3605-10. Bluetooth®
COROLLA_TMMMS_TMMC_U (OM02494U)■Bluetooth
® antenna
The antenna is built into the display.
If the portable audio player is behind the seat or in the glove box or console
box, or is touching or covered by metal objects, the connection status may
deteriorate.
If the cellular phone is behind the seat or in the console box, or touching or
covered by metal objects, the connection status may deteriorate.
■Battery charge/signal status
●This display may not correspond exactly with the portable audio player or
cellular phone itself.
●This system does not have a charging function.
●The portable audio player or cellular phone battery will be depleted quickly
when the device is connected to Bluetooth
®.
■When using the Bluetooth
® audio and hands-free system at the same
time
The following problems may occur.
●The Bluetooth
® audio connection may be interrupted.
●Noise may be heard during Bluetooth
® audio playback.
■About the contact in this system
The following data is stored for every registered cellular phone. When
another phone is connecting, you cannot read the registered data.
●Contact data
●Call history
●Favorite
●Message
When removing a Bluetooth
® phone from the system, the above-mentioned
data is also deleted.

3615-10. Bluetooth®
5
Audio system
COROLLA_TMMMS_TMMC_U (OM02494U)■Compatible models
The Bluetooth
® audio system supports portable audio players with the follow-
ing specifications
●Bluetooth
® specifications:
Ver. 2.0, or higher (Recommended: Ver. 3.0+EDR or higher)
●Profiles:
• A2DP (Advanced Audio Distribution Profile) Ver. 1.0, or higher
(Recommended: Ver. 1.2 or higher)
This is a profile to transmit stereo audio or high quality sound to Entune
Audio.
• AVRCP (Audio/Video Remote Control Profile) Ver. 1.0 or higher
(Recommended: Ver. 1.4 or higher)
This is a profile to allow remote control the A/V equipment.
However, please note that some functions may be limited depending on the
type of portable audio player connected.
The hands-free system supports cellular phones with the following specifica-
tions.
●Bluetooth
® specification:
Ver. 2.0 or higher (Recommended: Ver. 3.0+EDR or higher)
●Profiles:
• HFP (Hands Free Profile) Ver. 1.0 or higher (Recommended: Ver. 1.6 or
higher)
This is a profile to allow hands-free phone calls using a cellular phone or
head set. It has outgoing and incoming call functions.
• OPP (Object Push Profile) Ver. 1.1 or higher (Recommended: Ver. 1.2)
This is a profile to transfer contact data. When a Bluetooth
® compatible
cellular phone has both PBAP and OPP, OPP cannot be used.
• PBAP (Phone Book Access Profile) Ver. 1.0 or higher (Recommended:
Ver. 1.1)
This is a profile to transfer contact data.
• MAP (Message Access Profile) Ver.1.0 or higher
This is a profile to using phone message.
If the cellular phone does not support HFP, you cannot register it with the
hands-free system. OPP, PBAP or MAP services must be selected individu-
ally.

3625-10. Bluetooth®
COROLLA_TMMMS_TMMC_U (OM02494U)■Reconnecting the portable audio player
If the portable audio player is disconnected due to poor reception when the
engine switch is in the “ACC” or “ON” position (vehicles without smart key
system) or ACCESSORY or IGNITION ON mode (vehicles with smart key
system), the system automatically reconnects the portable audio player.
If you have switched off the portable audio player yourself, follow the instruc-
tions below to reconnect:
●Select the portable audio player again
●Enter the portable audio player
■When you sell your car
Be sure to delete your personal data. (→P. 284)
WARNING
■While driving
Do not use the portable audio player, cellular phone or connect a device to
the Bluetooth
® system.
■Caution regarding interference with electronic devices
●Your audio unit is fitted with Bluetooth
® antennas. People with implantable
cardiac pacemakers, cardiac resynchronization therapy-pacemakers or
implantable cardioverter defibrillators should maintain a reasonable dis-
tance between themselves and the Bluetooth
® antennas. The radio waves
may affect the operation of such devices.
●Before using Bluetooth
® devices, users of any electrical medical device
other than implantable cardiac pacemakers, cardiac resynchronization
therapy-pacemakers or implantable cardioverter defibrillators should con-
sult the manufacturer of the device for information about its operation
under the influence of radio waves. Radio waves could have unexpected
effects on the operation of such medical devices.
NOTICE
■When leaving the vehicle
Do not leave your portable audio player or cellular phone in the vehicle. The
inside of the vehicle may become hot, causing damage to the portable
audio player or cellular phone.

3665-11. Using the voice command system
COROLLA_TMMMS_TMMC_U (OM02494U)
The Mobile Assistant feature will activate Apple’s Siri® Eyes Free
mode via the steering wheel switches. To operate the Mobile Assis-
tant, a compatible cellular phone must be registered and connected to
this system via Bluetooth
®. (→P. 316)
Press and hold the off-hook on the steering wheel until you hear the
beeps.
The Mobile Assistant can be
used only when the following
screen is displayed.
To cancel the Mobile Assistant,
select “Cancel”, or press and hold
the off-hook on the steering wheel.
To restart the Mobile Assistant for
additional commands, press the
off-hook on the steering wheel.
• Mobile Assistant can only be restarted after the system responds to a
voice command.
• After some phone and music commands, the Mobile Assistant feature will
automatically end to complete the requested action.
■
Adjusting the Mobile Assistant volume
The volume of the Mobile Assistant can be adjusted using the
“PWR·VOL” knob or steering wheel volume switches. The Mobile
Assistant and phone call volumes are synchronized.
Mobile Assistant
1
Ty p e AType B
2

