2017 TOYOTA PRIUS C Power windows

1653-5. Opening and closing the windows
3
Operation of each component
PRIUS c_U (OM52J11U)■
Sunshade
The sunshade can be opened and closed manually. However, the sunshade
will open automatically when the moon roof is opened.
■ When the moon roof do es not close normally
Perform the following procedure:
● If the moon roof closes but then re-opens slightly
Stop the vehicle.
Press and hold the “CLOSE” switch.
*1
The moon roof will close, re-open and pause for approximately 10 sec-
onds.
*2 Then it will close again, tilt up and pause for approximately 1 sec-
ond. Finally, it will tilt down, open and close.
Check to make sure that the moon roof is completely closed and then
release the switch.
● If the moon roof tilts down but then tilts back up
Stop the vehicle.
Press and hold the “TILT” switch
*1 until the moon roof moves into the tilt up
position and stops.
Release the “TILT” switch once and then press and hold the “TILT” switch
again.
*1
The moon roof will pause for approximately 10 seconds in the tilt up posi-
tion.
*2 Then it will adjust slightly and pause for approximately 1 second.
Finally, it will tilt down, open and close.
Check to make sure that the moon roof is completely closed and then
release the switch.
*1: If the switch is released at the incorrect time, the procedure will have to be
performed again from the beginning.
*2: If the switch is released after the above mentioned 10 second pause, auto-matic operation will be disabled. In that case, press and hold the “CLOSE”
or “TILT” switch, and the moon roof will tilt up and pause for approximately
1 second. Then it will tilt down, open and close. Check to make sure that
the moon roof is completely closed and then release the switch.
If the moon roof does not fully close even after performing the above proce-
dure correctly, have the vehicle inspected by your Toyota dealer.
■ Moon roof open reminder function
The buzzer sounds and a message is shown on the multi-information display
in the instrument cluster when the “POWER” switch is turned off and the
driver's door is opened with the moon roof open.
1
2
3
1
2
3
4

1663-5. Opening and closing the windows
PRIUS c_U (OM52J11U)
WARNING
Observe the following precautions.
Failure to do so may cause death or serious injury.
■Opening the moon roof
● Do not allow any passengers to put their hands or heads outside the vehi-
cle while it is moving.
● Do not sit on top of the moon roof.
■ Closing the moon roof
● The driver is responsible for moon roof opening and closing operations.
In order to prevent accidental operation, especially by a child, do not let a
child operate the moon roof. It is possible for children and other passen-
gers to have body parts caught in the moon roof.
● Check to make sure that all passengers do not have any part of their body
in a position where it could be caught when the moon roof is being oper-
ated.
● Do not allow children to operate the moon roof.
Closing the moon roof on someone can cause death or serious injury. The
driver is responsible for instructing children not to operate the moon roof.
● When exiting the vehicle, turn the “POWER” switch off, carry the key and
exit the vehicle along with the child. There may be accidental operation,
due to mischief, etc., that may possibly lead to an accident.
■ Jam protection function
● Never use any part of your body to intentionally activate the jam protection
function.
● The jam protection function may not work if something gets caught just
before the moon roof fully closes.

217
4
Driving
PRIUS c_U (OM52J11U)
4-4. Refueling
●Vehicles without a smart key system:
Turn the engine switch to the “LOC K” poison and ensure that all the
doors and windows are closed.
Vehicles with a smart key system:
Turn the “POWER” switch off and ensure that all the doors and win-
dows are closed.
● Confirm the type of fuel.
■Fuel types
→P. 541
■ Fuel tank opening for unleaded gasoline
To help prevent incorrect fueling, your vehicle has a fuel tank opening that
only accommodates the special nozzle on unleaded fuel pumps.
Opening the fuel tank cap
Perform the following steps to open the fuel tank cap:
Before refueling the vehicle

5519-1. Specifications
9
Vehicle specifications
PRIUS c_U (OM52J11U)
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pres-
sure Tire pressure when the vehicle has been
parked for three hours or more, or has not
been driven more than 1 mile or 1.5 km under
that condition
Maximum inflation
pressure The maximum cold inflat
ed pressure to which
a tire may be inflated, shown on the sidewall of
the tire
Recommended infla-
tion pressure Cold tire inflation pressure recommended by a
manufacturer
Accessory weight The combined weight (in excess of those stan-
dard items which may be replaced) of hybrid
transmission, power steering, power brakes,
power windows, power seats, radio and
heater, to the extent that these items are avail-
able as factory-installed equipment (whether
installed or not)
Curb weight The weight of a motor vehicle with standard
equipment, including the maximum capacity of
fuel, oil and coolant, and if so equipped, air
conditioning and additional weight optional
engine
Maximum loaded vehi-
cle weight The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight
Normal occupant
weight 150 lb. (68 kg) times the number of occupants
specified in the second column of Table 1
* that
follows
Occupant distribution Distribution of occupants in a vehicle as speci-
fied in the third column of Table 1
* below
Production options
weight The combined weight of
installed regular pro-
duction options weighing over 5 lb. (2.3 kg) in
excess of the standard items which they
replace, not previously considered in curb
weight or accessory weight, including heavy
duty brakes, ride levelers, roof rack, heavy
duty battery, and special trim

