM
