2017 TOYOTA HIGHLANDER glove box

4616-3. Using the storage features
6
Interior features
HIGHLANDER_U (OM0E017U)
Unlock with the master key
(vehicles without a smart key
system) or mechanical key
(vehicles with a smart key sys-
tem)
Lock with the master key (vehi-
cles without a smart key sys-
tem) or mechanical key
(vehicles with a smart key sys-
tem)
Open (pull lever)
■Power back door main switch (vehicles with power back door)
The power back door main switch is located in the glove box. ( →P. 126)
To open the console box lids,
press on the knob and slide both
lids.
Glove box
1
2
3
Console box

5477-3. Do-it-yourself maintenance
7
Maintenance and care
HIGHLANDER_U (OM0E017U)
Vehicles without a smart key system:
Turn the engine switch to the “LOCK” position.
Vehicles with a smart key system:
Turn the engine switch off.
Open the glove box. Slide off
the damper.
Push in the glove box on the
vehicle’s outer side to discon-
nect the claws. Then pull out
the glove box and disconnect
the lower claws.
Pull down the cover.
Air conditioning filter
The air conditioning filter must be changed regularly to maintain
air conditioning efficiency.
Removal method
1
2
3
4

720Alphabetical index
HIGHLANDER_U (OM0E017U)
Flat tire...................................... 608
Floor mats .................................. 26
FluidAutomatic transaxle .............. 657
Brake .................................... 659
Washer ................................. 530
Fog lights ................................. 243 Replacing light bulbs............. 556
Switch ................................... 243
Wattage ................................ 663
Front automatic air
conditioning system ............. 442
Front door courtesy lights Location ................................ 458
Wattage ................................ 663
Front fog lights ........................ 243 Replacing light bulbs............. 556
Switch ................................... 243
Wattage ................................ 663
Front manual air
conditioning system ............. 436
Front passenger occupant classification system .............. 53
Front personal lights ............... 459 Wattage ................................ 663
Front seats ............................... 149 Adjustment ............................ 149
Cleaning................................ 504
Correct driving posture ........... 28
Driving position memory ....... 158
Head restraints ..................... 162
Seat heaters ......................... 456
Seat position memory ........... 158
Seat ventilators ..................... 456 Front side marker lights ......... 235
Light switch ........................... 235
Replacing light bulbs ............ 556
Wattage ................................ 663
Front turn signal lights ........... 233
Replacing light bulbs ............ 556
Turn signal lever ................... 233
Wattage ................................ 663
Fuel ........................................... 250 Capacity................................ 653
Fuel gauge.............................. 92
Fuel pump shut off system ... 580
Information............................ 664
Refueling .............................. 250
Type...................................... 653
Warning light......................... 582
Fuel consumption
Average fuel economy ............ 97
Current fuel consumption ......................... 97
Fuel filler door ......................... 250 If the fuel filler door cannot be opened .............. 252
Refueling .............................. 250
Fuel pump shut off system..... 580
Fuses ........................................ 552
Garage door opener ................ 481
Gauges ....................................... 92
Glass hatch .............................. 136
Glove box ................................. 461
Grocery bag hooks.................. 467
F
G