580What to do if... (Troubleshooting)
PRIUS c_U (OM52J11U)
●Vehicles without a smart key system:
Is the engine switch in the “ON” position?
If you cannot release the shift lever by depressing the brake pedal with the
engine switch in the “ON” position. (→P. 200)
●Vehicles with a smart key system:
Is the “POWER” switch in ON mode?
If you cannot release the shift lever by depressing the brake pedal with the
“POWER” switch in ON mode. (→P. 200)
●Vehicles without a smart key system:
It is locked to prevent theft of the vehicle if the key is pulled from the engine
switch. (→P. 186)
●Vehicles with a smart key system:
It is locked automatically to prevent theft of the vehicle. ( →P. 191)
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. ( →P. 160)
The shift lever cannot be shifted from P even if you depress
the brake pedal
The steering wheel cannot be tu rned after the hybrid system
is stopped
The windows do not open or close by operating the power
window switches

585Alphabetical index
PRIUS c_U (OM52J11U)
Child safetyAirbag precautions .................. 42
Child-protectors .................... 130
Child restraint system ............. 59
How your child should
wear the seat belt ................. 34
Installing child restraints ......... 63
Moon roof precautions .......... 166
Power window lock switch .... 160
Power window precautions ... 163
Removed key battery precautions ......................... 450
Seat belt extender precautions ........................... 38
Seat belt precautions .............. 36
Seat heater precautions........ 382
12-volt battery precautions ................. 430, 522
Cleaning Exterior ................................. 400
Interior................................... 403
Seat belts .............................. 404
Clock ........................................... 98
Coat hooks ............................... 394
Condenser ................................ 425
Console box ............................. 387
Cooling system
Hybrid system overheating ... 524
Cord hook................................. 284
Cruise control .......................... 250
Cup holders.............................. 389
Curtain shield airbags ............... 40
Customizable features ............ 556 Daytime running light
system.................................... 206
Defogger Rear window ......................... 376
Side mirrors .......................... 376
Dimension ................................ 532
Dinghy towing.......................... 183
Display Energy flow ........................... 110
Multi-information display ......... 96
Trip information....................... 96
Warning message................. 486
Do-it-yourself maintenance .... 413
Doors Back door ............................. 135
Door lock .............................. 129
Door windows ....................... 160
Rear door child protector ...... 130
Side doors ............................ 126
Side mirrors .......................... 158
Driver’s seat belt reminder light ........................................ 479
Driving
Break-in tips.......................... 170
Correct posture ....................... 28
Procedures ........................... 168
Winter driving tips ................. 273D

590Alphabetical index
PRIUS c_U (OM52J11U)
Navigation system*
Noise from under vehicle............ 8
Odometer.................................... 99
OilEngine oil .............................. 535
Opener
Back door.............................. 135
Fuel filler door ....................... 217
Hood ..................................... 416
Outside rear view mirrors Adjusting and folding ............ 158
Defogger ............................... 376
Outside temperature display .................................... 391
Overheating, Hybrid
system .................................... 524 Parking brake........................... 203
Parking lights
Replacing light bulbs ............ 459
Switch ................................... 204
Wattage ................................ 540
PCS (Pre-Collision system) .... 227 PCS (Pre-Collision system) switch...... .............. 230
Warning light......................... 480
Personal lights Switch ................................... 384
Wattage ................................ 540
Power outlet ............................. 393
“POWER” switch ..................... 188
Power windows ....................... 160
Pre-Collision system (PCS) .... 227 PCS (Pre-Collision
system) switch...... .............. 230
Warning light......................... 480
N
O
P

595Alphabetical index
PRIUS c_U (OM52J11U)
Warning buzzersBrake system ....... ................. 477
Electric power steering system ......... ....................... 478
Key reminder ........................ 495
LDA
(Lane Departure Alert)........ 240
Master warning ..................... 479
Pre-Collision warning ............ 480
Seat belt reminder ................ 479
Warning lights
Anti-lock brake system.......... 478
Brake assist system .............. 478
Brake system ....... ................. 477
Charging system ................... 478
Electric power steering system ......... ....................... 478
Front passenger occupant classification system........... 478
Low brake fluid...................... 477
Low fuel level ........................ 479
Low tire inflation pressure ..... 480
Malfunction indicator lamp .... 478
Master warning light.............. 479
Parking brake........................ 478
PCS warning light ................. 480
Pretensioners........................ 478
Seat belt reminder light ......... 479
Slip indicator light.................. 479
SRS airbag system ............... 478
Tire pressure......................... 480
Tire pressure warning system ......... ....................... 480 Warning messages.................. 486
Washer
Checking............................... 427
Preparing and checking before winter ...................... 273
Switch ........................... 210, 214
Washing and waxing ............... 400
Weight Cargo capacity...................... 181
Load limits ............................ 181
Weight .................................. 532
Wheels ...................................... 444
Window lock switch ................ 160
Windows Power windows..................... 160
Rear window defogger.......... 376
Washer ......................... 210, 214
Windshield wipers ................... 210
Wireless remote control key Replacing the key battery ..... 448
Wireless remote control ........ 121
WMA disc ................................. 300
W
