2017 TOYOTA LAND CRUISER tow

OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY &
EMERGENCY FEATURES
1
INDEX
Engine maintenance 9
Fuel tank door release and cap 8
Hood release 8
Indicator symbols 4-5
Instrument cluster 4
Instrument panel 2-3
Keyless entry
1 6
Light control-Instrument panel 9
Smart Key system
1,2 7
1 Visit your Toyota dealer for information on customizing this feature.2 Programmable by customer. Refer to the Owner’s Manual for instructio\
ns and more information.3 HomeLink® is a registered trademark of Gentex Corporation.
OVERVIEW
FEATURES & OPERATIONS FEATURES & OPERATIONS (continued)
SAFETY & EMERGENCY FEATURES TOYOTA SAFETY SENSE
Automatic air
conditioning/heating
22-23
Audio 20-21
Auto lock/unlock
1 10
Automatic transmission 10
Cooler box 28
Crawl Control 24
Cup holders 28
Door-Back 21
Door locks 26
Doors-Power sliding 16
Four-wheel drive 11
Garage door opener (HomeLink
®)3 27
Lights1 & turn signals 17
Moon roof 19
Multi-Information Display (MID)
2 25
Multi-terrain Monitor 24
Parking brake 28
Power outlets-12V DC 28
Power outlet-120V AC 29
Qi wireless charger 29
Rear seat entertainment system 27
Rear view mirror-Outside 19
Seat adjustments-Front 12
Seat adjustments-Rear 12
Seat ventilators/heaters 23
Seats-Head restraints 12
Seats-Stowing 3rd row seats 15 Seats-Tumbling 2nd row seats 13
Seats-Tumbling 3rd row seats 14
Steering lock release
11
Telephone controls (Bluetooth
®) 26
Tilt & telescopic steering wheel 25
Windows-Power 18
Windshield wipers & washers 18
Doors-Child safety locks 41
Floor mat installation 43
Seat belts 40
Seat belts-Shoulder belt anchor 40
Spare tire & tools 41
Star Safety System
™ 42
Tire Pressure Monitoring
(warning) System (TPMS) 40
Auto High Beams (AHB) 38-39
Dynamic Radar
Cruise Control (DRCC) 36-38
Lane Departure Alert (LDA) 33-35
Pedestrian Detection Function 33
Pre-Collision System (PCS) 31-32
Quick overview-
Toyota Safety Sense P 30
Sensors 30
BLUETOOTH® DEVICE
PAIRING SECTION 44-53

OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
13
Seats-Tumbling 2nd row seats
(1)
(5)
(3)
(2)
(4)
Pull Seat hook cover
Pull
Stow the seat belt buckles and
lower the head restraints.
Hook the seat belt to the seat
belt hangers.
Hook the holding strap to the assist
grip and secure the seat. Install the seat hook covers on the
seat hooks.
Fold down the seatback and swing the whole seat up and forward.

14
Seats-Tumbling 3rd row seats
FEATURES & OPERATIONS
Stow the seat belt buckles.Stow the center head restraint.
Hook the seat belt to the seat belt
hangers. Fold down the outer head restraints.
Fold the seats. Lift the seats sideward.
Lock the seats. Install the seat hook covers on the
seat hooks.
Install the seat hook covers into
the back of the seat cushions. Lower the seats to their
original
position.
(1)
(5)
(3)
(2)
(4)
Push
(6)
Pull
(7)(8)
Seat hook cover
Pull
Pull
Returning seats
(1)(2)

OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
15
Seats-Stowing 3rd row seats
MANUAL
POWER
Lower
An alarm will sound for 10 seconds and the indicator will light up on the
instrument panel if the seat is not fully open or stowed when vehicle is\
shifted out
of Park.
Refer to the Owner’s Manual for more details.
Third seat fold incomplete warning light
Stow the seat belt buckles
(2)
(1)
(3)Lower
Push down
Stow the seat belt buckles
Pull
(2)
(1)
(3)
Push and hold

25
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
Multi-Information Display (MID)
Tilt and telescopic steering wheel
Select: To select an
item/change pagesEnter/Set: Press to enter/
set, press and hold to reset
Menu/Display: Switch
the top screenReturn: To previous
screen
Push “Multi-Information switches” to view or change information in\
the following:
Drive information
Vehicle information display (if equipped)
Navigation system-linked display (if equipped)
Audio system linked display (if equipped)
Driving assist system information (if equipped)
Warning messages
Settings display
Up
Toward driver
Down
NOTE: Do not attempt to adjust while the vehicle is in motion.
Away from
driver
Control switch

39
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
ACTIVATING THE AHB SYSTEM
CONDITIONS WHERE AHB WILL TURN ON/OFF AUTOMATICALLY
When all of these conditions are met, high beams will be automatically t\
urned on
(after approximately 1 second):
• Vehicle speed is above approximately 25 mph (40 km/h).
• The area ahead of the vehicle is dark.
• There are no oncoming or preceding vehicles with headlights or tail\
lights
turned on.
If any of these conditions occur, the system is designed to automaticall\
y turn off
highbeams. • Vehicle speed drops below approximately 19 mph (30 km/h).
• The area ahead of the vehicle is not dark.
• Oncoming or preceding vehicles have headlights or tail lights
turned on.
• There are many streetlights on the road ahead.
(1) With the engine switch in IGNITION ON mode and headlight switch tu\
rned to
“AUTO” position, push lever away from you.
(2) Depress the Automatic High Beam “AUTO” switch. The AHB indicator will come on when the headlights are turned on automat\
ically
to indicate that the system is active.
Note: Pull the lever back toward you to turn the AHB system off.
The AHB indicator will turn off and the high beam indicator turns on.
