2017 TOYOTA HIGHLANDER USB

3825-6. Using an external device
HIGHLANDER_U (OM0E017U)●
MP3, WMA and AAC playback
• When a device containing MP3, WMA and AAC files is connected, all
files in the USB memory device are checked. Once the file check is fin-
ished, the first MP3, WMA and AAC file is played. To make the file check
finish more quickly, we recommend that you do not include any files other
than MP3, WMA and AAC files or create any unnecessary folders.
• When a USB memory device is connected and the audio source is
changed to USB memory mode, the USB memory device will start play-
ing the first file in the first folder. If the same device is removed and
reconnected (and the con- tents have not been changed), the USB mem-
ory device will resume play from the same point in which it was last used.
● Extensions
If the file extensions .mp3, .wma and .m4a are used for files other than
MP3, WMA and AAC files, they will be skipped (not played).
● Playback
• To play MP3 files with steady sound quality, we recommend a fixed bit
rate of at least 128 kbps and a sampling frequency of 44.1 kHz.
• There is a wide variety of freeware and other encoding software for MP3, WMA and AAC files on the market, and depending on the status of the
encoding and the file format, poor sound quality or noise at the start of
playback may result. In some cases, playback may not be possible at all.\
• Microsoft, Windows, and Windows Media are the registered trademarks of Microsoft Corporation in the U.S.A. and other countries.
WARNING
■While driving
Do not connect a USB memory device or operate the device controls.
NOTICE
■To prevent damage to the USB memory device or its terminals
● Do not leave the USB memory device in the vehicle. The temperature
inside the vehicle may become high, resulting in damage to the USB
memory device.
● Do not push down on or apply unnecessary pressure to the USB memory
device while it is connected.
● Do not insert foreign objects into the port.

435
6Interior features
HIGHLANDER_U (OM0E017U)6-1. Using the air conditioning
system and defogger
Front manual air conditioning system ........ 436
Front automatic air conditioning system ........ 442
Rear manual air conditioning system ........ 449
Rear automatic air conditioning system ........ 452
Heated steering wheel/ seat heaters/seat
ventilators........................ 455
6-2. Using the interior lights Interior lights list ................ 458
• Interior lights ................. 458
• Personal lights .............. 459
6-3. Using the storage features
List of storage features ........................... 460
• Glove box...................... 461
• Console box .................. 461
• Bottle holders ................ 462
• Cup holders .................. 463
• Auxiliary boxes.............. 465
• Open tray ...................... 466
Luggage compartment features ........................... 467 6-4. Using the other interior
features
Other interior features ........................... 469
• Sun visors ..................... 469
• Vanity mirrors................ 469
• Conversation mirror ............................ 470
• Clock ............................. 471
• Outside temperature display........................... 472
• Power outlets ................ 473
• USB charging ports .............................. 475
• Rear sunshades............ 477
• Armrest ......................... 478
• Coat hooks.................... 479
• Assist grips ................... 479
• Side table ...................... 480
Garage door opener.......... 481
Safety Connect ................. 488
Compass ........................... 494

4666-3. Using the storage features
HIGHLANDER_U (OM0E017U)
■Cable pass through
The open tray is provided with a hole that allows cables to be passed through
the tray from the USB/AUX port, USB charging ports or power outlet.
Open tray
Remove the cover.
WARNING
■Items unsuitable for the open tray
Observe the following precautions when putting items in the open tray. Fail-
ure to do so may cause items to be thrown out of the tray in the event of
sudden braking or steering. In these cases, the items may interfere with
pedal operation or cause driver distraction, resulting in an accident.
● Do not store items in the tray that can easily shift or roll out.
● Do not stack items in the tray higher than the tray’s edge.
● Do not put items in the tray that may protrude over the tray’s edge.