3675-11. Using the voice command system
5
Audio system
COROLLA_TMMMS_TMMC_U (OM02494U)
■ Notes about Mobile Assistant
●The available features and functions may vary based on the iOS version
installed on the connected device.
●Some Siri features are limited in Eyes Free mode. If you attempt to use an
unavailable function, Siri will inform you that the function is not available.
●If Siri is not enabled on the cellular phone connected via Bluetooth
®, an
error message will be displayed on the screen.
●While a phone call is active, the Mobile Assistant cannot be used.
●If using the navigation feature of the cellular phone, ensure the active audio
source is Bluetooth
® audio or iPod in order to hear turn by turn direction
prompts.

599
COROLLA_TMMMS_TMMC_U (OM02494U)
Alphabetical index
Alphabetical index
A/C .................................... 370, 377
Air conditioning filter ............. 457
ABS
(Anti-lock Brake System)...... 262
Function ................................ 262
Warning light ......................... 485
Air conditioning filter .............. 457
Air conditioning
system ............................ 370, 377
Air conditioning filter ............. 457
Airbags ....................................... 34
Airbag operating conditions .... 42
Airbag precautions for
your child .............................. 37
Airbag warning light .............. 484
Correct driving posture ........... 26
Curtain shield airbag operating
conditions ............................. 42
Curtain shield airbag
precautions ........................... 40
General airbag precautions .... 37
Locations of airbags................ 34
Modification and
disposal of airbags ............... 41
Side airbag operating
conditions ............................. 42
Side airbag precautions .......... 37
Side and curtain shield airbags
operating conditions ............. 42
Side and curtain shield airbags
precautions ........................... 37
SRS airbags............................ 34
Alarm .......................................... 70
Anchor brackets ........................ 58
Antennas
(smart key system)................ 124Anti-lock Brake System
(ABS) ...................................... 262
Function ................................ 262
Warning light......................... 485
Assist grips .............................. 399
Audio input
*........................... 276
Automatic High Beam ............. 200
Automatic light control
system.................................... 195
AUX port
*......................... 276, 309
Back-up lights
Replacing light bulb .............. 470
Wattage ................................ 551
Battery ...................................... 441
Battery checking ................... 441
If the vehicle has discharged
battery ................................ 530
Preparing and checking
before winter ...................... 268
Warning light......................... 493
Bluetooth
®*
Entune Audio ................ 324, 326
Bottle holders .......................... 393
Brake
Fluid ...................................... 549
Parking brake ....................... 194
Warning light......................... 484
Brake assist ............................. 262
Break-in tips ............................ 157
Brightness control
Instrument panel light
control ............................ 81, 90
A
B
*: For vehicles with Entune Premium Audio or Entune Audio Plus,
refer to the “NAVIGATION AND MULTIMEDIA SYSTEM
OWNER'S MANUAL”.

602Alphabetical index
COROLLA_TMMMS_TMMC_U (OM02494U)
Emergency flashers ................ 474
Engine....................................... 544
ACCESSORY mode ............. 178
Compartment ........................ 433
Engine switch................ 173, 176
Hood ..................................... 429
How to start the
engine......................... 173, 176
Identification number ............ 543
If the engine will not start ...... 525
Ignition switch
(engine switch) ........... 173, 176
Overheating .......................... 535
Engine coolant ......................... 437
Capacity ................................ 546
Checking ............................... 437
Preparing and checking
before winter....................... 268
Engine coolant temperature
gauge.................................. 79, 88
Engine immobilizer system ...... 67
Engine oil ................................. 434
Capacity ................................ 544
Checking ............................... 434
Preparing and checking
before winter....................... 268
Engine switch .................. 173, 176
Entune Audio ........................... 277
Audio input ............................ 276
AUX port/USB
port ..................................... 276
Bluetooth
® audio................... 324
CD player .............................. 294
iPod....................................... 300
MP3/WMA disc ..................... 294
Optimal use........................... 291
Portable music player ........... 276
Radio .................................... 292
Steering wheel audio
switch ................................. 342
USB memory ........................ 305
Entune Audio Plus
*
Entune Premium Audio*
EPS
(Electric Power Steering) ..... 262
Function ................................ 262
Warning light......................... 485
Flat tire
Vehicles with a spare tire...... 513
Floor mats .................................. 24
Fluid
Brake .................................... 549
Continuously variable
transmission ....................... 548
Washer ................................. 443
Front interior light ................... 389
Front passenger occupant
classification system .............. 47
Front seats ............................... 132
Adjustment............................ 132
Cleaning ............................... 415
Correct driving posture ........... 26
Head restraints ..................... 136
Seat heaters ......................... 387
Front turn signal lights ........... 193
Replacing light bulbs ............ 468
Turn signal lever ................... 193
Wattage ................................ 551
Fuel ........................................... 206
Capacity................................ 544
Fuel gauge........................ 79, 88
Fuel pump shut off system ... 483
Information............................ 552
Refueling .............................. 206
Type.............................. 544, 552
Warning light......................... 485
Fuel filler door ......................... 206
Refueling .............................. 206
Fuel pump shut off system..... 483
Fuses ........................................ 462
F
