2017 TOYOTA PRIUS C check engine light

2124-3. Operating the lights and wipers
PRIUS c_U (OM52J11U)
Washer/wiper dual operation
The wipers will automatically oper-
ate a couple of times after the
washer squirts.
■The windshield wipers and washer can be operated when
Vehicles without a smart key system
The engine switch is in the “ON” position.
Vehicles with a smart key system
The “POWER” switch is in ON mode.
■ If no windshield washer fluid sprays
Check that the washer nozzles are not blocked if there is washer fluid in the
windshield washer fluid reservoir.
7
WARNING
■Caution regarding the use of washer fluid
When it is cold, do not use the washer fluid until the windshield becomes
warm. The fluid may freeze on the windshield and cause low visibility. This
may lead to an accident, resulting in death or serious injury.

2154-3. Operating the lights and wipers
4
Driving
PRIUS c_U (OM52J11U)
Ty p e BIntermittent window
wiper operation
Normal window wiper
operation
Washer/wiper dual oper-
ation
Washer/wiper dual oper-
ation
The wipers will automatically oper-
ate a couple of times after the
washer squirts.
■The rear window wiper and w asher can be operated when
Vehicles without a smart key system
The engine switch is in the “ON” position.
Vehicles with a smart key system
The “POWER” switch is in ON mode.
■ If no washer fluid sprays
Check that the washer nozzle is not blocked if there is washer fluid in the
washer fluid reservoir.
1
2
3
4

2734-7. Driving tips
4
Driving
PRIUS c_U (OM52J11U)
●Use fluids that are appropriate to the prevailing outside tempera-
tures. • Engine oil
• Engine/power control unit coolant
• Washer fluid
● Have a service technician inspec t the condition of the 12-volt bat-
tery.
● Have the vehicle fitted with four snow tires or purchase a set of tire
chains for the front tires.
Ensure that all tires are the same size and brand, and that chains match
the size of the tires.
Perform the following accordin g to the driving conditions:
● Do not try to forcibly open a window or move a wiper that is frozen.
Pour warm water over the frozen area to melt the ice. Wipe away
the water immediately to prevent it from freezing.
● To ensure proper operation of the climate control system fan,
remove any snow that has accumulated on the air inlet vents in
front of the windshield.
● Check for and remove any excess ice or snow that may have accu-
mulated on the exterior lights, vehicle's roof, chassis, around the
tires or on the brakes.
● Remove any snow or mud from the bottom of your shoes before
getting in the vehicle.
Accelerate the vehicle slowly, keep a safe distance between you and
the vehicle ahead, and drive at a reduced speed suitable to road con-
ditions.
Winter driving tips
Carry out the necessary preparations and inspections before
driving the vehicle in winter. Al ways drive the vehicle in a man-
ner appropriate to the prevailing weather conditions.
Pre-winter preparations
Before driving the vehicle
When driving the vehicle

399
7Maintenance and care
PRIUS c_U (OM52J11U)7-1. Maintenance and care
Cleaning and protecting the vehicle exterior .......... 400
Cleaning and protecting the vehicle interior ........... 403
7-2. Maintenance Maintenance requirements ................... 406
General maintenance........ 409
Emission inspection and maintenance
(I/M) programs ................ 412
7-3. Do-it-yourself maintenance
Do-it-yourself service precautions ..................... 413
Hood ................................. 416
Positioning a floor jack ...... 418
Engine compartment ......... 419
12-volt battery ................... 428
Tires .................................. 432
Tire inflation pressure ....... 441
Wheels .............................. 444
Air conditioning filter.......... 446
Wireless remote control/ electronic key battery ...... 448
Checking and replacing fuses ............................... 451
Light bulbs......................... 455

413
7
Maintenance and care
PRIUS c_U (OM52J11U)
7-3. Do-it-yourself maintenance
Do-it-yourself service precautions
If you perform maintenance by yourself, be sure to follow the
correct procedure as given in these sections.
ItemsCheck points
12-volt battery condition (→P. 428) • Grease
• Conventional wrench
(for terminal clamp bolts)
Brake fluid level
(→P. 425)
• FMVSS No.116 DOT 3 or SAE J1703 brake
fluid
• Rag or paper towel
• Funnel (used only for adding brake fluid)
Engine/power control
unit coolant level (→P. 423)
• “Toyota Super Long Life Coolant” or a similar
high quality ethylene glycol based non-sili-
cate, non-amine, non-nitrite and non-borate
coolant with long-life hybrid organic acid tech-
nology
For the U.S.A.:
“Toyota Super Long Life Coolant” is pre-mixed
with 50% coolant and 50% deionized water.
For Canada:
“Toyota Super Long Life Coolant” is pre-mixed
with 55% coolant and 45% deionized water.
• Funnel (used only for adding coolant)
Engine oil level (→P. 420)• “Toyota Genuine Motor Oil” or equivalent
• Rag or paper towel
• Funnel (used only for adding engine oil)
Fuses ( →P. 451)• Fuse with same amperage rating as original
Light bulbs (→P. 455)
• Bulb with same number and wattage rating as
original
• Phillips-head screwdriver
• Flathead screwdriver
• Wrench
Radiator and condenser
(→P. 425)⎯
Tire inflation pressure
(→ P. 441)• Tire pressure gauge
• Compressed air source