4756-4. Using the other interior features
6
Interior features
HIGHLANDER_U (OM0E017U)
The USB charging ports are used to supply 2.1 A of electricity at 5 V
to external devices.
The USB charging ports are for charging only. They are not designed
for data transfer or other purposes.
Depending on the external device, it may not charge properly. Refer to
the manual included with the device before using a USB charging
port.
■Using the USB charging ports
Open the lid.
■ The USB charging ports can be used when
Vehicles without a smart key system
The engine switch is in the “ACC” or “ON” position.
Vehicles with a smart key system
The engine switch is in ACCESSORY or IGNITION ON mode.
■ Situations in which the USB chargi ng ports may not operate correctly
● If a device which consumes more than 2.1 A at 5 V is connected
● If a device designed to communicate with a personal computer, such as a
USB memory device, is connected
● If the connected external device is turned off (depending on device)
● If the temperature inside the vehicle is high, such as after the vehicle has
been parked in the sun
■ About connected external devices
Depending on the connected external device, charging may occasionally be
suspended and then start again. This is not a malfunction.
USB charging ports
FrontRear

4766-4. Using the other interior features
HIGHLANDER_U (OM0E017U)
NOTICE
■To prevent damage to the USB charging ports
● Do not insert foreign objects into the ports.
● Do not spill water or other liquids into the ports.
● When the USB charging ports are not in use, close the lids. If a foreign
object or liquid enters a port may cause a short circuit.
● Do not apply excessive force to or impact the USB charging ports.
● Do not disassemble or modify the USB charging ports.
■ To prevent damage to external devices
● Do not leave external devices in the vehicle. The temperature inside the
vehicle may become high, resulting in damage to an external device.
● Do not push down on or apply unnecessary force to an external device or
the cable of an external device while it is connected.
■ To prevent battery discharge
Do not use the USB charging ports for a long period of time with the engine
stopped.

719Alphabetical index
HIGHLANDER_U (OM0E017U)
Engine....................................... 653“ACC” position ...................... 218
ACCESSORY mode ............. 222
Compartment ........................ 519
Engine switch................ 218, 221
Hood ..................................... 516
How to start the engine......................... 218, 221
Identification number ............ 652
If the engine will not start ...... 633
Ignition switch (engine switch) ........... 218, 221
Overheating .......................... 644
Engine coolant ......................... 524
Capacity ................................ 656
Checking ............................... 524
Preparing and checking before winter....................... 339
Engine coolant temperature gauge........................................ 92
Engine immobilizer system ...... 80
Engine oil ................................. 521 Capacity ................................ 654
Checking ............................... 521
Oil pressure warning
message ............................. 598
Preparing and checking
before winter....................... 339
Engine switch .................. 218, 221
Enhanced VSC ......................... 331 Entune Audio ........................... 351
Audio input............................ 355
AUX port/
USB port............................. 355
CD player.............................. 369
iPod ...................................... 375
MP3/WMA disc ..................... 369
Optimal use .......................... 366
Portable music player ........... 383
Radio .................................... 367
Steering wheel audio
switch ................................. 354
USB memory ........................ 379
Entune Audio Plus
*
Entune Premium Audio*
EPS (Electric Power Steering) ..... 332
Function ................................ 332
Warning light......................... 582
Event data recorder (EDR)........ 10
*: Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”

730Alphabetical index
HIGHLANDER_U (OM0E017U)
Trailer sway control................. 331
Trailer towing .......................... 201
Transmission ........................... 227Automatic transmission......... 227
If the shift lever cannot be shifted from P ..................... 231
S mode ................................. 229
Turn signal lights..................... 233
Replacing light bulbs............. 556
Turn signal lever ................... 233
Wattage ................................ 663
USB charging ports ................. 475
USB port ................................... 355
Utility vehicle precautions ...... 343
Valet key ................................... 108
Vanity lights ............................. 469 Wattage ................................ 663
Vanity mirrors .......................... 469
Vehicle data recordings .............. 9
Vehicle identification number ................................... 651
Vehicle Stability Control (VSC) ...................................... 331
Voice command system
*....... 429
VSC (Vehicle Stability Control) .................................. 331 Warning buzzers
Brake system ....... ................. 581
Downshifting ......................... 230
Electric power steering system .......... ...................... 582
Key reminder ........................ 604
Parking brake ....................... 582
PCS (Pre-Collision System) ....... 583
Seat belt reminder ................ 582
Warning lights ........................... 87
ABS ...................................... 581
Brake system ....... ................. 581
Electric power steering
system .......... ...................... 582
LDA (Lane Departure Alert
with steering control) .......... 583
Low fuel level ........................ 582
Malfunction indicator lamp .... 581
Master warning light ............. 584
Parking brake ....................... 582
PCS (Pre-Collision System) ....... 583
Seat belt reminder light......... 582
Slip indicator ......................... 582
SRS ...................................... 581
Stop & Start cancel indicator .................. 583
Tire pressure ........................ 584