4838-2. Steps to take in an emergency
8
When trouble arises
PRIUS c_U (OM52J11U)■
If the tire pressure warning system is not functioning
→P. 437
■
If the tire pressure warning light frequently comes on after blinking
for 1 minute
If the tire pressure warning light frequently comes on after blinking for 1
minute when the engine switch is turned to the “ON” position (vehicles
without a smart key system) or the “POWER” switch is turned to ON
mode (vehicles with a smart key system ), have it checked by your Toyota
dealer.
■ Customization that can be co nfigured at Toyota dealer
The vehicle speed linked seat belt reminder buzzer can be disabled. (Cus-
tomizable features →P. 556) However, Toyota recommends that the seat belt
reminder buzzer be operational to alert the driver and front passenger when
seat belts are not fastened.
■ Warning buzzer
In some cases, the buzzer may not be heard because of noisy place or an
audio sound.
WARNING
■When the electric power steerin g system warning light comes on
The steering wheel may become extremely heavy.
When steering wheel operations are heavier than usual, grip the steering
wheel firmly and operate it using more force than usual.
■
If the tire pressure warning light comes on
Be sure to observe the following precautions. Failure to do so could
cause a loss of vehicle control and result in death or serious injury.
●Stop your vehicle in a safe place as soon as possible. Adjust the tire
inflation pressure immediately.
●If the tire pressure warning light co mes on even after tire inflation pres-
sure adjustment, it is probable that you have a flat tire. Check the tires.
If a tire is flat, change it with the spare tire and have the flat tire
repaired by the nearest Toyota dealer.
●Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate,
you could lose control of the steering wheel or the brakes.
■If a blowout or sudden air leakage should occur
The tire pressure warning system may not activate immediately.

586Alphabetical index
PRIUS c_U (OM52J11U)
Eco drive mode ........................ 199
Electric power steering ........... 264
Electronic keyIf the electronic key does not operate properly ........... 516
Emergency flashers Switch ................................... 466
Emergency, in case of
If a warning buzzer sounds ........................ 477, 486
If a warning light
turns on .............................. 477
If a warning message is displayed ............................ 486
If the electronic key does not operate properly ........... 516
If the hybrid system will
not start .............................. 514
If the vehicle becomes stuck ................................... 528
If the vehicle 12-volt battery is discharged .......... 518
If you have a flat tire ............ 501
If you lose your keys ............. 122
If you think something is
wrong.................................. 476
If your vehicle has to
be stopped in an
emergency.......................... 467
If your vehicle needs to
be towed ............................. 469
If your vehicle overheats ....... 524 Engine
Compartment ........................ 419
Engine switch ............... 184, 188
Hood ..................................... 416
How to start the hybrid
system ....... ................. 184, 188
Identification number ............ 533
If the hybrid system will not start .............................. 514
Ignition switch ............... 184, 188
Overheating .......................... 524
“POWER” switch................... 188
Engine coolant Capacity................................ 536
Checking............................... 423
Preparing and checking before winter ...................... 273
Engine oil Capacity................................ 535
Checking............................... 420
Preparing and checking before winter ...................... 273
Engine/power control unit
coolant Capacity................................ 536
Checking............................... 423
Preparing and checking before winter ...................... 273
Engine switch .................. 184, 188
EPS ........................................... 264
EV drive mode ......................... 195
Event data recorder................... 11
Exclusive jump starting terminal .................... 518
E

593Alphabetical index
PRIUS c_U (OM52J11U)
SwitchAutomatic High Beam
switch ................................. 245
Cruise control........................ 250
Eco drive mode switch .......... 199
Emergency flasher switch ..... 466
Engine switch................ 184, 188
EV drive mode switch ........... 195
Fog light switch ..................... 208
Hazard light switch................ 466
Headlight switch.................... 204
Ignition switch ............... 184, 188
LDA (Lane Departure Alert) switch ................................. 242
Light switches ....................... 204
Power door lock switch ......... 129
PCS (Pre-Collision system) switch ..... ............... 230
“POWER” switch ................... 188
Power window switch............ 160
Rear window wiper and washer switch ..................... 214
Steering wheel audio
switches.............................. 283
VSC OFF switch ................... 265
Window lock switch............... 160
Wiper and washer ......... 210, 214 Tail lights
Replacing light bulbs ............ 462
Switch ................................... 204
Theft deterrent system Immobilizer system .. ............... 84
Theft prevention labels ........... 86
Theft prevention labels ............. 86
Tire inflation pressure............. 441
Tire information Glossary ............................... 551
Size....................................... 547
Tire identification number ..... 546
Uniform tire quality grading ............................... 549
Tires Chains .................................. 274
Checking............................... 432
If you have a flat tire ............. 501
Inflation pressure .................. 539
Inflation pressure sensor ...... 433
Information............................ 544
Replacing.............................. 501
Rotating tires ........................ 432
Size....................................... 539
Snow tires ............................. 275
Spare tire .............................. 501
Tire pressure warning system ....... ................. 433, 480T
